2A96G-SNENVA10100Home Automation Sensor

eisla English Package Contents 1x Environment Sensor 1x User Manual 3x AAA Batteries 1x ResetTool Environmental Sensor Product Specification Model SNEVA10100 Power Source AAA batteries 1.2-1.5v (non lithium version) Radio Protocol TBD Operating Temp -10-45ºC ±0.5ºC Operating Humidity 0-95%RH ±3% (non condensing) Operating Pressure 30-110 kPa ±0.06 kPa Material PC / PP TBD Mounting Self adhesive pads (supplied) Dimensions H 97mm - W 50.5mm - D 16.5mm Original Operating Instructions eisla English ! Please Note: Installing this device on a metal surface or thick stone/brick wall will diminish the communication distance. An installation height of 1.5m is recommended where possible. Installation Instructions 1. Push to slide up the front cover then pull to expose the battery compartment. 2. Install the provided batteries and replace the cover. 3. Pair the sensor to the Zigbee network. (see pairing for detailed instructions) 4. Remove the adhesive strip covers and affix the sensor in the desired location. This device is compatible with the isla smart hub using the Zigbee protocol. This device can also be used with 3rd party gateways supporting the Zigbee protocol. eisla English QR Code Pairing Instructions 1. Download and install the free Samsung SmartThings application. 2. Install the device batteries. 3. To place the device into pairing mode, use the tool provided to depress the reset button and hold until the LED flashes, approx. 5s. (This will also erase any existing network settings) 3. Once paring mode has been initiated. • Open the SmartThings app and select add device. • Select isla from the manufacturer list section. • Locate and select the isla sensor from the device list. If pairing is unsuccessful, move the device closer to the Smart Hub. eisla English Product Details LED Status Reset Hole Sensor Features The ESZB-01 is a Zigbee device designed to detect the following environmental metrics within the installed location in real time. • Temperature • Humidity • Pressure • VOC • Light When connected to a Smart Home System you can create custom scenes to trigger operations of other connected devices. eisla English Trouble Shooting Compliance Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:1)Reorient or relocate the receiving antenna; 2) Increase the separation between the equipment and receiver;3) Connect the equipment to an outlet on a circuit different from that to which the receiver is connected; 4)Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance to this equipment would void the user’s authority to operate this device. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC ID: 2A96G-SNENVA10100 Eisla Home Systems Ltd Millbank Tower London SW1P 4QP United Kingdom Reserved for certification logo’s

V02072023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 08/31/2023 Ref: Attestation Statement Part 2.911(d)(7) Filing FCC ID:2A96G-SNENVA10100 P ROJECT ETOPIA certifies that, as of the dates of this application, Americas Compliance Consulting LLC dba iCertifi “iCertifi” is our designated U.S. agent for service of process for the above referenced FCC ID. PROJECT ETOPIA accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission-related proceeding involving the equipment. iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service process for the above referenced FCC ID. Designated U.S. Agent Information: N ame: Americas Compliance consulting, LLC dba iCertifi FCC FRN: 0033399411 Address: 1001 SW Disk Drive, Suite 250, Bend, Oregon 97702 Contact Person: Paul Preston Tel: 866-885-4575 Email: [email protected] Sin cerely, PROJECT ETOPIA FRN 0033369984 Americas Compliance Consulting LLC dba iCertifi Adam Allison Paul Preston Signature

Covered list attestation FCC application letter Kiwa Page 1 of 2 RF_755_01 09-02-2023 Certification Application Attestation Statements Project Etopia Millbank Tower, London, SW1P 4QP London, United Kingdom To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) [Project Etopia] certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) [Project Etopia] (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☒- is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: 2023-09-04 City: London Name(2) : Adam Allison Function: Head of Hardware Telephone number: +44 7590641452 Email address: [email protected] 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK” Covered list attestation FCC application letter Kiwa Page 2 of 2 RF_755_01 09-02-2023 Signature: Revision Record Sheet: Revisio n Section number Page number Date Remark(s) issued by 01 07-02-2023 1 st version RvM Issued/modified by : Richard van de Meer Function : Certification assessor Revision : 01 Date : 07-02-2023 Verified by : Willem Jan Jong Function : Team Lead Date : 09-02-2023 Released by : Axel Gase Function : Manager Quality Assurance Date of release: : 09-02-2023

RF_160, Issue 04 Declaration of Authorization We Name: Project Etopia Address: Millbank Tower, London, SW1P 4QP City: London Country: United Kingdom Declare that: Name Representative of agent: Joan Wu (1) Agent Company name: Universal Certification Technology Co., Ltd. Address: 13F.-5, No. 93, Sec. 1, Xintai 5th Rd., Xizhi Dist., City: New Taipei City Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Home Automation Sensor Type designation: SNENVA10100 Trademark: EISLA Validity/ expiry date 2024-09-03 on our behalf. Date: 2023-09-04 City: London Name: Adam Allison (2) Function: Head of Hardware Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 21- Nov-2018 RF_501, Issue 8 Page 1 of 1 Company Name: Project Etopia Address : Millbank Tower, London, SW1P 4QP City: London Country: United Kingdom To: Telefication B.V ., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2A96G-SNENVA10100 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: ☐ Bill(s) of Material ☒ Block D iagram s ☒ Operational Description ☒ Schem atic D iagram s ☐ Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): ☐ Internal Photos ☐ U ser’s M anual ☐ Test Set-up Photos ☐ External Photos Justification: Date: 2023-09-04 Name and signature of applicant: Adam Allison Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should stated in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Reference No.:BDBO-WTW-P23070029_ExtPho Page 1/3 CONSTRUCTION PHOTOS OF EUT Reference No.:BDBO-WTW-P23070029_ExtPho Page 2/3 Reference No.:BDBO-WTW-P23070029_ExtPho Page 3/3

Label will be placed on the bottom of the device.

Reference No.:BDBO-WTW-P23070029_IntPho Page 1/3 CONSTRUCTION PHOTOS OF EUT Reference No.:BDBO-WTW-P23070029_IntPho Page 2/3 Antenna Reference No.:BDBO-WTW-P23070029_IntPho Page 3/3

Report No.: MFBDBO-WTW-P23070029 Page No. 1 / 8 Report Format Version: 7.1.0 Reference No.: BDBO-WTW-P23070029 RF EXPOSURE REPORT CERTIFICATE OF CONFORMITY FCC Rule Part: FCC Part 2 (Section 2.1091) Report No.: MFBDBO-WTW-P23070029 FCC ID: 2A96G-SNENVA10100 Product: Home Automation Sensor Brand: eisla Model No.: SNENVA10100 Series Model: SNENVA1 Received Date: 2023/7/3 Test Date: 2023/8/16 Issued Date: 2023/9/19 Applicant: Project Etopia Address: Millbank Tower, London, SW1P 4QP, UK Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 Approved by: , Date: 2023/9/19 Jeremy Lin / Project Engineer This test report consists of 8 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Annie Chang / Senior Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: MFBDBO-WTW-P23070029 Page No. 2 / 8 Report Format Version: 7.1.0 Reference No.: BDBO-WTW-P23070029 Table of Contents Release Control Record ....................................................................................................................................................... 3 1 Certificate .................................................................................................................................................................... 4 2 Applicable RF Exposure Limit .................................................................................................................................. 5 3 Test Results ................................................................................................................................................................ 7 4 Conclusion .................................................................................................................................................................. 7 5 Information of the Testing Laboratories .................................................................................................................. 8 Report No.: MFBDBO-WTW-P23070029 Page No. 3 / 8 Report Format Version: 7.1.0 Reference No.: BDBO-WTW-P23070029 Release Control Record Issue No. Description Date Issued MFBDBO-WTW-P23070029 Original release. 2023/9/19 Report No.: MFBDBO-WTW-P23070029 Page No. 4 / 8 Report Format Version: 7.1.0 Reference No.: BDBO-WTW-P23070029 1 Certificate Product: Home Automation Sensor Brand: eisla Test Model: SNENVA10100 Series Model: SNENVA1 Sample Status: Engineering sample Applicant: Project Etopia Test Date: 2023/8/16 FCC Rule Part: FCC Part 2 (Section 2.1091) Standard: KDB 447498 D04 Interim General RF Exposure Guidance v01 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Report No.: MFBDBO-WTW-P23070029 Page No. 5 / 8 Report Format Version: 7.1.0 Reference No.: BDBO-WTW-P23070029 2 Applicable RF Exposure Limit § 1.1310 Radiofrequency radiation exposure limits. (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatialaverage SAR of 8 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit for occupational/controlled exposure is 20 W/kg, averaged over any 10 gram…

Text truncated - open the document above for the full version.

AMA01 - Antenna Specs Brand Model Type Peak gain Impedance Silicon Labs MGM210PA32JIA2 Built-in antenna Connectorized Coaxial Dipole 1.86 dBi 50 Ω 4.17.1 Antenna Radiation and Efficiency Typical MGM210P radiation patterns and efficiency for the on-board chip antenna under optimal operating conditions are plotted in the figures that follow. Antenna gain and radiation patterns have a strong dependence on the size and shape of the application PCB the module is mounted on, as well as on the proximity of any mechanical design to the antenna. Figure 4.1. Typical 2D Antenna Radiation Patterns and Efficiency Top Left: Phi 0 o , Top Right: Phi 90 o , Bottom Left: Theta 90 o , Bottom Right: Radiation Efficiency vs Application Board GND Plane Width MGM210P Wireless Gecko Multi-Protocol Module Data Sheet Electrical Specifications silabs.com | Building a more connected world.Rev. 1.3 | 24

Report No.: RFBDBO-WTW-P23070029 Page No. 1 / 32 Report Format Version: 7.1.0 Reference No.: BDBO-WTW-P23070029 TEST REPORT CERTIFICATE OF CONFORMITY Standard: 47 CFR FCC Part 15, Subpart C (Section 15.247) Report No.: RFBDBO-WTW-P23070029 FCC ID: 2A96G-SNENVA10100 Product: Home Automation Sensor Brand: eisla Model No.: SNENVA10100 Series Model: SNENVA1 Received Date: 2023/7/3 Test Date: 2023/8/1 ~ 2023/8/11 Issued Date: 2023/9/19 Applicant: Project Etopia Address: Millbank Tower, London, SW1P 4QP, UK Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 Approved by: , Date: 2023/9/19 Jeremy Lin / Project Engineer This test report consists of 32 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Annie Chang / Senior Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBDBO-WTW-P23070029 Page No. 2 / 32 Report Format Version: 7.1.0 Reference No.: BDBO-WTW-P23070029 Table of Contents Release Control Record ....................................................................................................................................................... 4 1 Certificate .................................................................................................................................................................... 5 2 Summary of Test Results .......................................................................................................................................... 6 2.1 Measurement Uncertainty ........................................................................................................................................ 6 2.2 Supplementary Information ...................................................................................................................................... 6 3 General Information ................................................................................................................................................... 7 3.1 General Description .................................................................................................................................................. 7 3.2 Antenna Description of EUT ..................................................................................................................................... 7 3.3 Channel List .............................................................................................................................................................. 7 3.4 Test Mode Applicability and Tested Channel Detail .................................................................................................. 8 3.5 Duty Cycle of Test Signal .......................................................................................................................................... 9 3.6 Test Program Used and Operation Descriptions .................................................................................................... 10 3.7 Connection Diagram of EUT and Peripheral Devices ............................................................................................ 10 4 Test Instruments ...................................................................................................................................................... 11 4.1 RF Output Power .................................................................................................................................................... 11 4.2 Power Spectral Density .......................................................................................................................................... 11 4.3 6 dB Bandwidth ...................................................................................................................................................... 11 4.4 Conducted Out of Band Emissions ......................................…

Text truncated - open the document above for the full version.

Reference No.:RFBDBO-WTW-P23070029-TSup Page 1/2 PHOTOGRAPHS OF THE TEST CONFIGURATION Unwanted Emissions below 1 GHz Reference No.:RFBDBO-WTW-P23070029-TSup Page 2/2 Unwanted Emissions above 1 GHz
