2A977-TF-D2-LHP-01PWave Series Petal PRO Smart-egg

春风浪系列浪潮智能跳蛋（海外版） 2023.2.7 V4 V120221221第一次版本 V220221222修改内容 V320221226修改封底内容 V420230207修改成A5尺寸 C:79 M:81 Y:8 K:0 四色印刷 148*210mm（成型尺寸74*70mm） A5 제품 설명서USB 충전 케이블파우치안마기 상품명: 트라이펀 웨이브 스마트 로터 PRO 상품 번호: TF-D2-LHP-01P 상품 사이즈: 102.5X106.5X32mm 상품 중량: 약 71g 상품 재질: 실리카겔, ABS(아크릴로나이트릴, 뷰타다이엔, 스타이렌), 나이론 배터리 용량: 240mAh 정격 전압: 3.7V 정격 출력: 1.5W 충전 전압: 5V 충전 전류: 330mA ※충전 시간: 약 60분 ※사용 시간: 약 35분 ※사용 시 소음: 52dB 이하 ※방수 등급: IPX7 1. 버튼을 2초간 눌러 전원을 켭니다. 전원이 켜지면 본체가 2번 진동하며, 로터가 대기 상태로 진입하며블루투스가 켜집니다. 대기 상태에서 20분 동안 아무런 조작이 없으면 자동으로 꺼집니다. 2. 대기 상태에서 블루투스가 켜지면 흰색 표시등이 계속 반짝이며, 블루투스 연결이 성공하면 흰색 등이 켜집니다. 10분 동안 앱과 연결하지 않으면 자동으로 블루투스가 꺼집니다. 3. 대기 상태에서 짧게 누르면 첫 번째 모드로 진입하며, 짧게 눌러 순차적으로 모드를 변경할 수 있습니다. 모드는 총 8개가 존재합니다. 진동 상태에서 2를 빠르게 2번 클릭하면 진동 기능 이 정지하며, 계속해서 2를 빠르게 2번 클릭하면 정지 전 진동 모드로 돌아갑니다. 4. 대기 혹은 진동 모드에서 버튼을 2초간 길게 누르면 종료합니다. 전원을 끄기 전에 로터와 앱을 연결했다면 블루투스는 5분간 켜져 있으며 표시등이 켜진 상태를 유지합니다. 5분 동안 아무런 조작이 없으면, 블루투스가 꺼지며, 표시등도 점멸하며 로터의 전원이 완전히 꺼집니다. 1. 사용 전, 사용할 부위에 충분한 윤활유를 바르면 더 원활하고 즐겁게 즐길 수 있습니다. 2. 진동 모드를 켜고, 질, 음핵, 허벅지 안쪽, 허리, 유두, 귀 뒤 등 민감한 부위를 자극합니다. 개인 취향에 따라 가장 편안한 모드를 찾아 즐겨보세요. 상품 규격 로터 기능 설명 1. 충전할 때는 버튼 표시등이 짧게 반짝입니다. 충전 중에는 로터를 사용할 수 없습니다. 2. 충전이 다 되면 버튼 표시등이 켜집니다. 충전 시 주의사항：1. 충전 헤드와 충전 구멍이 잘 접촉되었는지 확인하세요. 2. 마른 손으로 충전 케이블을 꽂고 뽑으세요. 3. 충전 시간은 약 60분으로 장시간 충전을 금합니다. 4. 충전은 5V, 1A 어댑터를 사용하세요. 5. 충전 중에는 사용할 수 없으므로 충전을 종료한 후에 전원을 빼고 사용하세요. 배터리 표시: 배터리가 3.3V 미만이면 표시등이 두 번 깜박입니다. 배터리가 3.0V 미만이면 로터는 자동으로 전원이 꺼집니다. 충전 설명 사용 설명 ①본 제품은 18세 이상 성인만 사용할 수 있습니다. 질병 감염을 방지하기 위해 개인용으로만 사용하고 여러 사람과 함께 사용하지 마십시오. ②몸이 불편할 경우 본 제품을 사용하지 마십시오. ③의료용 전자기기(심장박동기 등)를 사용 중이신 분, 임산부, 그 외 몸이 불편하신 분은 사용 을 금합니다. ④제품을 분해하지 마십시오. 제품이 손상되거나 위험할 수 있습니다. ⑤제품을 휴대하고 외출할 경우, 긁히거나 오염되는 것을 방지하기 위하여 별도로 보관하여 주십시오. 주의사항 환경 보호를 위하여 본 제품 혹은 기타 부품이 폐기되면, 소비자는 생활 쓰레기와 분리하고 재활용 장소로 보내야 합니다. 재활용 장소는 국가의 규정에 따라 분류, 해제, 회수, 재사용 등의 처리를 합니다. •제품을 폐기하기 전 분리할 수 있다면 배터리를 제품에서 분리하십시오. •배터리를 꺼내기 전 전원이 꺼져있는지 확인하십시오. •배터리는 안전하게 폐기하십시오. 제품 및 부품 회수 설명 取扱説明書USB充電ケーブル収納バッグバイブレーター 製品名：トライファンしぶきシリーズPROバイブレーター 型番：TF-D2-LHP-01P 寸法：102.5X106.5X32mm 重さ：約71g 材料：シリカゲル、ABS、ナイロン バッテリー容量：240mAh 定格電圧：3.7V 定格出力：1.5W 充電電圧：5V 充電電流：330mA ※充電時間：約60分 ※作動時間：約35分 ※作動時の騒音：52dB以下 ※防水規格：IPX7 1．2秒長押ししてオンにする。電源オン後に本体が2回振動すると、バイブレーターはスタンバイモー ドに入り、しかもBluetoothをオンにする。スタンバイモードで20分ぐらい何も操作しないと、バイブレー ターはオートオフになる。 2．スタンバイモードでBluetoothをオンにすると、白いライトは持続的に点滅する。Bluetoothが接続できた ら、白いライトは常時点灯する。10分間アプリに接続できなかったら、Bluetoothはオートオフになる。 3．スタンバイモードにおいて、短く押すと1段階モードに入る。さらに短く押すと、8つのモードを順番に 切り替えていく。バイブモードにおいて、素早く2回タップするとバイブモードを中止することができる。 さらに素早く2回タップすると、中止中のバイブモードを再開させる。 4．スタンバイまたはバイブモードにおいて、2秒間長押しするとオフにする。電源オフの前にバイブ レーターがアプリに接続されている場合、Bluetoothが5分間オンのままで、ライトが常時点灯する。5 分間何も操作しないと、Bluetoothがオフになり、ライトが消え、バイブレーターが完全オフになる。 1．順調に快感を楽しむよう、ご使用前に 陰部にローションをたっぷり塗ってください。 2．バイブ機能をオンにすると、膣や陰核、内股、腰部、乳首、耳後ろなどの敏感な部位に刺激を与 えられます。好みに応じて、最も快適なモードを見つけ、体に愉快さを与えましょう。 製品仕様 バイブレーターの機能について 1．充電中、ボタンを表示するライトが点滅する。この場合、バイブレーターは作動できない。 2．満充電後、ボタンを表示するライトが常時点灯する。 充電時のご注意： 1．プラグが完全に穴に差し込むように確保してください。 2．乾いた手で充電ケーブルを外したり差し込んでください。 3．充電時間が約60分です。過充電しないでください。 4．充電時、5V1Aのアダプターを使ってください。 5．充電中は製品をご利用いただけません。充電完了後、電源を切断してから使ってください。 バッテリー残量表示： バッテリー残量が3.3V以下になると、ハザードランプは点滅する。バッテリー残量が3.0V以下になる と、バイブレーターはオートオフになる。 充電について ご使用法 ①本製品は18歳以上の成人に向けています。伝染病を避けるべく、他人と共用せず自分だけでお使 いいただきます。 ②体調悪いときは本製品を使わないでください。 ③医療電子機器（ペースメーカーなど）を使っている方、妊婦またはその他の体調不良者は本製品の ご利用を中止してください。 ④製品のいずれかの部品を外さないでください。じゃないと、製品に破損を与えたり、お客様の安全を 害する恐れがあります。 ⑤かすり傷または汚染が発生しないよう、本製品を携帯して出かけるときに単独で保管してください。 注意事項 環境保全のため、消費者の一員として、廃棄された製品および部品を生活ゴミと分別して、資格の ある回収ステーションに出す必要があります。回収ステーションは国の関連規定に基づいてゴミの 分類・解体・リサイクルなどを行います。 •解体可能な器具を廃棄する前に、バッテリーを取り出した後廃棄してください •バッテリーを取り出す前に器具の電源が切れたかどうかを確認してください •バッテリーを安全に処置しなければなりません 製品と部品の回収について 产品说明书 USB 充电线 收纳袋按摩器 产品名称：春风浪系列浪花PRO智能跳蛋 产品型号：TF-D2-LHP-01P 产品尺寸：102.5X106.5X32mm 产品重量：约71g 产品材质：硅胶、ABS(丙烯腈-丁二烯-苯乙烯共聚物) 、尼龙 电池容量：240mAh 额定电压：3.7V 额定功率：1.5W 充电电压：5V 充电电流：330mA ※充电时间：约60分钟 ※使用时间：约35分钟 ※工作噪音: 低于52dB ※防水等级：IPX7 1.长按2秒开机，开机后机身震动两下，跳蛋进入待机状态，同时开启蓝牙。待机状态下，20 分钟内无任何操作，则自动关机。 2.待机状态下，蓝牙开启，白色指示灯持续闪烁，蓝牙连接成功则白灯长亮。10分钟内未连接 APP，则自动关闭蓝牙。 3.待机状态下，短按进入第一档模式，继续短按可依次切换模式，一共8种模式。震动状态 下，快速双击2下可暂停震动功能，继续快速双击2下可恢复暂停前的震动模式。 4.待机或震动状态下，长按按键2秒关机。如关机前跳蛋与APP连接，则蓝牙持续开启5分 钟，指示灯长亮。5分钟后无任何操作，蓝牙关闭，指示灯熄灭，跳蛋彻底关机。 产品规格 功能说明 1.充电时，按键指示灯呼吸闪烁。充电中，跳蛋无法工作。2.充满后，按键指示灯长亮。 充电时请注意：1.请确充电头和充电孔完全接触; 2.插拔充电线时，请保持手部干燥; 3.充电时间约60分钟，切勿长时间过充; 4.充电请使用5V，1A适配器; 5.充电期间无法使用，请在充电结束后拔下电源再使用。 电量提示：当电池电量低于3.3V时，指示灯双闪提示。电池电量低于3.0V时，跳蛋自动关机。 充电说明 1.使用前给私处涂抹足够的润滑液，可以让整个过程更顺畅和愉悦。 2.开启震动功能，可用于阴道、阴蒂、大腿内侧、腰部、乳头、耳后等敏感部位的刺激。根 据个人喜好寻找自己最舒服的模式，感受身体的愉悦。 使用说明 ①本产品适合18周岁及以上成年人使用，为避免传染疾病，请保持个人使用，勿与多人共用。 ②在身体不适的情况下，请不要使用本产品。 ③正在使用医疗电子产品（如心脏起搏器）的人士、孕妇或其他身体不适的人员，请停止使 用本产品。 ④请不要拆卸产品的任何部件，否则可能造成产品的损坏或危害您的安全。 注意事项 出于环境保护要求，本产品或其部件报废后，作为消费者的您有责任将其与生活垃圾分开，送 至有资质的回收站点，由回收站点按照国家相关规定进行分类拆解、回收再利用等处理。 ·废弃器具前，如可拆，须将电池从器具内取出 ·取出电池前，请确认器具是否断电 ·电池应安全地处置 产品及部件回收说明 Instruction Manual USB Charging Cable Storage BagMassager Product Name: Wave Series Petal PRO Smart-egg Product Model: TF-D2-LHP-01P Product Measurements: 102.5 x 106.5 x 32mm Product Weight: About 71g Product Materials: Silicone, ABS (acrylate-butadiene-styrene copolymer), Nylon Battery Capacity: 240mAh Rated Voltage: 3.7V Rated Power: 1.5W Charge Voltage: 5V Charge Current: 330mA Charge Time: About 60 min. Use Time: About 35 min. Operating Noise: Less than 52dB Water-Proof Rating: IPX7 1. Long press for 2s to turn on device, which will vibrate twice. Leaping Egg enters standby mode and activates bluetooth. Automatically shuts down after 20 min. with no operation in standby mode. 2. The white light flashes in standby mode with as bluetooth attempts to connect. The white light will stay on with a successful connection. If the APP cannot be connected within 10 minutes, then bluetooth shuts down. 3. In standby mode, quick press to enter “first gear” mode, continue pressing to switch to other modes (for a total of 8.) In vibration mode, double-click to pause vibration, double-click again to resume. 4. In standby or vibration mode, long press for 2s to shutdown. If the egg is already connected to the App, bluetooth will stay active for 5 min. The light will stay on. If five minutes pass, bluetoot…

Text truncated - open the document above for the full version.

TRYFUN PTE. LTD. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: TRYFUN PTE. LTD. Address: 987, SERANGOON ROAD, SINGAPORE, Singapore Product Name: Wave Series Petal PRO Smart-egg FCC ID: 2A977- TF-D2-LHP-01P Model(s): TF-D2-LHP-01P 2.911(d)(5)(i) Equipment Type We, [TRYFUN PTE. LTD.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Neil Lin Date: 2023.02.22 Title and Company name: Senior Ecommerce Operations Manager / TRYFUN PTE. LTD. NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

TRYFUN PTE. LTD. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: TRYFUN PTE. LTD. Address: 987, SERANGOON ROAD, SINGAPORE, Singapore Product Name: Wave Series Petal PRO Smart-egg FCC ID: 2A977- TF-D2-LHP-01P Model(s): TF-D2-LHP-01P 2.911(d)(5)(ii) Applicant filing We, [TRYFUN PTE. LTD.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Neil Lin Date: 2023.02.22 Title and Company name: Senior Ecommerce Operations Manager / TRYFUN PTE. LTD. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

TRYFUN PTE. LTD. U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 02-20-2023 Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2A977-TF-D2-LHP-01P TRYFUN PTE. LTD. (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC (“ the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: TRYFUN PTE. LTD. Address: 987, SERANGOON ROAD, SINGAPORE Signature: Contact Person: Neil Lin Tel: +86-13580589927 Email: [email protected]

TRYFUN PTE. LTD. Agent Authorization Company: TRYFUN PTE. LTD. Address: 987, SERANGOON ROAD, SINGAPORE, Singapore Product Name: Wave Series Petal PRO Smart-egg Model Number(s): TF-D2-LHP-01P Product Description: Wave Series Petal PRO Smart-egg We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.02.22 Name: Neil Lin Title: Senior Ecommerce Operations Manager Company: TRYFUN PTE. LTD.

TRYFUN PTE. LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 22, 2023 Subject; Request for Confidentiality FCC ID: 2A977-TF-D2-LHP-01P To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Neil Lin Title: Senior Ecommerce Operations Manager

EUT PHOTO(External Photos) FCC ID: 2A977-TF-D2-LHP-01P

Page 1 of 1 Label and Information FCC Label Sample FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

EUT PHOTO(Internal Photos) FCC ID: 2A977-TF-D2-LHP-01P ANT ※※※※※ END OF REPORT ※※※※※

FCC ID: 2A977-TF-D2-LHP-01P RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093， Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. For BLE Max Conducted Power(dBm) Tune-up Power(dBm) Max Tune-up Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 0.68 0(±1) 1 1.259 2402 5 0.390249 3.0 So a SAR test is not required

Report No: SSP23020006A Antenna Test Report Page 1 of 4 Antenna Test Report Test Standard: IEEE 149-1979 Manufacturer: SHENZHEN S-HANDE TECHNOLOGY CO., LTD Product Name: 2.4GHz Antenna Model: TF-D2-LHP-01P Report No.: SSP23020006A Tested Date: 2023-01-04 Issued Date: 2023-01-05 Tested By: William Liu (Engineer) Approved By: Lahm Peng (Manager) Prepared By: Shenzhen ZRLK Testing Technology Co., Ltd. 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Tel.: +86-755-33019599 Fax.: +86-755-33019599 Website: www.zrlklab.com Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen ZRLK Testing Technology Co., Ltd. Report No: SSP23020006A Antenna Test Report Page 2 of 4 1. General Information 1.1 Product Information Manufacturer Manufacturer: SHENZHEN S-HANDE TECHNOLOGY CO., LTD Address of Manufacturer: 1-5 F, Building 8, Xinxintian Industrial Park, Xinsha Road, Shajing Street, Bao’an District, Shenzhen General Description of Antenna Product Name: 2.4GHz Antenna Model No.: TF-D2-LHP-01P Frequency Range: 2400MHz-2483.5MHz Type of Antenna: Integral Antenna Antenna Gain: 0dBi (Max.) Impedance: 50 ohm Antenna View ( 70mm*1mm) 1.2 Test Methodology All measurements contained in this report were conducted with standards IEEE 149-1979 for IEEE Standard Test Procedures for Antennas. 1.3 Test Facilities Te s ting Lab: Shenzhen ZRLK Testing Technology Co., Ltd. All measurement facilities used to collect the measurement data are located at 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Report No: SSP23020006A Antenna Test Report Page 3 of 4 2. O TA Te s t 2.1 Gain Frequency Peak Gain (dBi) Polarity 2402MHz 0 Horizontal 2402MHz -0.43 Vertical 2442MHz -0.95 Horizontal 2442MHz -1.41 Vertical 2480MHz -1.95 Horizontal 2480MHz -2.58 Vertical 2.2 Radiation Pattern View Report No: SSP23020006A Antenna Test Report Page 4 of 4

Project No.: ZKT-230208L0572E Page 1 of 42 FCC TEST REPORT FCC ID: 2A977-TF-D2-LHP-01P Report Number. ................................ : ZKT-230208L0572E Date of Test ........................................ February 14, 2023 to February 16, 2023 Date of issue .................................... : February 17, 2023 Total number of pages ...................... 41 Test Result ..................................... : PASS Testing Laboratory. ........................ : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ......................... : TRYFUN PTE. LTD. Address .......................................... : 987, SERANGOON ROAD, SINGAPORE, Singapore Manufacturer's name ................... : SHENZHEN S-HANDE TECHNOLOGY CO., LTD Address .......................................... : 1-5 F, Building 8, Xinxintian Industrial Park, Xinsha Road, Shajing Street, Bao’an District, Shenzhen Test specification: Standard ........................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2013 Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-111_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2020-01-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................. : Wave Series Petal PRO Smart-egg Trademark ...................................... : -- Model/Type reference......................: TF-D2-LHP-01P Ratings ............................................. : DC 3.7V by battery, USB 5V Charging Project No.: ZKT-230208L0572E Page 2 of 42 Testing procedure and testing location: Testing Laboratory ................................... : Shenzhen ZKT Technology Co., Ltd. Address ...................................................... :1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Tom Zou Tested by (name + signature) .................... : Jackson Fang Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-230208L0572E Page 3 of 42 Table of Contents Page 1.VERSION 5 2. SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3. GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 4. EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 TEST PROCEDURE 13 4.1.3 DEVIATION FROM TEST STANDARD 13 4.1.4 TEST SETUP 14 4.1.5 EUT OPERATING CONDITIONS 14 4.1.6 TEST RESULT 15 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 TEST PROCEDURE 18 4.2.3 DEVIATION FROM TEST STANDARD 18 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 19 5.RADIATED BAND EMISSION MEASUREMENT 24 5.1 TEST REQUIREMENT: 24 5.2 TEST PROCEDURE 24 5.3 DEVIATION FROM TEST STANDARD 24 5.4 TEST SETUP 25 5.5 EUT OPERATING CONDITIONS 25 5.6 TEST RESULT 26 6.POWER SPECTRAL DENSITY TEST 27 6.1 APPLIED PROCEDURES / LIMIT 27 6.2 TEST PROCEDURE 27 6.3 DEVIATION FROM STANDARD 27 Project No.: ZKT-230208L0572E Page 4 of 42 Table of Contents Page 6.4 TEST SETUP 27 6.5 EUT OPERATION CONDITIONS 27 6.6 TEST RESULT 28 7. CHANNEL BANDWIDTH 30 7.1 APPLIED PROCEDURES / LIMIT 30 7.2 TEST PROCEDURE 30 7.3 DEVIATION FROM STANDARD 30 7.4 TEST SETUP 30 7.5 EUT OPERATION CONDITIONS 30 7.6 TEST RESULT 31 8.PEAK OUTPUT POWER TEST 35 8.1 APPLIED PROCEDURES / LIMIT 35 8.2 TEST PROCEDURE 35 8.3 DEVIATION FROM STANDARD 35 8.4 TEST SETUP 35 8.5 EUT OPERATION CONDITIONS 35 8.6 TEST RESULT 36 9. CONDUCTED BAND EDGE AND SPURIOUS EMISSION 38 9.1 APPLICABLE STANDARD 38 9.2 TEST PROCEDURE 38 9.3 DEVIATION FROM STANDARD 38 9.4 TEST SETUP 38 9.5 EUT OPERATION CONDITIONS 38 10.ANTENNA REQUIREMENT 41 11. TEST SETUP PHOTO 42 12. EUT CONSTRUCTIONAL DETAILS 42 Project No.: ZKT-230208L0572E Page 5 of 42 1.VERSION Report No. Version Description Approved ZKT-230208L0572E Rev.01 Initial issue of report February 17, 2023 Project No.: ZKT-230208L0572E Page 6 of 42 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247), Subpart C Standard Section Test Item Judgment Remark FCC part 15.203/15.247 (c) Antenna requirement PASS FCC part 15.207 AC Power Line Conducted Emission PASS FCC part 15.247 (b)(3)Conducted Peak Output Power PASS FCC part 15.247 (a)(2)Channel Bandwidth& 99% OCB PASS FCC part 15.247 (e) Power Spectral Density PASS FCC part 15.247(d) Band Edge PASS FCC part 15.205/15.209 Spurious Emission PASS NOTE: (1)“N/A” denotes test is not applicable in this Test Report Project No.: ZKT-230208L0572E Page 7 of 42 2.1 TEST FACILITY Shenzhen ZKT Technology Co., Ltd. Add. : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China FCC Test Firm Registration Number: 692225 Designation Number: CN1299 IC Registered No.: 27033 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximatel…

Text truncated - open the document above for the full version.
