Page 1 of 240 Report No.: S23020200406001 FCC SAR EVALUATION REPORT In accordance with the requirements of FCC 47 CFR Part 2(2.1093), ANSI/IEEE C95.1-1992 and IEEE Std 1528-2013 Product Name： Edanix Brand Name： N/A Model Name： Rocky_MT1 Family Model： N/A Report No.： S23020200406001 FCC ID： 2A97SEDANIXROCKYMT1 Prepared for Edanix Products Corporation 12500 Vickers Way, Richmond, BC Canada, V6V 1H9China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao'an District, Shenzhen 518126 P.R.China. Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 240 Report No.: S23020200406001 TEST RESULT CERTIFICATION Applicant’s name ................. : Edanix Products Corporation Address .................................. : 12500 Vickers Way, Richmond, BC Canada, V6V 1H9 Manufacturer's Name .......... : Edanix Products Corporation Address .................................. : 12500 Vickers Way, Richmond, BC Canada, V6V 1H9 Product description Product name ........................ : Edanix Brand Name ......................... : N/A Model and/or type reference .............................. : Rocky_MT1 Family Model ......................... : N/A Standards ............................. : FCC 47 CFR Part 2(2.1093) ANSI/IEEE C95.1-1992 IEEE Std 1528-2013 Published RF exposure KDB procedures This device described above has been tested by Shenzhen NTEK. In accordance with the measurement methods and procedures specified in IEEE Std 1528-2013 and KDB 865664 D01. Testing has shown that this device is capable of compliance with localized specific absorption rate (SAR) specified in FCC 47 CFR Part 2(2.1093) and ANSI/IEEE C95.1-1992. The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK, this document may be altered or revised by Shenzhen NTEK, personal only, and shall be noted in the revision of the document. Test Sample Number ............................. S230202004006 Date of Test Date (s) of performance of tests .............. : Feb. 03, 2023 ~ Feb. 17, 2023 Date of Issue ........................................... : Mar. 20, 2023 Test Result ............................................... : Pass Prepared By (Test Engineer) : (Jacob Chen) Approved By (Lab Manager) : (Alex Li) Page 3 of 240 Report No.: S23020200406001 ※ ※ Revision History ※ ※ REV. DESCRIPTION ISSUED DATE REMARK Rev.1.0 Initial Test Report Release Mar. 20, 2023 Jacob Chen Page 4 of 240 Report No.: S23020200406001 TABLE OF CONTENTS 1. General Information ............................................................................................ 6 1.1. RF exposure limits .................................................................................... 6 1.2. Statement of Compliance ........................................................................ 7 1.3. EUT Description ....................................................................................... 7 1.4. Test specification(s) .................................................................................. 9 1.5. Ambient Condition ................................................................................... 9 2. SAR Measurement System ................................................................................. 10 2.1. SATIMO SAR Measurement Set-up Diagram .......................................... 10 2.2. Robot ..................................................................................................... 11 2.3. E-Field Probe .......................................................................................... 12 2.3.1. E-Field Probe Calibration ................................................................. 12 2.4. SAM phantoms ...................................................................................... 13 2.4.1. Technical Data .................................................................................. 14 2.5. Device Holder ........................................................................................ 15 2.6. Test Equipment List ................................................................................ 16 3. SAR Measurement Procedures .......................................................................... 18 3.1. Power Reference ................................................................................... 18 3.2. Area scan & Zoom scan .......................................................................... 18 3.3. Description of interpolation/extrapolation scheme .............................. 20 3.4. Volumetric Scan ..................................................................................... 20 3.5. Power Drift ............................................................................................ 20 4. System Verification Procedure .......................................................................... 21 4.1. Tissue Verification ................................................................................. 21 4.1.1. Tissue Dielectric Parameter Check Results ...................................... 22 4.2. System Verification Procedure .............................................................. 23 4.2.1. System Verification Results .............................................................. 24 5. SAR Measurement variability and uncertainty .................................................. 25 5.1. SAR measurement variability ................................................................. 25 5.2. SAR measurement uncertainty .............................................................. 25 6. RF Exposure Positions .....................................................................................…

Text truncated - open the document above for the full version.

Page 161 of 240 Report No.: S23020200406001 Page 162 of 240 Report No.: S23020200406001 Page 163 of 240 Report No.: S23020200406001 Page 164 of 240 Report No.: S23020200406001 Page 165 of 240 Report No.: S23020200406001 Page 166 of 240 Report No.: S23020200406001 Page 167 of 240 Report No.: S23020200406001 Page 168 of 240 Report No.: S23020200406001 Page 169 of 240 Report No.: S23020200406001 Page 170 of 240 Report No.: S23020200406001 Page 171 of 240 Report No.: S23020200406001 Page 172 of 240 Report No.: S23020200406001 Page 173 of 240 Report No.: S23020200406001 Page 174 of 240 Report No.: S23020200406001 Page 175 of 240 Report No.: S23020200406001 Page 176 of 240 Report No.: S23020200406001 Page 177 of 240 Report No.: S23020200406001 Page 178 of 240 Report No.: S23020200406001 Page 179 of 240 Report No.: S23020200406001 Page 180 of 240 Report No.: S23020200406001 Page 181 of 240 Report No.: S23020200406001 Page 182 of 240 Report No.: S23020200406001 Page 183 of 240 Report No.: S23020200406001 Page 184 of 240 Report No.: S23020200406001 Page 185 of 240 Report No.: S23020200406001 Page 186 of 240 Report No.: S23020200406001 Page 187 of 240 Report No.: S23020200406001 Page 188 of 240 Report No.: S23020200406001 Page 189 of 240 Report No.: S23020200406001 Page 190 of 240 Report No.: S23020200406001 Page 191 of 240 Report No.: S23020200406001 Page 192 of 240 Report No.: S23020200406001 Page 193 of 240 Report No.: S23020200406001 Page 194 of 240 Report No.: S23020200406001 Page 195 of 240 Report No.: S23020200406001 Page 196 of 240 Report No.: S23020200406001 Page 197 of 240 Report No.: S23020200406001 Page 198 of 240 Report No.: S23020200406001 Page 199 of 240 Report No.: S23020200406001 Page 200 of 240 Report No.: S23020200406001

Page 201 of 240 Report No.: S23020200406001 Page 202 of 240 Report No.: S23020200406001 Page 203 of 240 Report No.: S23020200406001 Page 204 of 240 Report No.: S23020200406001 Page 205 of 240 Report No.: S23020200406001 Page 206 of 240 Report No.: S23020200406001 Page 207 of 240 Report No.: S23020200406001 Page 208 of 240 Report No.: S23020200406001 Page 209 of 240 Report No.: S23020200406001 Page 210 of 240 Report No.: S23020200406001 Page 211 of 240 Report No.: S23020200406001 Page 212 of 240 Report No.: S23020200406001 Page 213 of 240 Report No.: S23020200406001 Page 214 of 240 Report No.: S23020200406001 Page 215 of 240 Report No.: S23020200406001 Page 216 of 240 Report No.: S23020200406001 Page 217 of 240 Report No.: S23020200406001 Page 218 of 240 Report No.: S23020200406001 Page 219 of 240 Report No.: S23020200406001 Page 220 of 240 Report No.: S23020200406001 Page 221 of 240 Report No.: S23020200406001 Page 222 of 240 Report No.: S23020200406001 Page 223 of 240 Report No.: S23020200406001 Page 224 of 240 Report No.: S23020200406001 Page 225 of 240 Report No.: S23020200406001 Page 226 of 240 Report No.: S23020200406001 Page 227 of 240 Report No.: S23020200406001 Page 228 of 240 Report No.: S23020200406001 Page 229 of 240 Report No.: S23020200406001 Page 230 of 240 Report No.: S23020200406001 Page 231 of 240 Report No.: S23020200406001 Page 232 of 240 Report No.: S23020200406001 Page 233 of 240 Report No.: S23020200406001 <Justification of the extended calibration> If dipoles are verified in return loss (<-20dB, within 20% of prior calibration for below 3GHz, and <-8dB, within 20% of prior calibration for 5GHz to 6GHz), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. <Head 750MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -23.80 - 56.4 - Mar. 01, 2021 -23.642 0.66 56.998 0.598 Feb. 28, 2022 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data Page 234 of 240 Report No.: S23020200406001 <Head 835MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -25.44 - 54.40 - Mar. 01, 2021 -25.803 1.43 54.492 0.092 Feb. 28, 2022 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data Page 235 of 240 Report No.: S23020200406001 <Head 1800MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -28.85 - 47.90 - Mar. 01, 2021 -28.545 1.06 47.809 0.091 Feb. 28, 2022 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data Page 236 of 240 Report No.: S23020200406001 <Head 1900MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -24.79 - 50.80 - Mar. 01, 2021 -24.518 1.10 50.516 0.284 Feb. 28, 2022 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data Page 237 of 240 Report No.: S23020200406001 <Head 2450MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -23.18 - 56.30 - Mar. 01, 2021 -23.39 0.91 56.342 0.042 Feb. 28, 2022 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data Page 238 of 240 Report No.: S23020200406001 <Head 2600MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -21.15 - 52.70 - Mar. 01, 2021 -21.248 0.46 53.053 0.353 Feb. 28, 2022 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data Page 239 of 240 Report No.: S23020200406001 <Head 5200MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -9.15 - 21.17 - Mar. 01, 2021 -9.1819 0.35 21.191 0.021 Feb. 28, 2022 The return loss is <-8dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data Page 240 of 240 Report No.: S23020200406001 <Head 5800MHz> Return Loss (dB) Delta (%) Impedance Delta(ohm) Date of Measurement -14.30 - 54.74 - Mar. 01, 2021 -14.349 0.34 55.115 0.375 Feb. 28, 2022 The return loss is <-8dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data _______________________________________END _____________________________________

致力于为客户提供专业级天线解决方案 Z-TECH Z6501S AntennaTest Report Radio frequency: He Lei Date：2023-1-11 Contact mobile no.：15767667652 致力于为客户提供专业级天线解决方案 射频：曾祥好 日期：2021 -10-12 报告版次：V0.1 Project development environment Yusheng Communication's products cover almost all antenna applications for wireless terminal equipment, including automotive antennas, high- precision surveying and mapping antennas, drone ground and satellite data navigation, high- precision positioning antennas, medical equipment wireless transmission, consumer antennas (mobile phone antennas) , PAD, laptop antenna), base station/indoor distribution antenna, smart wearable antenna (smart watch, TWS earphone), security home antenna and a variety of wireless data transmission and wireless control smart device antennas, etc. We are moving from the Internet age to the smart age, and the country is building a digital society and smart city. In the next 5-10 years, both the consumer electronics market and the Internet of Things market have huge development potential. The field of wireless communication is very diversified. In the future, relying on the customer platform advantages of the main antenna business and its own comprehensive strength, Yusheng will strive to provide customers with professional -level product solutions with market competitiveness. 致力于为客户提供专业级天线解决方案 1 Introduction to project commissioning Report Version Outline Antenna Active Parameters Antenna Passive Parameters Antenna environment treatment and improvement Summary & Additional Notes 2 3 4 5 6 致力于为客户提供专业级天线解决方案 Introduction to project commissioning Model Tablet Plate type motherboard Frequency Band and Antenna Material main antenna Bands Materials 2GGSM850/900/1800/1900 FPC 3GWCDMA B2/4/5 4GLTE B2/4/5/7/12/13/17 other antenna GWB1575.42MHz/2.450GHz FPC DRX824MHz-2700MHz FPC Performance requirements Execute according to customer requirements 致力于为客户提供专业级天线解决方案 Main Antenna Active Parameters TestGSM 850PCS 1900 Channel128190251512661810 TRP(dBm) 26.3326.1426.0924.1224.3624.45 TIS(dBm) -102.13-102.36 TestEGSM 900DCS 1800 Channel162124512698885 TRP(dBm) 25.2625.4325.1124.2324.3524.48 TIS(dBm) -100.36-102.39 致力于为客户提供专业级天线解决方案 Main Antenna Active Parameters TestWCDMA_IIWCDMA_V Channel966298009938435744084458 TRP(dBm) 17.4217.2617.1716.1316.2216.19 TIS(dBm) -103.07-102.36 TestWCDMA_VI Channel153716381738 TRP(dBm) 17.4117.2717.19 TIS(dBm) -103.05 致力于为客户提供专业级天线解决方案 Main Antenna Active Parameters TestFDD B2FDD B4 Channel186501890019150 200502017520350 TRP(dBm) 16.3516.6716.4316.4616.0916.42 TIS(dBm) -93.25-93.13 TestFDD B5FDD B7 Channel204502052520600208002110021400 TRP(dBm) 16.5516.3616.2816.5516.6116.88 TIS(dBm) -91.43-92.24 TestFDD B12FDD B13 Channel230352309523155231302323023330 TRP(dBm) 15.3515.6916.1415.4615.7715.89 TIS(dBm) -90.53-90.38 致力于为客户提供专业级天线解决方案 Main Antenna Active Parameters TestFDD B17 Channel237802379023800 TRP(dBm) 15.7616.1716.33 TIS(dBm) -90.58 致力于为客户提供专业级天线解决方案 GPS Test 致力于为客户提供专业级天线解决方案 Antenna environment treatment and improvement 1. The middle frame and the screen are grounded. 2. The screen FPC is shielded with conductive cloth. 3. Middle frame plus sponge and grounding. 致力于为客户提供专业级天线解决方案 Antenna environment treatment and improvement 1、The earphone is grounded with a conductive cloth 致力于为客户提供专业级天线解决方案 Antenna environment treatment and improvement 1. Motherboard and screen grounding. 2. The earphone socket is shielded with conductive cloth. 致力于为客户提供专业级天线解决方案 Antenna environment treatment and improvement 1. The small plate and the middle frame are grounded with double-sided conductive cloth. 2. Speaker grounding. 致力于为客户提供专业级天线解决方案 DRX matching 1. String 4.3PF, parallel NC 致力于为客户提供专业级天线解决方案 Small plate matching 致力于为客户提供专业级天线解决方案 Switch logic RF1(0 Euro） GSM900/1800/1900 WCDMA B2 LTEB2/7 RF2（1.5NH） GSM850 WCDMA B4/5 LTEB4/5 RF3（27NH） GSM WCDMA LTEB12/13/17 致力于为客户提供专业级天线解决方案 BandGain（MAX） GSM850 0.58 EGSM900 0.45 DCS1800 0.61 PCS1900 0.57 WCDMA1700 0.59 WCDMA1900 0.57 WCDMA850 0.58 Band2 0.57 Band4 0.59 Band5 0.58 Band70.64 Band120.52 Band130.52 Band170.52 Antenna gain GPS 1.09 WiFi2.4G 1.05 BT 1.05 WiFi5G 1.05 致力于为客户提供专业级天线解决方案 Apple diagram 致力于为客户提供专业级天线解决方案 Apple diagram 致力于为客户提供专业级天线解决方案 Apple diagram 致力于为客户提供专业级天线解决方案 Apple diagram 致力于为客户提供专业级天线解决方案 Apple diagram 致力于为客户提供专业级天线解决方案 Apple diagram 致力于为客户提供专业级天线解决方案 Apple diagram Shenzhen Address: 4th Floor, Building 2, Nantaiyun Chuanggu, Guangming Avenue, Guangming New District, Shenzhen Tel：0755-23984257 Fax：0755-86090455

Report No.: S23020200405005 1 / 40 13 Conducted output power Band Channel Frequency (MHz) Power (dBm) Verdict EGPRS1900 1 Slot 512 1850.2 28.81 PASS EGPRS1900 1 Slot 661 1880 28.28 PASS EGPRS1900 1 Slot 810 1909.8 28.41 PASS EGPRS1900 2 Slot 512 1850.2 27.80 PASS EGPRS1900 2 Slot 661 1880 27.49 PASS EGPRS1900 2 Slot 810 1909.8 27.33 PASS EGPRS1900 3 Slot 512 1850.2 24.84 PASS EGPRS1900 3 Slot 661 1880 24.43 PASS EGPRS1900 3 Slot 810 1909.8 24.59 PASS EGPRS1900 4 Slot 512 1850.2 22.64 PASS EGPRS1900 4 Slot 661 1880 22.16 PASS EGPRS1900 4 Slot 810 1909.8 22.38 PASS EGPRS850 1 Slot 128 824.2 34.03 PASS EGPRS850 1 Slot 189 836.4 33.86 PASS EGPRS850 1 Slot 251 848.8 33.78 PASS EGPRS850 2 Slot 128 824.2 33.86 PASS EGPRS850 2 Slot 189 836.4 33.67 PASS EGPRS850 2 Slot 251 848.8 33.52 PASS EGPRS850 3 Slot 128 824.2 33.56 PASS EGPRS850 3 Slot 189 836.4 33.19 PASS EGPRS850 3 Slot 251 848.8 32.65 PASS EGPRS850 4 Slot 128 824.2 32.72 PASS EGPRS850 4 Slot 189 836.4 32.21 PASS EGPRS850 4 Slot 251 848.8 31.78 PASS 15 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict EGPRS1900 512 1850.2 4.97535865 13.00 PASS EGPRS1900 661 1880 4.983245283 13.00 PASS EGPRS1900 810 1909.8 4.904054054 13.00 PASS EGPRS850 128 824.2 3.504769231 13.00 PASS EGPRS850 189 836.4 3.435747126 13.00 PASS EGPRS850 251 848.8 3.428990385 13.00 PASS EGPRS1900 Channel=512 Report No.: S23020200405005 2 / 40 EGPRS1900 Channel=661 EGPRS1900 Channel=810 Report No.: S23020200405005 3 / 40 EGPRS850 Channel=128 EGPRS850 Channel=189 Report No.: S23020200405005 4 / 40 EGPRS850 Channel=251 16 Occupied bandwidth Report No.: S23020200405005 5 / 40 Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict EGPRS1900 512 1850.2 252.585 324.009 PASS EGPRS1900 661 1880 248.246 316.225 PASS EGPRS1900 810 1909.8 257.704 312.187 PASS EGPRS850 128 824.2 511.706 726.711 PASS EGPRS850 189 836.4 437.537 651.882 PASS EGPRS850 251 848.8 433.651 673.633 PASS EGPRS1900 Channel=512 EGPRS1900 Channel=661 Report No.: S23020200405005 6 / 40 EGPRS1900 Channel=810 EGPRS850 Channel=128 Report No.: S23020200405005 7 / 40 EGPRS850 Channel=189 EGPRS850 Channel=251 Report No.: S23020200405005 8 / 40 17 Band edge Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict EGPRS1900 512 1850.2 1849.98 -28.48 -13 PASS EGPRS1900 810 1909.8 1910.01 -31.58 -13 PASS EGPRS850 128 824.2 823.99 -27.39 -13 PASS EGPRS850 251 848.8 849.02 -24.99 -13 PASS EGPRS1900 Channel=810 Report No.: S23020200405005 9 / 40 EGPRS1900 Channel=512 EGPRS850 Channel=128 Report No.: S23020200405005 10 / 40 EGPRS850 Channel=251 18 Out-of-band emissions Report No.: S23020200405005 11 / 40 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict EGPRS1900 512 1850.2 25956.70 -18.57 -13 PASS EGPRS1900 661 1880 25942.81 -18.70 -13 PASS EGPRS1900 810 1909.8 26036.78 -18.71 -13 PASS EGPRS850 128 824.2 26015.60 -20.65 -13 PASS EGPRS850 189 836.4 25978.54 -20.18 -13 PASS EGPRS850 251 848.8 25965.31 -19.53 -13 PASS EGPRS1900 Channel=661 EGPRS1900 Channel=512 Report No.: S23020200405005 12 / 40 EGPRS1900 Channel=810 EGPRS850 Channel=189 Report No.: S23020200405005 13 / 40 EGPRS850 Channel=128 EGPRS850 Channel=251 Report No.: S23020200405005 14 / 40 07 Conducted output power Band Channel Frequency (MHz) Power (dBm) Verdict GPRS1900 1 Slot 512 1850.2 29.64 PASS GPRS1900 1 Slot 661 1880 29.41 PASS GPRS1900 1 Slot 810 1909.8 29.28 PASS GPRS1900 2 Slot 512 1850.2 28.89 PASS GPRS1900 2 Slot 661 1880 28.62 PASS GPRS1900 2 Slot 810 1909.8 28.46 PASS GPRS1900 3 Slot 512 1850.2 27.06 PASS GPRS1900 3 Slot 661 1880 26.74 PASS GPRS1900 3 Slot 810 1909.8 26.54 PASS GPRS1900 4 Slot 512 1850.2 25.85 PASS GPRS1900 4 Slot 661 1880 25.50 PASS GPRS1900 4 Slot 810 1909.8 25.29 PASS GPRS850 1 Slot 128 824.2 32.35 PASS GPRS850 1 Slot 189 836.4 32.48 PASS GPRS850 1 Slot 251 848.8 32.52 PASS GPRS850 2 Slot 128 824.2 31.59 PASS GPRS850 2 Slot 189 836.4 31.70 PASS GPRS850 2 Slot 251 848.8 31.76 PASS GPRS850 3 Slot 128 824.2 29.64 PASS GPRS850 3 Slot 189 836.4 29.73 PASS GPRS850 3 Slot 251 848.8 29.84 PASS Report No.: S23020200405005 15 / 40 GPRS850 4 Slot 128 824.2 28.39 PASS GPRS850 4 Slot 189 836.4 28.50 PASS GPRS850 4 Slot 251 8…
