2A97W-SPIRITSPIRIT Radon Sensor

Spirit Radon detector User Guide Radonova Laboratories AB Version 1.0 2 1.0Getting started SPIRIT includes the following parts: • SPIRIT radon device • USB adapter & cable • Quick start manual Included parts 1.1 Place the device where you want to measure radon. Power the device by pressing and holding down the power button for 3 seconds until the LED indicates blue. Verify that the device is measuring by pressing the status button. See the section about LED indicators for more information. To see your measurement, please visit https://spirit.radonova.com. Here you can create an account and add your device to your account. When your measurement is complete, power down the device by pressing and holding the power button for 3 seconds until the LED indicates red. If you also want to power down the network connection, press and hold both status- and power button for 3 seconds. 1 2 3 4 5 For detailed instructions, see section 3.0. This section is a quick start to easily get started with a measurement. Quick start guide 1.2 3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including inter- ference that may cause undesired operation. CAUTION: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer- ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep- tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. 2.0Disclaimer RF exposure statement This equipment meets the exemption from the routine evaluation limits in section 2.5 of RSS-102. It should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body. Cetéquipementestconforme à l'exemption des limitesd'évaluationhabituelle de la section 2.5 de la norme RSS-102. Il doitêtre- installé et utilisé à une distance minimale de 20 cm entre le radiateur et toutepartie de votre corps. This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Devel- opment Canada license-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L'émetteur/récepteur exempt de licencecontenudans le présentappareilestconformeaux CNRd'Innovation, Sciences et Développementéconomique Canada applicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes : 1) L'appareil ne doit pas produire de brouillage; 2) L'appareildoitaccepter toutbrouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le fonc- tionnement. Canadian Compliance Statement This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This equip- ment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body. RF exposure statement FCC Compliance Statement 4 Warning! Risk of explosion if the battery is replaced with an incorrect type of battery. Warning! Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery can result in an explosion. Warning! Leaving a battery in an extremely high temperature surrounding environment can result in an explo- sion or the leakage of flammable liquid or gas. Safety2.2 The trash-symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose your waste by taking it to a collection point designated for the recycling of electrical and electronic appliances. Separate collection and recycling of your waste at the time of disposal will contribute to conserving natural resources and guarantee recycling that respects the environment and human health. For further information concerning your nearest recycling center, please contact your nearest local authority/town hall offices, your household waste collection company or the shop where you bought the product. Environmental2.1 5 3.0Instrument operation The instrument is started and stopped using the power-button on the device. The button must be pressed for three seconds until the measuring LED lights up in blue, then release. The instrument starts measuring immediately when it is started. Start and stop of measurement 3.1 Each time the device is started with the power button, a new measure serie is started. This can be used to distinguish between different measurement locations. When retrieving and analyzing the data, it will be grouped by measurement series. Measure series 3.2 The device has three status-leds which will light up each time the status button is pressed. LED-indicators 3…

Text truncated - open the document above for the full version.

Radonova Laboratories AB Rapsgatan 25 75450 Uppsala, Sweden Date: 04/03/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A97W-SPIRIT Attestation Statements Part 2.911(d)(5)(i) Filing To whom it may concern, Radonova Laboratories AB, certifies that the equipment is seeking authorization is not on the “List of Equipment and Services Covered by Section 2 of the Secure Networks Act,” which it is prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Patrik Starck Development Engineer IT & Projects

Radonova Laboratories AB Rapsgatan 25 75450 Uppsala, Sweden Date: 04/03/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A97W-SPIRIT Attestation Statements Part 2.911(d)(5)(ii) Filing To whom it may concern, Radonova Laboratories AB certifies that, as of the date of the filing of the application, Radonova Laboratories AB is not identified on the “List of Equipment and Services Covered by Section 2 of the Secure Networks Act,” as an entity producing “covered” equipment. Sincerely, Signature: Patrik Starck Development Engineer IT & Projects

Radonova Laboratories AB Rapsgatan 25 75450 Uppsala, Sweden Date: 04/03/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A97W-SPIRIT US Agent – Attestation Statement / Part 2.911(d)(7) Radonova Laboratories AB, that as of 04/03/2023, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2A97W-SPIRIT. Radonova Laboratories AB accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Radonova Laboratories AB for FCC ID: 2A97W-SPIRIT. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: Radonova Laboratories AB Designated Agent: FCC US Agent, LLC Company Representative: Patrik Starck Designated Agent Representative: Tim Payne Signature: Signature:

Radonova Laboratories AB Rapsgatan 25 75450 Uppsala, Sweden Date: 04/03/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A97W-SPIRIT Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: ☒Block Diagram ☐Tune-Up Information ☒Operational Description ☐Security Information ☒Schematics ☐Software Defined Radio (SDR) Information ☒Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature: Patrik Starck Development Engineer IT & Projects

Radonova Laboratories AB Rapsgatan 25 75450 Uppsala, Sweden Date: 04/03/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A97W-SPIRIT Declaration of Authorization To whom it may concern, I, the undersigned, hereby authorize, Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jandy So, of Waltek Testing Group (Shenzhen) Co., Ltd., (WALTEK) on our behalf shall have the same effects as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Signature: Patrik Starck Development Engineer IT & Projects

Reference No.: WTX23X02010589W Page 2 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X02010589W Page 3 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X02010589W Page 4 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6

Reference No.: WTX23X02010589W Page 1 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX23X02010589W Page 5 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTX23X02010589W Page 6 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTX23X02010589W Page 7 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 3 Solder Board-Component View 4 Reference No.: WTX23X02010589W Page 8 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 5 Solder Board-Component View 6

Reference No.: WTX23X02010589W Page 9 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 7 Antenna View

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Radonova Laboratories AB Address of applicant: Rapsgatan 25, 75450 Uppsala, SWEDEN Manufacturer: Radonova Laboratories AB Address of manufacturer: Rapsgatan 25, 75450 Uppsala, SWEDEN General Description of EUT: Product Name: SPIRIT Radon Sensor Trade Name / Model No.: SPIRIT Adding Model(s): / Rated Voltage: Battery:DC3.6V USB Port:DC5V Battery Capacity 6700mAh Power Adapter: / FCC ID: 2A97W-SPIRIT Equipment Type: Mobile device Technical Characteristics of EUT: 902.3-914.9MHz Frequency Range: 902.3-914.9MHz RF Output Power: 19.22dBm (Conducted) Modulation: GFSK Quantity of Channels: 64 Channel Separation: 200kHz Type of Antenna: Stamped metal antenna Antenna Gain: 2.4dBi 903MHz-914.2MHz Frequency Range: 903-914.2MHz RF Output Power: 18.42dBm (Conducted) Modulation: GFSK Quantity of Channels: 8 Channel Separation: 600kHz Type of Antenna: Stamped metal antenna Antenna Gain: 2.4dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) 902.3-914.9MHz 902.3 19.22 2.4 100 20.00 20.25 903-914.2MHz 903 18.42 2.4 100 19.00 19.25 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 902.3 C 20.00 20.25 105.93 461.98 0.23 Pass 903 C 20.00 19.25 84.14 462.34 0.18 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Note: Can't transmit at the same time Result: Pass

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 40 TEST REPORT Reference No. .................... : WTX23X02010589W002 FCC ID ................................ : 2A97W-SPIRIT Applicant ........................... : Radonova Laboratories AB Address.............................. : Rapsgatan 25, 75450 Uppsala, SWEDEN Manufacturer ..................... : The same as Applicant Address.............................. : The same as Applicant Product Name ................... : SPIRIT Radon Sensor Model No.. .......................... : SPIRIT Standards .......................... : FCC Part 15.247 Date of Receipt sample .... : 2023-02-01 Date of Test........................ : 2023-02-01 to 2023-03-23 Date of Issue ..................... : 2023-03-23 Test Report Form No. ....... : WTX_Part 15_247W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Mike Shi Silin Chen Reference No.: WTX23X02010589W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 40 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .........................................................................4 1.2 TEST STANDARDS .................................................................................................................................................5 1.3 TEST METHODOLOGY ...........................................................................................................................................5 1.4 TEST FACILITY ......................................................................................................................................................5 1.5 EUT SETUP AND TEST MODE ..............................................................................................................................6 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................7 1.7 TEST EQUIPMENT LIST AND DETAILS ...................................................................................................................8 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 11 3. ANTENNA REQUIREMENT ................................................................................................................................. 12 3.1 STANDARD APPLICABLE ..................................................................................................................................... 12 3.2 EVALUATION INFORMATION ................................................................................................................................ 12 4. POWER SPECTRAL DENSITY ........................................................................................................................... 13 4.1 STANDARD APPLICABLE ..................................................................................................................................... 13 4.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 13 4.3 TEST PROCEDURE .............................................................................................................................................. 13 4.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 13 5. DTS BANDWIDTH ................................................................................................................................................. 14 5.1 STANDARD APPLICABLE ..................................................................................................................................... 14 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 14 5.3 TEST PROCEDURE .............................................................................................................................................. 14 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 14 6. RF OUTPUT POWER ............................................................................................................................................ 15 6.1 STANDARD APPLICABLE ..................................................................................................................................... 15 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 15 6.3 TEST PROCEDURE .............................................................................................................................................. 15 6.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 15 7. FIELD STRENGTH OF SPURIOUS EMISSIONS ............................................................................................. 16 7.1 STANDARD …

Text truncated - open the document above for the full version.

ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory Features • Supports 868, 915 or 868+2400 MHz • Profile of 4.93 mm • Mixed Linear Polarization • Surface Mount • Durable-Shelf life of upto 10 years • Three different evaluation boards available: o “SMD 868” for 860-870 MHz o “SMD 915” for 902-928 MHz o “SMD 868+2400” for 860-870 + 2400-2500 MHz Applications • Wi-Fi/BT/LPWA/LoRA/SigFox/ISM • IoT, M2M o Industrial o Infrastructure o Medical • Remote Technology / Monitoring • Network devices • Consumer Tracking • Smart Metering Product Image ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory Electrical Specification Note: All measurements were conducted on its evaluation board in free space. Performance will vary depending on the ground plane, application, and environment. Mechanical Specification Environmental Specification Parameter Specification Unit “SMD 868” “SMD 915” “SMD 868+2400” Operating Frequency 860 - 870 902 - 928 860 - 870 2400 - 2500 MHz Center Frequency 865 915 865 2450 Return Loss ˂ -9.9 ˂ -6.6 < -8.3 < -4.3 dB dB Polarization Mixed Linear Peak Gain 1.7 2.4 1 3.8 dBi Efficiency > 63 > 50 > 49 > 43 % Impedance 50 Ω Parameter Specification Antenna Dimension 34.00 x 11.53 x 4.93 mm Evaluation board Dimension “SMD 868” 120 x 50 mm Evaluation board Dimension “SMD 915” 120 x 50 mm Evaluation board Dimension “SMD 868+2400” 95 x 38 mm Mounting Type Surface Mount Parameter Specification Operating Temperature -40°C to +125°C Storage Temperature Maximum Temperature 400°C RoHS Compliance Yes Compliant with EU directive 2011/65/EU and 2015/863 Shelf life 10 years MSL Level 1, unlimited Mechanical resistance Immunity to vibrations IEC/EN 60068-2-6, Fc test Immunity to shock IEC/EN 60068-2-27, Ea test ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory Product Dimension Unit : mm Antenna pins and keep-out block Unit : mm ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory PCB layout and antenna pin numbering The antenna uses PIFA technology and should thus be mounted on a ground plane. If there are several layers in the PCB, there is an advantage to add vias for smooth interconnection of the ground areas to avoid splits in the ground plane. It is also important that there is a ground clearance around the NC pads and the RF feed pad, through all layers of the PCB. It is recommended to implement a matching network to optimize the antenna impedance in your application. The components can be positioned under the antenna. See recommendations in the figures below. Pin configuration PCB Layout (from evaluation board) Clearance through all layers Unit: mm ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory Measurement Setup The antenna measurements for 868 MHz were done with the OnBoard “SMD 868” evaluation board (PRO-EB-472, 120 x 50 mm) - measured in free space. The antenna measurements for 915 MHz were done with the OnBoard “ SMD 915” evaluation board (PRO-EB-476, 120 x 50 mm) - measured in free space. The antenna measurements for 868+2400 MHz were done with the OnBoard “SMD 868+2400” evaluation board (PRO-EB-531, 95 x 38 mm) - measured in free space. ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory Reflection Characteristics “SMD 868” – Return Loss Total Radiation Efficiency “SMD 868” Maximum Radiation Gain “SMD 868” ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory Reflection Characteristics “SMD 915” – Return Loss Total Radiation Efficiency “SMD 915” Maximum Radiation Gain “SMD 915” ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For terms and conditions of sales, please visit: www.abracon.com OnBoard 868/915/868+2400 MHz - Antenna PRO-OB-471 34.00 x 11.53 x 4.93 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory Reflection Characteristics “SMD 868+2400” – Return Loss Total Radiation Efficiency “SMD 868+2400” Maximum Radiation Gain “SMD 868+2400” ABRACON IS ISO9001-2015 CERTIFIED Hidden Creek Ln Spicewood TX 78669 5101 Phone: 512-371-6159 | Fax: 512-351-8858 REVISED: For ter…

Text truncated - open the document above for the full version.

Reference No.: WTX23X02010589W Page 10 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emissions Radiation Emission Test Setup (Below 30MHz) Reference No.: WTX23X02010589W Page 11 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (30MHz to 1GHz) Radiation Emission Test Setup (1GHz to 18GHz) Reference No.: WTX23X02010589W Page 12 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ***** END OF REPORT *****
