Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOT E: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help.
Shenzhen Maifeng Trading Co., Ltd Agent Authorization Company: Shenzhen Maifeng Trading Co., Ltd Address: 410 Fukang Science and Technology Building, Longhua District, Shenzhen, China Product Name: Mini camera Trade Mark: N/A Model Number(s): A9 FCC ID: 2A9GL-A9 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-11-22 Name: Xiaolian He Title: General Manager Company: Shenzhen Maifeng Trading Co., Ltd
Shenzhen Maifeng Trading Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-11-22 Subject; Request for Confidentiality FCC ID: 2A9GL-A9 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM Software Security Requirements Tune up In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name / Title: Xiaolian He / General Manager Company: Shenzhen Maifeng Trading Co., Ltd Address: 410 Fukang Science and Technology Building, Longhua District, Shenzhen, China Phone: 13424252726 Fax: / E-Mail: [email protected]
FCC ID: 2A9GL-A9 Fig. 1 Fig. 2 FCC ID: 2A9GL-A9 Fig. 3 Fig. 4 FCC ID: 2A9GL-A9 Fig. 5 Fig. 6 FCC ID: 2A9GL-A9 Fig. 7
_____________________________________________________________________________________________________ LABEL AND LOCATION (Size: L2.5cm x 2.5cm) Label Location Mini camera Model : A9 FCC ID: 2A9GL-A9 Input:DC 5.0V
FCC ID: 2A9GL-A9 Fig. 1 Fig. 2 FCC ID: 2A9GL-A9 Fig. 3 Fig. 4 FCC ID: 2A9GL-A9 Fig. 5 Fig. 6 Antenna FCC ID: 2A9GL-A9 Fig. 7
Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong RF Exposure evaluation Report Reference No...................... : FCC ID. ............................................ : GTS20221107009-1-2 2A9GL-A9 Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Jenny Zeng Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Nov.21, 2022 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Maifeng Trading Co., Ltd Address ............................................ : 410 Fukang Science and Technology Building, Longhua District, Shenzhen, China Test specification ........................... : Standard ........................................... : 47CFR §1.1310 Basis and purpose 47CFR §2.1091 Radiofrequency radiation exposure evaluation: mobile devices KDB447498 D01 General RF Exposure Guidance v06 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Mini camera Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Shengshida Technology Co., Ltd Model/Type reference ...................... : A9 Listed Models .................................. : N/A Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 5.0V by Adapter Result ............................................... : PASS Report No.: GTS20221107009-1-2 Page 2 of 11 T E S T R E P O R T Test Report No. : GTS20221107009-1-2 Nov.21, 2022 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mini camera Model /Type : A9 Listed model : N/A Applicant : Shenzhen Maifeng Trading Co., Ltd Address : 410 Fukang Science and Technology Building, Longhua District, Shenzhen, China Manufacturer : Shenzhen Shengshida Technology Co., Ltd Address : 8/F, Building B, Dadan Industrial Park, Bantian Street, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20221107009-1-2 Page 3 of 11 Contents 1. SUMMARY ................................................................................................................................................................. 4 1.1 EUT CONFIGURATION ........................................................................................................................................................ 4 1.2 PRODUCT DESCRIPTION ..................................................................................................................................................... 4 2. TEST ENVIRONMENT ................................................................................................................................................. 4 2.1 ADDRESS OF THE TEST LABORATORY ..................................................................................................................................... 5 2.2 TEST FACILITY .................................................................................................................................................................. 5 2.3 ENVIRONMENTAL CONDITIONS ............................................................................................................................................ 5 2.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY .................................................................................................................. 5 3. METHOD OF MEASUREMENT .................................................................................................................................... 6 3.1 APPLICABLE STANDARD ...................................................................................................................................................... 6 3.2 REQUIREMENT ................................................................................................................................................................. 6 3.3 LIMIT ............................................................................................................................................................................. 6 3.4 MPE CALCULATION METHOD ............................................................................................................................................. 7 3.5 ANTENNA INFORMATION ................................................................................................................................................... 7 4. CONDUCTED POWER RESULTS ........................................................................................................…
Text truncated - open the document above for the full version.
Antenna Describe 1: Antenna Describe Antenna PCB Antenna Gain 0dBi Frequency Range 2.4Ghz-2.5Ghz Connector Type Direct Location of mearement(company name) SHENZHENSHIXINZHONGXN TECHNOLOGY.CO.,LTD 2:External View Drawing Picture of antenna 3:Measurement Result 3.1 Return Loss (S11 ) 3.2 Smith Chart 3.3 Gain
Case No. : GST20221107009-1-1 Ambient Condition: 24 °C, 51 %RH, Atmos100.1Kpa, Test Date: 2022.11.09 Test Engineer: Jenny zeng Appendix A.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 8.520 2408.000 2416.520 0.5 PASS 2437 7.600 2433.440 2441.040 0.5 PASS 2462 8.040 2457.960 2466.000 0.5 PASS 11G Ant1 2412 15.040 2404.480 2419.520 0.5 PASS 2437 12.840 2430.680 2443.520 0.5 PASS 2462 14.160 2455.360 2469.520 0.5 PASS 11N20SISO Ant1 2412 14.000 2405.760 2419.760 0.5 PASS 2437 15.600 2429.520 2445.120 0.5 PASS 2462 15.080 2454.480 2469.560 0.5 PASS 11N40SISO Ant1 2422 33.920 2405.680 2439.600 0.5 PASS 2437 35.040 2419.480 2454.520 0.5 PASS 2452 32.640 2436.960 2469.600 0.5 PASS Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 11G_Ant1_2412 11G_Ant1_2437 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Appendix A.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 12.979 2405.574 2418.553 --- --- 2437 12.868 2430.631 2443.499 --- --- 2462 12.866 2455.602 2468.468 --- --- 11G Ant1 2412 16.942 2403.621 2420.563 --- --- 2437 16.783 2428.661 2445.444 --- --- 2462 16.810 2453.624 2470.434 --- --- 11N20SISO Ant1 2412 17.924 2403.066 2420.990 --- --- 2437 17.812 2428.130 2445.942 --- --- 2462 17.768 2453.111 2470.879 --- --- 11N40SISO Ant1 2422 36.127 2404.115 2440.242 --- --- 2437 36.116 2419.104 2455.220 --- --- 2452 36.217 2433.984 2470.201 --- --- Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 11G_Ant1_2412 11G_Ant1_2437 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Appendix A.3: Maximum conducted output power Test Result Peak TestMode Antenna Frequency[M Hz] Peak Powert[dBm] Conducted Limit[dBm] Verdict 11B Ant1 2412 16.03 ≤30.00 PASS 2437 17.19 ≤30.00 PASS 2462 17.43 ≤30.00 PASS 11G Ant1 2412 20.26 ≤30.00 PASS 2437 21.31 ≤30.00 PASS 2462 21.43 ≤30.00 PASS 11N20SISO Ant1 2412 22.13 ≤30.00 PASS 2437 20.67 ≤30.00 PASS 2462 21.12 ≤30.00 PASS 11N40SISO Ant1 2422 20.48 ≤30.00 PASS 2437 21.31 ≤30.00 PASS 2452 21.57 ≤30.00 PASS Appendix A.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -9.49 ≤8.00 PASS 2437 -8.78 ≤8.00 PASS 2462 -7.53 ≤8.00 PASS 11G Ant1 2412 -11.29 ≤8.00 PASS 2437 -10.85 ≤8.00 PASS 2462 -10.81 ≤8.00 PASS 11N20SISO Ant1 2412 -10.04 ≤8.00 PASS 2437 -10.09 ≤8.00 PASS 2462 -9.46 ≤8.00 PASS 11N40SISO Ant1 2422 -13.87 ≤8.00 PASS 2437 -13.26 ≤8.00 PASS 2452 -13.39 ≤8.00 PASS Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 11G_Ant1_2412 11G_Ant1_2437 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Appendix A.5: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 4.58 -45 ≤-15.42 PASS High 2462 6.14 -48.88 ≤-13.86 PASS 11G Ant1 Low 2412 2.87 -32.27 ≤-17.13 PASS High 2462 4.43 -45.21 ≤-15.57 PASS 11N20SISO Ant1 Low 2412 4.37 -25.41 ≤-15.63 PASS High 2462 4.25 -46.21 ≤-15.75 PASS 11N40SISO Ant1 Low 2422 0.35 -34.83 ≤-19.65 PASS High 2452 1.38 -35.63 ≤-18.62 PASS Test Graphs 11B_Ant1_Low_2412 11B_Ant1_High_2462 11G_Ant1_Low_2412 11G_Ant1_High_2462 11N20SISO_Ant1_Low_2412 11N20SISO_Ant1_High_2462 11N40SISO_Ant1_Low_2422 11N40SISO_Ant1_High_2452 Appendix A.6: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 Reference 4.25 4.25 --- PASS 30~1000 4.25 -60.49 ≤-15.75 PASS 1000~26500 4.25 -44.08 ≤-15.75 PASS 2437 Reference 4.97 4.97 --- PASS 30~1000 4.97 -60.42 ≤-15.03 PASS 1000~26500 4.97 -44.12 ≤-15.03 PASS 2462 Reference 4.98 4.98 --- PASS 30~1000 4.98 -60.27 ≤-15.02 PASS 1000~26500 4.98 -45.61 ≤-15.02 PASS 11G Ant1 2412 Reference -0.54 -0.54 --- PASS 30~1000 -0.54 -60.45 ≤-20.54 PASS 1000~26500 -0.54 -47.95 ≤-20.54 PASS 2437 Reference 2.05 2.05 --- PASS 30~1000 2.05 -60.35 ≤-17.95 PASS 1000~26500 2.05 -47.51 ≤-17.95 PASS 2462 Reference 1.92 1.92 --- PASS 30~1000 1.92 -59.86 ≤-18.08 PASS 1000~26500 1.92 -47.48 ≤-18.08 PASS 11N20SISO Ant1 2412 Reference 2.88 2.88 --- PASS 30~1000 2.88 -60.51 ≤-17.12 PASS 1000~26500 2.88 -47.06 ≤-17.12 PASS 2437 Reference -0.83 -0.83 --- PASS 30~1000 -0.83 -59.98 ≤-20.83 PASS 1000~26500 -0.83 -47.1 ≤-20.83 PASS 2462 Reference 0.76 0.76 --- PASS 30~1000 0.76 -59.9 ≤-19.24 PASS 1000~26500 0.76 -47.46 ≤-19.24 PASS 11N40SISO Ant1 2422 Reference -0.96 -0.96 --- PASS 30~1000 -0.96 -60.46 ≤-20.96 PASS 1000~26500 -0.96 -46.56 ≤-20.96 PASS 2437 Reference 1.24 1.24 --- PASS 30~1000 1.24 -60.42 ≤-18.76 PASS 1000~26500 1.24 -47.36 ≤-18.76 PASS 2452 Reference 0.03 0.03 --- PASS 30~1000 0.03 -60.57 ≤-19.97 PASS 1000~26500 0.03 -47.36 ≤-19.97 PASS Test Graphs 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 11B_Ant1_2437_1000~26500 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 11B_Ant1_2462_1000~26500 11G_Ant1_2412_0~Reference 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 11G_Ant1_2437_0~Reference 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_0~Reference 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 11N40SISO_Ant1_2422_0~Reference 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 11N40SISO_Ant1_2452_0~Reference 11N40SISO_An…
Text truncated - open the document above for the full version.
Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. .....................: FCC ID. ............................................ : GTS20221107009-1-1 2A9GL-A9 Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Jenny Zeng Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Nov.21, 2022 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Shenzhen Maifeng Trading Co., Ltd Address ............................................ : 410 Fukang Science and Technology Building, Longhua District, Shenzhen, China Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400- 2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mini camera Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Shengshida Technology Co., Ltd Model/Type reference....................... : A9 Listed Models .................................. : N/A Operation Frequency ........................ : From 2412MHz to 2462MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 5.0V by Adapter Result................................................ : PASS Report No.: GTS20221107009-1-1 Page 2 of 36 T E S T R E P O R T Test Report No. : GTS20221107009-1-1 Nov.21, 2022 ____________________________________________________________________________________ Date of issue Equipment under Test : Mini camera Model /Type : A9 Listed model : N/A Applicant : Shenzhen Maifeng Trading Co., Ltd Address : 410 Fukang Science and Technology Building, Longhua District, Shenzhen, China Manufacturer : Shenzhen Shengshida Technology Co., Ltd Address : 8/F, Building B, Dadan Industrial Park, Bantian Street, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20221107009-1-1 Page 3 of 36 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 6 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 6 2.5. EUT operation mode .............................................................................................................................. 6 2.6. Block Diagram of Test Setup ................................................................................................................. 6 2.7. Related Submittal(s) / Grant (s) ............................................................................................................. 7 2.8. EUT Exercise Software .......................................................................................................................... 7 2.9. Special Accessories ............................................................................................................................... 7 2.10. External I/O Cable ................................................................................................................................ 7 2.11. Modifications ........................................................................................................................................ 7 3. TEST ENVIRONMENT ..................................................................................................................................... 8 3.1. Address of the test laboratory ................................................................................................................ 8 3.2. Test Facility ............................................................................................................................................ 8 3.3. Environmental conditions ...................................…
Text truncated - open the document above for the full version.
FCC ID: 2A9GL-A9 _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2A9GL-A9 _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 3
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 163.30 mW |
