Gazer Limited Agent Authorization Company: Gazer Limited Address: 17 HANOVER SQUARE, LONDON, UNITED KINGDOM, W1S 1BN Product Name: TV Model Number(s): TV43-FS3B, TV43-FS3S, TV43-FS3W, TV43-FS3G Product Description: TV We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-12-02 Name: Yevhen Shtykh Title: Import manager Company: Gazer Limited

Gazer Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022/12/02 Subject; Request for Confidentiality FCC ID: 2A9L7TV43-FS3B To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description FCC Software Security Requirements for UNII devices Rev 2.1 In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Yevhen Shtykh Title: Import manager

Gazer Limited Model Difference Data：2022.12.02 Product description: TV Model name: TV43-FS3B, TV43-FS3S, TV43-FS3W, TV43-FS3G Trade Name: GAZER FCC ID: 2A9L7TV43-FS3B All the model are the same circuit and RF module, except model names . Regards Sincerely Client’s signature : Client’s name / title : Yevhen Shtykh（Import manager） Contact information / address：17 HANOVER SQUARE, LONDON, UNITED KINGDOM, W1S 1BN

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 4 Model: TV43-FS3B External Photos Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 4 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 4 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 4

Model: TV43-FS3B FCC ID: 2A9L7TV43-FS3B Label Location

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 6 Model: TV43-FS3B Internal Photos Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 6 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 6 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 4 of 6 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 5 of 6 BT ANT 2.4GWIFI +5GWIFI ANT1 2.4GWIFI +5GWIFI ANT2 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 6 of 6

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2A9L7TV43-FS3B Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation Modes& Channel Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result BLE GFSK &LCH 1±1 2 1.5849 1.5849 (2dBi) 0.0005 1 Pass EDR 8DPSK &HCH 4±1 5 3.1623 1.5849 (2dBi) 0.001 1 Pass 2.4GWIFI ANT1 802.11b &2462 14±1 15 31.6228 2.9309 (4.67dBi) 0.01845 1 Pass 2.4GWIFI ANT2 802.11b &2412 14±1 15 31.6228 2.9309 (4.67dBi) 0.01845 1 Pass 5.2GWIFI ANT1 802.11ac2 0&5180 14±1 15 31.6228 1.9409 (2.88dBi) 0.01222 1 Pass 5.2GWIFI ANT2 802.11a &5240 14±1 15 31.6228 1.9409 (2.88dBi) 0.01222 1 Pass 5.3GWIFI ANT1 802.11ac2 0&5280 14±1 15 31.6228 2.0559 (3.13dBi) 0.01294 1 Pass 5.3GWIFI ANT2 802.11n(H T20)&528 0 14±1 15 31.6228 2.0559 (3.13dBi) 0.01294 1 Pass 5.6GWIFI ANT1 802.11ac2 0&5580 14±1 15 31.6228 2.1677 (3.36dBi) 0.01364 1 Pass 5.6GWIFI ANT2 802.11n(H T20)&550 0 14±1 15 31.6228 2.1677 (3.36dBi) 0.01364 1 Pass 5.8GWIFI ANT1 802.11a &5700 14±1 15 31.6228 2.0606 (3.14dBi) 0.01297 1 Pass 5.8GWIFI ANT2 802.11ac2 0 &5700 14±1 15 31.6228 2.0606 (3.14dBi) 0.01297 1 Pass BT+WIFI supported simultaneous transmission: EDR+2.4GWIFI MIMO : ∑MPE Ratio =0.001+0.0369=0.0379≤1, So passed. EDR+5GWIFI MIMO: ∑MPE Ratio =0.001+0.02728=0.02828≤1, So passed. Note: 2.4GWIFI and 5GWIFI do not support simultaneous transmission. Tech nolo gy Tune up Produce power(dBm) Maximum Tune-up (dBm) Antenna Gain(ANT 1/ANT 2) (numeric) Power Density (S) (mW/ cm2) MPE Limit (mW/ cm2) ∑MPE Ratio ∑ MPE Ratio Limit Result ANT 1 ANT 2 ANT 1 ANT 2 ANT 1 ANT 2 2.4G WIFI MIM O 14 ±1 14 ±1 15 15 2.9309 (4.67dBi) 0.0184 5 0.0184 5 1 0.0369 1 Pass Tech nolo gy Tune up Produce power(dBm) Maximum Tune-up (dBm) Antenna Gain(ANT 1/ANT 2) (numeric) Power Density (S) (mW/ cm2) MPE Limit (mW/ cm2) ∑MPE Ratio ∑ MPE Ratio Limit Result ANT 1 ANT 2 ANT 1 ANT 2 ANT 1 ANT 2 5G WIFI MIM O 14 ±1 14 ±1 15 15 2.1677 (3.36dBi) 0.0136 4 0.0136 4 1 0.0272 8 1 Pass
