2A9M7AP3220LWireless LAN Access Point

– 1 – Install the AP a. Install it on the Wall 1. Rotate the bracket onto the T-bar of the ceiling. 2. Push the AP toward the bracket until it snaps into place. Connect Cables 1. Connect the external cable to the GE/PoE_IN port. 2. Connect the local LAN switch or computer cable to the LAN1 port. 1 2 1. AP3220L access point 2. 3.One pack of screws Quick Start Guide 2. Push the AP toward the bracket until it snaps into place. One mounting bracket 4 . Package Contents 150200002388H R01 2 Mode 2: First insert the mounting bracket into the AP then insert the Docume ntation— Quick Start Guide (this document ), Warning: For indoor use only. The access point and all 1. Fix two screws on the wall and 110 mm apart. 2. Slide the AP’S wall mounting slots down onto the screws so b. Install it on the Ceiling T-Bar d. Install it on the Ceiling Bracket Mode 1: The hole on the back of the access point is threaded into the cable tie, and secured to the water pipe at the top. connected cables are not suitable for outdoor use. Certificate and Warranty card that the unit is secure. at the top position. 1. Use the included screws to attach the mounting bracket to the wall. c. Install it with Cable Ties (with or without bracket) AP3220L Wireless Access Point 1 2 33 3 4 Quick Start Guide – 2 – Size(WxDxH) 191.0x195.0x44mm Weight360g TemperatureWorking˖0° C to 45° C Storage: -20° C to 60° C Humidity5 % to 95% (No-condensation) 2.4 GHz Radio IEEE 802.11b/g/n 5 GHz Radio I EEE 802.11a/ac/n PoEGE port support s PoE, 802.3af/at power supply 1 LAN1 portSupport 10/100/1000Mbps 1 GE/PoE IN portSupport 10/100/1000Mbps 1 Console RJ45 port 1 USB2.0 port5V/500mA Check AP LED 1. Power LED— green means normal operation. 2. 2.4G-WiFi and 5G-WiFi LEDs — green means radio enabled. 3 1 Reset button Port Description NOMOR:63194/SDPPI/2019 HIDF16000136 ALIBABA CLOUD CON{PUTING CO., LTD Bt74t040919AE0lA2 This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) this device may not cause harmful interference. (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and consider removing the no-collocation statement. Caution! responsible for compliance could void the user's authority to operate the equipment. Frequency band: 5150 - 5250 MHz: Indoor use: Inside buildings only. Installations and use inside road vehicles and train carriages are not permitted. Limited outdoor use: systems (UAS) is limited to within the 5170 - 5250 MHz band. Frequency band: 5250 - 5350 MHz: Indoor use: Inside buildings only. Installations and use in road vehicles, trains and aircraft are not permitted. Outdoor use is not permitted. Frequency band: 5470 - 5725 MHz: Installations and use in road vehicles, trains and aircraft and use for unmanned aircraft systems (UAS) are not permitted. 1 DC 12V port12V DC Operating frequency 5G 2.4G Maximum output power 5G 2.4G 2400~2483.5MHz 2402~2480MHz 5150~5350MHz/5~5MHz 20dBm (single chain power) 30dBm (single chain power) Hereby, MUXI declares that the radio equipment type AP3220L is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: muxi-connect.com. BLE BLE 10dBm

Rev 1/26/2023 (MuXi Technology Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 02-07-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2A9M7AP3220L MuXi Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, henglung chen Signature:  . Rev 1/26/2023 (MuXi Technology Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 02-07-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2A9M7AP3220L MuXi Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, henglung chen Signature:  .

(MuXi Technology Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 02-15-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2A9M7AP3220L MuXi Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, TianHeng Consulting, LLC is our designated U.S. agent for service of process for the above referenced FCC ID. TianHeng Consulting, LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Sincerely, Designated U.S. Agent Information: Name: TianHeng Consulting, LLC FRN: 0033401258 Contact Person: Hualing Dong Address: 392 Andover Street, Wilmington, MA 01887, United States Tel.: +1 617-997-4010 Email: [email protected] U.S. Agent Signature: Applicant: Company Name: MuXi Technology Co., Ltd. Grantee Code: 2A9M7 Contact Name: henglung chen Address: Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., Nanjing, 210012, China Tel.: 021-64859922 Email: [email protected] Applicant Signature: Hualing Dong

MuXi Technology Co., Ltd. Declaration of Authorization We Name: MuXi Technology Co., Ltd. Address: Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., City: Nanjing Country: China Declare that: Name Representative of agent: Ms. Rose Liu Agent Company name: BTL Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s) and signing all the related documents including 731 forms: Product description: Wireless LAN Access Point Type designation: AP3220L Trademark: FCC ID: 2A9M7AP3220L on our behalf. Date: 2022-12-06 City: Nanjing Name: Henglung Chen Function: Manager Signature: Henglung Chen

MuXi Technology Co., Ltd. Date: 2022.12.06 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2A9M7AP3220L Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description 4. Schematics 5. Block Diagram 6. Operatinal Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature henglung chen

MuXi Technology Co., Ltd. Ad Hoc Mode Declaration Date: 2022-12-06 We, the undersigned company Company Name: MuXi Technology Co., Ltd. Address: Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., Nanjing, 210012, China Declare that: Product description: Wireless LAN Access Point Type designation: AP3220L Brand: FCC ID: 2A9M7AP3220L 1. The EUT doesn’t have Ad Hoc Mode function on “non-US frequencies”. 802.11a/n Ad Hoc mode should not be supported even on US DFS frequencies (5.25 ~5.35GHz/5.47 ~5.725GHz). 2. In addition, the frequency selection feature is disabled by firmware for devices marketed to the US. The product meets all other requirements specified in Part 15E Section 15.407 and no configuration controls are provided to change the frequency of operations outside the grant of certification for US operation. 3. Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: Henglung Chen Name: Henglung Chen Tel: 021-64859922 Email: [email protected]

MuXi Technology Co., Ltd. Declaration Letter Date: 2022.12.06 We, the undersigned company Company Name: MuXi Technology Co., Ltd. Address: Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., Nanjing, 210012, China Declare that: Product description: Wireless LAN Access Point Type designation: AP3220L Brand: FCC ID: 2A9M7AP3220L This device with Bridge and Mesh modes of operation are permitted to operate in the DFS band and employ a DFS function. The functionality of the Bridge mode as specified in §15.403(a) and the Mesh mode is validated in the DFS test report by performing a test statistical performance check on any one of the radar types. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: Henglung Chen Name: henglung chen Tel: 021-64859922 Email: [email protected]

Report No.: FCC022022-5923Appendix Page 1 / 5 TIRT-TRF/FCC01-2(E):2021A0 Appendix for External Photographs Project No: 022022-5923 Equipment: Wireless LAN Access Point Model: AP3220L FCC ID: 2A9M7AP3220L Report No.: FCC022022-5923Appendix Page 2 / 5 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923Appendix Page 3 / 5 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923Appendix Page 4 / 5 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923Appendix Page 5 / 5 TIRT-TRF/FCC01-2(E):2021A0 END

246000003070H UL LABEL EAP7205AAX-0321-CH 01.05.23 01.05.23 Jing_Lin AP3220L 电源额定值 POWER RATING: DC 12V; 2A or POE -48V; 0.6A 02 增加认证logo Ver.2 卷状来料 CMIIT ID:XXXXXXXXXX FCC ID:2A9M7AP3220L 6th floor,Datcent Technology Building,21 huashen road,Yuhuatai district,Nanjing MuXi Technology Co.,Ltd. Made in China

Report No.: FCC022022-5923 Appendix Page 1 / 11 TIRT-TRF/FCC01-2(E):2021A0 Appendix for Internal Photographs Project No: 022022-5923 Equipment: Wireless LAN Access Point Model: AP3220L FCC ID: 2A9M7AP3220L Report No.: FCC022022-5923 Appendix Page 2 / 11 TIRT-TRF/FCC01-2(E):2021A0 WIFI Ant1 WIFI Ant2 BLE Ant Report No.: FCC022022-5923 Appendix Page 3 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 4 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 5 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 6 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 7 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 8 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 9 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 10 / 11 TIRT-TRF/FCC01-2(E):2021A0 Report No.: FCC022022-5923 Appendix Page 11 / 11 TIRT-TRF/FCC01-2(E):2021A0 END

Report No.: FCC022022-5923RF14 Page 1 of 7 Product Name: Wireless Access Point Report No: FCC022022-5923RF14 Product Model: AP3220L Security Classification: Open Version: V1.0 Total Page: 7 TIRT Testing Report Prepared By: Checked By: Approved By: Stone Tang Randy Lv Daniel Chen Report No.: FCC022022-5923RF14 Page 2 of 7 FCC RF EXPOSURE REPORT FCC ID: 2A9M7AP3220L Project No. : 022022-5923 Equipment : Wireless LAN Access Point Brand Name : Test Model : AP3220L Series Model : N/A Applicant : MuXi Technology Co., Ltd. Address : Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., Nanjing, JiangSu,210012, China Manufacturer : MuXi Technology Co., Ltd. Address : Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., Nanjing, JiangSu,210012, China Date of Receipt : Aug. 24, 2022 Date of Test : Aug. 25, 2022 ~ Nov. 01, 2022 Issued Date : Nov. 15, 2022 Report Version : V1.0 Test Sample : Engineering Sample No.: 20220814019907 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 • The test result referred exclusively to the presented test model /sample. • Without written approval of TIRT Inc. the test report shall not reproduced except in full. Lab: Beijing TIRT Technology Service Co.,Ltd Shenzhen Add: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China TEL: +86-0755-27087573 Report No.: FCC022022-5923RF14 Page 3 of 7 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note FCC022022-5923RF14 V1.0 Original Report Nov. 11, 2022 Valid Report No.: FCC022022-5923RF14 Page 4 of 7 1. TEST FACILITY Company: Beijing TIRT Technology Service Co.,Ltd Shenzhen Address: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China CNAS Registration Number: CNAS L14158 A2LA Registration Number: 6049.01 FCC Accredited Lab. Designation Number: CN1309 FCC Test Firm Registration Number: 825524 Telephone: +86-0755-27087573 Report No.: FCC022022-5923RF14 Page 5 of 7 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna For BLE: Ant. Brand P/N Antenna Type Connector Gain (dBi) 1 P244001-T4-120G13U1 PCB N/A 4.7 Note: The antenna gain is provided by the manufacturer. For WIFI 2.4GHz: Antenna Specification: Ant. Brand P/N Antenna Type Connector Gain (dBi) 1 126-002-382 PCB Domestic 137 terminal 4.00 2 126-002-383 PCB Domestic 137 terminal 4.05 Note: 1) This EUT supports CDD, and all antenna gains are not equal, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=4.05. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=4.05+10log(2/1)dBi=7.06. Then, the power spectral density limit is 8-(7.06-6)=6.94. 2) The antenna gain is provided by the manufacturer. Table for Antenna Configuration: Operating Mode TX Mode 2TX IEEE 802.11b V(Ant. 1 + Ant. 2) IEEE 802.11g V(Ant. 1 + Ant. 2) IEEE 802.11n(HT20) V(Ant. 1 + Ant. 2) IEEE 802.11n(HT40) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE20) V(Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V(Ant. 1 + Ant. 2) Report No.: FCC022022-5923RF14 Page 6 of 7 For WIFI 5GHz: Antenna Specification: Ant. Brand P/N Antenna Type Connector Gain (dBi) 1 126-002-382 PCB Domestic 137 terminal 5.24 2 126-002-383 PCB Domestic 137 terminal 5.12 Note: 1） This EUT supports CDD, and all antenna gains are not equal, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=5.24. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=5.24+10log(2/1)dBi=8.25. Then, the UNII-1 power spectral density limit is 17-(8.25-6)=14.75, the UNII-2A, UNII-2C power spectral density limit is 11-(8.25-6)=8.75, the UNII-3 power spectral density limit is 30-(8.25-6)=27.75. 2） The antenna gain is provided by the manufacturer. Table for Antenna Configuration: Operating Mode TX Mode 2TX IEEE 802.11a V (Ant. 1 + Ant. 2) IEEE 802.11n(HT20) V (Ant. 1 + Ant. 2) IEEE 802.11n(HT40) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT20) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT40) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT80) V (Ant. 1 + Ant. 2) IEEE 802.11ac(VHT160) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE20) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE40) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE80) V (Ant. 1 + Ant. 2) IEEE 802.11ax(HE160) V (Ant. 1 + Ant. 2) Report No.: FCC022022-5923RF14 Page 7 of 7 3. TEST RESULTS For BT (BLE): Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Tune up Power (dBm) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4.7 2.9513 7.42 8.00 0.0037 1 Complies For 2.4GHz: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Tune up Power (dBm) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4.05 2.5410 26.35 27.00 0.2534 1 Complies For 5GHz: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Tune up Power (dBm) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 5.24 3.3420 23.74 24.00 0.1670 1 Complies For the max simultaneous transmission MPE: Ratio Total Limit of Ratio Test Result BT 2.4GHz 5GHz 0.0037 0.2534 0.167 0.4241 1 Complies Note: 1. The calculated distance is 20 cm. 2. Max. Tune up Power is declared by the manufacturer. 3. WIFI 2.4GHz and 5GHz can be simultaneously transmitted. End of Test Report

Report No.: FCC022022-5923RF1 Page 1 of 107 Product Name: Wireless LAN Access Point Report No: FCC022022-5923RF1 Product Model: AP3220L Security Classification: Open Version: V1.0 Total Page: 107 TIRT Testing Report Prepared By: Checked By: Approved By: Stone Tang Randy Lv Daniel Chen Report No.: FCC022022-5923RF1 Page 2 of 107 FCC Radio Test Report FCC ID: 2A9M7AP3220L This report concerns: Original Grant Project No. : 022022-5923 Equipment : Wireless LAN Access Point Brand Name : Test Model : AP3220L Series Model : N/A Applicant : MuXi Technology Co., Ltd. Address : Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., Nanjing, JiangSu,210012, China Manufacturer : MuXi Technology Co., Ltd. Address : Tecsun Technology Building, 6/F, No.21 , Huashen Avenue,Yuhuatai District,Nanjing., Nanjing, JiangSu,210012, China Factory : Joy Technology (ShenZhen) Corporation Address : HengKeng Ind., Shangpai,Shangwu,Aiqun Rd., Shiyan Town,Shenzhen 518108 China Date of Receipt : Aug. 24, 2022 Date of Test : Aug. 25, 2022 ~ Nov. 01, 2022 Issued Date : Nov. 15, 2022 Report Version : V1.0 Test Sample : Engineering Sample No.: 20220814019907 Standard(s) : FCC CFR Title 47, Part 15, Subpart C FCC KDB 558074 D01 15.247 Meas Guidance v05r02 FCC KDB 662911 D01 Multiple Transmitter Output v02r01 ANSI C63.10-2013 • The test result referred exclusively to the presented test model /sample. • Without written approval of TIRT Inc. the test report shall not reproduced except in full. Lab: Beijing TIRT Technology Service Co.,Ltd Shenzhen Add: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China TEL: +86-0755-27087573 Report No.: FCC022022-5923RF1 Page 3 of 107 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 12 2.3 PARAMETERS OF TEST SOFTWARE 13 2.4 DUTY CYCLE 14 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 16 2.6 SUPPORT UNITS 16 3 . AC POWER LINE CONDUCTED EMISSIONS 17 3.1 LIMIT 17 3.2 TEST PROCEDURE 17 3.3 DEVIATION FROM TEST STANDARD 17 3.4 TEST SETUP 18 3.5 EUT OPERATION CONDITIONS 18 3.6 TEST RESULTS 18 4 . RADIATED EMISSIONS 19 4.1 LIMIT 19 4.2 TEST PROCEDURE 20 4.3 DEVIATION FROM TEST STANDARD 21 4.4 TEST SETUP 21 4.5 EUT OPERATION CONDITIONS 22 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 22 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 22 4.8 TEST RESULTS - ABOVE 1000 MHZ 22 5 . BANDWIDTH 23 5.1 LIMIT 23 5.2 TEST PROCEDURE 23 5.3 DEVIATION FROM STANDARD 23 5.4 TEST SETUP 23 Report No.: FCC022022-5923RF1 Page 4 of 107 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 23 5.6 TEST RESULTS 23 6 . MAXIMUM OUTPUT POWER 24 6.1 LIMIT 24 6.2 TEST PROCEDURE 24 6.3 DEVIATION FROM STANDARD 24 6.4 TEST SETUP 24 6.5 EUT OPERATION CONDITIONS 24 6.6 TEST RESULTS 24 7 . CONDUCTED SPURIOUS EMISSIONS 25 7.1 LIMIT 25 7.2 TEST PROCEDURE 25 7.3 DEVIATION FROM STANDARD 25 7.4 TEST SETUP 25 7.5 EUT OPERATION CONDITIONS 25 7.6 TEST RESULTS 25 8 . POWER SPECTRAL DENSITY 26 8.1 LIMIT 26 8.2 TEST PROCEDURE 26 8.3 DEVIATION FROM STANDARD 26 8.4 TEST SETUP 26 8.5 EUT OPERATION CONDITIONS 26 8.6 TEST RESULTS 26 9 . MEASUREMENT INSTRUMENTS LIST 27 10 . EUT TEST PHOTO 28 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 30 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 33 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 34 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 37 APPENDIX E - BANDWIDTH 74 APPENDIX F - MAXIMUM OUTPUT POWER 81 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 88 Report No.: FCC022022-5923RF1 Page 5 of 107 Table of Contents Page APPENDIX H - POWER SPECTRAL DENSITY 101 Report No.: FCC022022-5923RF1 Page 6 of 107 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note FCC022022-5923RF1 V1.0 Original Report. Nov. 15, 2022 Valid Report No.: FCC022022-5923RF1 Page 7 of 107 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emissions APPENDIX G PASS ------ 15.247(e) Power Spectral Density APPENDIX H PASS ------ 15.203 Antenna Requirement ------ PASS Note(2) Note: (1) “N/A” denotes test is not applicable in this test report. (2) The device what use a permanently attached antenna were considered sufficient to comply with the provisions of 15.203. Report No.: FCC022022-5923RF1 Page 8 of 107 1.1 TEST FACILITY Company: Beijing TIRT Technology Service Co.,Ltd Shenzhen Address: 101, 3 # Factory Building, Gongjin Electronics Shatin Community, Kengzi Street, Pingshan District, Shenzhen, China CNAS Registration Number: CNAS L14158 A2LA Registration Number: 6049.01 FCC Accredited Lab. Designation Number: CN1309 FCC Test Firm Registration Number: 825524 Telephone: +86-0755-27087573 1.2 MEASUREMENT UNCERTAINTY ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)) The TIRT measurement uncertainty as below table: Uncertainty Parameter Uncertainty Occupied Channel Bandwidth ±142.12kHz RF power conducted ±0.74dB RF power radiated ±3.25dB Spurious emissions, conducted (9kHz～40GHz) ±1.78dB Spurious emissions, radiated (9kHz～30MHz) ±2.8dB Spurious emissions, radiated (30MHz～1GHz) ±4.6dB Spurious emissions, radiated (1GHz ~ 18GHz) ±4.9dB Spurious emissions, radiated (18GHz ~ 40GHz) ±5.54dB Conduction Emissions(150kHz~30MHz) ±3.1dB Humidity …

Text truncated - open the document above for the full version.

Report No.: FCC022022-5923RF1 Page 92 of 107 Test Mode TX G Mode_Ant. 2 Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 93 of 107 Test Mode TX N(HT20) Mode_Ant. 1 Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 94 of 107 Test Mode TX N(HT20) Mode_Ant. 2 Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 95 of 107 Test Mode TX N(HT40) Mode_Ant. 1 Bandedge-CH03 Bandedge-CH09 CH03 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH09 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 96 of 107 Test Mode TX N(HT40) Mode_Ant. 2 Bandedge-CH03 Bandedge-CH09 CH03 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH09 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 97 of 107 Test Mode TX AX(HE20) Mode_Ant. 1 Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 98 of 107 Test Mode TX AX(HE20) Mode_Ant. 2 Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 99 of 107 Test Mode TX AX(HE40) Mode_Ant. 1 Bandedge-CH03 Bandedge-CH09 CH03 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH09 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 100 of 107 Test Mode TX AX(HE40) Mode_Ant. 2 Bandedge-CH03 Bandedge-CH09 CH03 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH09 – 10th Harmonic of the fundamental frequency Report No.: FCC022022-5923RF1 Page 101 of 107 APPENDIX H - POWER SPECTRAL DENSITY Report No.: FCC022022-5923RF1 Page 102 of 107 Test Mode TX B Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 2.63 6.94 Complies 06 2437 2.96 6.94 Complies 11 2462 2.62 6.94 Complies CH01 CH06 CH11 Test Mode TX B Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 2.43 6.94 Complies 06 2437 1.12 6.94 Complies 11 2462 2.02 6.94 Complies CH01 CH06 CH11 Test Mode TX B Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 5.54 6.94 Complies 06 2437 5.15 6.94 Complies 11 2462 5.34 6.94 Complies Report No.: FCC022022-5923RF1 Page 103 of 107 Test Mode TX G Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -1.12 6.94 Complies 06 2437 -1.31 6.94 Complies 11 2462 -0.63 6.94 Complies CH01 CH06 CH11 Test Mode TX G Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -0.65 6.94 Complies 06 2437 -1.40 6.94 Complies 11 2462 -0.56 6.94 Complies CH01 CH06 CH11 Test Mode TX G Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 2.13 6.94 Complies 06 2437 1.66 6.94 Complies 11 2462 2.42 6.94 Complies Report No.: FCC022022-5923RF1 Page 104 of 107 Test Mode TX N(HT20) Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 1.89 6.94 Complies 06 2437 0.58 6.94 Complies 11 2462 1.49 6.94 Complies CH01 CH06 CH11 Test Mode TX N(HT20) Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 2.62 6.94 Complies 06 2437 1.20 6.94 Complies 11 2462 1.02 6.94 Complies CH01 CH06 CH11 Test Mode TX N(HT20) Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 5.28 6.94 Complies 06 2437 3.91 6.94 Complies 11 2462 4.27 6.94 Complies Report No.: FCC022022-5923RF1 Page 105 of 107 Test Mode TX N(HT40) Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -4.75 6.94 Complies 06 2437 -5.89 6.94 Complies 09 2452 -5.00 6.94 Complies CH03 CH06 CH09 Test Mode TX N(HT40) Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -4.56 6.94 Complies 06 2437 -6.17 6.94 Complies 09 2452 -5.91 6.94 Complies CH03 CH06 CH09 Test Mode TX N(HT40) Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -1.64 6.94 Complies 06 2437 -3.02 6.94 Complies 09 2452 -2.42 6.94 Complies Report No.: FCC022022-5923RF1 Page 106 of 107 Test Mode TX AX(HE20) Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 0.65 6.94 Complies 06 2437 -0.70 6.94 Complies 11 2462 -0.67 6.…

Text truncated - open the document above for the full version.
