2A9PA-PRO300-APAroma Diffuser

Accessories and spare parts NAME Aroma diffuser Adapter Cap Key Pneumatic fittings 1PC 1PC 1PC 2PC 1PC NAMEQUANTITYQUANTITY Manual Fragrance card Nozzle gasket Thank you Card 1PC 1PC 1PC 1PC After sales service support 1. Free Technical Solutions and Installation Process Guidance. 2. Free online FAQ consultation and scent-marketing suggestions. Warranty 1. The equipment has a 1-year warranty from its date of purchase (please keep your proof of purchase). 2. This warranty does not cover damage resulting from human error, faulty operation, unauthorized attempts to repair, or from any use not in accordance with the instruction manual. CUSTOMER SERVICE: E-mail: [email protected] Phone: +1 321 710-9232 WhatsApp: +1 407 312-3317 Owner’s Manual AromaPlan’s scent diffusers are powerful and easy to use. Our innovative technology converts the liquid perfume into dry vaporous microparticles, creating a practically invisible mist that drifts evenly throughout any space. When using scented candles, most of the scent is immediately around the candle. Our diffusers are different from candles in that the space is evenly scented, regardless of where you are. AromaPlan’s diffusers give you ultimate control. You can program its working period and intervals, as well as when it will automatically turn on and off to perfectly scent your environment according to your daily needs, without ever wasting your favorite fragrance. Features: • Easy floor or wall installation. • Space evenly scented. • No Residue. • Safe for Kids & Pets • Diffusion without heating or water. • Automatic scheduling on/off according to your daily needs. • Ultracold mist. • Microparticles permit immediate and even diffusion for lasting results. NO FLAME Covers up to 1.500 SQ FT No water is required with our scents. NO RESIDUE PET-FRIENDLY White Diffuser DAP-1001 & Black Diffuser DAP-1002 Avoid casualties and property loss, please always follow the instructions as below. (PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLING AND USING THE DIFFUSER. ) Cautions WARNING When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, property damage and injury to person, including the following: INSTALLING • Use appliance only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, property damage, or injury to person. • To avoid fire or shock hazards, plug the appliance directly into a safe electrical outlet. DO NOT plug in the cord with wet hands. • Keep the cord out of heavy traffic areas. • DO NOT operate any appliance with a damaged cord or plug, after the appliance malfunctions, or if it has been dropped or damaged in any manner. • DO NOT use the diffuser in a high temperature or wet environment. • DO NOT allow the mist outlets to face the wall directly. Install the diffuser in a ventilated and adequate space. • NEVER place the diffuser in an area where it is accessible to children. • DO NOT operate the diffuser without first turning off the unit. Failure to heed this warning may cause personal injury. NEVER tilt, move, or attempt to empty the unit while operating. • DO NOT block the air outlet while the unit is running. • Always place the diffuser on a firm, flat, level surface. NEVER place it on a rug or carpet, or on a finished floor that may be damaged by exposure to water or moisture. • DO NOT use inflammable, explosive, corrosive, and other hazardous solvents with the diffuser. DO NOT spill water or corrosive liquid on the diffuser surface. • Suggested average daily usage time should not exceed 14 hours. • Shut down the unit in an extreme weather environment. ATTENTION This diffuser should only be used with fragrance oil without adding water. For a better performance of the perfume in the environment, we recommend using AROMAPLAN’s scents only. Model: DAP 1001 (white) / DAP 1002 (black) Voltage: 12V Power: 7.5W Capacity: 10.14 fl oz / 300ml Weight: 0.9KG Coverage: up to 1500SF Size: (L) 6.7 in X (W) 3.17 in X (H) 8.11 in Specification 6.7 in 3.17 in 8.11 in Atomizer Nozzle Fragrance oil bottle ECO-FRIENDLY Register now your diffuser through the QRCODE to get a 1-year warranty. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLING AND USING THE DIFFUSER. Owner’s Manual WHITE DIFFUSER - DAP 1001 & BLACK DIFFUSER - DAP 1002 + APP FOR IOS AND ANDROID (VIA BLUETOOTH) POWERFUL, SAFE AND EASY TO USE ATTENTION! This diffuser is only configured through the app via Bluetooth. In case of doubt, contact our CUSTOMER SERVICE! TO START CONFIGURING THE DIFFUSER, DOWNLOAD THE APP VIA QRCODE 3. Bluetooth Go to Settings on your smartphone and make sure the Bluetooth in ON. Click [BLUETOOTH], the APP automatically searches for nearby diffusers, and click on the diffuser name to connect. The default password is: “1 2 3 4” 1. Install the APP Follow these steps to use your scent diffuser 4. The control interface is shown below: Through the app, control the diffuser’s functions ON and OFF, TIMES and DAYS. Follow the operation of your equipment through the animate countdown timer of working time. Below, we have the WORK time and the essence diffusion PAUSE time. 6. Reset your AromaPlan Diffuser to factory settings: 1 -Please make sure that your AromaPlan Diffuser is connected to power. 2 -On the left side of the diffuser, press and hold the button below the light until you hear 5 continuos BEEPS. Then release the button. 3 -Wait about a minute for the diffuser to fi nish restarting. 4 -When you hear a long BEEP, the diffuser will reset to its original factory settings. 5. Working Period Panel How to use the equipment Frequently asked questions 1 - How to clean the diffuser? Let the diffuser run for 10 minutes with liquid alcohol to clean the fi lter and diffuser nozzle at each fragrance change. 2- How long does the fragrance oil last before I need to refi ll the diffuser? On average, this diffuser consumes 1ml per hour. 3- How do I connect my diffuser to…

Text truncated - open the document above for the full version.

Sincerely, Name/Title： Heber attos/Manager Company: FULLYSENSE LLC Address: 5950 LAKEHURST DR, SUITE 235, ORLANDO, FLORIDA, USA, ZIP CODE 32819 Phone: (321) 710-9232 Fax: N/A E-Mail: [email protected]

FCC ID: 2A9PA-PRO300-AP External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A9PA-PRO300-AP Photo 4 Photo 5 Photo 6 FCC ID: 2A9PA-PRO300-AP Photo 7 Photo 8 Photo 9 FCC ID: 2A9PA-PRO300-AP Photo 10 Photo 11 Photo 12

Label and Location Size: L: 4.0cm*W: 3.0cm Label and Location Aroma Diffuser Model No.: Pro300-AP FCC ID : 2A9PA-PRO300-AP Caution : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2A9PA-PRO300-AP Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A9PA-PRO300-AP Photo 4 Photo 5 Photo 6 BT /2.4G WIFI (PCB)Antenna )Antenna FCC ID: 2A9PA-PRO300-AP Photo 7 Photo 8 Photo 9 FCC ID: 2A9PA-PRO300-AP Photo 10

RF Exposure evaluation FCC ID: 2A9PA-PRO300-AP Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information L4K1 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: BLE/2.4GWIFI / PCB antenna 1.94dBi for 2400-2500MHz; 5. Manufacturing Tolerance BLE GFSK(Peak) Channel Channel 00 Channel 19 Channel 39 Target (dBm) 1.0 1.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 WIFI(Peak) Frequency (MHz) 11b 2412 2437 2462 Target (dBm) 14.0 14.0 14.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11g 2412 2437 2462 Target (dBm) 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) 11n(HT20) 2412 2437 2462 Target (dBm) 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 0.0dBi, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BLE 2.0 1.5849 1.94 1.5631 0.0005 1.0000 2.4GWIFI 15.0 31.6228 1.94 1.5631 0.0098 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

1. Antenna Description: Antenna type PCB antenna Model Pro300-AP Frequency range 2400-2500MHz Manufacturer Shenzhen Crearoma Tech Ltd. ANT Peak Gain 1.94 dBi 2. Antenna Photo: 3. Test Equipment & Conditions Length :11.52mm Width:4.70mm 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz
