UserManual Doorbell Model：2301SF1T1R A.ImportantInstallationInstructions 1.Doorchimeisdesignedforindooruseonly. 2.Avoidmountingthepushbuttononmetalframes,andmakesurethemountingsurface issmooth. 3.Avoidmountingthechimeaboveheatsourcessuchasradiators,orinhumid circumstancessuchasakitchenorbathroom. 4.Pleasedonotopenandrepairthedevicewithoutprofessionalguideinordertoavoid anybreakdownofcomponents. 5.Pleasedonotexposeittothesunandrainforalongtimeandkeepitawayfrom metallicobjectwhendeviceisinuse. 6.Thetransmittingrangeofthedoorbelldependsoninstallationlocationandsignal attenuationofwallorfloor. 7.Ifnotusingthedoorbellforlongperiods,unplugthechimefromsocket. B.MountDoorChime Justplugthedoorchimeintostandardoutletinroom,thenitwillwork. C.MountPushButton 1.Useeitherscrewsordouble-sidedtapetomountpushbutton. 2.Tomountwithscrews,removebackofcasebypushingtabonbottomwithasmall screwdriver. 3.Usescrewstoattachbackofcasetodoorjamborwall,thenlockthefrontofpush buttononit. 4.Tomountwithdoublesidedtape,makesurethesurfaceofthedoorjamborwallis cleanandsmooth. D.FunctionKeyDescription 1.SETvolumelevel:Pressthevolumebuttontocontrolthevolumeofthemelody.There are4adjustablevolumelevels. 2.Changemelodies:Pressthemelodybuttontoselectthemelodyyoulike.Thereare50 differentmelodies. 3.Reset:PressandholdtheMelodybuttonfor3seconds,themelodywillberesettothe defaultone. E.WorkingModes 1.Thisdoorbellcomeswithamemoryfunctionincaseofunexpectedpowerdown. 2.Changeworkingmodesforthedoorbell: Pressthemodebuttontoselect ①LEDlightflashingonly ②Soundonly ③LEDlightflashingandsound F.Howtomatchmoredevices–CodeLearningFunction: Thisunitcomeswithacodelearningfunction,whichallowsyoutoexpandyourunitwith morepushbuttonordoorchimes. 1.Plugthechimeintothesocketandpoweron. 2.PresstheModebuttonfor3secondstoenterthecodelearningmode. 3.Pressthepushbutton,ifamelodyisheard,thencodelearningissuccessful.Ifnot, repeattheabovesteptolearnthecodeagain. FrequentlyAskedQuestion(FAQ) Problems 1.Chimedoesnotsound Checkwhethertheplugiswellinsertedintothesocket. Makesurethecodeofpushbuttonandchimematchproperly.Ifnot,pleasefollowthe codelearninginstructiontomatchthecode. 2.Chimedoesnotworkwheninstalled Donotmountthechimeorpushbuttononmetalortooclosetometalstuds.Thismay reducethetransmittingrange. Donotmountthechimetooclosetogroundlevelconcreteslabs.Thismayalsoreduce therange.Mountthechimeawayfromthefloor. Trydifferentlocationsforthechimeclosertothepushbutton.Alsotrytoorientthe chimeatadifferentangeltoincreasetherange. FCCStatement ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice, pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful interferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing measures: Reorientorrelocatethereceivingantenna. Increasetheseparationbetweentheequipmentandreceiver. Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris connected. Consultthedealeroranexperiencedradio/TVtechnicianforhelp. Caution:Anychangesormodificationstothisdevicenotexplicitlyapprovedbymanufacturercould voidyourauthoritytooperatethisequipment. Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany interferencereceived,includinginterferencethatmaycauseundesiredoperation. RFExposureInformation ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.Thedevicecanbeused inportableexposureconditionwithoutrestriction.
