2A9Q6-TBX2TBOX

FOREWORD ▐ Thank you very much for purchasing our product which will give you many years of reliable service. ▐ The introduction in this manual sets out the correct manner of operating, maintaining and checking the product to ensure long-term durability. ▐ Please ensure correct operation of the product as incorrect can cause substantial mechanical damage as well as cause accidents with the associated injuries. ▐ Please note that in some cases differences can exist between this manual and your tractor due to the manu- facture’s policy of constant product improvement. ▐ In the event that you encounter a problem not covered by this manual, please contact your nearest dealer who will assist you in resolving your problem. TABLE OF CONTENTS HOW TO IDENTIFY SPECIFIC MACHINE MODEL ............................ 1 MACHINE CLASSIFICATION TABLE ..................................................... 2 SIGN UP & LOGIN ........................... 4 THE APP INSTALLATION ..... 5 LAUNCH THE APP ............ 5 LOCATION PERMISSION ..... 6 SET LOCATION PERMISSION 6 SIGN UP......................... 7 LOGIN ........................... 9 REGISTER YOUR MACHINE . 9 SET PIN CODE ............... 10 LOGIN WITH PIN CODE .... 11 FIND ID ........................ 11 RESET PASSWORD ......... 11 HOME MENU ................................... 13 HOME SCREEN .............. 14 USE OTHER MACHINE ..... 15 NOTIFICATION ............... 15 NOTIFICATION (DETAIL) .... 16 PUSH MESSAGE SETTING . 17 MACHINE PHOTO ............ 17 STATUS OF CONNECTION . 17 REMOTE ENGINE START ... 18 REMOTE ENGINE STOP .... 18 MACHINE STATUS ........... 19 MACHINE STATUS (SETTING) .................................. 19 MACHINE STATUS (MORE) 20 FIND YOUR MACHINE ....... 20 STATUS OF MACHINE ................... 22 MACHINE STATUS ........... 23 BATTERY ...................... 23 FUEL LEVEL ................... 24 COOLANT TEMPERATURE . 24 PARKING BRAKE ............. 24 SHUTTLE DIRECTION ....... 25 PTO ............................. 25 AIR CLEANER ................. 25 TRANSMISSION OIL TEMP. 26 UREA LEVEL .................. 26 ENGINE HOURS .............. 26 MACHINE MANAGEMENT ......... 27 MANAGEMENT ............... 28 EMERGENCY NOTIFICATION .................................. 28 ERROR ......................... 29 CONSUMABLES .............. 29 REPLACEMENT HISTORY .. 30 WORK SHEET ................................... 31 WORK SHEET ................ 32 STATISTICAL CHART OF USAGE ......................... 33 STATISTICAL CHART OF USAGE (MONTHLY) ......... 34 MENU (MORE) ................................ 36 MENU (MORE) ............... 37 USER PROFILE ............... 37 DELETE ACCOUNT .......... 38 LOGIN SETTING .............. 39 NOTICE ........................ 39 NOTICE (DETAIL) ............ 40 IMPLEMENT SETTING ....... 40 GEOFENCE ................... 41 REGISTER GEOFENCE ..... 41 IDENTIFY GEOFENCE....... 42 EMERGENCY CONTACT .... 42 REGISTER EMERGENCY CONTACT ..................... 43 AUTOMATIC ENGINE OFF . 43 CUSTOMER SERVICE ....... 44 APPLICATION INFORMATION .................................. 44 LOGOUT ....................... 45 INDEX .................................................. 46 FCC INSTRUCTIONS ..................... 49 STATEMENTS .................................... 50 ▌1 HOW TO IDENTIFY SPECIFIC MACHINE MODEL Follow the below to identify your specific machine model name. Specific machine model name is carved on the product nameplate. 2▐ MACHINE CLASSIFICATION TABLE Status icons of machine or optional functions are available on specific machine models. See below to find machine category based on specific machine model name. CATEGORY MACHINE MODEL NAME TYPE A TS130CP6ANBV, T115 TYPE B TX76CQPANV TYPE C K110E TYPE D K120 ▌3 STATUS ICONS OF MACHINE (PAGE 23) BATTERY FUEL LV. COOLANT TEMP. PARKING BRAKE DIRECTION ALL ALL ALL ALL ALL PTO ENGINE HOURS AIR CLEANER TRANSMISSION OIL TEMP. UREA LV. ALL ALL A, B A, C, D A, C, D OPTIONAL FUNCTIONS FUNCTION MACHINE CATEGORY REF. PAGE REMOTE ENGINE START&STOP A, D 18 AUTOMATIC ENGINE OFF A, D 43 SIGN UP & LOGIN ▌SIGN UP & LOGIN ▌5 THE APP INSTALLATION Use the keyword of ‘mytym’ to search the app ‘MYTYM – SAM (Telematics)’ on Google Play or App Store. LAUNCH THE APP After installation, launch the app by tapping ‘MYTYM – SAM’ icon on the home screen or app drawer. SIGN UP & LOGIN▐ 6▐ LOCATION PERMISSION Allowance to access the de- vice’s location is required to use the application for various functions. ▶ While using the app Access to the device’s location is allowed while using the app. No need to allow again in next time use. ▶ Only this time Access to the device’s location is allowed only this time. A pop- up window appears again in next time use. ▶ Don’t allow Access to the device’s location is denied. The application will shut down immediately. SET LOCATION PERMISSION You can change the policy for allowance to access to the de- vice’s location by tapping the ‘setting’ ① icon. 1 ▌SIGN UP & LOGIN ▌7 Tap the ‘Permissions’ ① to change the policy of permission to access to device’s location. SIGN UP ‘Sign up’ ① is essential to use the application. Read and agree to the Terms and Conditions and others. Check the agreement boxes ①② ③ to proceed next step to cre- ate an account. 1 1 1 2 3 SIGN UP & LOGIN▐ 8▐ ▶ ID At least 5 characters with capi- tal, lower case or numbers only. ▶ Password At least 8 characters combined with capital, lower case and special letter. ⚠ A password must include three types of capital, lowercase, and special letters. ▶ Required field Name Fill it with an alphabet. Cellular Number Fill it in with your current cellular phone number. Address Fill it in with your resident ad- dress. ▶ Optional field E-mail Fill it in with current your E-mail address. ▌SIGN UP & LOGIN ▌9 LOGIN Log in using your ID and pass- word. ⚠ Use ‘Auto Login’ ① only on your cellular phone due to security issues. ⚠ When the “Registration of your machine is required” message is shown, contact your dealer to register your machine. REGISTER Y…

Text truncated - open the document above for the full version.

Je vous remercie beaucoup de faire partie de la famille TYM ▐ Ce manuel d'utilisation est destiné à décrire les méthodes de manipulation et les précautions pour votre sécurité et une utilisation correcte de la machine. ▐ Veuillez l'utiliser après l'avoir lu attentivement et le conserver à proximité de la machine en cas d'urgence. ▐ Si vous ne savez pas comment manipuler la machine, si vous ne l'utilisez pas correctement ou si vous la démontez, réparez ou modifiez, cela peut provoquer un accident ou un dysfonctionnement de la machine, veuillez donc en être conscient. ▐ Lors de la location ou du transfert de la machine, veuillez fournir ce manuel d'utilisation avec la machine. S'il est perdu ou endommagé, commandez-le rapidement auprès d'un centre de service ou d'un revendeur. ▐ Les spécifications de la machine et le contenu décrit dans ce manuel peuvent être partiellement modifiés en fonction des modifications de la conception de la machine, donc s'il y a des informations peu claires pour vous, contactez le centre de service ou le revendeur le plus proche. SOMMAIRE Identifier le modèle de la machine que vous possédez ...... 1 Véhicule (Classification de la machine) ............................................... 2 S’inscrire et se connecter ............. 4 Installation de l’application .. 5 Exécution de l’application ... 5 Autoriser la géolocalisation .. 6 Définir l'autorisation de géolocalisation ................. 6 S’inscrire ........................ 7 Se connecter ................... 9 Enregistrement de la machine ................................. 10 Enregistrement du mot de passe .......................... 10 Connexion simple ........... 11 Rechercher l’ID .............. 12 Réinitialiser le mot de passe ................................. 12 Menu d'accueil ................................ 14 Icônes du Menu d'accueil .. 15 Sélection du véhicule ........ 16 Alerte ........................... 16 Message d'alerte (en détail) .................................. 17 Message d'alerte (Paramètres de message d’alerte Push) . 18 Photo du véhicule ............ 18 État de la connexion de communication ............... 19 Démarrage à distance ON .. 19 Démarrage à distance OFF 20 État de mon véhicule ........ 20 État de mon véhicule (Paramètres) .................. 21 État de mon véhicule (Voir en détail) .......................... 21 Emplacement du véhicule et recherche de l'itinéraire ..... 22 États du véhicule ............................ 24 États du véhicule ............ 25 Batterie ........................ 25 Carburant ..................... 26 Température du liquide de refroidissement ............... 26 Frein de stationnement ..... 27 Sens de marche .............. 27 PTO ............................ 27 Filtre à air obstrué ........... 28 Température de l’huile de transmission .................. 28 AdBlue ......................... 28 Temps d’utilisation .......... 29 Menu de gestion ........................... 30 Gestion du véhicule ......... 31 Alerte d’urgence ............. 31 En panne ...................... 32 Gestion des consommables 33 Historique de remplacement des consommables .......... 33 Journal ................................................ 34 Journal de travail ............ 35 Voir les statistiques d’utilisation ................... 36 Statistiques mensuelles..... 38 Voir en détail ................................... 40 Icône Voir en détail .......... 41 Informations sur les adhérents .................................. 41 Suppression d’un compte .. 42 Paramètres de connexion .. 43 Annonce de notification .... 43 Annonce de notification (Voir en détail) ...................... 44 Paramètres de la machine de travail .......................... 44 Zone de sécurité ............. 45 Enregistrement de la zone de sécurité ........................ 45 Vérification de la zone de sécurité ........................ 46 Contact d'urgence .......... 46 Enregistrement du contact d'urgence ..................... 47 Temps de maintien en démarrage .................... 48 Service client ................. 48 Informations sur l'application ................................. 49 Se déconnecter .............. 49 Index et annexe .............................. 50 Déclarations ...................................... 53 ▌1 Identifier le modèle de la machine que vous possédez La méthode pour vérifier le nom de modèle exact du véhicule que vous pos- sédez est la suivante. Vous pouvez vérifier le nom du modèle sur la plaque signalétique du véhicule (En bas de carroserie). 2▐ Véhicule (Classification de la machine) Selon le véhicule, les éléments affichés ou les fonctions prises en charge peu- vent varier en fonction du modèle de votre véhicule, veuillez donc vérifier le modèle correspondant dans le tableau de classification ci-dessous. CATEGORY MACHINE MODEL TYPE A TS130CP6ANBV, T115 TYPE B TX76CQPANV TYPE C K110E TYPE D K120 ▌3 Éléments d'affichage de l'état du véhicule (page 25) Batterie Carburant Température du liquide de refroidissement Frein de stationnement Sens de marche En commun En commun En commun En commun En commun PTO Temps d’utilisation Filtre à air Température de l’huile de transmission AdBlue En commun En commun A, B A, C, D A, C, D Liste des véhicules équipés de caractéristiques individuelles Nom de la fonction Type de véhicule équipé Référence à la page Démarrage et arrêt à distance A, D 19 Arrêt automatique du moteur A, D 48 S’inscrire et se connecter ▌S’inscrire et se connecter ▌5 Installation de l’application Recherchez « MYTYM » dans Google Play Store ou App Store et installez l'application « MYTYM - SAM (Télématique) ». Exécution de l’application Une fois l'installation terminée, cliquez sur l'application « MYTYM - SAM » pour l'exécuter. S’inscrire et se connecter▐ 6▐ Autoriser la géolocalisation Si vous autorisez l'accès à la localisation de la machine, vous pouvez utiliser des services, tels que la localisation de la ma- chine en temps réel, les iti- néraires de déplacement et les itinéraires de trav…

Text truncated - open the document above for the full version.

TYMICT 222-12, Sangseo-ri, Useong-myeon, Gongju-si, Chungcheongnam-do, Republic of Korea February 28, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for 2A9Q6-TBX2 [TYMICT] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Chul-jin Jung TYMICT 222-12, Sangseo-ri, Useong-myeon, Gongju-si, Chungcheongnam-do, Republic of Korea February 28, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for 2A9Q6-TBX2 [TYMICT ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Chul-jin Jung

Attestation Statements March 7, 2023 T O: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for 2A9Q6-TBX2 TYMICT, the undersigned, hereby authorize TYM North America Inc to act as our designated U.S. agent for service of process, TYMICT accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. TYM North America Inc accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： TYMICT Contact Name: Chul-jin Jung Address: 222-12, Sangseo-ri, Useong-myon, Gongju-si, Chungcheongnam-do, Republic of Korea Telephone No: +82-41-851-7777 Email: [email protected] Signature [Chul-Jin Jung] U .S. Agent Information: Company Name: TYM North America Inc Address: 2100 Cedartown Hwy, Rome, GA 30161 FRN: 0033457193 Contact Name: JAEHYUN PARK Telephone No: +1(252) 293 1224 x225 Email: [email protected] Signature [JAEHYUN PARK]

TYMICT 222-12, Sangseo-ri, Useong-myeon, Gongju-si, Chungcheongnam-do, Republic of Korea Date: February 08, 2023 E urofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (TBOX/T BX2/2A9Q6-T BX2) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (below list) required to be submitted with this application be permanently withheld from public review. Permanent Confidential Request -. Schematics -. Block Diagram -. Operational Description -. Part list -. Tune up procedure SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. S incerely, C hul-jin Jung / Principal Research Engineer

TYMICT 222-12, Sangseo-ri, Useong-myeon, Gongju-si, Chungcheongnam-do, Republic of Korea Date: January 02, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (TBOX/TBX2/2A9Q6-TBX2) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (below list) required to be submitted with this application be short-term Confidentiality for a period of 180 days after grant is issued. Short-Term Confidential Request -. External Photos -. Internal Photos -. Test set-up photo -. User Manual SPECIFY REASON FOR REQUEST (i.e. These documents contain detailed system and equipment descriptions and related information about the product, which we considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, we feel that this information would be of benefit to our competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, C hul-jin Jung / Principal Research Engineer

TYMICT 222-12, Sangseo-ri, Useong-myeon, Gongju-si, Chungcheongnam-do, Republic of Korea Date: January 02, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern : We, the undersigned, hereby authorize Ms. Chloe Lee/Deputy General Manager of Eurofins KCTL Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, C hul-jin Jung / Principal Research Engineer

This document shall not be reproduced, except in full, without the written approval External photos of EUT This document shall not be reproduced, except in full, without the written approval This document shall not be reproduced, except in full, without the written approval This document shall not be reproduced, except in full, without the written approval

[Label information] [Top]

This document shall not be reproduced, except in full, without the written approval Internal photos of EUT This document shall not be reproduced, except in full, without the written approval LTE Diversity Antenna LTE Main Antenna

This test report shall not be reproduced, except in full, without the written approval * RF Exposure FCC ID: 2A9Q6-T101 1. Regulation Regulation This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC rules and Regulations. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310, is listed in Table 1-1. According to FCC §1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Table 1 – Limits for Maximum Permissible Exposure (MPE) Frequency Range (㎒) Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [㎽/㎠] Averaging Time [minute] (A) Limits for Occupational / Controlled Exposure 0.3 ~ 3.0 614 1.63 *100 6 3.0 ~ 30 1842/f 4.89/f *900/f 2 6 30 ~ 300 61.4 0.163 1.0 6 300 ~ 1 500 / / f/300 6 1 500 ~ 15 000 / / 5 6 (B) Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19/f *180/f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1 500 / / f/1 500 30 1 500 ~ 15 000 / / 1.0 30 f=frequency in ㎒, *= plane-wave equivalent power density Per the guidance of KDB 680106, the E-field and H-field limits shown in the table above are extended down to 100 ㎑ in Appendix C): 1) For test separation distances > 50 ㎜ and < 200 ㎜, the power threshold at the corresponding test separation distance at 100 ㎒ in step b) is multiplied by [1 + log(100/f(㎒))] 2) For test separation distances ≤ 50 ㎜, the power threshold determined by the equation in c) 1) for 50 ㎜ and 100 ㎒ is multiplied by ½ 3) SAR measurement procedures are not established below 100 ㎒. When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any SAR test results below 100 ㎒ to be acceptable. This test report shall not be reproduced, except in full, without the written approval 2. Result MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01  SPGRRPGS4 4 2  S = power density [㎽/㎠] P = Power input to antenna [㎽] G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna [㎝] RF Exposure Compliance Issue The information should be included in the user’s manual: This appliance and its antenna must not be co-located or operation is conjunction with any other antenna or transmitter. A minimum separation distance of 20 ㎝ must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. Note. 1. The power density P d (5th column) at a distance of 20 ㎝ calculated from the friis transmission Formula is far below the limit of 1 ㎽/㎠. 2. Unequal antenna gains, with equal transmit powers. For antenna gains given by G1, G2, ..., GN ㏈i (i) If transmit signals are correlated, then Directional gain = 10 log[(10G 1 /20 + 10G 2 /20 + ... + 10G N /20)2/NANT] ㏈ i [Note the “20”s in the denominator of each exponent and the square of the sum of terms; the object is to combine the signal levels coherently.] This test report shall not be reproduced, except in full, without the written approval Calculation Result of RF Exposure Band Max Tune-up Power [㏈m] Max Tune-up Power [㎽] Ant Gain [㏈i] Power density at 20 ㎝ [㎽/㎠] Limit [㎽/㎠] LTE 2 25.00 316.23 3.67 0.15 1.00 LTE 4 25.00 316.23 3.43 0.14 1.00 LTE 5 25.00 316.23 2.73 0.12 0.55 LTE 12 25.00 316.23 4.00 0.16 0.47 LTE 13 25.00 316.23 2.17 0.10 0.52 LTE 14 25.00 316.23 2.66 0.12 0.53 LTE 66 25.00 316.23 3.43 0.14 1.00 LTE 71 25.00 316.23 1.39 0.09 0.45
