2A9QB-KLYDE-1174Car Multimedia Player

SHENZHEN KLYDE ELECTRONICS CO., LTD.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Aug 04, 2024
Application Purpose: Original Equipment
Date of Application: Aug 04, 2024
Equipment Note: Car Multimedia Player
Frequency Range: 2402.00000000 - 2480.00000000
Company: SHENZHEN KLYDE ELECTRONICS CO., LTD.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

$BS.VMUJNFEJB1MBZFS User Manual Golf FDUW entertainment system This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: two conditions: (1) This device may not cause harmful interference. (2) this device must accept interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement: FCC Warning 1. Do not use this product while driving. WARNINGS 2. Do not install or use this product with wet hands. 3. Avoid installing this product in areas with high temperatures, humidity, or where flammable or explosive gases or liquids are present. view or compromises driving safety. 4. Do not install this product in a location that obstructs the driver's deployment area. 5. Do not install this product on the airbag cover or within the airbag’s temperatures for long periods. 7. Operate this product only at the specified voltage. 8. Use only original cables and accessories. 9. Do not use sharp objects like awls or scissors on this product or its 10. Do not disassemble, repair, or modify this product or its accessories. 6. Avoid leaving this product in a closed vehicle exposed to high accessories yourself. 11.Keep this product out of the reach of children under 16years old. CONTENTS MAIN MENU OPEARATION...................................................................................... BLUETOOTH OPERATION....................................................................................... SYSTEM SETTING.................................................................................................... CARPLAY CONNECTION......................................................................................... USB PLAYING OPERATION..................................................................................... 3 RADIO FUNCTION OPEARATION............................................................................ 2 WIRING DIAGRAM.................................................................................................... 9 INSTRUMENT PANEL.............................................................................................. 1 4 5 6 8 INSTRUMENT PANEL 1 1 READY Gear level : R N D Trouble light: When there is a fault, the corresponding fault icon is displayed. Power meter: Power value during operation. Car Icons: Click to access the media entertainment system. Voltage: Current operating voltage value. Battery capacity: Remaining battery capacity value. Total travelling time: unitH Single travelling timeunitH Single trip: unitKm Total distance travelled: unitKm RPM: Number of revolutions per minute. 1 2 3 4 5 6 7 8 9 10 11 12 13 Operating current: Current operating current value. Speedometer: Speed values during operation. 14 3 2 14 13 12 4 6 7 11 10 9 8 5 1 2 3 4 5 789 6 11 12131415 16 10 1. Power On/Off 2. 3. 4. 5. 6. 7. 8. Home page Return to the previous menu Volume increase Volume decrease Dates Time Status bar 9. 10. 11. 12. 13. 14. 15. 16. Music/Radio Carplay Phone Dashboard Menu Radio Bluetooth Setting MAIN MENU OPEARATION Tap the menu button in the home area to display more APP ICONS. Click the back button to return Click the car on the dashboard to enter the home page, enter different programs, click the instrument icon to enter the instrument interface. to the previous interface, as shown below: 2 3 RADIO FUNCTION OPERATION 1. Press to enter the Homepage Radio Interface Automatic Search RDS Function FM Status Backward Automatic search RDS EQ setting Forward 1. Click the RDS icon to enter the interface and turn on the rds switch. 2. Return to the screen and search for related channels to listen to. DX/ LOC switch AM Status 2. Click Radio to enter the radio interface Press and hold the [ ] key for more than 2 seconds, and the searched stations will be automatically saved in the number list on the right. 5DGLR 5DGLR 4 USB PLAYING OPERATION EQ setting Media list 1. Press to enter the Homepage. Music Playback Video Playback Picture browsing 2. Click Music to enter the music playback interface. 1. Press to enter the Homepage. 2. Click Video to enter the video playback interface. 3. Notice: for safety driving, don’t support play video. 1. Press to enter the Homepage. 2. Click Gallery to enter the picture browsing. Previous track Next track Repeat Playback/Random Playback Play / Pause Previous track Next track Play Pause 1 86% 86% 86% 5 CARPLAY CONNECTION Connect to iPhone Note: When Bluetooth is in use, the carplay link will be interrupted if it is accidentally disconnected. 1.…

Text truncated - open the document above for the full version.

Attestation Statements

---- SHENZHEN KL Y DE ELECTRONICS CO., LTD. Building C & D, Zunlong Science Park, X ieping Ro a d, Wulian Village, Longg 邸 gDist., Shenzhen City, Chin a -- --------------------------------------------------------叩--------------- ---------- -------------------------------------------------------- Date: 2024-07 -31 Federal Communi cation s Commission Autho rization and Evaluation Division 7 435 Oakland Mills Road Colum bia, MD 21046 USA FCC ID: 2A9QB-KLYDE-1174 Ap plicant FRN: 0033180803 SHENZHEN KL YOE ELECTRONICS CO., LTD. certifies that, as of 2024-07- 31, we have designated FCC US Agent, LLC to ace 忑 pt service of process on our behalf for FCC ID: 2A9QB-KLYDE-1174. SHENZHEN KL YOE ELECTRONICS CO., LTD., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanent ly termina ted all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equip ment, wh ichever is later. FCC US Agent, LLC, accepts as of the date of the 行 ling of this appli cation, the obligation of being the designated agent for the purpose of accepting service of pr:ocess on behalf of SHENZ HEN KLYDE ELECTRONICS CO., LTD. for FCC ID: 2A9 QB-KLYDE-1174. Designated Agent Information: Company Name: FCC US Agent, LLC U.S. Agent FRN: 0033402884 Address: 3722 Illin ois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: Support@FCCUSA gent.com Sincerely, Company: SHENZHEN KL YOE ELECTRONICS CO., LTD. Company Representative: Tina chen Signatur e: Designated Agent: FCC US Agent, LLC Designated Agent Representative: Tim Payne Signature:

Cover Letter(s)

SHENZHEN KLYDE ELECTRONICS CO., LTD. Building C & D, Zunlong Science Park, X ieping Road, Wulian Vill ag e, Longgang Dist., Shenzhen C i ty , China ----------------------- ---------------------------------- --------------------------------------------------------------------------------------------- Date: 2024 -07-31 FEDERAL COMMUNICATIONS COMMISSION AUTHO RIZATION AND EVALUATION DIVISION 7 435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application fo 「 FCC ID: 2A9QB-KLYDE-1174 Confidentiality Request To whom it may concern, Pursuant to the provisions of the Commi ssion's rules Title 47 Sections §0.457 and§0.45 9, we are requesting the Commi ssion to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. 因 Block Diagram 冈 Operational Desc ription 因S chematics 口 Parts List 口 Tune-Up Information 因 Security Information 口 Software Defined Radio (SOR) Information Th e above materials contain trade secrets and proprietary information not customa 「 ily 「 eleased to the public. The public disclosure of these materials may be harm ful to廿1e applicant and provide unjustified benefits to its compet itors. In additional to above mentioned documents, in orde 「 to comply with the marketing regula tions in Title 47 CFR §2.803 and the import ation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we 「 equest Short Term Confidentiality of the following attachme nt(s); 口 External Photos O Test Setup Photos 口 Internal Photos 口 User Manual 口 For 45 days, pursuant to Public Notice DA 04-170 5. or 口 For 180 days pursuant to KDB 726920 D01. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signatory ) [Tina chen, sales manager]

Cover Letter(s)

SHENZHEN KL YDE ELECTRONICS CO., LTD. Building C & D, Zunlong Science Park, X ieping Road, Wulian Vill C hin a ag e, L onggang Dist., Shenzhen City, ------------------------------------------------ ------------ - - -------- - - ------- -- - - -- -一-- - -- --- -- - -- - ----- -- - --- - -------------------------------- ----- Date: 2024-07-31 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7 435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application fa「FCC ID: 2A9QB-KLYDE-1174 POWER OF ATTORNEY To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf, to apply to the Fede r al Communica tio ns Commission on our e q uipment. Any and all acts ca 「 ried out by Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on ou 「 behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, SHENZHEN KL YOE ELEC TRONICS CO., LTD. are not subject to a denial of fede「al benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 2 1 USC853a, and no party to th e application is subject to a denial of federal benefits pursuant to that section. Sinc erely, Signato [Tina C1 n, sales manager]

External Photos

ReferenceNo.:WTH24X07156134W001/002/003/004Page2of12 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EXHIBIT2-EUTEXTERNALPHOTOGRAPHS EUTView1 EUTView2 ReferenceNo.:WTH24X07156134W001/002/003/004Page3of12 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EUTView3 EUTView4 ReferenceNo.:WTH24X07156134W001/002/003/004Page4of12 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EUTView5 EUTView6 ReferenceNo.:WTH24X07156134W001/002/003/004Page5of12 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cn EUTView7

ID Label/Location Info

Reference No.: WTH24X07156134W001/002/003/004 Page 1 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2A9QB-KLYDE-1174 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCCIDLabel Location

Internal Photos

Reference No.: WTH24X07156134W001/002/003/004 Page 6 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTH24X07156134W001/002/003/004 Page 7 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Solder Board-Component View 3 Reference No.: WTH24X07156134W001/002/003/004 Page 8 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 4 Solder Board-Component View 5

Internal Photos

Reference No.: WTH24X07156134W001/002/003/004 Page 9 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 6 Solder Board-Component View 7 Reference No.: WTH24X07156134W001/002/003/004 Page 10 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 8 Antenna View BT/WIFIAnt.

RF Exposure Info

1.RFExposureRequirements 1.1GeneralInformation ClientInformation Applicant:SHENZHENKLYDEELECTRONICSCO.,LTD. Addressofapplicant: BuildingC&D,ZunlongSciencePark,XiepingRoad,WulianVillage, LonggangDist.,ShenzhenCity,China Manufacturer:SHENZHENKLYDEELECTRONICSCO.,LTD. Addressofmanufacturer: BuildingC&D,ZunlongSciencePark,XiepingRoad,WulianVillage, LonggangDist.,ShenzhenCity,China GeneralDescriptionofEUT: ProductName:CarMultimediaPlayer TradeName:/ ModelNo.:KD-1174 AddingModel(s):/ RatedVoltage:DC12V BatteryCapacity:/ PowerAdapter:/ FCCID:2A9QB-KLYDE-1174 EquipmentType:Mobiledevice TechnicalCharacteristicsofEUT: Bluetooth(BLEmode) BluetoothVersion:V4.2(BLEmode) FrequencyRange:2402-2480MHz RFOutputPower:4.47dBm(Conducted) DataRate:1Mbps Modulation:GFSK QuantityofChannels:40 ChannelSeparation:2MHz TypeofAntenna:IntegralAntenna AntennaGain:0.44dBi Bluetooth(BR/EDRmode) BluetoothVersion:V4.2(BR/EDRmode) FrequencyRange:2402-2480MHz RFOutputPower:4.95dBm(Conducted) DataRate:1Mbps,2Mbps,3Mbps Modulation:GFSK,π/4DQPSK,8DPSK QuantityofChannels:79 ChannelSeparation:1MHz TypeofAntenna:IntegralAntenna AntennaGain:0.44dBi Wi-Fi(2.4GHz) SupportStandards:802.11b,802.11g,802.11n FrequencyRange: 2412-2462MHzfor802.11b/g/n(HT20) 2422-2452MHzfor802.11n(HT40) RFOutputPower:16.20dBm(Conducted) TypeofModulation:CCK,OFDM,QPSK,BPSK,16QAM,64QAM QuantityofChannels:11for802.11b/g/n(HT20);7for802.11n(HT40) ChannelSeparation:5MHz TypeofAntenna:IntegralAntenna AntennaGain:0.44dBi Wi-Fi(5GHz) SupportStandards:802.11a,802.11n(HT20),802.11n-HT40,802.11ac-VHT80 FrequencyRange:5745-5825MHz Max.RFOutputPower:12.44dBm(Conducted) TypeofModulation:QPSK,16QAM,64QAM TypeofAntenna:IntegralAntenna AntennaGain:2.35dBi 1.2RFExposureExemption Accordingto§1.1307(b)(3)andKDB447498D04InterimGeneralRFExposureGuidancev01,system operatingundertheprovisionsofthissectionshallbeoperatinginamannerthatthepublicisnotexposedto radiofrequencyenergylevelinexcesslimitformaximumpermissibleexposure. OptionA:FCCRulePart1.1307(b)(3)(i)(A):Theavailablemaximumtime-averagedpowerisnomorethan 1mW,regardlessofseparationdistance. OptionB:FCCRulePart1.1307(b)(3)(i)(B):Theavailablemaximumtime-averagedpoweroreffective radiatedpower(ERP),whicheverisgreater,islessthanorequaltothethresholdP th (mW)describedinthe followingformula.P th isgivenby: OptionC:FCCRulePart1.1307(b)(3)(i)(C):Theminimumseparationdistance(Rinmeters)fromthebodyof anearbypersonforthefrequency(finMHz)atwhichthesourceoperates,theERP(watts)isnomorethanthe calculatedvalueprescribedforthatfrequency.Rmustbeatleastλ/2π,whereλisthefree-spaceoperating wavelengthinmeters. SingleRFSourcesSubjecttoRoutineEnvironmentalEvaluation RFSourcefrequency(MHz)ThresholdERP(watts) 0.3-1.341,920R 2 1.34-303,450R 2 /f 2 30-3003.83R 2 300-1,5000.0128R 2 f 1,500-100,00019.2R 2 ForMultipleRFsources:FCCRulePart1.1307(b)(3)(ii): (A)Theavailablemaximumtime-averagedpowerofeachsourceisnomorethan1mWandthereisa separationdistanceoftwocentimetersbetweenanyportionofaradiatingstructureoperatingandthe nearestportionofanyotherradiatingstructureinthesamedevice,exceptifthesumofmultiplesourcesis lessthan1mWduringthetime-averagingperiod,inwhichcasetheymaybetreatedasasinglesource (separationisnotrequired). (B)InthecaseoffixedRFsourcesoperatinginthesametime-averagingperiod,orofmultiplemobileor portableRFsourceswithinadeviceoperatinginthesametimeaveragingperiod,ifthesumofthe fractionalcontributionstotheapplicablethresholdsislessthanorequalto1asindicatedinthefollowing equation. 1.3CalculatedResult Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-AveragedPower ERP (MHz)(dBm)(dBi)(%)(dBm)(dBm) Bluetooth24024.950.44100 5.003.29 Wi-Fi(2.4GHz)241216.200.44100 17.0015.29 Wi-Fi(5GHz)574512.442.3510013.0013.20 Frequency Option Min.DistanceMax.PowerExposureLimit Ratio Result (MHz)(cm)(dBm)(mW)(mW)Pass/Fail 2402C20.003.292.13768.000.01Pass 2412C20.0015.2933.81768.000.04Pass 5745C20.0013.2020.89768.000.03Pass Note:1.Time-AveragedPower=OutputPower*DutyCycle;ERP=Time-AveragedPower+Antenna gain-2.15dB 2.OptionA,BandCrefersasclause1.2. 3.ForoptionB,Max(time-averagedpower,effectiveradiatedpower(ERP))convertstoMax.Power.For optionC,ERPconvertstoMax.Power; 4.ForoptionB,P th (mW)convertstoExposureLimit(mW);ForoptionC,ERP(W)convertstoExposure Limit(mW). 5.Ratio=Tune-UpERP(mW)/ExposureLimit(mW) ModeforSimultaneousMulti-bandTransmission: RadioAccess Technology Ratio1Ratio2 Simultaneous Ratio Limit Result Pass/Fail ------------ Note:BTandWi-Fican’ttransmitatthesametime. Result:Pass

Test Report

WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 1 of 62 TESTREPORT ReferenceNo.......................:WTH24X07156134W003 FCCID....................................: 2A9QB-KLYDE-1174 Applicant...............................:SHENZHENKLYDEELECTRONICSCO.,LTD. Address.................................: BuildingC&D,ZunlongSciencePark,XiepingRoad,WulianVillage, LonggangDist.,ShenzhenCity,China Manufacturer........................:ThesameasApplicant Address.................................:ThesameasApplicant ProductName......................:CarMultimediaPlayer ModelNo... ............................: KD-1174 Standards..............................:FCCPart15.247 DateofReceiptsample.....:2024-07-03 DateofTest ...........................: 2024-07-03to2024-07-22 DateofIssue........................:2024-07-30 TestReportFormNo. ......... : WTX_Part15_247W TestResult ............................: Pass Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbe reproduced,exceptinfull,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithout specificstampoftestinstituteandthesignaturesofapprover. PreparedBy: WaltekTestingGroup(Shenzhen)Co.,Ltd. Address:1/F.,Room101,Building1,HongweiIndustrialPark,Liuxian2ndRoad, Block70Bao'anDistrict,Shenzhen,Guangdong,China Tel.:+86-755-33663308Fax.:+86-755-33663309Email:[email protected] Testedby:Approvedby: DashanChenJasonSu ReferenceNo.:WTH24X07156134W003 WaltekTestingGroup(Shenzhen)Co.,Ltd. Http://www.waltek.com.cnPage 2 of 62 TABLEOFCONTENTS 1.GENERALINFORMATION.....................................................................................................................................5 1.1PRODUCTDESCRIPTIONFOREQUIPMENTUNDERTEST(EUT)........................................................................5 1.2TESTSTANDARDS.................................................................................................................................................6 1.3TESTMETHODOLOGY...........................................................................................................................................6 1.4TESTFACILITY.......................................................................................................................................................6 1.5EUTSETUPANDTESTMODE..............................................................................................................................7 1.6MEASUREMENTUNCERTAINTY.............................................................................................................................9 1.7TESTEQUIPMENTLISTANDDETAILS................................................................................................................10 2.SUMMARYOFTESTRESULTS.........................................................................................................................13 3.ANTENNAREQUIREMENT.................................................................................................................................14 3.1STANDARDAPPLICABLE......................................................................................................................................14 3.2EVALUATIONINFORMATION................................................................................................................................14 4.FREQUENCYHOPPINGSYSTEMREQUIREMENTS....................................................................................15 4.1STANDARDAPPLICABLE......................................................................................................................................15 4.2FREQUENCYHOPPINGSYSTEM.........................................................................................................................15 4.3EUTPSEUDORANDOMFREQUENCYHOPPINGSEQUENCE..............................................................................16 5.QUANTITYOFHOPPINGCHANNELSANDCHANNELSEPARATION....................................................17 5.1STANDARDAPPLICABLE......................................................................................................................................17 5.2TESTSETUPBLOCKDIAGRAM...........................................................................................................................17 5.3TESTPROCEDURE..............................................................................................................................................17 5.4SUMMARYOFTESTRESULTS/PLOTS................................................................................................................18 6.DWELLTIMEOFHOPPINGCHANNEL............................................................................................................19 6.1STANDARDAPPLICABLE......................................................................................................................................19 6.2TESTSETUPBLOCKDIAGRAM...........................................................................................................................19 6.3TESTPROCEDURE..............................................................................................................................................19 6.4SUMMARYOFTESTRESULTS/PLOTS................................................................................................................20 7.20DBBANDWIDTH................................................................................................................................................21 7.1STANDARDAPPLICABLE......................................................................................................................................21 7.2TESTSETUPBLOCKDIAGRAM...........................................................................................................................21 7.3TESTPROCEDURE....................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

TOXU TECHNOLOGY CO., LTD. UNLESS OTHER SPECIFIED TOLERANCES ON： TOXU TECHNOLOGY CO., LTD. X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF TOXU TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： LI CHECKED BY: YS DESIGNED BY: De wen APPROVED BY: YS TITLE：KC.WA.00054 Antenna Specification SPEC REV. P0 PAGE 1 OF 7 KC.WA.00054 Antenna Specification 1. Application: This application shall apply for antenna unit which shall be used such as automotive, conventional communications, smart home, etc.. 2.Electrical Specification: Those specifications were specially defined for customer’s model, and all characteristics were measured under the model’s handset testing jig . 2-1. Frequency Band: Frequency Band MHz BT /WiFi 2400-2500/5150-5850MHz 2-2. Impedance 50 ohm nominal 2-3. VSWR 2-3-1.Measurement frequency points and VSWR value Frequency Band(MHz) 2400 2500 5150 5850 Typical Value:（VSWR） 2.4 2.8 3.9 2.2 TOXU TECHNOLOGY CO., LTD. UNLESS OTHER SPECIFIED TOLERANCES ON： TOXU TECHNOLOGY CO., LTD. X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF TOXU TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： LI CHECKED BY: YS DESIGNED BY: De wen APPROVED BY: YS TITLE：KC.WA.00054 Antenna Specification SPEC REV. P0 PAGE 2 OF 7 2-3-4 Measuring Method 1. A 50Ωcoaxial cable is connected to the antenna. Then this cable is connected to a network analyzer to measure the VSWR. 2. Keeping this jig away from metal at least 20 cm 2-3-5 Picture TOXU TECHNOLOGY CO., LTD. UNLESS OTHER SPECIFIED TOLERANCES ON： TOXU TECHNOLOGY CO., LTD. X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF TOXU TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： LI CHECKED BY: YS DESIGNED BY: De wen APPROVED BY: YS TITLE：KC.WA.00054 Antenna Specification SPEC REV. P0 PAGE 3 OF 7 2-4. Efficiency and Gain 4-5.1 Measure method 1. Using a low loss coaxial cable to link a standard handset jig 2. Fixed this handset jig on chamber’s rotator plane 3. Linking jig into network analyzer port and using a probing horn antenna to collect data. 4. Using another standard gain horn antenna to calibrated those data 4-5.2 Chamber definition 1. An anechoic chamber (7mx4mx3m) which satisfied far-field condition was applied to avoid multi-path effect 2. The quite room region is 40cmx40cmx40cm at the center of rotator 3. The distance between DUT and standard antenna is 4.38 m 4. Probing antenna (9120D horn antenna) and standard gain horn antenna (BBHA9120 LPF 700MHz ~6GHz) 4.38 m Rotatory controller Vector Network Aanlyzer Port 2Port 1 DUT Far-Field Chamber Std. Ant. TOXU TECHNOLOGY CO., LTD. UNLESS OTHER SPECIFIED TOLERANCES ON： TOXU TECHNOLOGY CO., LTD. X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF TOXU TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： LI CHECKED BY: YS DESIGNED BY: De wen APPROVED BY: YS TITLE：KC.WA.00054 Antenna Specification SPEC REV. P0 PAGE 4 OF 7 2-4-1 Efficiency and Gain and 3D Date Frequency/Mhz MaxGain/dBi Efficiency / % 2400 0.26 34.12 2405 0.44 37.07 2410 0.09 34.59 2415 0.06 35.73 2420 0.03 37.33 2425 -0.31 36.73 2430 -0.47 37.5 2435 -0.41 38.73 2440 -0.38 38.73 2445 -0.75 35.48 2450 -0.45 37.84 2455 -0.31 39.26 2460 -0.4 39.08 2465 -0.16 42.85 2470 -0.24 40.83 2475 -0.42 40.36 2480 -0.27 41.5 2485 -0.59 38.11 2490 -0.32 40.74 2495 -0.23 41.5 2500 -0.5 39.08 TOXU TECHNOLOGY CO., LTD. UNLESS OTHER SPECIFIED TOLERANCES ON： TOXU TECHNOLOGY CO., LTD. X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF TOXU TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： LI CHECKED BY: YS DESIGNED BY: De wen APPROVED BY: YS TITLE：KC.WA.00054 Antenna Specification SPE…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Tina chen(sales manager)

[email protected]86-13480183821Fax: 0755-84854790

Test Firm

Waltek Testing Group (Shenzhen) Co., Ltd.Jandy So

[email protected]86 755 33663308Fax: 86-755-33663309

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	3.10 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed and operated so as to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures, or as evaluated in this filing. End-users must be informed of operating requirements for satisfying RF exposure compliance.
