2A9QY-W1000SWireless Video Transmission System

WirelessVideoTransmissionSystem UserManual 1 ThankyouforpurchasingFEELWORLDwirelessvideotransmission system.Pleasereadthismanualcarefullybeforeusingtheproduct,wish youahappyexperience! Caution Donotexposethisdevicetoextremehot,cold,dustyorhumid environments. Donotscratchthedevicewithsharpobjects. Donotdropthisdevicefromhighplace,asthismaycausehardware damage. Thisdeviceisdesignedfornon-waterproofing.Pleasedonotallowany liquidtopenetrateintothedevice. Donotattemptdismantle,openorrepairthisdevicebynon-technical person,asthismaycausepermanentdamagetothedevice. Features DualHDMI&SDI(optional)signalinterfaces Transmissionrangeupto1000ft,withultra-lowlatency0.08S Upto1080P60Hz Withtype-CtoEthernetadapteraccessory,achievelivestreaming Thetransmittercanbeswitchedasareceiveratwill. Wirelessfull-duplextalkback,real-timeintercombetweenthedirector andthephotographer. OneTXtomultipleRX SupportAPPmonitoringforAndroid/IOSsystem. 2 InstallationInstruction----------------------------------------------3 PortInstruction-------------------------------------------------------4 UIInstruction----------------------------------------------------------6 StreamingInstruction-----------------------------------------------11 APPOperationInstruction-----------------------------------------12 Parameter--------------------------------------------------------------15 FrequencyChart------------------------------------------------------16 3 4 Transmitter ①:AntennaPorts⑧:DOWNbutton ②:PowerOFF/ON⑨:HDMISignalOutput ③:Type-CPowerInput/Upgrade⑩:HDMISignalInput ④:DCPowerIN⑪:SDISignalInput（optional） ⑤:OLEDScreen⑫:3.5mmEarphonePort ⑥:UPbutton⑬:1/4ScrewHole ⑦:OKbutton 5 Receiver ①:AntennaPorts⑧:DOWNbutton ②:PowerOFF/ON⑨:HDMISignalOutput1 ③:Type-CPowerInput/Upgrade⑩:HDMISignalOutput2 ④:DCPowerIN⑪:SDISignalOutput(optional) ⑤:OLEDScreen⑫:3.5mmEarphonePort ⑥:UPbutton⑬:1/4ScrewHole ⑦:OK/MENUbutton 6 1.Startup Thestartupscreenisasabove.Whenthedeviceruns,themainmenu willdisplay. 2.MainMenu Mainmenuincludingchannel,devicetype(TX/RX),linkstatus,signal strength,videoformat,intercommode,batterylevel,temperature,fan status,etc.information. 1)Channelswitch:press“△”or“▽”tochangechannels.Press“□”to confirmthechannel. 2)Longpress“△”onthetransmitter,thescreenwilldisplaydevicename andpassword.Longpress“△”onthereceiver,thescreenwillalsodisplay devicenameandpasswordifitisconnectedtotransmitter. 3.SecondaryMenu Longpress“ □ ”for2secondstoenterintothesecondarymenu. Longpress“□”for2secondsagaintobacktothesecondarymenu. Press“△”or“▽”toswitchtheoptionsinsecondarymenuand press“ □ ”toconfirmselection. 7 Device(transmitteronly):devicetype SwitchTX(transmitter)andRX(receiver)manually. Source(transmitterwithSDIportonly):signalsource SwitchthesignalsourcebetweenHDMIandSDIontransmitter.SDIinput isselectedbydefaultifbothHDMIandSDIsourcesareconnected. FANstatus Turnonoroffthefanmanually 8 Intercom SwitchbetweenFullDuplex,TDmode(TDspeak,Cameramanlisten), OFF(turnoffintercom) WPS:pairing Topairtransmitterandreceiver.OneTransmitterallowstopair4receiver maximum.TurningonWPSbothfortransmitterandreceiveratthesame time,thenturnoffthereceivewhichfinishedpairing.Usingthesame pairingmethodtoaddnextonereceiver.Last,turningonallofthe paireddevices. Priority Choosehighimagequalitypriororlowlatencyprior. 9 WIFI_SSDI Showingdevicenameandpassword Version Showingthedevice’sversionnumber Web 10 Telephone Language IP:IPaddress(onlythereceiverhasthismenu) 11 Afterthereceiverlinkstotransmitterandreceivesthevideo,plugtheType-Cto Ethernet adaptertoreceiver’sType-Cport.TheType-CtoEthernetadapterwillflashredlight. StaticIPsetting 1.Thereceiver’sdefaultmodeisstaticIP.Itcanbeselectedinthesecondarymenu IP->staticIP 2.Asthepictureshownabove,connecttheType-CtoEthernetadapterwith computerviaLANcable. 3.Thereceiver’sstaticIPaddressis192.168.11.111.Itcanbefoundonthereceiver’s secondarymenu.ThecomputeralsohastobesettostaticIP.Setthecomputer’s staticIPtobe192.168.11.xxx,xxxcanbereplacedbyanynumberbetween2and 254notinclude111.Afterthesettingscompleted,runCMD->ping192.168.11.111 oncomputertocheckifitworks. 4.UsetheURLrtsp://192.168.11.111:554/test.264onupstreamingsoftwaresuchas VLCorOBS. RouteIPsetting 1.Enterintothesecondarymenuonthereceiver’sIP.ThenselectrouteIP 2.Connectamonitortothereceiver.Thenconnectthereceivertotherouterviathe Type-CtoEthernetadapter.Ifthebluelightflashesontheadapter,itindicatesthat theconnectionisgood.ThemonitorwillshowtheIPaddress. 3.Connectthecomputertotherouter.Pushstreamingwiththeurl:rtsp://IPaddress shownonthemonitor/test.264 12 1.APPDownload iOSAPPDownload iOSusersearch“feelworld”toget (APPname:MMonitor) AndroidAPPDownload(APPname:FeelworldWireless) Search“feelworldwireless”onGooglePlay toget ScantheQRcodetodownload 2.Connectsmartdevicestotransmitter Afterthetransmitterispoweredon,gotoSetting-Wireless&networks onsmartphone/tablet,selectthetransmitter’snameandinputthe passwordtoconnectthedevices.Pleasefindthetransmitter’snameand initialpasswordasbelow.ThengotoAPPhomepageandclick“Video” tomonitor. 13 (Note:Noneedtoinputpasswordagainifitwassavedonsmart phone/tablet) Devicename:FEELWORLD _5G_XXXXX Password:12345678 3.APPOperation(e.g.AndroidSystem) a.Click“Video”onhomepageto enterintomonitoringmode. b.Click“∨”atthebottomofscreen.ItwillshowSAVEIMAGE,RECORD (onlyavailableforAndroidatpresent),MATERIAL,CONFIGURATION. 14 Longpressthescreentoshowuptheprofessionalmonitoringmenu. Monochrome,FalseColor,CenterMarkerareavailableatpresent,more featuresaredeveloping. c.Click“Material”tochecktheimagesandvideossavedon smartphone/tablet. d.Click“Configuration”toaccessconfigurationscreen. e.Click英文版/ChineseVersionatthebottomofhomepagetochange language. 15 TransmitterReceiver ScreenOLEDOLED Interface 1 * SDI input(optional) 1 * HDMIinput,1* HDMIoutput 2 *Antennaport（RP-SMAMale） DC powerinput, 3.5mmheadphone jack , Type-C 2* HDMIoutput 1* SDI output(optional) 2 *Antennaport（RP-SMAMale） DC powerinput, 3.5mmheadphone jack , Type-C PowerSupply Way /VoltageRange F970battery, Type-C:5V/1.5A DC ada…

Text truncated - open the document above for the full version.

Page1of1 Declarationonmodeldifference We,ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD, theundersignedherebyconfirmthatthesemodelsareidentical,andallmodels havethesameRFmoduleandAntenna,exceptforthemodelnameis differentandtheappearancecolorisdifferent,themaintestmodelisW1000S. ProductnameWirelessVideoTransmissionSystem ModelNo. W1000S,W1000H,W1000SP,W1000HP,W1500,W2000,FT6P,FR6P, FRT6P,FRT6U TradenameN/A FCCID2A9QY-W1000S Confirmedby: Client’ssignature: Client’sname/title:YanjunZhuang/SalesManager Date:2022-12-16

C5266091_X24_Ed.1 1/1 ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD “AttestationStatements” TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 TheCommissionadoptedrulesthatprohibitequipmentauthorizationfor“covered” telecommunicationsequipmentandvideosurveillanceequipmentproducedbyentitiesidentified ontheCommission’sCoveredList 1 ,whichisperiodicallyupdated.SeetheCoveredListformore details.ThisAttestationStatementistoconfirmthatwefollowtheSection2.911(d)(5)(i)-(ii) Applicant Companyname:ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD Granteecode:2A9QY FCCID:2A9QY-W1000S ContactName:YanjunZhuang Address:3#B503GREENLAKEPLAZA,No.1HUBINROAD,LONGWENDISTRICT,ZHANGZHOU, FUJIAN,China TelephoneNo:+86-596-2182566 FaxNo:+86-596-2182566 Email:[email protected] i.[ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD](“the applicant”)certifiesthattheequipmentforwhichauthorizationissoughtis not“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules.Theapplicant mustsignthiscertification. ii.[ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD](“the applicant”)certifiesthat,asofthedateofthefilingoftheapplication,the applicant[isnot]identifiedontheCoveredListasanentityproducing “covered”equipment.Theapplicantmustsignthiscertification. Date:2023/02/08 Applicant’sName:YanjunZhuang Title:SalesManager Signature 1 TheCommission’sCoveredListispublishedbythePublicSafetyandHomelandSecurityBureauandpostedonthe Commission’swebsite.ThisCoveredList,whichisperiodicallyupdated,identifiesparticularequipment,producedby particularentities,thatconstitutes“covered”equipment.https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 LetterofAuthorization ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD Company:ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD Address:3#B503GREENLAKEPLAZA,No.1HUBINROAD,LONGWEN DISTRICT,ZHANGZHOU,FUJIAN ProductName:WirelessVideoTransmissionSystem ModelNumber: W1000S,W1000H,W1000SP,W1000HP,W1500,W2000,FT6P,FR6P, FRT6P,FRT6U FCCIdentifier:2A9QY-W1000S WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:YanjunZhuangDate:2022-12-16 Title:SalesManager Signatureofapplicant:

C5266091_X10_Ed.2 1/1 ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-12-16 Subject: Request for Confidentiality FCC ID: 2A9QY-W1000S To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☒ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☒ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name: Yanjun Zhuang Title:Sales Manager

C5266091_X13_ Ed.1 ZHANGZHOULAISHIKEELECTRONICTECHNOLOGYCO.,LTD FCCSoftwareConfigurationControlDeclaration Date:2022-12-16 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Attn:OETDept. Product/ModelNumber:WirelessVideoTransmissionSystem/ W1000S,W1000H,W1000SP,W1000HP,W1500,W2000,FT6P,FR6P, FRT6P,FRT6U RegardingFCCCountryCodeSelectionguidelinesidentifiedinKDB594280. “Allapplicationsforequipmentauthorizationfortransmittersthatcanhave radioparameters,orothertechnicalparameters,reportedtotheCommission setbysoftwaremusthaveanattestationindicatingthatnothirdpartywillhave software,orconfigurationcontrol,toprogramthedeviceoutofcomplianceof thetechnicalrulesunderwhichithasbeencertified.” Wedeclarethatnothirdpartywillhavesoftware,orconfigurationcontrol,to programthedeviceoutofcomplianceofthetechnicalrulesunderwhichithas beencertified. Signatureofapplicant: Name:YanjunZhuang Title:SalesManager 1/1

ANT 1 ANT 2

Page 1 of 61 Report No.: LCSA121222024E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT For ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD Wireless Video Transmission System Test Model:W1000S Additional Model No.: Please Refer to Page 6 Prepared for : ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD Address : 3#B503 GREEN LAKE PLAZA , No.1 HUBIN ROAD, LONGWEN DISTRICT, ZHANGZHOU, FUJIAN Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (86)755-82591330 Fax : (86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : December 13, 2022 Number of tested samples Sample number : : 2 A121222024-1, A121222024-2 Serial number : Prototype Date of Test : December 13, 2022~December 23, 2022 Date of Report : December 27, 2022 Page 2 of 61 Report No.: LCSA121222024E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT Report Reference No. ............... : LCSA121222024E Date Of Issue .............................. : December 27, 2022 Testing Laboratory Name ........ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ....................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ....... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ...................... : ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD Address ....................................... : 3#B503 GREEN LAKE PLAZA , No.1 HUBIN ROAD, LONGWEN DISTRICT, ZHANGZHOU, FUJIAN Test Specification: Standard ...................................... : IEEE Std C95.1, 2019/IEEE Std 1528™-2013/FCC Part 2.1093 Test Report Form No. ................. : LCSEMC-1.0 TRF Originator ........................... : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ................................. : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes noresponsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. .............. : Wireless Video Transmission System Trade Mark ................................. : / Test Model .................................. : W1000S Operation Frequency .................. : WLAN5.2G, WLAN5.8G Ratings ........................................ : Adapter: Model: FJ-SW1261201000DN Input: 100-240V~50/60Hz 0.4A Output:DC12.0V,1.0A 12.0W Result ........................................ : Positive Compiled by: Supervised by: Approved by: Jay Zhan / File administrators Cary Luo / Technique principal Gavin Liang / Manager Page 3 of 61 Report No.: LCSA121222024E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA121222024E December 27, 2022 Date of issue Type / Model......................... : W1000S EUT....................................... : Wireless Video Transmission System Applicant.............................. : ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD Address.................................. : 3#B503 GREEN LAKE PLAZA , No.1 HUBIN ROAD, LONGWEN DISTRICT, ZHANGZHOU, FUJIAN Telephone.............................. : / Fax......................................... : / Manufacturer....................... : ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD Address.................................. : 3#B503 GREEN LAKE PLAZA , No.1 HUBIN ROAD, LONGWEN DISTRICT, ZHANGZHOU, FUJIAN Telephone.............................. : / Fax......................................... : / Factory.................................. : / Address.................................. : / Telephone.............................. : / Fax......................................... : / Page 4 of 61 Report No.: LCSA121222024E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revison History Revision Issue Date Revision Content Revised By 000 December 27, 2022 Initial Issue --- Page 5 of 61 Report No.: LCSA121222024E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity TABLE OF CONTENTS 1. TEST STANDARDS A…

Text truncated - open the document above for the full version.

编制 Prepa red by 审 核 Check ed by 批 准 App roved by 承 认 Con fir med by S.He 批 准 App roved by 何 修明 编制日期 Prepared Dat e: 06.21 签署Signatu re 客户Custo mer 供 应商Supp lier 产品名称 Part Name: Direct-connect External Antenna 料号 P/ N: 3D2601BK00-002 规格描述 Spec Description : 规 格 书 specific G26 black with silk screen, PCB, 141+SMA male and female pins, exposed length 47mm. Size: 115.3x18mm Peak Gain 2.4GHz-2.5GHz 3dBi 5.150GHz-5.850GHz 5.18dBi ation 制造厂商 Manufacturer : 地址 Address: Dongguan HJ Technology Co. Ltd No.3, taihe road,quantang industrial zone, liaobu town, dongguan city, guangdong province, china CONTENTS 目 录 Title Page ---------------------------------------------------------- 1 Contents ------------------------------------------------------------ 2 Drawings ----------------------------------------------------------- 3 Test Report -------------------------------------------------------- 4 Wire Material Specification ------------------------------------ 5 8 7 PCB正视图 铜片焊接编织 *[4] 95.00±1.00 *[5] 13.50±0.20 在此处焊接铜片 PCB背视图 BACDEFGH 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 BACDEFGH P/N: SHEET: SCALE: REVISION: TITLE: mm 1:1 ENG/DATE:CHE/DATE:APP/DATE:FILE NAME: REVISION DESCRIPTION DATE DRAFTER X.XXX ±0.01 X.XX ±0.05 LINEAR: ±0.20 X.X ±0.15 X.XXX° ±1.00°X.XX° ±2.00°ANGLE:X° ±4.00° X.X° ±3.00° COMPLIANCE WITH THE REQUIREMENT: █ RoHS ; □HF; □SONY SS-00259; □OTHERS *NO USING ESTRICTED AND BANNED SUBSTANCE GENERAL TOLERANCE: X UNIT: A0 FIRST RELEASE 18.10.19 Mark Mark/18.10.19 产品图 3D2601BK00-002 A0 1/1 技术要求： 电气特性：使用矢量网络分析仪 测试。 特性阻抗 ；适用频率范围 ；驻波比 最大 增益 峰值增益 。 驻波比 最大 增益 峰值增益 尺寸检验： 为 检测项目； 为重点检测项目；■为 管制项目。 外观检验：目视全检。产品表面不得有刮伤、破损和脏污 镀层色泽光亮均匀，不得有氧化。 包装规范： 袋， 包。 环保要求：产品及其使用之物料皆需要符合 要求。 射频天线组件 直连式外置天线,G26黑色有丝印,PCB结构, 141黑色+SMA公头母针,外露长度47mm 115.3 47±5 1 2 4 6 18.0 3 5 No. PART NUMBER PART NAME & DESCRIPTION Q'TY REMARKS 123 4 1111 2C5A14111BK1 2LC15PS022-8 2SBKG26112SBKG2621 微细同轴电缆SFX-141 --------- SMA公头,塑胶外壳，黑色外壳,L115.3*W18.0mm,ABS,黑色,有柱子有丝印外壳,L115.3*W18.0mm,ABS,黑色,无柱子有丝印 5 1 2TC064BK0-025 --- 热缩管，双壁含胶型, ∅ 6.40*L25.0，黑色 6 1 2YC006 --- 铜片,L8.20*W4.00*H4.20*T0.5 黄铜 2LC15PS022-5 SMA 母针OD1.8*L7.8mm 1 ------ 7 1 2YP013 --- L95.00*W13.50*T0.6,白色高频板, 铜箔镀镍. 8 25.0 H461 *[6] 61.00±1.00 *[9] 13.00±0.50 *[7] 3.00±0.50 *[10] 3.50±0.50 *[11] 8.50±0.50 裁 线 图 P1端 焊接PCB P2端 铆接公头母针 *[8] 1.00±0.50 A1 A1 A5 A1 变更裁线尺寸 21.09.06 S.He A5 A2 变更接头、测试标准VSMR小于2.0、加EVA 21.09.26 S.He 1 2MH106 --- EVA 黑色 L45.0*W10.0*T1.0mm,EVA+单面3M 9448A 背胶 9 9 A2 A2 A2 A3 环焊后塞改为铆压后塞 21.10.20 S.He 铆压后塞2-3mm，保持力6kgf以上 A3 EVA贴在PCB板正面位置如图 A4 变更线材剥线尺寸及料号 21.12.01 S.He A5 变更线材剥线尺寸及料号 22.04.25 S.He 天 线电气特性测试报告 Antenna Electrical Characteristic Test Report 文件编号 :HJ-QR-Q-22 Rev:A0 产品料号 Par t Number : 测试项目 Item 规格 Spec 结果判定 Judge 产品名称 Par t Name: Char acteristic impedance 特性阻抗 50Ω/ 测试设备 Test Equipment Network Analyzer / Microwave chamber 2400~2500MHz VSWR Max OK 数 量 Ｑuantity 5pcs 5150~5850MHz VSWR .0 Max OK 测试日期 Test Date 2020/6/1 Gain 增 益 O 5.18 dBi K 审 核Checker: 王 俊测试者Tester:Mark Sword Type wifi Antenna Antenna Peak Gain(dBi)=Peak EIRP(dBm) - Ant.port Input Pwr(dBm)

Report No.: PTC22102405901E-FC01 Page 1 of 88 FCC TEST REPORT FCC ID: 2A9QY-W1000S Product : Wireless Video Transmission System Model Name : W1000S,W1000H,W1000SP,W1000HP,W1500,W2000,FT6P,FR6P, FRT6P, FRT6U Brand : N/A Report No. : PTC22102405901E-FC01 Prepared for ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD 3#B503 GREEN LAKE PLAZA , No.1 HUBIN ROAD, LONGWEN DISTRICT, ZHANGZHOU, FUJIAN Prepared by Precise Testing & Certification Co., Ltd Building 1, No. 6, Tongxin Road, Dongcheng Street, Dongguan, Guangdong, China Report No.: PTC22102405901E-FC03 Page 2 of 88 1 TEST RESULT CERTIFICATION Applicant’s name : ZHANGZHOU LAISHIKE ELECTRONIC TECHNOLOGY CO.,LTD Address : 3#B503 GREEN LAKE PLAZA , No.1 HUBIN ROAD, LONGWEN DISTRICT, ZHANGZHOU, FUJIAN Manufacture's name : ZHANGZHOU SEETEC OPTOELECTRONICS TECHNOLOGY CO., LTD Address : NO.9A, Fuxing Industrial Zone, NO.9, Jinmin Road, Jinfeng Development Zone, Zhangzhou, Fujian Product name : Wireless Video Transmission System Model name : W1000S,W1000H,W1000SP,W1000HP,W1500,W2000,FT6P,FR6P, FRT6P,FRT6U Standards : FCC CFR47 Part 15 Section 15.407 Test procedure : ANSI C63.10:2013 Test Date : Nov. 07, 2022 to Dec. 12, 2022 Date of Issue : Dec. 30, 2022 Test Result : Pass This device described above has been tested by PTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of PTC, this document may be altered or revised by PTC, personal only, and shall be noted in the revision of the document. Test Engineer: Simon Pu / Engineer Technical Manager: Ronnie Liu / Manager Report No.: PTC22102405901E-FC03 Page 3 of 88 Contents Page 1 TEST RESULT CERTIFICATION ........................................................................................................................ 2 2 TEST SUMMARY ................................................................................................................................................... 5 3 GENERAL INFORMATION ................................................................................................................................ 6 3.1 GENERAL DESCRIPTION OF E.U.T. ...................................................................................................................... 6 3.2 CHANNEL LIST .................................................................................................................................................... 7 3.3 TEST SITE ......................................................................................................................................................... 13 4 EQUIPMENT DURING TEST ............................................................................................................................. 14 4.1 EQUIPMENTS LIST............................................................................................................................................. 14 4.2 MEASUREMENT UNCERTAINTY ......................................................................................................................... 16 4.3 DESCRIPTION OF SUPPORT UNITS ................................................................................................................... 17 5 CONDUCTED EMISSION ................................................................................................................................... 18 5.1 E.U.T. OPERATION ........................................................................................................................................... 18 5.2 EUT SETUP ...................................................................................................................................................... 18 5.3 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................................. 19 5.4 MEASUREMENT PROCEDURE ........................................................................................................................... 19 5.5 CONDUCTED EMISSION LIMIT ........................................................................................................................... 19 5.6 MEASUREMENT DESCRIPTION .......................................................................................................................... 19 5.7 CONDUCTED EMISSION TEST RESULT ............................................................................................................. 19 6 RADIATED SPURIOUS EMISSIONS ............................................................................................................... 22 6.1 EUT OPERATION .............................................................................................................................................. 23 6.2 TEST SETUP ..................................................................................................................................................... 24 6.3 SPECTRUM ANALYZER SETUP .......................................................................................................................... 25 6.4 TEST PROCEDURE ............................................................................................................................................ 26 6.5 SUMMARY OF TEST RESULTS .......................................................................................................................... 27 6.6 BAND EDGE MEASUREMENTS ........................................................................................................................... 45 6.7 RESTRICTED BAND ........................................................................................................................................... 49 7 EMISSION BANDWIDTH AND OCCUPIED BANDWIDTH .....................................................................…

Text truncated - open the document above for the full version.

Report No.: PTC22102405901E-FC03 Page 51 of 88 7 Emission Bandwidth and Occupied Bandwidth Test Requirement : FCC CFR47 Part 15 Section 15.407(a)(e) Test Method : ANSI C63.10:2013 Test Limit According to FCC §15.407(a), The maximum power spectral density is measured as a conducted emission by direct connection of a calibrated test instrument to the equipment under test. If the device cannot be connected directly, alternative techniques acceptable to the Commission may be used. Measurements in the 5.725- 5.85 GHz band are made over a reference bandwidth of 500 kHz or the 26 dB emission bandwidth of the device, whichever is less. Measurements in the 5.15-5.25 GHz, 5.25-5.35 GHz, and the 5.47-5.725 GHz bands are made over a bandwidth of 1 MHz or the 26 dB emission bandwidth of the device, whichever is less. A narrower resolution bandwidth can be used, provided that the measured power is integrated over the full reference bandwidth. As per FCC §15.407(e): for equipment operating in the band 5725 – 5850 MHz, the minimum 6 dB bandwidth of U-NII devices shall be 500 kHz. 7.1 Test Procedure According to KDB 789033 D02 General UNII Test Procedures New Rules v02r01, Emission Bandwidth (EBW) a) Set RBW = approximately 1% of the emission bandwidth; b) Set the VBW > RBW; c) Detector = Peak; d) Trace mode = max hold; e) Measure the maximum width of the emission that is 26 dB down from the maximum of the emission. Compare this with the RBW setting of the analyzer. Readjust RBW and repeat measurement as needed until the RBW/EBW ratio is approximately 1%;99% Occupied Bandwidth The 99% occupied bandwidth is the frequency bandwidth such that, below its lower and above its upper frequency limits, the mean powers are each equal to 0.5 % of the total mean power of the given emission. Measurement of the 99% occupied bandwidth is required only as a condition for using the optional band- edge measurement techniques described in II.G.3.d). Measurements of 99% occupied bandwidth may also optionally be used in lieu of the EBW to define the minimum frequency range over which the spectrum is integrated when measuring maximum conducted output power as described in II.E. However, the EBW must be measured to determine bandwidth dependent limits on maximum conducted output power in accordance with 15.407(a). The following procedure shall be used for measuring (99 %) power bandwidth: 1. Set center frequency to the nominal EUT channel center frequency. 2. Set span = 1.5 times to 5.0 times the OBW. 3. Set RBW = 1 % to 5 % of the OBW 4. Set VBW ≥ 3 · RBW 5. Video averaging is not permitted. Where practical, a sample detection and single sweep mode shall be used. Otherwise, peak detection and max hold …

Text truncated - open the document above for the full version.
