2A9R7GC614196Holo Frame

User Manual of Immers Gallery “Open the Door of Holographic Metaverse to Feel the New Vision of Naked Eye” Thanks for choosing the Immers Gallery to bring you an immersive visual feast. Contents 01 Safety Instruction 02 Product Information 03 Instructions 04 Fault Analysis and Clearing 05 Cautions 01 Safety Instruction 1. Please read the user manual carefully and save for reference before using the product. 2. Product picture & descriptions are for reference only. Detailed information is in accordance with the final product. 3. Please follow the instructions carefully. 4. Design and specifications of this product are subject to change without prior notice. 02 Product Information Product Name Holo Frame Model No IG079-Pro Screen 7.9 Inch LCD Display Resolution 1536*2048 Dimensions 193.7mm×135.4mm×40.7mm Usage Environment Indoor only View Distance 0.5m above Display Area 159.7*119.8mm Brightness 220cd/m 2 Contrast Ratio 1000:1 Response Time 35ms Package Size 240*191*85mm OS Android 11 Touch No Power Supply 100V～240V AC,50~60Hz, 12V/2.5A Input TypeC View Points 49 Filter Type Holo Lens Player Holo OS Content Format Multi-tile Plug_In Unity plug-in Product Configuration 01 Immers Gallery*1 02 Adaptor*1 03 Power Cord*1 04 Type-C Connector*1 05 Clean Wiper 06 User Manual*1 03 Instructions Power on Connect power cord, touch and hold the power button to power on, wait few seconds to enter operation interface. Network Binding and Unbinding Preparations: Please keep the device be fully charged before network connection. Click setting, select network and enter password to make connection. 1) Binding: Download “Immers” app to your phone and sign up as required. Click the top right corner to add device, scan the QR code of device ID on Immers Gallery, reminder of “connection succeed” means binding is completed. (“Immers” account can be bound to multiple Immers Gallery, but a single devide can be bound to one account only which can be bonded to other account after unbinding.) Scan QR code to download Immers app Download Immers To bind the device in home page Immerse Gallery Setting Enter account page, scan the QR code to make binding 2) Unbinding: Go to mobile app setting, click “unbind device”. Unbind Device Photo and Video Transmission There are 2 transmission methods optional. 1) USB Flash: Put USB flash to the type c interface via adaptor, copy content to the local file of Immers Gallery (only picture format jpg/png and video format mp4 supported so far). 2) Immers App: Open Immers app, select corresponding Immers Gallery, click upload button, select camera or local picture, which will be uploaded to server to make 3D conversion, then to be downloaded to Immers Gallery automatically to play (all uploaded file can be viewed in playlist of app setting). Camera or Local Picture Playlist Content Playback 1) Select video or photo file in Immers Gallery to play To select 3D content format and 3D focus setting in playback interface if needed. 2) Select corresponding device through the app, click control button to adjust play, pause, volume up and down, previous picture and next picture. Immers Control Interface Power Off 1) Touch and hold the power button for 3 seconds to power off. 2) Go to setting page of the app, click power off. Immers Power Off Setting 04 Fault Analysis and Clearing Fault Analysis and Clearing 1) Display does not light up: Please check the remaining battery capacity and power supply, make sure the display is power in. 2) Flashing Screen: Restart the device, if the fault cannot be rectified, please contact our technical staff. 3) No Sound: Go to setting---sound to adjust volume. 05 Cautions Operation and Maintenance 1） Cautions The surface of display is glass, please do not apply mechanical impact, such as impact or height crash. Do not apply too much pressure to display surface or the connection area of the LCD module to avoid tonal variation. If the display is spotless, please wipe it with a soft dry cloth gently. If solvent is required, only alcohol can be used. 2） Environment Keep a dry environment and avoid chemicals. Do not expose the product to rain, humidity, or direct sunlight, so as not to affect normal use. Storage temperature :-20°C to 60° Storage temperature :-20°C to 60° Relative humidity: ≤65% Do not plug the ventilation hole. Do not put the display near radiator, heat source or any other equipment that may affect normal ventilation. 3） Tips for Recycling To protect the environment better, please comply with the national laws and regulations on electrical and electronic product recycling and treatment, and hand it over to the local manufacturer with the national recognized recycling and treatment qualification for recycling and treatment when the user no longer needs the product, or the product is life terminated. 4) The following problems may occur, which is normal occurrence and not quality issue of the display: a. Due to the specialty of LCD display, screen flicker may occur on initial use. Please power off and restart the display to ensure that the screen does not flicker again. b. The effective pixels of the LCD display reach or exceed 99.99%, but there will also be 0.01% or less pixel loss or brightness loss in the display. c. The image brightness may be slightly uneven when you use different desktop patterns. d. Due to the specialty of LCD display, there will be no pixel residue in normal operation. However, when the same static image is displayed for a long time and then the image is switched, the previous residual image may continue to be retained, which is called "residual image". The best way to avoid it is to run a screen saver with monochrome or moving images when you're not using the system. Manufacturer: Shenzhen Smart Superv Co., Ltd ADD: 8F, Block A7, Nanshan Intelligent Park, 1001 Xueyuan Avenue, Taoyuan Town, Nanshan District, Shenzhen, China Support Line: Homepage:https://www.smartsuperv.com/ This device complies with part 15 of the FCC Rules. Opera…

Text truncated - open the document above for the full version.

Shenzhen SmartSuperV Co.,Ltd Company: Shenzhen SmartSuperV Co.,Ltd Address: 8F, Block A7, Nanshan Intelligent Park, 1001 Xueyuan Avenue, Taoyuan Town, Nanshan District, Shenzhen, China Product Name: Holo Frame Model Number(s): IG079-Pro, IG079-Lite, IG089, IG101, IG108, IG125, IG133, IG156 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023/01/12 Name: Jane Huang Title: PM Director Company: Shenzhen SmartSuperV Co.,Ltd

Shenzhen SmartSuperV Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject ; Request for Confidentiality FCC ID: 2A9R7GC614196 To Whom It May Concern, Date: 2023/01/12 Pursuant to the provisions of the Commission ’ s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s ) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprieta叩informationin operation of the equipment. The public disclosure of these documents might be ha「mfulto our company and would give competitors an unfair advantage in the market. 因SchematicDiagram 囚BlockDiag「am 因OperationalDescription In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the impo叫ationrules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Te「m Confidentiality of the following attachment(s ); 口UserManual 口For45 days, pursuant to Public Notice DA 04-1705. OR 口For180 days pursuantto KDB 726920 001. It is our understanding that all measu「ementtest reports, FCC ID label format and correspondence during the ce「tificationreview process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Date: 2023/01/12 Name: Title: Company: Shenzhen SmartSuperV Co.,Ltd

EUT EXTERNAL PHOTOGRAPHS EUT Photo 1 EUT Photo 2 EUT Photo 3 EUT Photo 4 EUT Photo 5 EUT Photo 6 EUT Photo 7 ----------------The end----------------

Label and location Label location

EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 EUT Housing and Board View 3 EUT Housing and Board View 4 EUT Housing and Board View 5 EUT Housing and Board View 6 EUT Housing and Board View 7 EUT Housing and Board View 8 ----------------The end---------------- Antenna

FCC ID : 2A9R7GC614196 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 ,If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 11.2 Measurement Result WIFI2.4G Antenna gain: 4.48 dBi Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 16.49 15 to 17 17 2.8 0.028 1

No.：BCTC/RF-EMC-005 Page: 1 of 65 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2211195402E Applicant: Shenzhen SmartSuperV Co.,Ltd Product Name: Holo Frame Model/Type reference: IG079-Pro Tested Date: 2022-11-18 to 2022-12-05 Issued Date: 2023-01-17 Report No.: BCTC2211195402E No.：BCTC/RF-EMC-005 Page: 2 of 65 Edition：A.5 FCC ID: 2A9R7GC614196 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Holo Frame Trademark: N/A Model/Type reference: IG079-Pro, IG079-Lite, IG089, IG101, IG108, IG125, IG133, IG156 Prepared For: Shenzhen SmartSuperV Co.,Ltd Address: 8F, Block A7, Nanshan Intelligent Park, 1001 Xueyuan Avenue, Taoyuan Town, Nanshan District, Shenzhen, China Manufacturer: Shenzhen SmartSuperV Co.,Ltd Address: 8F, Block A7, Nanshan Intelligent Park, 1001 Xueyuan Avenue, Taoyuan Town, Nanshan District, Shenzhen, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhanche ng , Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2022-11-18 Sample tested Date: 2022-11-18 to 2022-12-05 Report No.: BCTC2211195402E Test Standards: FCC Part15.247 ANSI C63.10-2013 Test Results: PASS Remark: This is WIFI-2.4GHz band radio test report. Tested by: Approved by: Brave Zeng/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2211195402E No.：BCTC/RF-EMC-005 Page: 3 of 65 Edition：A.5 Table of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information and Test Setup ...................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 9 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List ........................................................................................................ 10 4.5 Test Mode ........................................................................................................... 10 4.6 Table Of Parameters Of Text Software Setting ................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test procedure .................................................................................................... 13 6.4 EUT operating Conditions ................................................................................... 13 6.5 Test Result .......................................................................................................... 14 7. Radiated Emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test procedure .................................................................................................... 18 7.4 EUT Operating Conditions .................................................................................. 19 7.5 Test Result .......................................................................................................... 19 8. Radiated Band Emission Measurement and Restricted Bands Of Operation ...... 25 8.1 Block Diagram Of Test Setup .............................................................................. 25 8.2 Limit .................................................................................................................... 25 8.3 Test procedure .................................................................................................... 26 8.4 EUT Operating Conditions .................................................................................. 26 8.5 Test Result .......................................................................................................... 27 9. Power Spectral Density Test ............................................................................... 29 9.1 Block Diagram Of Test Setup .............................................................................. 29 9.2 Limit .................................................................................................................... 29 9.3 Test procedure .................................................................................................... 29 9.4 EUT Operating Conditions .................................................................................. 29 9.5 Test Result ...................................................…

Text truncated - open the document above for the full version.

Report No.: BL-SZ2310300-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: Shenzhen Smart Superv Co., Ltd Address: 801, Building A7, Nanshan Zhiyuan, No. 1001, Xueyuan Avenue, Changyuan Community, Taoyuan Street, Nanshan District, Shenzhen Equipment Type: Holo Frame Model Name: IG079 Brand Name: N/A Test Standard: ANSI/IEEE Std 149-2021 Sample Arrival Date: Jan. 09, 2023 Test Date: Jan. 10, 2023 Date of Issue: Jan. 12, 2023 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Mai Jintian Checked by: Zou Liu Approved by: Tolan Tu (Testing Director) _______________ _______________ _______________ Report No.: BL-SZ2310300-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Jan. 12, 2023 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................... 3 1.1 Test Laboratory ..................................................................................................................... 3 1.2 Test Location ......................................................................................................................... 3 2 PRODUCT INFORMATION ......................................................................................................... 4 2.1 Applicant Information ............................................................................................................ 4 2.2 Manufacturer Information ...................................................................................................... 4 2.3 General Description for Equipment under Test (EUT) .......................................................... 4 2.4 Ancillary Equipment .............................................................................................................. 4 2.5 Technical Information ............................................................................................................ 4 3 SUMMARY OF TEST RESULTS ................................................................................................. 5 3.1 Test Standards ...................................................................................................................... 5 3.2 Test Verdict ........................................................................................................................... 5 3.3 Test Uncertainty .................................................................................................................... 5 4 GENERAL TEST CONFIGURATIONS ........................................................................................ 6 4.1 Test Condition ....................................................................................................................... 6 4.2 Test Equipment List .............................................................................................................. 6 4.3 Test Setup ............................................................................................................................. 7 ANNEX A TEST RESULTS ............................................................................................................. 8 A.1 Gain and Efficiency ............................................................................................................... 8 A.2 VSWR ................................................................................................................................... 9 ANNEX B RADIATION PATTERN ................................................................................................ 10 ANNEX C TEST SETUP PHOTOS ............................................................................................... 13 ANNEX D EUT PHOTO ................................................................................................................ 13 Report No.: BL-SZ2310300-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Report No.: BL-SZ2310300-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant Shenzhen Smart Superv Co., Ltd Address 801, Building A7, Nanshan Zhiyuan, No. 1001, Xueyuan Avenue, Changyuan Community, Taoyuan Street, Nanshan District, Shenzhen 2.2 Manufacturer Information Manufacturer Shenzhen Smart Superv Co., Ltd Address 801, Building A7, Nanshan Zhiyuan, No. 1001, Xueyuan Avenue, Changyuan Community, Taoyuan Street, Nanshan District, Shenzhen 2.3 General Description for Equipment under Test …

Text truncated - open the document above for the full version.

Report No.: BL-SZ2310300-AA 1 / 1 EUT PHOTO --BLANK BELOW -- Antenna

Report No.: BL-SZ2310300-AO 1 / 2 TEST SETUP PHOTOS Report No.: BL-SZ2310300-AO 2 / 2 --BLANK BELOW --

TEST SETUP PHOTOGRAPHS 1.1. Photos of Conducted Emission Measurement 1.2. Photos of Radiation Emission Measurement Spurious Emission Test Setup (Between 30MHz – 1GHz) Spurious Emission Test Setup (Above 1G) ----------------The end----------------
