2A9RHS4T01Power Strip with USB,LED with bluetooth

1 LotusLantern APP Manual 1. Software Overview 1.1 Overview LotusLantern is a mobile APP to control LED strip by both Apple and Android phones. The traditional control ways like infrared, 433MHz, 2.4GHz and others old wired ways will be replaced by mobile phone control way with convenient, powerful and scalable features. Through this mobile APP，you can not only control the color, brightness and color temperature of the LED strips but also set up all kinds of fancy flash mode；Also this APP can change the light of the LED strip according to the rhythm of the music. This APP can set and control several LED strips through Bluetooth and the operation is very simple, easy to learn and easy to use. 1.2 Features Adjust color LED strips with 60,000 colors to change color and brightness and adjust monochrome LED stips to change brightness and color temperature Play music or turn on a sound playback device, you can let the light change the color and brightness with the rhythm of music, the music rhythm beautiful Inside multiple setting mode for color change and control LED strips without mobile Long distance control with omni-directional antenna, and many-to-many group control mode Once the connection is successful, connect automatically next time 1.3 Performance LotusLantern APP is easy for use as well as great compatible for all kinds of smart phones; After the actual test of hundreds of mobile phones verification, the compatibility is above 95% of mobile phones in the market. APP is small and convenient, it consumes less system resources, so the requirements of the mobile configuration are low. Control delay is small, the operation feel good, light control is smooth with people’s visual sense. 2. Operating Environment This APP program requires phones of system above Andriod 4.3 and iOS 8.0. Mobile phone configuration is not limited. 3. Instuctions Note: Android version and iOS version download and use the same method, here in the Android version as an example. 3.1 APP Download Scan the QR code iOS and Android systems can download the "LotusLantern" APP by scanning the QR code. Open the browser or other tools with "Scan QR code" function, scan the "LotusLantern" QR code as below: 3.2 App Operation (1)Click on the LotusLantern APP icon, enter the APP page: 2 (2)After entering the APP interface, if Bluetooth is not enabled, "an application wants to enable the Bluetooth function of this device." Click [Allow] (3)switch to color and brightness interface: Click to show the lamp list Switch the color wheel Click to display setting view Lamp switch button Adjust the color Display the RGB value Click to manual adjustment view Click square icon to adjust the color Click to shift the interface 3 （4） click to show the lamp list, view lamp list: （5） Click to RGB manual adjustment view: Bluetooth auto connect after search for devices Lamp list Status of device connection Status of device connection 4 （6） switch to the mode interface: （7） switch to the music rhythm interface: Scroll the selection mode Adjust seed Adjust luminance Recycle mode Previous song, Pause/Play, Next song Music List 5 （8） Switch to the online music interface: （9） Switch to the microphone rhythm interface: Music rhythm through cell phone microphone Switch phone microphone and external microphone Music rhythm through the microphone on the product Switch phone microphone and external microphone 4-style rhythm Change the sensitivity of MIC to match the sound 6 （10） Switch to the schedule interface: （11）Switch to the modify pin sequence interface: Enable or disable the Light-On function Repeat setting No selection for once Light-On Set the time of Light-On Enable or disable the Light-Off function Repeat setting No selection for once Light-Off Set the time of Light-Off Click to save the new assignment Change the real color of this line FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 7

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhenshi Saisitong Wangluokejiyouxiangongsi Address: Longgangqu,Pinghujiedao,Shangmugucuncaizibeilu9hao708 Shenzhen 518111 Product Name: Power Strip with USB,LED with bluetooth Model Number: S4T-01 FCC Identifier: 2A9RHS4T01 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: xing Peng Date: 2022.12.20 Title: legal person Signature of applicant:

C5266091_X10_Ed.2 1/1 < Shenzhenshi Saisitong Wangluokejiyouxiangongsi > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022.12.20 Subject: Request for Confidentiality FCC ID: 2A9RHS4T01 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: xing Peng Title: legal person

External Photo FCC ID: 2A9RHS4T01

Lable and Location (Size: L3.0cm x 1.5cm) Bluetooth controller Model: S4T-01 FCC ID: 2A9RHS4T01

Page 1 of 2 Address: No.11, WuSong Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com FCC ID : 2A9RHS4T01 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)/(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 ,If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. RF Exposure Information: The radiated output power of this device meets the limits of FCC/IC radio frequency exposure limits.This device should be operated with a minimum separation distance of 20cm (8 inches) between the equipment and a person's body. 90966-22-72-22-PP002 Page 2 of 2 Address: No.11, WuSong Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com 11.2 Measurement Result BT/BLE Antenna gain: 0.23 dBi Modulati on Channel Freq. (MHz) Measured power (dBm) Tune-up power (dBm) Max tune- up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) GFSK （BLE） 2402 -5.55 ±1 -5 1.05 0.000066 1 2440 -5.58 ±1 -5 1.05 0.000066 1 2480 -5.01 ±1 -5 1.05 0.000066 1 Therefore the worst-case situation is 0.000066, which is less than “1”, This confirmed that the device comply with FCC 1.1310 MPE limit. THE END

Page 1 of 39 Address:No.11,WuSongRoad, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com TEST REPORT Report Number. ..................... : 90992-22-72-22-PP001 Date of issue ......................... : 2022-12-16 Tested by (+signature) ......... : Duke Approved by (+signature) .... : Jason Testing Laboratory name ..... : SLG-CPC Testlaboratory Co., Ltd. Address ................................. : No. 11, Wu Song Road, Dongcheng District, Dongguan, Guangdong Province, China 523117 Applicant’s name .................. : Shenzhenshi Saisitong Wangluokejiyouxiangongsi Address ................................. : Longgangqu,Pinghujiedao,Shangmugucuncaizibeilu9hao708 Shenzhen 518111 Manufacturer’s name .......... : Shenzhenshi Saisitong Wangluokejiyouxiangongsi Address ................................. : Longgangqu,Pinghujiedao,Shangmugucuncaizibeilu9hao708 Shenzhen 518111 Factory’s name .................... : Shenzhenshi Saisitong Wangluokejiyouxiangongsi Address ................................. : Longgangqu,Pinghujiedao,Shangmugucuncaizibeilu9hao708 Shenzhen 518111 Standard(s) ............................ : FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C Test item description ............ : Power Strip with USB,LED with bluetooth Trade Mark ............................. : N/A Model/Type reference ........... : S4T-01 FCC ID .................................... : 2A9RHS4T01 Date of receipt of test item .. : 2022-12-09 Date (s) of performance of test.......................................... : 2022-12-10 to 2022-12-15 Summary of Test Results..... : Pass The Summary of Test Results based on a technical opinion belongs to the standard(s). General disclaimer: This report shall not be reproduced except in full, without the written approval of SLG-CPC Testlaboratory Co., Ltd. The test results in the report only apply to the tested sample. 90992-22-72-22-PP001 Page 2 of 39 Address:No.11,WuSongRoad, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com Table of Contents 1 EUT TECHNICAL DESCRIPTION ..................................................................................................... 4 2 SUMMARY OF TEST RESULT ......................................................................................................... 5 3 TEST METHODOLOGY .................................................................................................................... 6 3.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................. 6 3.2 MEASUREMENT EQUIPMENT USED ....................................................................................... 6 3.3 DESCRIPTION OF TEST MODES .............................................................................................. 7 4 FACILITIES AND ACCREDITATIONS............................................................................................... 8 4.1 FACILITIES .................................................................................................................................. 8 4.2 LABORATORY ACCREDITATIONS AND LISTINGS .................................................................. 8 5 TEST SYSTEM UNCERTAINTY ........................................................................................................ 9 6 SETUP OF EQUIPMENT UNDER TEST ......................................................................................... 10 6.1 RADIO FREQUENCY TEST SETUP 1 ...................................................................................... 10 6.2 RADIO FREQUENCY TEST SETUP 2 ...................................................................................... 10 6.3 CONDUCTED EMISSION TEST SETUP .................................................................................. 12 6.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ..................................................... 13 6.5 SUPPORT EQUIPMENT ........................................................................................................... 13 7 TEST REQUIREMENTS .................................................................................................................. 14 7.1 DTS 6DB BANDWIDTH ............................................................................................................. 14 7.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ................................................................ 17 7.3 MAXIMUM POWER SPECTRAL DENSITY .............................................................................. 20 7.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS .............................. 23 7.5 RADIATED SPURIOUS EMISSION .......................................................................................... 28 7.6 CONDUCTED EMISSIONS TEST ............................................................................................ 36 7.7 ANTENNA APPLICATION ......................................................................................................... 39 90992-22-72-22-PP001 Page 3 of 39 Address:No.11,WuSongRoad, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com Modified Information Report No. Revision Data Summary 90992-22-72-22-PP001 2022-12-16 Original Version 90992-22-72-22-PP001 Page 4 of 39 Address:No.11,WuSongRoad, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com 1 EUT TECHNICAL DESCRIPTION Product Power Strip with USB,LED with bluetooth Model Number S4T-01 Device Type Bluetooth V5.1 Data Rate : 1Mbps for GFSK modulation Modulation: Bluetooth DTS: GFSK Operating Frequency Range: 2402-2480MHz Number of Channels: 40 Channels for Bluetooth DTS; Transmit Power Max: -5.01 dBm Antenna Type: PCB Antenna Antenna Gain: 0.23 dBi Power supply AC 100-240V 50/60Hz Temperat…

Text truncated - open the document above for the full version.

AntennaSpecifications 1.Modelnumber:H66B2 2.Manufacture:ShenzhenLenzeTechnologyCo.,Ltd. 3.Adress:East,7thFloor,NewspaperPrintingBuilding,LianhuaStreet, FutianDistrict,Shenzhen 4.Antennaefficiencyandgain Frequency (MHz) Gain(dBi) 24000.23 2440-0.53 2480-1.61 5.AntennaPhoto&Length(mm)

Setup Photo FCC ID: 2A9RHS4T01
