2A9UE-SN0303Tablet Magnetic Wireless Charger Stand

品牌：JSAUX 产品型号： SN0303 产品名称： 平板电脑无线充支架 USB-A输入： 5V 3A/ 9V 2A/ 12V 1.5A USB-C输入： 5V 3A/ 9V 2.22A/ 12V 1.67A 无线充输出： 15W Max（ 兼容10W, 7.5W, 5W ） 产品材质： 铝合金 + 硅胶 + PC + TPU 产品重量： 275 g 产品尺寸： 178 × 92 × 13.5mm 线缆长度： 1.5 m 执行标准： Q/JSAUX 006-2021 Packing Accessories (×1) Tablet Magnetic Wireless Charger Stand (×1) User manual (×1) Warranty Card 包装清单 平板电脑无线充支架 × 1 用户手册 × 1 保修卡 × 1 USB-A male to USB-C female adapter Brand: JSAUX Product Model: SN0303 Product Name: Tablet Magnetic Wireless Charger Stand USB-A Input: 5V 3A/ 9V 2A/ 12V 1.5A USB-C Input: 5V 3A/ 9V 2.22A/ 12V 1.67A Wireless Output: 15W Max ( Compatible with 10W, 7.5W, 5W ) Material: Aluminum Alloy + Silicone + PC + TPU Weight: 275 g Dimensions: 178 × 92 × 13.5 mm Cable length: 5 ft This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Wilson Tech Service LLC FRN: 0033402033 Contact Name: Wilson Cheung Address: 1312 17th Street Suite692DenverCO80202.US Telephone No: +1-716-965-5112 Email: [email protected] Applicant: Company name: Shenzhen Wuyishi Technology Co.,Ltd. Grantee code: 2A9UE FCC ID: 2A9UE-SN0303 Contact Name: Jade yang Address: Room 501-505, Building B, No. 17, Yongxiang East Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen Telephone: 18906679427 Fax: 18906679427 E-mail: [email protected] [Shenzhen Wuyishi Technology Co.,Ltd.] certifies that, as of the date of this filing of the application with the TCB, [Wilson Tech Service LLC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Wuyishi Technology Co.,Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Wilson Tech Service LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/07/03 Applicant’s Name: Jade yang US Agent’s Name: Wilson Cheung Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Wuyishi Technology Co.,Ltd. Grantee code: 2A9UE FCC ID: 2A9UE-SN0303 Contact Name: Jade yang Address: Room 501-505, Building B, No. 17, Yongxiang East Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen Telephone: 18906679427 Fax: 18906679427 E-mail: [email protected] i. [Shenzhen Wuyishi Technology Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Wuyishi Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Wuyishi Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/07/03 Applicant’s Name: Jade yang Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Wuyishi Technology Co.,Ltd. 1/1 Letter of Authorization Company: Shenzhen Wuyishi Technology Co.,Ltd. Address: Room 501-505, Building B, No. 17, Yongxiang East Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen Product Name: Tablet Magnetic Wireless Charger Stand Model Number(s): SN0303 FCC ID: 2A9UE-SN0303 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jade yang Date: 2023-07-03 Title: Manager Signature of applicant:

Size:18*12mm M/N: SN0303 FCC ID: 2A9UE-SN0303 Label location

ANT Wireless charging

FCC ID: 2A9UE-SN0303 Product Name: Tablet Magnetic Wireless Charger Stand Trade Mark: JSAUX Model No.: SN0303 Model Difference: N/A Transmitting mode Keep the EUT in continuously wireless charging mode Power supply: Input: DC 5V/3A, 9V/2A, 12V/1.5A Wireless Output: 5W/7.5W/10W/15W Max. Date of Receipt: May. 26, 2023 Test Date: May. 26, 2023 - Jun. 07, 2023 Date of Report: Jun. 07, 2023 Test Modes: Mode1. Wireless Output Mode(5W) Mode2. Wireless Output Mode(7.5W) Mode3. Wireless Output Mode(10W) Mode4. Wireless Output Mode(15W) Note: 1. We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. 2. All modes have been tested, and the report only shows the results of the worst mode 4. RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. Yes; the device operate in the frequency range from 115 KHz to 205 KHz (2) Output power from each primary coil is less than or equal to 15 watts. Yes; the maximum output power of the primary coil is 15W. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. Yes; the transfer system includes only one primary coils. (4) Client device is placed directly in contact with the transmitter. Yes; Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, mobile exposure conditions only. (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away Yes, see test result in item 6. from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 v03r01. Remark：The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Description of Support Units Adapter (Provide by test lab): Manufacturer: XIAOMI Model: AD65G I/P: AC 100-240V 50/60Hz O/P: DC 5V/3A, DC 9V/3A, DC 10V/5A, DC 12V/3A, DC 15V/3A, DC 20V/3.25A Mobile phone (Provide by test lab): Manufacturer: SAMSUNG Model: Galaxy S21 5G 6 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Exposure Level Tester Narda ELT-400 N-0231 June. 25 2022 June. 26 2023 Magnetic field probe 100cm 2 Narda ELT probe 100cm 2 M0675 June. 25 2022 June. 26 2023 Field Probe ETS HI-6105 / June. 25 2022 June. 26 2023 Laser Data Interface ETS HI-6113 / June. 25 2022 June. 26 2023 7 Test Uncertainty E-Filed Strength : ±0.08V/m H-Filed Strength : ±0.02A/m 8 Test Result E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 0.115-0.205 0.23 0.15 0.14 0.13 614 E-Filed Strength at 20 cm from the top of the EUT (V/m) Frequency Range (MHz) Test Position E Limits (V/m) 0.115-0.205 0.15 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 0.115-0.205 0.03 0.12 0.03 0.14 1.63 H-Filed Strength at 20 cm from the top of the EUT (A/m) Frequency Range (MHz) Test Position E Limits (A/m) 0.115-0.205 0.15 1.63 9 Test Set-up Photo Please see annex test setup photos.

深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 1 页 产品规格书 PRODUCTSPECIFICATIONFORAPPROVAL 客户名称： CUSTOMER 荣合电子 产品名称： PRODUCTNAME A11 线圈 物料编码： PARTNo. 20.001-025 产品规格： PRODUCTSPEC 磁片规格：43.5*5.3*1开槽 线材规格：0.08*105*10Ts/出线9.5mm 贴背胶/感量6.3uh±10％ 日期： DATE 2023年5月12日 版本型号： VERSION REV1.0 版本 Revision 变更内容 ModifiedContent 责任人 Principle 日期 Date 备注 Note REV1.0首次发布薛磊2023-5-12 制定/PREPAREDBY审核/CHECKEDBY核准/APPROVEDBY 李小云周小菊薛磊 客户认可签名及盖章 Authorizedsignature& companychop 附上的是产品规格书，有任何疑问，请及时反馈给我们，谢谢 ! 深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 2 页 产品规格 SPECIFICATION 一、产品尺寸 磁片直径 A 43.5±0.5mm 线圈外径B41mm±1mm 线圈内径C20.5mm±0.5mm 产品厚度D<2.4mm 出线长度E9.5mm±2mm 焊锡长度F3mm±1mm 磁片开孔直径G5.3mm±0.3mm 磁片厚度1mm±0.1.5mm 磁片形状圆形开槽 背胶厚度普通双面胶 圆片黑环无 深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 3 页 二、原理图 三、绕线参数 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 WindingDirection SF 丝包线 0.08*105 10TsCCW 四、电气特性： 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±20% 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS IND.S-F 6.3uH±10% 100KHz/1.0VLCZMETER1062B 深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 4 页 五、包装说明： 珍珠棉尺寸为35*24.5*6.2cm,每 个珍珠棉共有40个格子，每个格 子装6PCS产品，共240PCS产品 每箱装三层珍珠棉； 纸箱尺寸为：36.5*25.5*21CM， 每箱装720PCS产品。

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230607053E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 16 TEST REPORT FCC ID: 2A9UE-SN0303 Applicant: Shenzhen Wuyishi Technology Co.,Ltd. Address: Room 501-505, Building B, No. 17, Yongxiang East Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen Manufacturer: Shenzhen Wuyishi Technology Co.,Ltd. Address: Room 501-505, Building B, No. 17, Yongxiang East Road, Ma'antang Community, Bantian Street, Longgang District, Shenzhen EUT: Tablet Magnetic Wireless Charger Stand Trade Mark: JSAUX Model Number: SN0303 Date of Receipt: May. 26, 2023 Test Date: May. 26, 2023 - Jun. 07, 2023 Date of Report: Jun. 07, 2023 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 Subpart C ANSI C63.10:2013 Test Result: Pass Report Number: DL-20230607053E Prepared (Engineer): Lily Fu Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230607053E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 16 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ................................................................................................................................................. 3 2. TEST SUMMARY ..................................................................................................................................... 3 3. GENERAL INFORMATION ..................................................................................................................... 4 4. TEST INSTRUMENT USED ..................................................................................................................... 5 5. CONDUCTED EMISSION TEST .............................................................................................................. 6 6. RADIATION EMISSION TEST ............................................................................................................... 10 7. BANDWIDTH TEST ............................................................................................................................... 15 8. SETUP PHOTOGRAPHS ...................................................................................................................... 16 9. EUT PHOTOGRAPHS ........................................................................................................................... 16 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230607053E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 16 1. VERSION Version No. Date Description 00 Jun. 07, 2023 Original 2. TEST SUMMARY EMC Emission Test Item Section in CFR 47 Result Remark AC Power Line Conducted Emission 15.207 PASS Spurious Emission 15.209(a)(f) PASS 20dB Bandwidth 15.215 PASS Antenna requirement 15.203 PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) Test Facility: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230607053E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 16 3. GENERAL INFORMATION 3.1 Description of Device (EUT) Product Name: Tablet Magnetic Wireless Charger Stand Trade Mark: JSAUX Model No.: SN0303 Model Difference: N/A Serial No.: N/A Hardware version: H1.0 Software version: S1.0 Operation Frequency: 115kHz ~ 205KHz Modulation type: MSK Antenna Type: Inductive loop coil Antenna Antenna gain: 0dBi Power supply: Input: DC 5V/3A, 9V/2A, 12V/1.5A Wireless Output: 5W/7.5W/10W/15W Max. 3.2 Tested System Details None. 3.3 Block Diagram of Test Set-up 3.4 Test Mode Description Mode1. Wireless Output Mode(5W) Mode2. Wireless Output Mode(7.5W) Mode3. Wireless Output Mode(10W) Mode4. Wireless Output Mode(15W) Note: 1. We have evaluated 1%, 50% and 99% battery charging mode, and the worst mode (99%) is showed in this report. 2. All modes have been tested, and the report only shows the results of the worst mode 4. 3.5 Test Auxiliary Equipment Adapter (Provide by test lab): Manufacturer: XIAOMI Model: AD65G I/P: AC 100-240V 50/60Hz O/P: DC 5V/3A, DC 9V/3A, DC 10V/5A, DC 12V/3A, DC 15V/3A, DC 20V/3.25A Mobile phone (Provide by test lab): Manufacturer: SAMSUNG Model: Galaxy S21 5G 3.6 Test Uncertainty Conducted Emission Uncertainty(150KHz-30MHz) : ±2.56dB 20dB Bandwidth : ±0.5kHz Radiated Emission Uncertainty(9KHz-1GHz) : ±3.24dB AC Mains EUT Adapter Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20230607053E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 16 4. TEST INSTRUMENT USED For Conducted Emission Test (843 Shielded Room) Equipment Manufacturer Model Serial Last Cal. Next Cal. 843 Shielded Room ChengYu 843 Room 843 Sep. 20, 2022 Sep. 19, 2025 EMI Receiver R&S ESR 101421 Nov. 05, 2022 Nov. 04, 2023 LISN R&S ENV216 102417 Nov. 05, 2022 Nov. 04, 2023 Clamp COM-POWER CLA-050 431071 Nov. 05, 2022 Nov. 04, 2023 3-Loop Antenna DAZE ZN30401 13021 Nov. 05, 2022 Nov. 04, 2023 ISN T8 Schwarzbeck NTFM 8158 101135 Nov. 05, 2022 Nov. 04, 2023 ISN T5 Schwarzbeck NTFM 8158 101136 Nov. 05, 2022 Nov. 04, 2023 843 Cable 1# ChengYu CE Cable 001 Nov. 05, 2022 Nov. 04, 2023 843 Cable 1# ChengYu CE Cable 002 Nov. 05, 2022 Nov. 04, 2023 For Radiated Emission Test (966 chamber) Equipment Manufacturer Model Serial Last Cal. Next Cal. 966 Chamber ChengYu 966 …

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
