2A9W7-OE10WBluetooth Headphones

HeadphonesX 1 User manual X 1X 1 3.5mm AUX lineX 1 Charging cableX 1 Product schematic description Volume +/Previous track ANC witch on/o Charge port Aux port Volume-/Next track Turn on/Turn o/Play/Pause /Answer the call/End the call Product specicationUsage Instruction (1) Don’t attempt to disassemble the unit and change any part, except there is operation method mentioned in the manual. (2) Don’t expose the unit to liquid, moisture or humidity, since it is not a waterproof product. (3) Disconnect the unit with your BT device and move it to the safe area if the liquid get inside the unit. (4) Don’t assemble or disassemble the unit to avoid electric shock, if there is water on your hands. (5) Don’t expose the unit to extremely high temperature or dispose of the unit in re as it will result in an explosion. (6) Don’t place the unit in an electromagnetic interference environment to avoid malfunction. Packing list ANC BLUETOOTH HEADPHONE Manual Please read all instructions carefully and retain for future use • BT version : • Battery capacity : • Charging time : • Transmission distance : • Horn impedance : • Frequency range : • Speaker size : • Playing time : • Rated input : • Audio interface : • SNR : • Microphone sensitivity : • ANC depth : V5.0 400 mAh About 2.5 hours 10 meters 32Ω±15% 20 Hz-20KHz 40 mm About 15 hours 5V 350mA AUX 115dB±3dB -38dB±3dB -25dB±3dB (All technical information is subject to actual performance) Active Noise cancelling Turn on Earphones charging Earphones fully charged Battery low prompt Turn o ANC mode ANC shut o Reconnect Bluetooth connected Search the Bluetooth device Bluetooth disconnect Red and blue LED light ash alternately Red LED light normally on Red LED light die out Red LED light ash 1 time every 10 seconds. Red and blue LED light die out Green LED light normally on Green LED light die out Red and blue LED light ash alternately Red and blue LED light die out Red and blue LED light ash alternately Red and blue LED light ash alternately Single click: Answer the call/End the call Click twice: Rewind the phone Long press 2 seconds: Reject the call Operating instruction LED light introduction 1. Turn on/Turn o • When the earphones is in turn o states,long press the button for 3 seconds to start the earphone. • When the earphones is in turn on states, long press the button for 3 seconds to power o the earphone. 2. BT pairing Step 1: When the earphones is in turn o states,long press the button for 3 seconds to start the earphone. Step 2: Open the smart device BT list, search and nd “PeopleLink Sonic OE10W”,click it to connect. 3.Switch on/o ANC mode Single Click: Volume up Single click: Play/Pause Long press 2 seconds: Previous track Single click: Volume down Long press 2 seconds: Next track 4.During the music playing 5. Phone hands-free • When the earphones is in non ANC mode,put the switch button up to open the ANC mode. • When the earphones is in ANC mode, put the switch button down to o the ANC mode. BT BT Version Set TS16 My device ANC OFF ANC ON ANC switch button Normal Mode/ANC mode Reminder: After using the headset, please turn o the headphone, meanwhile switch the ANC noise reduction button to the "ANC o" side to avoid running out of power SONIC OE10W FCC statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause u ndesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement in portable exposure condition without restriction. Product Model: PeopleLink Sonic OE10W PMN: Bluetooth Headphones ISED statement English: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. French: Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont conformes aux RSS exemptés de licence d'Innovation, Sciences et Développement économique Canada. L'exploitation est soumise aux deux conditions suivantes : (1) Cet appareil ne doit pas provoquer d'interférences. (2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un fonctionnement indésirable de l'appareil. This device meets the …

Text truncated - open the document above for the full version.

PeopleLink Collaboration Inc 2055 Limestone Rd, STE 200-C Wilmington, Delaware -19808, Wilmington, Delaware, United States The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 5/16/2023 U.S. Agent Designation PeopleLink Collaboration Inc acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2A9W7-OE10W): Name and company of U.S. agent: Formates LLC Physical U.S. address of agent: 1400 Hudson St, Hoboken, New Jersey, 07030, USA FRN of U.S. agent: 0033456468 Email address of U.S. agent: [email protected] Formates LLC acknowledges their obligation to accept service of process on behalf of PeopleLink Collaboration Inc PeopleLink Collaboration Inc with the FRN 0033244518 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature Amit Chowdry PeopleLink Collaboration Inc Signature Abi Aribisala Project Manager Formates LLC 48_[mo del] US_Agent_2.911(d)(7) - U, V04

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 3 EXTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 3 Fig.3 Fig.4 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 3 Fig.5 Fig.6

Label & Label Location Size: 20mm(L)*15mm(W) Model(HVIN): PeopleLink Sonic OE10W IC: 29914-OE10W FCC ID: 2A9W7-OE10W

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 4 INTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 4 Fig.3 Fig.4 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 4 Fig.5 Fig.6 Bluetooth Antenna Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 4 of 4 Fig.7 Fig.8

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 3 RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 3 The example values shown in Table B.2 are for illustration only. Frequency (MHz) Distance (mm) 5 10 15 20 25 30 35 40 45 50 300 39 65 88 110 129 148 166 184 201 217 450 22 44 67 89 112 135 158 180 203 226 835 9 25 44 66 90 116 145 175 207 240 1900 3 12 26 44 66 92 122 157 195 236 2450 3 10 22 38 59 83 111 143 179 219 3600 2 8 18 32 49 71 96 125 158 195 5800 1 6 14 25 40 58 80 106 136 169 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 3 Conducted Power Results Test Mode Channel Frequency (MHz) Measured Peak Output Power (dBm) GFSK 00 2402 -7.67 39 2441 -6.81 78 2480 -6.86 π/4-DQPSK 00 2402 -4.91 39 2441 -4.08 78 2480 -4.09 8-DPSK 00 2402 -4.08 39 2441 -3.48 78 2480 -3.55 Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -8.0 -7.0 -7.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4-DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -5.0 -4.5 -4.5 Tolerance ±(dB) 1.0 1.0 1.0 8-DPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -4.5 -3.5 -4.0 Tolerance ±(dB) 1.0 1.0 1.0 Results Test Mode Channel Frequency (MHz) Max. Tune Up Power (dBm, Peak) Max. Eirp including Tune Up (dBm, Peak) Max. Eirp including Tune Up (mW, Peak) Exemption Limit (mW) GFSK 2402 -7.0 -2.1 0.62 3 2441 -6.0 -1.1 0.78 3 2480 -6.0 -1.1 0.78 3 π/4-DQPSK 2402 -4.0 0.9 1.23 3 2441 -3.5 1.4 1.38 3 2480 -3.5 1.4 1.38 3 8-DPSK 2402 -3.5 1.4 1.38 3 2441 -2.5 2.4 1.74 3 2480 -3.0 1.9 1.55 3 The antenna gain of the EUT for BT is 4.9dBi (Max). the Maximum Eirp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

2.4GHz 3216 Chip Antenna: AAN3216H2P2G45 ______________________________________________________________________________________________________ Application: WLAN, 802.11b/g, Bluetooth, etc... Features SMD, high reliability, ultra Impact, Omni-directional... Part number AAN 3216 - H2 P 2G45 (1) (2) (3) (4) (5) (1)Product Type Chip Antenna (2)Size Code 3.2x1.6mm (3)Type Code H2 (4)Packing Paper Tape (5)Frequency 2.45GHz Electrical Specification W orking Frequency Range 2400 ~2484 MHz Peak Gain 4.9 dBi (Typ.) Impedance 50 Ohm Return loss 10 dB ( Min) Polarization Linear Azimuth Beamwidth Omni-directional Operation Temperature(°C) -40 ~85°C The specification is defined on EVB. Dimension and Terminal Configuration Evaluation Board Reference Dimension (mm) No. Terminal Name L 3.20+-0.15 1 Feeding/Soldering W 1.60+-0.15 2 Soldering/Feeding T 0.55+-0.10 D 0.60+-0.15 P.S : Symmetrical, No direction 2.4GHz 3216 Chip Antenna: AAN3216H2P2G45 ______________________________________________________________________________________________________ PCB Dimension Antenna Layout Reference Unit : mm Component 1, 2,3, 4 are matching circuit Foot Print Unit : mm □: Chip Antenna □: Land Pattern P.S. PCB layout footprint need cover antenna bottom pad Electrical Characteristics Return Loss & Radiation Return Loss Frequency (MHz) S11 (dB) 2400 -16.3 2442 -46.5 2484 -15.9 -40 -30 -20 -10 0 10 20 30 40 0 1 Pwr0 dBm Ch1Start2 GHzStop3.5 GHz Trc1 Trc2 S11 S22 dB Mag dB Mag 10 dB / 10 dB / Ref 0 dB Ref 0 dB Cal int Offs Cal int Offs • M 1 M 2 M 3 2.400000 2.442000 2.484000 GHz GHz GHz -16.312 -46.509 -15.874 dB dB dB S11 M 1 M 2 M 3 8/19/2015, 7:08 AM 2.4GHz 3216 Chip Antenna: AAN3216H2P2G45 ______________________________________________________________________________________________________ Radiation 2.442GHz Frequency 2.442GHz Peak gain 4.9dBi Efficiency 60% Taping Specifications Reel and Taping Specification Reel Specification TYPE SIZE A ψB ψC ψD W ψM 3216 7” 5K/Reel 2.0±0.5 13.5±1.0 21±1.0 60±1.0 11.5±2.0 178±2.0 Tapping Specification Packaging Type A B W E F G H T ψD P Paper Type 3216 1.90±0.20 3.50±0.20 8.0±0.20 1.75±0.10 3.5±0.05 4.0±0.10 2.0±0.05 0.75±0.10 +0.10 1.50 -0 4.0±0.1 Reliability Table 2.4GHz 3216 Chip Antenna: AAN3216H2P2G45 ______________________________________________________________________________________________________ Test ItemProcedure Requirements Ceramic Type Remark (Reference) Electrical Characterization Fulfill the electrical specification User Spec. Thermal Shock 1. Preconditioning: 50 ± 10°C / 1 hr , then keep for 24 ± 1 hrs at room temp. 2. Initial measure: Spec: refer Initial spec. 3. Rapid change of temperature test: -30°C to +85°C; 100 cycles; 15 minutes at Lower category temperature; 15 minutes at Upper category temperature. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 107 Temperature Cycling 1. Initial measure: Spec: refer Initial spec. 2. 100 Cycles (-30°C to +85°C), Soak Mode=1 (2 Cycle/hours). 3. Measurement at 24 ± 2Hours after test condition. No Visible Damage. Fulfill the electrical specification. JESD22 JA104 High Temperature Exposure 1. Initial measure: Spec: refer Initial spec. 2. Unpowered; 500hours @ T=+85°C. 3. Measurement at 24 ± 2 hours after test. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Low Temperature Storage 1. Initial measure: Spec: refer Initial spec. 2. Unpowered: 500hours @ T= -30°C. 3. Measurement at 24 ± 2 hours after test. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 108 Solderability (SMD Bottom Side) Dipping method: a. Temperature: 235 ± 5°C b. Dipping time: 3 ± 0.5s The solder should cover over 95% of the critical area of bottom side. IEC 60384-21/22 4.10 Soldering Heat Resistance (RSH) Preheating temperature: 150 ± 10°C. Preheating time: 1~2 min. Solder temperature: 260 ± 5°C. Dipping time: 5 ± 0.5s No Visible Damage.IEC 60384-21/22 4.10 Vibration5g's for 20 min., 12 cycles each of 3 orientations Note: Use 8"X5" PCB .031" thick 7 secure points on, one long side and 2 secure points at corners of opposite sides. Parts mounted within 2" from any secure point. Test from 10-2000 Hz. No Visible Damage.MIL-STD-202 Method 204 Mechanical Shock Three shocks in each direction shall be applied along the three mutually perpendicular axes of the test specimen (18 shocks) Peak value: 1,500g’s Duration: 0.5ms Velocity change: 15.4 ft/s Waveform: Half-sine No Visible Damage.MIL-STD-202 Method 213 Humidity Bias 1. Humidity: 85% R.H., Temperature: 85 ± 2 °C. 2. Time: 500 ± 24 hours. 3. Measurement at 24 ± 2hrs after test condition. No Visible Damage. Fulfill the electrical specification. MIL-STD-202 Method 106 2.4GHz 3216 Chip Antenna: AAN3216H2P2G45 ______________________________________________________________________________________________________ Revision History Revision Date Content 1 2015/11/13 New issue Board Flex (SMD) 1. Mounting method: IR-Reflow. PCB Size (L:100 × W:40 × T:1.6mm) 2. Apply the load in direction of the arrow until bending reaches 2 mm. No Visible Damage.AEC-Q200 005 AdhesionForce of 1.8Kg for 60 seconds.No Visible Damage Magnification of 20X or greater may be employed for inspection of the mechanical integrity of the device body terminals and body/terminal junction. AEC-Q200 006 Physical Dimension Any applicable method using x10 magnification, micrometers, calipers, gauges, contour projectors, or other measuring equipment, capable of determining the actual specimen dimensions. In accordance with specification. JESD22 JB100

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 1 of 43 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: Bluetooth Headphones Trade Mark: PeopleLink Test Model: PeopleLink Sonic OE10W FCC ID: 2A9W7-OE10W Environmental Conditions Temperature: 25.5C Relative Humidity: 55% ATM Pressure: 100.0 kPa Test Engineer: Anna Hu Supervised by: Hugo Chen NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Channel 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.855 2401.523 2402.378 --- --- 2441 0.927 2440.517 2441.444 --- --- 2480 0.888 2479.514 2480.402 --- --- 2DH5 Ant1 2402 1.245 2401.358 2402.603 --- --- 2441 1.308 2440.319 2441.627 --- --- 2480 1.302 2479.316 2480.618 --- --- 3DH5 Ant1 2402 1.215 2401.349 2402.564 --- --- 2441 1.221 2440.349 2441.570 --- --- 2480 1.224 2479.349 2480.573 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 2 of 43 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 3 of 43 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 4 of 43 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 5 of 43 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.82856 2401.5582 2402.3868 --- --- 2441 0.82663 2440.5521 2441.3787 --- --- 2480 0.82140 2479.5594 2480.3808 --- --- 2DH5 Ant1 2402 1.1827 2401.3829 2402.5656 --- --- 2441 1.1762 2440.3831 2441.5593 --- --- 2480 1.1801 2479.3829 2480.5630 --- --- 3DH5 Ant1 2402 1.1680 2401.3864 2402.5544 --- --- 2441 1.1569 2440.3952 2441.5521 --- --- 2480 1.1588 2479.3927 2480.5515 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 6 of 43 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 7 of 43 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 8 of 43 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 9 of 43 Appendix C: Maximum Peak conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict DH5 Ant1 2402 -7.67 ≤30 PASS 2441 -6.81 ≤30 PASS 2480 -6.86 ≤30 PASS 2DH5 Ant1 2402 -4.91 ≤20.97 PASS 2441 -4.08 ≤20.97 PASS 2480 -4.09 ≤20.97 PASS 3DH5 Ant1 2402 -4.08 ≤20.97 PASS 2441 -3.48 ≤20.97 PASS 2480 -3.55 ≤20.97 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 10 of 43 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 11 of 43 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 12 of 43 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 13 of 43 Appendix D: Carrier frequency separation Test Result TestMode Antenna Channel Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1.008 ≥0.927 PASS 2DH5 Ant1 Hop 1.004 ≥0.872 PASS 3DH5 Ant1 Hop 1.012 ≥0.816 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 14 of 43 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 15 of 43 Appendix E: Time of occupancy Test Result TestMode Antenna Channel BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH5 Ant1 Hop 2.899 110 0.319 ≤0.4 PASS 2DH5 Ant1 Hop 2.904 50 0.145 ≤0.4 PASS 3DH5 Ant1 Hop 2.907 60 0.174 ≤0.4 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 16 of 43 Test Graphs DH5_Ant1_Hop DH5_Ant1_Hop 2DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 17 of 43 2DH5_Ant1_Hop 3DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 18 of 43 Appendix F: Number of hopping channels Test Result TestMode Antenna Channel Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 19 of 43 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 20 of 43 Appendix G: Band edge measurements Test Result TestMode Antenna ChName Channel RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -8.09 -57.98 ≤-28.09 PASS High 2480 -7.10 -58.67 ≤-27.1 PASS Low Hop_2402 -9.01 -60.01 ≤-29.01 PASS High Hop_2480 -7.73 -58.68 ≤-27.73 PASS 2DH5 Ant1 Low 2402 -8.11 -59.02 ≤-28.11 PASS High 2480 -7.33 -59.18 ≤-27.33 PASS Low Hop_2402 -11.31 -59.84 ≤-31.31 PASS High Hop_2480 -9.24 -59.13 ≤-29.24 PASS 3DH5 Ant1 Low 2402 -7.68 -56.39 ≤-27.68 PASS High 2480 -7.09 -58.78 ≤-27.09 PASS Low Hop_2402 -8.04 -60.13 ≤-28.04 PASS High Hop_2480 -7.10 -59.24 ≤-27.1 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 21 of 43 Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 22 of 43 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 2DH5_Ant1_High_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 23 of 43 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 3DH5_Ant1_Low_2402 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 24 of 43 3DH5_Ant1_High_2480 3DH5_…

Text truncated - open the document above for the full version.

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 25 of 43 Appendix H: Conducted Spurious Emission Test Result TestMode Antenna Channel FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference -8.54 -8.54 --- PASS 30~1000 -8.54 -61.77 ≤-28.54 PASS 1000~26500 -8.54 -50.17 ≤-28.54 PASS 2441 Reference -7.73 -7.73 --- PASS 30~1000 -7.73 -60.62 ≤-27.73 PASS 1000~26500 -7.73 -47.8 ≤-27.73 PASS 2480 Reference -7.34 -7.34 --- PASS 30~1000 -7.34 -61.34 ≤-27.34 PASS 1000~26500 -7.34 -49.89 ≤-27.34 PASS 2DH5 Ant1 2402 Reference -8.05 -8.05 --- PASS 30~1000 -8.05 -60.45 ≤-28.05 PASS 1000~26500 -8.05 -49.8 ≤-28.05 PASS 2441 Reference -7.33 -7.33 --- PASS 30~1000 -7.33 -60.3 ≤-27.33 PASS 1000~26500 -7.33 -50.6 ≤-27.33 PASS 2480 Reference -8.11 -8.11 --- PASS 30~1000 -8.11 -60.86 ≤-28.11 PASS 1000~26500 -8.11 -51.79 ≤-28.11 PASS 3DH5 Ant1 2402 Reference -9.24 -9.24 --- PASS 30~1000 -9.24 -61.08 ≤-29.24 PASS 1000~26500 -9.24 -50.48 ≤-29.24 PASS 2441 Reference -7.11 -7.11 --- PASS 30~1000 -7.11 -60.99 ≤-27.11 PASS 1000~26500 -7.11 -49.61 ≤-27.11 PASS 2480 Reference -7.10 -7.10 --- PASS 30~1000 -7.10 -61.23 ≤-27.1 PASS 1000~26500 -7.10 -51.2 ≤-27.1 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 26 of 43 Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 27 of 43 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 DH5_Ant1_2441_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 28 of 43 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 DH5_Ant1_2480_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 29 of 43 2DH5_Ant1_2402_0~Reference 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 30 of 43 2DH5_Ant1_2441_0~Reference 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 31 of 43 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 32 of 43 3DH5_Ant1_2402_0~Reference 3DH5_Ant1_2402_30~1000 3DH5_Ant1_2402_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 33 of 43 3DH5_Ant1_2441_0~Reference 3DH5_Ant1_2441_30~1000 3DH5_Ant1_2441_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 34 of 43 3DH5_Ant1_2480_0~Reference 3DH5_Ant1_2480_30~1000 3DH5_Ant1_2480_1000~26500 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 35 of 43 Appendix I: Duty Cycle Test Result TestMode Antenna Channel Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 1/T[kHz] DH5 Ant1 2402 2.89 3.75 77.07 0.35 2441 2.90 3.75 77.33 0.34 2480 2.90 3.75 77.33 0.34 2DH5 Ant1 2402 2.90 3.75 77.33 0.34 2441 2.91 3.76 77.39 0.34 2480 2.90 3.75 77.33 0.34 3DH5 Ant1 2402 2.90 3.75 77.33 0.34 2441 2.90 3.75 77.33 0.34 2480 2.90 3.75 77.33 0.34 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 36 of 43 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 37 of 43 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 38 of 43 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A9W7-OE10W Report No.: TZ230304194-E Page 39 of 43 Appendix J: Emissions in Restricted Bands Test Result TestMode Antenna ChName Channel Detector Freq(MHz) Result(dBm) Limit(dBm) Verdict DH5 Ant1 Low 2402 AV 2310.000 -56.19 ≤-41.20 PASS AV 2376.125 -55.8 ≤-41.20 PASS AV 2390.000 -55.93 ≤-41.20 PASS Peak 2310.000 -50.13 ≤-21.20 PASS Peak 2384.420 -46.3 ≤-21.20 PASS Peak 2390.000 -48.37 ≤-21.20 PASS High 2480 AV 2483.500 -54.76 ≤-41.20 PASS AV 2483.520 -54.76 ≤-41.20 PASS AV 2500.000 -55.26 ≤-41.20 PASS Peak 2483.500 -48.82 ≤-21.20 PASS Peak 2496.800 -45.55 ≤-21.20 PASS Peak 2500.000 -46.15 ≤-21.20 PASS 2DH5 Ant1 Low 2402 AV 2310.000 -56.2 ≤-41.20 PASS AV 2389.145 -55.77 ≤-41.20 PASS AV 2390.000 -55.87 ≤-41.20 PASS Peak 2310.000 -48.13 ≤-21.20 PASS Peak 2357.540 -44.91 ≤-21.20 PASS Peak 2390.000 -49.88 ≤-21.20 PASS High 2480 AV 2483.500 -54.52 ≤-41.20 PASS AV 2483.520 -54.52 ≤-41.20 PASS AV 2500.000 -55.19 ≤-41.20 PASS Peak 2483.500 -49.38 ≤-21.20 PASS Peak 2499.600 -44.01 ≤-21.20 PASS Peak 2500.000 -49.01 ≤-21.20 PASS 3DH5 Ant1 Low 2402 AV 2310.000 -56.19 ≤-41.20 PASS AV 2382.845 -55.8 ≤-41.20 PASS AV 2390.000 -55.92 ≤-41.20 PASS Peak 2310.000 -48.64 ≤-21.20 PASS Peak 2318.690 -46.18 ≤-21.20 PASS Peak 2390.000 -48.28 ≤-21.20 PASS High 2480 AV 2483.500 -54.48 ≤-41.20 PASS AV 2483.520 -54.48 ≤-41.20 PASS AV 2500.000 -55.18 ≤-41.20 PASS Peak 2483.500 -47.71 ≤-21.20 PASS Peak 2…
