2A9WO-03AMagnetic Wireless Power Bank

FCC statement: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. During the operation of device a distance of 0 cm surrounding the device and 0 cm above the top surface of thedevice must be respected.

Sincerely, Name/Title： Xiaoyan Ni/PM Company: SHENZHEN XPADSP TECHNOLOGY CO.,LTD Address: Room 403, Building C8, Zhigu, No. 6, Xiawei Industrial Zone 1st Road, Zhangkengjing Community,Longhua District,Shenzhen China Phone: 13620214161 Fax: N/A E-Mail: [email protected]

FCC ID: 2A9WO-03A External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A9WO-03A Photo 4 Photo 5 Photo 6 FCC ID: 2A9WO-03A Photo 7

Label and Location Size: L: 2.0cm*W: 1.5cm Label and Location Model: 03A FCC ID : 2A9WO-03A

FCC ID: 2A9WO-03A Internal Photos of the EUT Photo 1 Photo 2 Photo 3 BLE PCB antenna FCC ID: 2A9WO-03A Photo 4 Photo 5 Photo 6

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : CTA22122100402 2A9WO-03A Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Jan. 03, 2023 Representative Laboratory Name .: Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Address ............................................ : Room 403, Building C8, Zhigu, No. 6, Xiawei Industrial Zone 1st Road, Zhangkengjing Community,Longhua District,Shenzhen China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Magnetic Wireless Power Bank Trade Mark ....................................... : Weetla Manufacturer .................................... : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Model/Type reference....................... : 03A Listed Models .................................. : V01, V02, V03, V04, V05, V06, V07, V08, V09 Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : USB-C Input: DC 5V, 2.4A/9V, 2A USB-C Output: DC 5V, 2.4A Wireless Output: 5W Result................................................ : PASS Report No.: CTA22122100402 Page 2 of 14 Equipment under Test : Magnetic Wireless Power Bank Model /Type : 03A Listed Models : V01, V02, V03, V04, V05, V06, V07, V08, V09 Applicant : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Address : Room 403, Building C8, Zhigu, No. 6, Xiawei Industrial Zone 1st Road, Zhangkengjing Community,Longhua District,Shenzhen China Manufacturer : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Address : Room 403, Building C8, Zhigu, No. 6, Xiawei Industrial Zone 1st Road, Zhangkengjing Community,Longhua District,Shenzhen China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22122100402 Page 3 of 14 Contents 1 S U M M A R Y ............................................................................ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Special Accessories 5 1.5 Modifications 5 2 T E S T E N V I R O N M E N T .............................................................. 6 2.1 Address of the test laboratory 6 2.2 Test Facility 6 2.3 Environmental conditions 6 2.4 Summary of measurement results 7 2.5 Statement of the measurement uncertainty 7 2.6 Equipments Used during the Test 7 3 T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 8 3.1 Applicable Standard 8 3.2 Limit 8 3.3 Test Setup 8 3.4 Measurement Procedure 9 3.5 Test Result of E and H field Strength 9 3.6 Equipment Approval Considerations 13 3.7 Conclusion 13 4 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 14 Report No.: CTA22122100402 Page 4 of 14 1 S U M M A R Y 1.1 General Remarks Date of receipt of test sample : Dec. 21, 2022 Testing commenced on : Dec. 21, 2022 Testing concluded on : Jan. 03, 2023 1.2 Product Description Product Name: Magnetic Wireless Power Bank Model/Type reference: 03A Hardware version: V1.0 Software version: V1.0 Test samples ID: CTA221221004-1# (Engineer sample), CTA221221004-2# (Normal sample) Power supply: USB-C Input: DC 5V, 2.4A/9V, 2A USB-C Output: DC 5V, 2.4A Wireless Output: 5W Adapter information (Auxiliary test supplied by test Lab） Model: EP-TA20CBC Input: AC 100-240V 50/60Hz Output: DC 9V 2A Operation frequency: 110KHz - 205KHz Modulation type: ASK Antenna type: Loop coil antenna Antenna Gain: 0 dBi(Max) 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Conditions Description Exposure conditions TM1 EUT + iphone (Battery Level ＜1%) Mobile Portable Record TM2 EUT + iphone (Battery Level 50%) Mobile Portable Record TM3 EUT + iphone (Battery Level＞99%) Mobile Portable Record TM4 AC/DC Adapter (9V/2.0A) + EUT + Full load Mobile Portable Record TM5 AC/DC Adapter (9V/2.0A) + EUT + Half load Mobile Portable Record TM6 AC/DC Adapter (9V/2.0A) + EUT + Empty load Mobile Portable Record TM7 AC/DC Adapter (5V/2.4A) + EUT + Full load Mobile Portable Pre-Tested TM8 AC/DC Adapter (5V/2.4A) + EUT + Half load Mobile Portable Pre-Tested TM9 AC/DC Adapter (5V/2.4A) + EUT + Empty load Mobile Portable Pre-…

Text truncated - open the document above for the full version.

1. Antenna Description: Antenna type Loop coil antenna Model 03A Frequency range 110KHz~205KHz Manufacturer SHENZHEN XPADSP TECHNOLOGY CO.,LTD Gain 0.00 dBi 2. Antenna Photo: Length:40.15mm diameter:10.84mm

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT Report Reference No. .................... : FCC ID. ........................................... : CTA22122100401 2A9WO-03A Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Amy Wen Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Jan. 03, 2023 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ........................................... : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ........................... : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Address ........................................... : Room 403, Building C8, Zhigu, No. 6, Xiawei Industrial Zone 1st Road, Zhangkengjing Community,Longhua District,Shenzhen China Test specification ........................... : Standard ........................................... : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Magnetic Wireless Power Bank Trade Mark ....................................... : Weetla Manufacturer .................................... : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Model/Type reference ...................... : 03A Listed Models .................................. : V01, V02, V03, V04, V05, V06, V07, V08, V09 Modulation Type ............................... : ASK Operation Frequency ....................... : From 110KHz~205KHz Rating ............................................... : USB-C Input: DC 5V, 2.4A/9V, 2A USB-C Output: DC 5V, 2.4A Wireless Output: 5W Result ............................................... : PASS Report No.: CTA22122100401 Page 2 of 24 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Magnetic Wireless Power Bank Model /Type : 03A Listed Models : V01, V02, V03, V04, V05, V06, V07, V08, V09 Applicant : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Address : Room 403, Building C8, Zhigu, No. 6, Xiawei Industrial Zone 1st Road, Zhangkengjing Community,Longhua District,Shenzhen China Manufacturer : SHENZHEN XPADSP TECHNOLOGY CO.,LTD Address : Room 403, Building C8, Zhigu, No. 6, Xiawei Industrial Zone 1st Road, Zhangkengjing Community,Longhua District,Shenzhen China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22122100401 Page 3 of 24 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Description of the test mode 5 2.4 Special Accessories 5 2.5 Modifications 5 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 The 20dB bandwidth 17 4.4 Antenna Requirement 18 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 19 6 PH O T O S O F T H E E U T ........................................................... 20 Report No.: CTA22122100401 Page 4 of 24 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C (Section 15.207): Conducted limits. FCC Rules and Regulations Part 15 Subpart C (Section 15.209): Radiated emission limits; general requirements. ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: CTA22122100401 Page 5 of 24 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Dec. 21, 2022 Testing commenced on : Dec. 21, 2022 Testing co…

Text truncated - open the document above for the full version.

FCC ID: 2A9WO-03A Test Setup Photos of the EUT
