2A9X2STISKM2001Key Panel Smart Key Manager v2

Table of contents Chapter 1 : Product description .............................................................................................................. 2 Chapter 2 : Installation procedure .......................................................................................................... 4 Example of layout/installation ............................................................................................................ 4 Wall mounting instructions ................................................................................................................. 5 Key holder Assembly Instruction ...................................................................................................... 11 Device information ............................................................................................................................... 12 Specifications .................................................................................................................................... 12 Maintenance operation .................................................................................................................... 12 Precautions ....................................................................................................................................... 12 Copyright ........................................................................................................................................... 14 Chapter 1: Product description A SmartKey Manager Skv2 is composed of the following elements: Central Unit (UC) Key panel (KP) Badges Key rings (with unique identification) Mounting template trunking Central Unit/Panels 270mm: 270mm Trunking Mounting Template Panels/Panels 334mm 334 mm Wall mounting bracket Central Unit and Key Panels: Chapter 2 : Installation procedure Example of layout/installation Any configuration can be made with a Central Unit and Key Panels on the right and left or above and below. Note: No panels can be installed below and above the Central Unit Wall mounting instructions • Position the wall mounting bracket Central Unit and Key Panels Wall bracket Central Unit and Key Panels Mounting template trunking Central Unit/Panels 270mm Mounting template trunking Central Unit/Panels 270mm Trunking Mounting Template 334mm • Position a spirit level • Point out the 4 holes of the bracket for drilling on the wall • Drill 4 holes Ø8mm, minimum depth 50 mm for the wall plugs with the 180mm x 110mm centers of the wall bracket • (Use suitable plugs according to the type of wall) • Fixing the support with 4 screws, diameter 5 x 50mm • Use the appropriate trunking (Central Unit/Panels or Panels/Panels) to fix the other supports. • (For information: the channel is used as a drilling template, but it must be kept on the assemblies because it is also used to pass the cables) NOTE: This is the same principle for fixing the central unit. • Hook the key panels or the central unit (as shown in the picture) • Fixing the key panel to the mounting bracket with the CHC screw M5x10 Connection to the electrical network and Ethernet network • Open the central unit by unlock the lock located at the top of the Central Unit • Unscrew the 2 CHC M3x8 screws. • Flip the box to access inside. • Plug RJ45 cable (cat6 & S/FTP type) and power cable • Put back the box and screw it with 2 CHC M3x8 screws • Connect the earth to the chassis by sliding the crimped earth cable from the outside to the inside of the central unit through the wall bracket (as shown below). Key holder Assembly Instruction The RFID key ring consists of: • 1 Key ring body • 1 RFID tag holder • A handle allowing to attach one or several elements such as keys or others • A self-breaking screw allowing to make the shackle unremovable after installation • 1 RFID tag • Put the key(s) in the key ring • Position the tag holder inside the key ring body, step 1 • Press firmly to place the shackle into the key ring body, step 2 • Tighten the self-tightening screw until the screw breaks, step 3 RFID Tag Support RFID Tag Self-tightening screw Key ring body Keyring handle 1. 1 2 3 Device information Specifications Central Unit Key Panel RFID Frequency 125kHz – 13.56MHz 125kHz Protection Factor IP40 IP40 Temperature 5 °C to +45 °C 5 °C to +45 °C Storage Temperature (power off) 0 to 60°C 0 to 60°C Dimensions (L x W x D) 315mm x 95mm x 360mm 403mm x 96mm x 360mm Weight 5 kg 8.5 kg Power supply 80-264V CA, 113-370V CC 12VCC Via Central Unit Max Consumption 80,4W – 6,7A for the full system Cabinet material Steel + Polyester paint Steel + Polyester paint Plastic part material POLYLAC PA-707K/ Iupital F20- 03 POLYLAC PA-707K/ Iupital F20-03 Ethernet Interface 100 Mbit Max consumption 80,4W – 6,7A for the full system Max no of key panel 8 ethernet interface 10/100 Mbit with IEEE 1588 Display Size 10.1 inchs (16:9 Diagonal) Operating System Embedded Linux Maintenance operation 1. Fuse replacement: Use Ø5x20mm - 2.5A Time Delay / 250VAC (certified to IEC 60127-6) 2. Replacement of a key entry, contact your dealer 3. Replacement of the touch screen, contact your dealer 4. Replacement of a key ring, contact your dealer Precautions Important safety instructions 1. Read these instructions carefully. 2. Keep these instructions. 3. Follow all warnings. 4. Follow all instructions. Warning/Precautions • Do not position the cabinet in a corridor leading to an emergency exit where it could impede evacuation. • Electrical connections must be made by a professionally trained and authorized electrician. • The earth wire of the system must be correctly and continuously connected to ground. • Before powering up, the correct insulation of the cables, the earthing of the elements and the correct connection of the 220V cables to the power supply must be carried out. • Install the Skv2 out of reach of children. • The wall where the Smart Key Manager is installed must be able to support at least 5 kg per Central Unit and 10 kg p…

Text truncated - open the document above for the full version.

SERV TRAYVOU INTERVERROUILLAGE SA au capital de 1 524 490,17- RCS 391 438 967 NACE 2572Z TVA/VAT n° FR 90391438967 Siège social : 1ter rue du Marais 93106 Montreuil cedex France - Tél. : +33 1 48 18 15 15 fax. +33 1 48 59 68 50 Email : [email protected] Web : www.servtrayvou.com Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-02-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2A9X2STISKM2001 Serv Trayvou Interverrouillage sought is not section 2.903 of the FCC rules. Sincerely, Romain kouppé de ker martin Global product development manager

SERV TRAYVOU INTERVERROUILLAGE SA au capital de 1 524 490,17- RCS 391 438 967 NACE 2572Z TVA/VAT n° FR 90391438967 Siège social : 1ter rue du Marais 93106 Montreuil cedex France - Tél. : +33 1 48 18 15 15 fax. +33 1 48 59 68 50 Email : [email protected] Web : www.servtrayvou.com Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-02-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2A9X2STISKM2001 Serv Trayvou Interverrouillage the applicant is not identified on the Covered List as an ent Sincerely, Romain kouppé de ker martin Global product development manager

SERV TRAYVOU INTERVERROUILLAGE SA au capital de 1 524 490,17€- RCS 391 438 967 – NACE 2572Z – TVA/VAT n° FR 90391438967 Siège social : 1ter rue du Marais – 93106 Montreuil cedex France - Tél. : +33 1 48 18 15 15 – fax. +33 1 48 59 68 50 Email : [email protected] – Web : www.servtrayvou.com Date : 12/01/2023 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: 2A9X2STISKM2001 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the supplier Declaration of Conformity procedure to the Class B digital devices portion of this composite filing. Note: We understand that devices subject to the SDoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to- government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telecom MRA are not recognized by the FCC to test for the SDoC procedure. Regards, Date :12/01/2023 By Romain kouppé de ker martin Global product development manager

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03/31/2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2A9X2STlSKM2001 Serv Trayvou Interverrouillage ("the applicant") certifies that, as of the date of the filing of the application, Kirk Key Interlock Company LLC is our designated U.S. agent for service of process for the above referenced FCC ID. Serv Trayvou Interverrouillage accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Kirk Key Interlock Company LLC accepts, as of the date of the fifing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Kirk Key Interlock Company FRN : 0033603531 Address: 9048 Meridian Circle, NW - North Canton, OH 44720, USA Contact Person: Matt Define Tel.: 330.417.9307 Email: [email protected] Sincerely, Serv Trayvou Interverrouillage Kirk Key Interlock Company LLC Romain kouppé de der martin Global product development Manager Matt Define VP Service & Solution SERV TRAWOU INTERVERROUILLAGE SA au capital de 1 524 490,17€. RCS 391 438 967 - NACE 2572- TVANAT n o FR 90391438967 Siége social : Iter rue du Marais — 93106 Montreuil cedex France - Tél. : +33 1 48 18 15 15 — fax. +33 1 48 59 68 50 Email : [email protected] - Web : www.servtrayvou.com

SERV TRAYVOU INTERVERROUILLAGE SA au capital de 1 524 490,17€- RCS 391 438 967 – NACE 2572Z – TVA/VAT n° FR 90391438967 Siège social : 1ter rue du Marais – 93106 Montreuil cedex France - Tél. : +33 1 48 18 15 15 – fax. +33 1 48 59 68 50 Email : [email protected] – Web : www.servtrayvou.com Attn: TIMCO Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 Authority to Act as Agent FCC ID: 2A9X2STISKM2001 On our behalf, I appoint M. Mathieu DUMESNIL from Emitech Angers, 21 rue de la Fuye PA de Lanserre, 49610 Juigné sur Loire FRANCE, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by TIMCO Engineering Inc., still resides with Serv Trayvou Interverrouillage. This authorization is valid until further written notice from Serv Trayvou Interverrouillage. Date :12/01/2023 By Romain kouppé de ker martin Global product development manager

SERV TRAYVOU INTERVERROUILLAGE SA au capital de 1 524 490,17€- RCS 391 438 967 – NACE 2572Z – TVA/VAT n° FR 90391438967 Siège social : 1ter rue du Marais – 93106 Montreuil cedex France - Tél. : +33 1 48 18 15 15 – fax. +33 1 48 59 68 50 Email : [email protected] – Web : www.servtrayvou.com Attn: TIMCO Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 Confidentiality Request regarding application for certification of FCC ID: 2A9X2STISKM2001 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram BlkDia.pdf Schematics Schem.pdf Operational Description OpDes.pdf Parts List PartsLst.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name External Photos ExtPho.pdf Internal Photos IntPho.pdf User Manual UserManEN.pdf Test Setup Photos Setup.pdf For 180 days pursuant to KDB 726920 D01. Sincerely, Date :01/02/2023 By Romain kouppé de ker martin Global product development manager

Siège Social : Emitech – 3 avenue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES B 344 545 645 - APE 7112B Attn: TIMCO Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 FCC ID: 2A9X2STISKM2001 Justification statement for antenna I confirm that all measurements were performed radiated (as might be the case for Part 15.249 devices) and therefore additional antenna gain documentation is not required. Date :31 January 2023 By Mathieu Dumesnil Radio Technical Manager

FCC ID : 2A9X2STISKM2001 System Key Panel + Central Unit FCC ID : 2A9X2STISKM2001 FCC ID : 2A9X2STISKM2001 FCC ID : 2A9X2STISKM2001 FCC ID : 2A9X2STISKM2001 Key Panel FCC ID : 2A9X2STISKM2001 FCC ID : 2A9X2STISKM2001

FCC ID: 2A9X2STISKM2001

Product: Key Panel Smart Key Manager v2 Company name: Serv Trayvou Interverrouillage Address: 1 Ter Rue du Marais, 93100 Montreuil FCC ID: 2A9X2STISKM2001 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID : 2A9X2STISKM2001 Page 1/9 FCC ID : 2A9X2STISKM2001 Page 2/9 FCC ID : 2A9X2STISKM2001 Page 3/9 FCC ID : 2A9X2STISKM2001 Page 4/9 FCC ID : 2A9X2STISKM2001 Page 5/9 Antenna location FCC ID : 2A9X2STISKM2001 Page 6/9 FCC ID : 2A9X2STISKM2001 Page 7/9 FCC ID : 2A9X2STISKM2001 Page 8/9 FCC ID : 2A9X2STISKM2001 Page 9/9 Antenna location

S 51 RTY 000 EMF 00006 [ 0 2 ] Siège Social : Emitech – 3 avenue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES B 344 545 645 - APE 7112B REM-EMIESS22N617SER-03Av0 MPE test report According to the standard: CFR 47 FCC PART 15 Equipment under test: Key Panel Smart Key Manager v2 FCC ID: 2A9X2STISKM2001 Company: SERV TRAYVOU INTERVERROUILLAGE Distribution: Mrs TRAN (Company: SERV TRAYVOU INTERVERROUILLAGE) Number of pages: 5 Technical Verification and Quality Approval Ed. Date Modified Page(s) Name and Function Visa 0 26-Jan-23 Creation M. DUMESNIL, Radio Laboratory Manager Duplication of this document is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Information in italics are declared by the manufacturer/customer and are under his responsibility REM-EMIESS22N617SER-03Av0 Page 2/5 DESIGNATION OF PRODUCT: Key Panel Smart Key Manager v2 Serial number (S/N): Prototype Reference / model (P/N): SKM2KP000 Software version: V1.0.0 Hardware version: V2.0.0 MANUFACTURER: SERV TRAYVOU INTERVERROUILLAGE COMPANY SUBMITTING THE PRODUCT: Company: SERV TRAYVOU INTERVERROUILLAGE Address: 1 TER RUE DU MARAIS BATIMENT B 93100 - MONTREUIL FRANCE Responsible: Mrs TRAN Person(s) present during the tests: Mr KOUPPE DE KER MARTIN (The first day) DATES OF TEST: From 26-Sep-22 to 3-Oct-22 TESTING LOCATION: EMITECH ANGERS laboratory at JUIGNE SUR LOIRE (49) FRANCE FCC Accredited under US-EU MRA Designation Number: FR0009 Test Firm Registration Number: 873677 TESTED BY: B. VOVARD VISA: WRITTEN BY: B. VOVARD REM-EMIESS22N617SER-03Av0 Page 3/5 CONTENTS TITLE PAGE 1. INTRODUCTION ....................................................................................................................................... 4 2. PRODUCT DESCRIPTION ....................................................................................................................... 4 3. NORMATIVE REFERENCE ...................................................................................................................... 5 4. RF EXPOSURE ......................................................................................................................................... 5 REVISIONS HISTORY Revision Date Modified pages Modifications 0 11-Jan-23 / Creation REM-EMIESS22N617SER-03Av0 Page 4/5 1. INTRODUCTION This report presents the results of radio test carried out on the following radio equipment: Key Panel Smart Key Manager v2, in accordance with normative reference. The equipment under test integrates two parts:  125 kHz / 13.56MHz Elatec GmbH TWN4 MultiTech M (FCCID: WP5TWN4F17 / IC: 7948A-TWN4F17) module already certified (Central Unit).  125 kHz function not already certified (Key Panel). This report concern the 125 kHz function of the Key Panel. 2. PRODUCT DESCRIPTION Class: B Utilization: Residential use Antenna type and gain: integral antenna (unknown gain) Operating frequency: 125 kHz Number of channels: 1 Channel spacing: Not concerned Power source: 120 Vac 60 Hz Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. REM-EMIESS22N617SER-03Av0 Page 5/5 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 (2022) Radio Frequency Devices ANSI C63.10 2013 Procedures for ComplianceTesting of Unlicensed Wireless Devices. 447498 D04 Interim General RF Exposure Pocedures and Equipment Authorization Policies for Mobile and RF Exposure Guidance v01 Portable Devices 4. RF EXPOSURE In accordance with KDB 447498 D04 Interim General RF Exposure Guidance v01. 1-mW Test Exemption according paragraph 2.1.2 Maximum measured power = 55.88 dBμV/m = 1.87 x 10 -7 mW at 125 kHz with P = (E×d) 2 / (30×Gp) with d = 3 m and Gp = 1 The equipment fulfils the requirements on 1-mW Test Exemption according §1.1307(b)(3)(i)(A).

Siège Social : Emitech - 3, rue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B S51 RTY 000 INT 00018 [ 0 1 ] LIST OF ACCREDITED SITES AND SCOPE AVALAIBLE ON WWW.COFRAC.FR TESTING ACCREDITATIONS N° 1-0826, 1-0827, 1- 1925, 1-2069,1-2070, 1-2206, 1-2376 & 1-6086 RRA-EMIESS22N617SER-03Av0 Certification Radio test report According to the standard: CFR 47 FCC PART 15 RSS GEN – Issue 5 RSS 210 - Issue 10 Equipment under test: Key Panel Smart Key Manager v2 FCC ID: 2A9X2STISKM2001 IC NUMBER: 29944-STISKM2001 Company: SERV TRAYVOU INTERVERROUILLAGE Distribution : Mrs TRAN (Company: SERV TRAYVOU INTERVERROUILLAGE) Number of pages: 23 with 1 appendix Technical Verification and Quality Approval Ed. Date Modified Page(s) Name and Function Visa 0 26-Jan-23 Creation M. DUMESNIL, Radio Laboratory Manager Duplication of this document is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Information in italics are declared by the manufacturer/customer and are under his responsibility RRA-EMIESS22N617SER-03Av0 Page 2/23 DESIGNATION OF PRODUCT: Key Panel Smart Key Manager v2 Serial number (S/N): Prototype Reference / model (P/N): SKM2KP000 Software version: V1.0.0 Hardware version: V2.0.0 MANUFACTURER: SERV TRAYVOU INTERVERROUILLAGE COMPANY SUBMITTING THE PRODUCT: Company: SERV TRAYVOU INTERVERROUILLAGE Address: 1 TER RUE DU MARAIS BATIMENT B 93100 - MONTREUIL FRANCE Responsible: Mrs TRAN Person(s) present during the tests: Mr KOUPPE DE KER MARTIN (The first day) DATES OF TEST: From 26-Sep-22 to 3-Oct-22 TESTING LOCATION: EMITECH ANGERS laboratory at JUIGNE SUR LOIRE (49) FRANCE FCC Accredited under US-EU MRA Designation Number: FR0009 Test Firm Registration Number: 873677 ISED Accredited under CANADA-EU MRA Designation Number: FR0001 Industry Canada Registration Number: 4452A TESTED BY: B. VOVARD VISA: WRITTEN BY: B. VOVARD RRA-EMIESS22N617SER-03Av0 Page 3/23 CONTENTS TITLE PAGE 1. INTRODUCTION ....................................................................................................................................... 4 2. PRODUCT DESCRIPTION ....................................................................................................................... 4 3. NORMATIVE REFERENCE ...................................................................................................................... 5 4. TEST METHODOLOGY ............................................................................................................................ 6 5. TEST EQUIPMENT CALIBRATION DATES ............................................................................................ 7 6. TESTS RESULTS SUMMARY .................................................................................................................. 8 7. MEASUREMENT UNCERTAINTY ...........................................................................................................10 8. AC CONDUCTED EMISSION ..................................................................................................................11 9. OCCUPIED BANDWIDTH .......................................................................................................................14 10. RADIATED EMISSION LIMITS; GENERAL REQUIREMENTS ..............................................................16 APPENDIX 1: TEST EQUIPMENT LIST ........................................................................................................................... 23 REVISIONS HISTORY Revision Date Modified pages Modifications 0 11-Jan-23 / Creation RRA-EMIESS22N617SER-03Av0 Page 4/23 1. INTRODUCTION This report presents the results of radio test carried out on the following radio equipment: Key Panel Smart Key Manager v2, in accordance with normative reference. The equipment under test integrates two parts:  125 kHz / 13.56MHz radio module already certified (Central Unit) - Elatec GmbH TWN4 MultiTech M (FCCID: WP5TWN4F17 / IC: 7948A-TWN4F17),  125 kHz function not already certified (Key Panel), This report concerns only 125 kHz radio part of the Key Panel. The EUT possesses 16 antennas 125 kHz, only fundamental and harmonics are checked on 16 antennas, others measurements are realized on the most powerful antenna. 2. PRODUCT DESCRIPTION Class: B Utilization: Residential use Antenna type and gain: integral antenna (unknown gain) Operating frequency: 125 kHz Number of channels: 1 Channel spacing: Not concerned Power source: 120 Vac 60 Hz Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. RRA-EMIESS22N617SER-03Av0 Page 5/23 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 FCC Part 15 (2022) Radio Frequency Devices ANSI C63.10 2013 Procedures for ComplianceTesting of Unlicensed Wireless Devices. RSP-100 Issue 12, August 2019 Certification of Radio Apparatus and Broadcasting equipment RSS-Gen Issue 5, April 2018 General Requirements for Compliance of Radio Apparatus RSS-210 Issue 10, December 2019 Licence-Exempt Radio Apparatus: Category I equipment. RRA-EMIESS22N617SER-03Av0 Page 6/23 4. TEST METHODOLOGY Radio performance tests procedures given in CFR 47 part 15: Subpart C – Intentional Radiators Paragraph 203: Antenna requirement Paragraph 205: Restricted bands of operation Para…

Text truncated - open the document above for the full version.

Ground plane Ground plane FCC ID : 2A9X2STISKM2001 Open area setup Below 30 MHz Turntable 1: Equipment Under Test 2: Measurement antenna 3: Measurement equipment Between 30 MHz and 1 GHz Turntable 1: Equipment Under Test 2: Measurement antenna 3: Measurement equipment 1 2 Antenna mast with range 1 m to 4 m 0.8 m 3 Distance : 10 m 1 2 Antenna height: 1 m 0.8 m 3 Distance : 10 m Installation of Equipment Under Test Open area test site Measure below 30 MHz Measure between 30 MHz to 200 MHz Measure between 200 MHz to 1000 MHz Conducted measurement setup
