2A9XH-DGDCS101Spinning cycle

LYDSTO SPINNING BIKE S1 NSTRUCTION MANUAL CONNECTION WITH APPS VIA BLUETOOTH This Bluetooth module integrates bluetooth wireless technology that allows the connection with APPS such as Kinomap and Zwift. Active the Bluetooth on your Smartphone or Tablet. Install and open the app and register representative log in. Add the exercise device as follows: 1.Switch to "More" in the lower left corner of APPClick "Fitness Equipment Management". 2.Click the "+" in the upper right corner and press Add fitness equipment. 3.Select the machine type to add. 4.Select the link you want to connect in the following table Connected Bluetooth Union Standard Protocol. 5.Wait for the search list, select Click the corresponding device to pair. 6.Manually enter the brand of the device And model. (Lydsto S1) 7.Select the currently connected device and click the "Settings" button on the right. 8.Select "Heart Rate" and " Sensor" to add heart rate device and sensor 6.Sensor device pairing completion point Click the "Save" button in the upper right corner. Product Name Spinning bike Product Model 120kg XD-DGDCS101 Maximum bearing capacity Product Parameters Certificate of Conformity Checked already Manufacturer：Guangdong Xiaoda Technology Co.,LTD. Address:Room ���, No. �, Songhu Zhigu R&D Center, No. �,Renju Road, Liaobu Town, Dongguan City, Guangdong Province Service Hotline：+�� ���-���-���� Lydsto Kondisyon Bisikleti S1 Kullanım Kılavuzu Güvenlik Talimatları Uyarı: Ciddi yaralanma riskini düşürmek için ürünü kullanmadan aşağıdaki güvenlik talimatlarını okuyun 1.Cihazın üzerine yapıştırılmış bütün uyarıları okuyun. Bu kılavuzdaki bütün güvenlik talimatlarını takip edin. 2.Cihazı kullanmadan önce bu kılavuzu dikkatlice okuyun ve kavrayın. Cihazı kullanmadan önce doğru bir şekilde kurulduğundan ve bütün bağlantıların sıkıldığından emin olun. 3.Çocukların ya da evcil hayvanların cihazla oynamalarına izin vermeyin. Cihaz çalışırken çocukları ve evcil hayvanları cihazdan uzak tutun. 4.Bu cihaz 14 yaşının altındaki çocuklar ve hamile kadınlar için uygun değildir. 5.Cihaz, yer seviyesinde sert bir zemine ya da kısa tüylü bir halının üzerine yerleştirilmelidir. Cihazı gevşek halıların ya da düz olmayan zeminlere yerleştirmeyin. 6.Her kullanımdan önce eskimiş veya gevşek parçalar olabileceğinden cihazı kontrol edin. 7.Cihazı kullanmadan önce eskimiş veya gevşemiş parçaları değiştirin / sıkın. 8.Cihazın hareketli parçalarının içine parmağınızı veya başka bir nesneyi sokmayın. 9.Cihazın etrafına herhangi keskin bir cisim yerleştirmeyin. Cihazın açık kısımlarına herhangi bir cisim düşürmeyin veya sokmayın. 10.Her zaman fiziksel gücünüze ve esneklik seviyenize en uygun olan antrenmanı seçin. Limitlerin- izi bilin ve ona göre göre çalışın. Antrenman yaparken her zaman akla uygun olanı yapın. 11.Cihazı kullanırken gevşek ya da sarkan kıyafetler giymeyin. 12. Asla çıplak ayakla veya çorapla egzersiz yapmayın. Her zaman koşu veya yürüyüş ayakkabısı gibi doğru tür bir ayakkabı seçin. 13.Cihazı kullanmadan önce düzgün bir şekilde ısınmak için her zaman esneme hareketlerini yapın. 14.Ürünün üstüne çıkarken dengenizi korumaya özen gösterin. Ürünü kullanırken veya inerken yaşanan denge kayıpları düşmelere veya ciddi yaralanmalara sebep olabilir. 15.Cihaz 267 pound / 120 kilo üstündeki insanlar tarafından kullanılmamalıdır. 16.Cihaz aynı anda yalnızca bir kişi tarafından kullanılmalıdır. 17.Bu cihaz sadece ev kullanımı için uygundur. 18.Kusurlu parçaları acilen değiştirin ya da ürün tamir edilene kadar ürünü kullanmaya ara verin. 19.Yalnızca cihazın etrafındaki açıklık minimum bir derece ve üstünde olduğunda egzersiz yapın. 20.Bayılacak gibi hissediyorsanız ya da başınız dönüyorsa, cihazı kullanmayı acilen bırakın. Eğer cihaz düzgün bir şekilde kurulmamış ve kullanılmamış ise ciddi yaralanmalar meydana gelebilir. Bütün talimatların takip edilmemesi ayrıca ciddi yaralanmalara sebep olabilir. Uyarı: Herhangi bir egzersize ya da kondisyon programına başlamadan önce fiziki bir muayene ihtiyacınız olup olmadığını görmek için kişisel doktorunuza başvurun. Bu özellikle eğer 35 yaşının üstündeyseniz, daha önce egzersiz yapmadıysanız, hamileyseniz ya da bir hastalıktan muzdarip iseniz gerçekten önemlidir. GÜVENLİK ÖNLEMLERİNİ OKUYUN VE UYGULAYIN. BU TALİMATLARI TAKİP ETMEMEK CİDDİ YARALANMALARA NEDEN OLABİLİR. Güvenlik Talimatları Aşağıdaki montaj parçaları listesini kontrol edin ve montaj parçalarının iyi durumda ve eksik olmadığından emin olun. Garanti süresi dolana kadar paketleme malzemesini atmayın. Eğer herhangi bir parça kayıpsa paketleme malzemesinin içinde kalmadığından emin olmak için pake- tleme malzemesini kontrol edin. Parça No. Parça No. Montaj parçaları Ana çerçeve Sol/Sağ pedal Sele Gidon kapağı Gidon Gidon direği Ön sabitleyici Arka sabitleyici Civata M10*55 Pul 10*20*2 Montaj parçaları Yaylı pul 10 Civata M8*40 Civata M8*12 Bombeli pul 8 Pul 8*16*1.6 Yaylı pul İngiliz Anahtarı 17#-19# İngiliz Anahtarı 13#-15# Alyan Anahtarı 5# Alyan Anahtarı 6# MiktarMiktar Montaj Talimatları 1.Cihazı kargo kutusundan çıkartın ve paketleme malzemelerinden ayırın. 2.#1 ana çerçeveyi #7 numaralı sabitleyiciye ve #8 numaralı sabitleyiciye bağlayın. Civata delikleri- nin doğru şekilde hizalandığından emin olun. 3. 4 parça pulu ve 4 parça yaylı pulu 4 parça civatanın üzerine takın. 4.Ana çerçeveyi ana sabitleyiciye ve arka sabitleyiciye adım üçteki civata ve pulları #20 alyan anahtarıyla sıkarak sabitleyin. Kurulum sırasında ana çerçevenin düşmemesi için dikkatli olunma- lıdır. Adım 1 Adım 2 1.#2 numaralı sol ve sağ pedal birbirinin yerine kullanılamaz. Sağ pedalı sağ anadingil koluna sol pedalı ise sol anadingil koluna takmalısınız. Sağ ve sol pedal birbirlerinden üstlerindeki işaretten ayırt edebilirler. Yukarıdaki talimatların takip edilmemesi hasara sebep olabilir. 2.Pedalın üstündeki somunu çıkarın. Sol pedalı sol anadingil koluna oturtun ve ellerinizi kullanarak pedalı saat yönünün tersine doğru çevirin. Pedal yerine sıkıştırıldıktan sonra #17 …

Text truncated - open the document above for the full version.

Guangdong Xiaoda Technology Co.,LTD. 2023-02-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for 2A9XH-DGDCS101 Guangdong Xiaoda Technology Co.,LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Li gui jian project managers Guangdong Xiaoda Technology Co.,LTD. Room 701, No. 5, Songhu Zhigu R&D Center, No. 1,Renju Road, Liaobu Town, Dongguan City, Guangdong Province Guangdong Xiaoda Technology Co.,LTD. 2023-02-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for 2A9XH-DGDCS101 Guangdong Xiaoda Technology Co.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Li gui jian project managers Guangdong Xiaoda Technology Co.,LTD. Room 701, No. 5, Songhu Zhigu R&D Center, No. 1,Renju Road, Liaobu Town, Dongguan City, Guangdong Province

AttestationStatements 2023/3/10 TO:FederalCommunicationsCommission Authorizationand EvaluationDivision 7435OaklandMillsRoad Columbia,MD 21046, USA RE: AttestationStatementsPart 2.911(d)(7)requestfor GuangdongXiaodaTechnologyCo.,LTD.,the undersigned,herebyauthorizeVISHTECLLC to act as our designatedU.S. agentfor serviceof process,GuangdongXiaoda TechnologyCo.,LTD.acceptsto maintainan agentfor no less thanone year afterthe granteehas terminatedall marketingand importationor the conclusionof any Commission-relatedproceedinginvolvingthe equipment. VISHTECLLC acceptsthe responsibilityto act as designatedU.S. agentfor serviceof process. This agreementis valid until 03/10/2025 ApplicantInformation： Companyname:GuangdongXiaodaTechnologyCo.,LTD. ContactName:gui jian Li Address:Room701, No. 5, SonghuZhiguR&DCenter,No. 1,RenjuRoad,LiaobuTown, DongguanCity,GuangdongProvince TelephoneNo:13692581779 Email:[email protected] Signature [Li gui jian] U.S. Agent Information: Company Name: VISHTEC LLC Address: 9888 W Belleview Ave Ste 2142 Denver CO 80123 FRN: 0033407131 Contact Name: Alan Graham Telephone No: / Email: [email protected] Signature [AlanGraham]

Guangdong Xiaoda Technology Co.,LTD. 2023-02-07 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize DongGuan Anci Electronic Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Li gui jian project managers Guangdong Xiaoda Technology Co.,LTD. Room 701, No. 5, Songhu Zhigu R&D Center, No. 1,Renju Road, Liaobu Town, Dongguan City, Guangdong Province

Guangdong Xiaoda Technology Co.,LTD. 2023-02-07 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: Spinning cycle /Model: XD-DGDCS101 /FCC ID: 2A9XH-DGDCS101) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram ,Operational Description,Schematics) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Li gui jian project managers Guangdong Xiaoda Technology Co.,LTD. Room 701, No. 5, Songhu Zhigu R&D Center, No. 1,Renju Road, Liaobu Town, Dongguan City, Guangdong Province

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that maycause undesired operation.

ANT

RF EXPOSURE EVALUATION EUT Specification EUT Spinning bike Model Number XD-DGDCS101 FCC ID 2A9XH-DGDCS101 Antenna gain (Max) 3.65dBi Operation Frequency GFSK: 2402-2480MHz Input Rating DC 3V Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation GFSK Max. output power 3.35dBm(0.002W) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. GFSK: According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Tiger Xu Date: 2023-01-09 Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK 2.96 3±1 4 0.612806 3 2440 GFSK 3.35 3±1 4 0.675743 3 2480 GFSK 3.15 3±1 4 0.650393 3

TRF No.: 01-R001-3A-LE TRF Originator: GTG TRF Date: 2022-06-29 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT FCC PART 15 SUBPART C REQUIREMENT OF Spinning bike Model No.: XD-DGDCS101 Trademark: N/A FCC ID: 2A9XH-DGDCS101 Report No.: E01A23010054F00101 Issue Date: February 07, 2023 Prepared for Guangdong Xiaoda Technology Co.,LTD. Room 701, No. 5, Songhu Zhigu R&D Center, No. 1,Renju Road, Liaobu Town, Dongguan City, Guangdong Province Prepared by Dong Guan Anci Electronic Technology Co., Ltd. 1-2 Floor, Building A, No.11, Headquarters 2 Road, Songshan, Lake Hi-tech Industrial Development Zone, Dongguan City, Guangdong Pr., China.. This report shall not be reproduced, except in full, without the written approval of Dong Guan Anci Electronic Technology Co., Ltd. 2 of 50 Report No.: E01A23010054F00101 TRF No.: 01-R001-3A-LE Global Testing , Great Quality. VERIFICATION OF COMPLIANCE Applicant: Guangdong Xiaoda Technology Co.,LTD. Room 701, No. 5, Songhu Zhigu R&D Center, No. 1,Renju Road, Liaobu Town, Dongguan City, Guangdong Province Manufacturer: Guangdong Xiaoda Technology Co.,LTD. Room 701, No. 5, Songhu Zhigu R&D Center, No. 1,Renju Road, Liaobu Town, Dongguan City, Guangdong Province Product Description: Spinning bike Trade Mark: N/A Model Number: XD-DGDCS101 We hereby certify that: The above equipment was tested by Dong Guan Anci Electronic Technology Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2022). Date of Test : January 04, 2023 to January 10, 2023 Prepared by : Tomas Yang/Editor Approved & Authorized Signer : Tiger Xu / Supervisor 3 of 50 Report No.: E01A23010054F00101 TRF No.: 01-R001-3A-LE Global Testing , Great Quality. Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / E01A23010054F00101 4 of 50 Report No.: E01A23010054F00101 TRF No.: 01-R001-3A-LE Global Testing , Great Quality. Table of Contents 1. GENERAL INFORMATION ................................................................................................... 6 1.1 PRODUCT DESCRIPTION .......................................................................................................... 6 1.2 TEST METHODOLOGY .............................................................................................................. 6 2. TEST FACILITY ...................................................................................................................... 7 3. DESCRIPTION OF TEST MODES....................................................................................... 8 4. SUMMARY OF TEST RESULTS ....................................................................................... 10 5. TEST SYSTEM UNCERTAINTY ........................................................................................ 11 6. CONDUCTED EMISSIONS TEST ..................................................................................... 12 6.1 MEASUREMENT PROCEDURE: ................................................................................................ 12 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................ 12 6.3 MEASUREMENT EQUIPMENT USED: ........................................................................................ 12 6.4 CONDUCTED EMISSION LIMIT ..................................................................................................... 13 6.5 MEASUREMENT RESULT: ....................................................................................................... 13 6.5 CONDUCTED MEASUREMENT PHOTOS: ........................................................................................... 7. RADIATED EMISSION TEST ............................................................................................. 14 7.1 MEASUREMENT PROCEDURE ................................................................................................. 14 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................ 16 7.3 MEASUREMENT EQUIPMENT USED: ........................................................................................ 17 7.4 RADIATED EMISSION LIMIT .......................................................................................................... 18 7.5 MEASUREMENT RESULT .......................................................................................................... 19 7.6 RADIATED MEASUREMENT PHOTOS: ........................................................................................... 25 8. 6DB BANDWIDTH MEASUREMENT ............................................................................... 26 8.1 MEASUREMENT PROCEDURE ................................................................................................. 26 8.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................ 26 8.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 26 8.4 LIMIT ........................................................................................................................................ 27 8.5 MEASUREMENT RESULTS: ..................................................................................................... 27 9. MAXIMUM PEAK OUTPUT POWER TEST .............................................................................. 30 9.1 MEASUREMENT PROCEDURE ................................................................................................. 30 9.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................ …

Text truncated - open the document above for the full version.

Report No.: BL-SZ22A0666-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: ThinkFIT (Xiamen) Information & Technology Co., Ltd. Address: Room 1101, 997 Tianlu Road, Jimei District, Xiamen City Equipment Type: PCB Antenna Model Name: 2.4G ANT Brand Name: N/A Test Standard: ANSI/IEEE Std 149-1979 Test Date: Oct. 24, 2022 Date of Issue: Oct. 28, 2022 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Mai Jintian Checked by: Tolan Tu Approved by: Wei Yanquan (Chief Engineer) _______________ _______________ _______________ Report No.: BL-SZ22A0666-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Oct. 28, 2022 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ........................................................................................................ 3 1.1 Test Laboratory ................................................................................................................... 3 1.2 Test Location ....................................................................................................................... 3 2 PRODUCT INFORMATION ....................................................................................................... 4 2.1 Applicant Information ........................................................................................................... 4 2.2 Manufacturer Information .................................................................................................... 4 2.3 Factory Information ............................................................................................................. 4 2.4 General Description for Equipment under Test (EUT) ......................................................... 4 2.5 Ancillary Equipment ............................................................................................................. 4 2.6 Technical Information .......................................................................................................... 4 3 SUMMARY OF TEST RESULTS ............................................................................................... 5 3.1 Test Standards .................................................................................................................... 5 3.2 Test Verdict ......................................................................................................................... 5 3.3 Test Uncertainty .................................................................................................................. 5 4 GENERAL TEST CONFIGURATIONS ...................................................................................... 6 4.1 Test Condition ..................................................................................................................... 6 4.2 Test Equipment List ............................................................................................................. 6 4.3 Test Setup ........................................................................................................................... 7 ANNEX A TEST RESULTS ........................................................................................................... 8 A.1 Gain and Efficiency ............................................................................................................. 8 ANNEX B RADIATION PATTERN ................................................................................................ 9 ANNEX C TEST SETUP PHOTO ................................................................................................ 12 ANNEX D EUT PHOTO .............................................................................................................. 13 Report No.: BL-SZ22A0666-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Report No.: BL-SZ22A0666-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 14 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-01-12) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant ThinkFIT (Xiamen) Information & Technology Co., Ltd. Address Room 1101, 997 Tianlu Road, Jimei District, Xiamen City Contact Person Guozhibin Telephone Number 17689291145 E-mail Address [email protected] 2.2 Manufacturer Information Manufacturer N/A Address N/A 2.3 Factory Information Factory N/A Address N/A 2.4 General Description for Equipment under Test (EUT) EUT Name PCB Antenna Model Name Under Test 2.4G ANT Antenna Type PCB Antenna Dimensions 12*3mm 2.5 Ancillary Equipment Note: Not applicable. 2.6 Technical Information Frequen…

Text truncated - open the document above for the full version.
