2A9XV-FFP219972-IN-1 SMART BOWL

Product size Pic(2) Pic(1) Button(A) function instruction: Turn onPress once （Default Display after Turn on） Units convert Press once （“g” “ml” “fl:oz”“oz”） TareDouble click (shows “0”) Turn offLong press 5 seconds Thank you for choosing our products Please read this manual carefully before using Instruction Manual 4-1 (A) (D) (E) (B) (F) (C) (A) Button (B) LCD Display (C) Stainless Steel bowl (D) Slow eating pad (E) Type-C USB interface (F)Reset button Pic(3) ①wifi② minus③ digit ④ g⑤ ml⑥ fl:oz⑦ oz Attention: 1.USB adapter power supply requires DC/5V output. 2.The pet bowl scale device should always be connected to external USB adapter power supply during using; 3.The built-in lithium battery is only used for short time work in case of sudden power failure; 4.Restore factory Settings： · Locate the device bar on the APP interface → long press the device for 2 seconds → click Remove device in the pop-up dialog box; ·Connect the USB cable to the device → press the“reset button” for 5 seconds with an object ≤ 2mm in diameter and release it; Instruction Manual Specifications: · Removable stainless steel bowl · A mechanical button · WiFi APP connection: Wifi · Unit: Solid (g/ oz）/ Liquid(ml/fl.oz) · Capacity: 2g～1000g · Division: 1g/ 1ml/ 0.05fl:oz/ 0.05oz · High precision sensor · Power cable: USB cable (Type-C interface) · Power supply: external 5V adapter/built-in emergency 3.7V(250mAh lithium battery) · Data collection :24 hours, constant data, calculation and statistics of data before and after feeding; Attention: 1.The product is only for family pets feeding using, cannot for any commercial using; 2.The main body of the product can not be immersed in water, stainless steel bowl and silicone cushion can be disassembled to clean 3.If the product is not used for a long time, please shut down and then remove the USB cable to store the product 4.Please do not load the weight beyond the product weighing range onto the stainless steel bowl, so as not to damage the sensor 5.Pay attention to the products not close to high temperature and high humidity, especially close to fire sources and flammable goods WIFI Instruction: 1. Connect the USB cable to the device Note:It is best for the first network distribution device to be about 1 meter away from the router 2. Automatic turn on after power connection If not turned on (please click the device button to turn on) After turn on, the LCD display show “0 g” and Wifi “sign” will flash 3.
Turn on your phone’s Wifi and Bluetooth connections 4.
Open the Smart Life APP as shown in (5)～(10) for network distribution




operations 4-2 LCD display description for the end device troubleshooting: indicates that the sensor is unstable; displays a message indicating that the network is not connected indicating low charge of built-in rechargeable lithium battery; is displayed alternately, indicating that the network is being configured indicating that the weight of the item is overloaded; 4-3 Instruction Manual Pic(5)Pic(6)Pic(7) Pic(8)Pic(9)Pic(10) 4-4 Instruction Manual Feeding operation: 1. Open “Smart Life”APP 2. Select feeding items(pic 7) Food→unit switch ：“g”/“oz" Liquid→unit switch ：“ml”/“fl.oz" 3. Tare 4. Feeding food →put food into the bowl 5. APP panel operation: click→before feeding (pic 11) 6. Pet feeding process→ feeding is complete 7. APP panel operation: click→after feeding (pic 12) 8. The feeding data has been recorder
(pic 13) Pic(11)Pic(12)Pic(13) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Fetch for Pets, LLC. 1/1 Letter of Authorization Company: Fetch for Pets, LLC. Address: 1407 Broadway STE 601 New York, NY 10018 Product Name: 2-IN-1 SMART BOWL Model Number: FFP21997 FCC Identifier: 2A9XV-FFP21997 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: chen zhen Date: 2023-01-04 Title: Manager Signature of applicant:

Fetch for Pets, LLC. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-01-04 Subject: Request for Confidentiality FCC ID: 2A9XV-FFP21997 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: chen zhen Title: Manager

Size:18*14mm M/N: FFP21997 FCC ID: 2A9XV-FFP21997 Label location

ANT

FCC ID: 2A9XV-FFP21997 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 7.664 5.8398 0.00149 1.0 PASS 802.11g 6.923 4.9238 0.00125 1.0 PASS 802.11n HT20 7.259 5.3199 0.00135 1.0 PASS 802.11n HT40 7.426 5.5284 0.00141 1.0 PASS Remark: antenna gain=1.07dBi

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20221230024E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 56 FCC Part 15C Test Report FCC ID: 2A9XV-FFP21997 Applicant: Fetch for Pets, LLC. Address: 1407 Broadway STE 601 New York, NY 10018 Manufacturer: GUANGZHOU TAIZA ELECTRONIC TECHNOLOGY CO., LTD Address: No.2 XinZhuang 5th Road, Yonghe Town,Economic and Technical Development Zone, Guangzhou, 511356,China EUT: 2-IN-1 SMART BOWL Trade Mark: N/A Model Number: FFP21997 Date of Receipt: Dec. 19, 2022 Test Date: Dec. 19, 2022 - Dec. 30, 2022 Date of Report: Dec. 30, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20221230024E Prepared (Test Engineer): Pxing Huang Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20221230024E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 56 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 23 3.3.1 TEST REQUIREMENT: 23 3.3.2 TEST PROCEDURE 23 3.3.3 DEVIATION FROM TEST STANDARD 23 3.3.4 TEST SETUP 24 3.3.5 EUT OPERATING CONDITIONS 24 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 29 3.4.1 APPLICABLE STANDARD 29 3.4.2 TEST PROCEDURE 29 3.4.3 DEVIATION FROM STANDARD 29 3.4.4 TEST SETUP 29 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20221230024E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 56 Table of Contents Page 3.4.5 EUT OPERATION CONDITIONS 29 3.4.6 TEST RESULTS 29 4 . AVERAGE OUTPUT POWER 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . POWER SPECTRAL DENSITY TEST 37 5.1 APPLIED PROCEDURES / LIMIT 37 5.1.1 TEST PROCEDURE 37 5.1.2 DEVIATION FROM STANDARD 37 5.1.3 TEST SETUP 37 5.1.4 EUT OPERATION CONDITIONS 37 5.1.5 TEST RESULTS 38 6 . 6DB BANDWIDTH TEST 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . ANTENNA REQUIREMENT 45 7.1 STANDARD REQUIREMENT 45 7.2 EUT ANTENNA 45 8 . TEST SEUUP PHOTO 46 9 . EUT PHOTO 48 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20221230024E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 56 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.205, 15.247(d) Band Edge Emission& Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20221230024E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 56 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: 2-IN-1 SMART BOWL Trademark N/A Model No.: FFP21997 Model Difference N/A Operation Frequency: 2412~2462 MHz for 802.11b/g/nHT20 2422~2452 MHz for 802.11nHT40 Channel numbers: 11 Channels for 802.11b/g/n(HT20) 7 channels for 802.11nHT40 Channel separation: 5MHz Modulation technology: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n(20): DSSS (CCK, DQPSK,DBPSK)+OFDM (QPSK, BPSK, 16-QAM, 64-QAM) Rate of Transmitter 802.11b: 11/5.5/2/1Mbps 802.11g: 54/48/36/24/18/12/9/6Mbps 802.11n: up to 150Mbps Antenna Type: Internal Antenna Antenna gain: 1.07dBi Power supply: DC 5V from adapter DC 3.7V from battery Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20221230024E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 56 2. Channel List(802.11b/g/nHT20) Channel Freq…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
