2A9Z6-BB420SpotLite

SpotLite EEG Device Instructions for Use LB-10001 Rev A -DRAFT 27APR2023 SpotLite IFU LB-10001_RevA_DRAFT Confidential and Proprietary 2 Current Issues to Resolve: Distribution: Per Jean, digital is satisfactory for 510K submission, but physical copies could be needed. That need is based on the preference of the hospitals. Should we plan to include a physical copy within the SpotLite System box? References • Peer IFUs and FDA Guidance • Draft SpotLite User manual for compliance testing • STAT Hardware Manual • Byteflies Kit SpotLite IFU LB-10001_RevA_DRAFT Confidential and Proprietary 3 Table of Contents (Go to View > Show Outline and it should appear to the left of the document) Getting Started What's in the box✅ Completed Your box includes: • SpotLite EEG Device • Charging Dock • Power Adapter • USB-C Cable You should also have received • A number of patch envelopes which contain o The patch with SpotLite cradle attached o 2 skin prep wipes You should also have • A mobile device with the SpotLite app installed and it is connected to the Wi-Fi Descriptions  Ready for ReviewThe Beacon SpotLite System is a wearable self-contained EEG system designed to amplify and digitize and record the electroencephalogram (EEG) from a patient’s scalp. The recorded EEG signals are acquired by the SpotLite Device, transmitted to a mobile device in real time, and uploaded to the cloud storage after a recording session is completed. The recorded data is available for access for viewing on the Beacon Platform (not included in the SpotLite system). The Beacon platform provides the recorded signals for post-hoc review ONLY. Indications for Use  Ready for ReviewThe SpotLite EEG System is intended to record, store, and display EEG signals. A reusable SpotLite Device is intended to amplify, capture and wirelessly transmit the signals to the cloud storage via a mobile device. A single use, disposable SpotLite Patch is an EEG electrode array to be used with the SpotLite Device to record up to 8 channels of EEG signals. The Beacon SpotLite EEG System does not provide any diagnostic conclusion about the subject's condition and does not provide any automated alerts of an adverse clinical event. It is intended for prescription use in the home, healthcare facility or clinical site where reduced montage EEG monitoring may be desired. Contraindications ✅ Completed SpotLite IFU LB-10001_RevA_DRAFT Confidential and Proprietary 4 • The SpotLite EEG System should not be used when real time EEG monitoring is required. • The SpotLite EEG System does not provide real time alarms and should not be used to make life saving decisions. • The SpotLite System should not be used on children under the age of 6 • The SpotLite Patch is manufactured with medical grade adhesives containing silicones, acrylics and conductive hydrogels. The Patch should not be used on patients with a suspected or known allergy to skin adhesives, acrylics, hydrogels, or silicones. Warnings  Ready for Review • The SpotLite Device and SpotLite Patch have not been evaluated for safety in the MR environment. The SpotLite Device and SpotLIte Patch have not been tested for heating or unwanted movement in the MR environment. The safety of the SpotLite Device within the MR environment is unknown. Performing an MR exam on a person who has this medical device may result in injury or device malfunction. • Only place the Patch on intact skin, do not place the Patch on open wounds or abrasions. • Depending on wireless connectivity, a temporary interruption of data transmission is possible. Data will be stored on the device for transfer once connectivity is reestablished. • Do not use the SpotLite EEG Device or Patch in conjunction with defibrillation devices PrecautionsIn Progress • Wireless electronic devices may cause signal interference during data transmission. Avoid close proximity with interfering devices. • The Patch is single use only. Do not reapply or reuse the patch once it is removed. • Do not use the SpotLite EEG Device or Patch if the package has been opened, or appears used, damaged, or expired. • If prolonged discomfort or irritation occurs, the Patch should be removed. If mild soreness or redness is experienced after removing the Patch, take care to let the area heal prior to applying another Patch. • Incorrect handling, excessive force, or dropping the SpotLite EEG Device may cause malfunction or permanent damage • The SpotLite Device and Patch are not intended to be used in a wet environment; do not use the device while showering or under water. • Keep the SpotLite EEG Device away from children and pets. The device may be a choking hazard, and may be harmful if swallowed. • If the SpotLite EEG Device fails to operate, contact your healthcare provider immediately. • This device has not been evaluated for use in a HF surgical environment. System Overview System Components Ready for Review • SpotLite EEG Device The device is electrically connected to the Patch, samples the EEG signals, monitors the impedance of each Patch electrode, and wirelessly transmits the data to a connected mobile device. • Charging Dock A wireless charging dock used to both charge and protect the SpotLite EEG Device when not in use. When SpotLite IFU LB-10001_RevA_DRAFT Confidential and Proprietary 5 the SpotLite EEG Device is placed within the charging dock, all EEG acquisition functions are automatically disabled. • Patch Multiple electrodes are attached to the forehead with adhesive on each electrode. Each Patch has a cradle to securely mount the EEG device. The conductive pads allow the EEG device to electrically connect to the Patch. • Power Adaptor 100-240 V AC power adapter used to charge the SpotLite EEG Device. Only use the included power adapter to charge the SpotLite EEG Device. • USB-C Cable Cable used to connect the SpotLite EEG Device to the power adapter for charging. • Mobile Device A user interacts with the SpotLite system with a mobile device. The app installe…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Pag e 1 of 1 Original Issue: Jan. 4, 2021 SGS No rth America Inc. 620 Old Peach tree Ro ad SUITE 100 Suwan ee, Geo rg ia 30024 United States Ap p lican t Leg al Busin ess Name Beacon Biosignals, Inc. Ad d ress 22 Boston Wharf RD floor 7 Boston Massachusetts United Sta tes 02210 Grantee Code 2A9Z6 FCC ID 2A9Z6-BB201 Auth o rized Co n tact Name Jarrett Revels Contact Email jarrett@bea con.bio Contact Phone (804)517-5155 I, th e un d ersig n ed , certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the represen tatio n s mad e in th is ap p licatio n , th e Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if th e Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure th at p ro d uctio n un its o f th is eq uip men t will co n tin ue to co mp ly with th e FCC’s tech n ical req uiremen ts. d) in accordance with 47 CFR 2.909 an d KDB394321, t he Applicant has read, understood and agrees to accept th at th ey are th e resp o n sible party an d ag ree to abid e by th eir responsibilities as specified under 47 CFR 2.909 an d KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 an d RSP-100, th e Applicant has read, understood, accepts an d ag rees to abid e by th e post market surveillance requirements. (1) th e Ap p lican t un d erstan d s, accep ts an d ag rees th at a samp le may be req uested fo r surveillan ce testin g . (2) the Applicant shall make p ro visio n s to always h ave a p ro d uctio n samp le available up o n req uest by SGS, FCC an d /or ISED. (3) the Applicant shall, up on request by SGS, at th e Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as in structed. Th e sample shall include all sup p o rt d evices, cables, so ftware, accesso ries o r o th er h ard ware o r software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Sectio n 5301 o f th e An ti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distri bution o f a c o ntrol led s ubstanc e. See 47CFR 1.2002(b) fo r th e d efin itio n o f a “p arty” fo r th ese p urp o ses. g) th e Ap p lican t h as read, understood, accepts an d ag rees to abid e by th e SGS No rth America, In c.(TCB) terms an d co n d itio ns. Lin k to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-an d-innovation-division/rules-regulations-title-47 Lin k to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Lin k to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Lin k to th e Co vered List: Covered List [Beacon Biosignals, Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment p rohibited fro m receivin g an eq uip men t auth o rizatio n p ursuan t to sectio n 2.903 o f th e FCC rules. [[Bea con Biosigna ls, I nc. (“the applicant”) certifies that, as of the date of the filing of the application, the applican t [is n o t] identified on the Covered list, established pursuant to §1.50002, as an en tity p ro d ucin g “co vered ” eq uip men t. Ap p lican t Sig n ature: Date: 2023-07-13 Prin t Name: Jarrett Revels Title: CTO *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UNITED STATES DESIGNATED AGENT LETTER Date: 2023/07/11 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Co lumb ia, MID 21046 Applicant U.S. designated agent Co mp any Name: Beacon Biosignals, Inc. Co mp any Name: Beacon Biosignals, Inc. Grantee Code: 2A9Z6 FRN: Co ntact Name: 0033269408 Jarrett Revels Co ntact Name: Jarrett Revels Address: 22 Boston Wharf RD floor 7 Boston Massachusetts United States 02210 Address: 22 Boston Wharf RD floor 7 Boston Massachusetts United States 02210 City/Pro vince/Zip: 02210 City/Pro vince/Zip: 02210 Telep ho ne: (804) 517-5155 Telep ho ne: (804) 517-5155 Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: < 2A9Z6-BB420> ATTN: Director of Certification: We, < Beacon Biosignals, Inc.> understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States f or matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, < Beacon Biosignals, Inc. > acknowledge the applicant’s acceptance of its obligation to maintain an agent f or service of process in the United States f or no less than one year af ter either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Jarrett Revels Name (Printed): Jarrett Revels Tit le: CTO Tit le: CTO Signature: Signature:

Beacon Biosignals, Inc Cover Letter-Wireless Charger Approval Date: 2023/07/11 Gentlemen: We request your authorization for a wireless charger for our EEG device, via an inductive wireless power transfer mechanism. The s p ec if ic p ro d uc t as b elo w, Spotlite, with its designed features and specified description, meets special requirements f or KDB 680106 D01 section 5.2 requirements. Company: Beacon Biosignals, Inc. Product Name: Spotlite Model Number: BB420 FCC ID: 2A9Z6-BB420 KDB 680106 D01 Section 5.2 Requirements Product Technical Specification Reply a) Power transf er f requency is less that 1 MHz174.2-176.5kHz Yes b) Output power from each primary coil is less than or equal to 15 watts. 5W Max Yes c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils Yes d) Client device is placed directly in contact with the transmitter. Yes e) Mobile exposure conditions onlyYes f) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Please refer to RF exposure report Yes Print Name: Jarrett Revels Title: CTO Signature: On behalf of Company: Beacon Biosignals, Inc Telephone: (804) 517-5155 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 5 Appendix External Photos for SZCR2303000573AT FCC ID:2A9Z6-BB420 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 5 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 4 Appendix Internal Photos for SZCR2303000573AT FCC ID:2A9Z6-BB420 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 4 EUT Constructional Details (EUT Photos) Coil Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 4 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057303 Page: 1 of 9 Keny Xu EMC Laboratory Manager 1 COVER PAGE Human Exposure Report Application No.: SZCR2303000573AT Applicant: Beacon Biosignals, Inc. Address of Applicant: 22 Boston Wharf RD floor 7 Boston Massachusetts United States 02210 Manufacturer: Shenzhen Kaifa Technology Co., Ltd. Address of Manufacturer: 7006 Caitian Rd., Futian Dist., Shenzhen, Guangdong, China Factory: Shenzhen Kaifa Technology Co., Ltd. Address of Factory: 7006 Caitian Rd., Futian Dist., Shenzhen, Guangdong, China Equipment Under Test (EUT): EUT Name: SpotLite Model No.: BB420 Trade Mark: Beacon FCC ID: 2A9Z6-BB420 Standards: 47 CFR PART 1, Subpart I, Section 1.1310 47 CFR PART 2, Subpart J, Section 2.1091 Date of Receipt: 2023-03-07 Date of Test: 2023-03-09 to 2023-03-22 Date of Issue: 2023-03-24 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057303 Page: 2 of 9 Revision Record Version Chapter Date Modifier Remark 01 2023-03-24 Original Authorized for issue by: Edison Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057303 Page: 3 of 9 2 Contents 1 COVER PAGE ......................................................................................................................................................... 1 2 CONTENTS .............................................................................................................................................................. 3 3 GENERAL INFORMATION ................................................................................................................................... 4 3.1 DETAILS OF E.U.T. ................................................................................................................................................. 4 3.2 DESCRIPTION OF SUPPORT UNITS ........................................................................................................................... 4 3.3 TEST MODES DESCRIPTION ...................................................................................................................................... 4 3.4 TEST LOCATION ...................................................................................................................................................... 5 3.5 TEST FACILITY ....................................................................................................................................................... 5 3.6 DEVIATION FROM STANDARDS ............................................................................................................................... 5 3.7 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 5 4 EQUIPMENTS USED DURING TEST .................................................................................................................. 6 5 TEST RESULTS ...................................................................................................................................................... 7 5.1 RF EXPOSURE TEST ................................................................................................................................................ 7 5.1.1 E.U.T. Operation ........................................................................................................................................ 8 5.1.2 Test Block Diagram ................................................................................................................................. 8 5.1.3 Measurement Data .................................................................................................................................. 9 6 RF EXPOSURE SETUP PHOTOS ....................................................................................................................... 9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057303 Page: 4 of 9 3 General Information 3.1 Details of E.U.T. Power supply: Switching Power Supply Model: MQ05A-050B Input: AC 100-240V, 50/60Hz, 0.2A Output: DC 5.0V, 1.0A, 5.0W Max Input: DC 5V, 1A Wireless Input: DC 5V, 1A Wireless Output: 5W max USB cable: 120cm unshielded Operation frequency: 174.2kHz to 176.5kHz Modulation type: Load modulation Antenna type: Loop Antenna 3.2 Description of Support Units Description Manufacturer Model No. Serial No. EEG Beacon Spotlite BEA31060053 3.3 Test modes description Pre-scan / Final test Mode Code Description Final test 01 Charge mode_Keep the EUT charging(5W) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057303 Page: 5 of 9 3.4 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch E&E Lab, No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong,China 518057. Tel: +86 755 2601 2053 Fax: +86 755 2671 0594 No tests were sub-contracted. 3.5 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regu…

Text truncated - open the document above for the full version.

Justification statement for Antenna To: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2A9Z6-BB420 Dear Sir/Madam, Only radiated measurements are used for EUT with FCC ID: 2A9Z6-BB420 to show compliance with FCC limits for fundamental and spurious emissions. All measurements were performed radiated and therefore additional antenna gain documentation is not required. The detailed information for antenna as below shows: Output 1 Antenna： Design Specifications Typical Antenna Type Loop Working Frequency 174.2kHz to 176.5kHz Overall Dimensions 18.6mm Turns 8

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057302 Page: 1 of 28 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2303000573AT Applicant: Beacon Biosignals, Inc. Address of Applicant: 22 Boston Wharf RD floor 7 Boston Massachusetts United States 02210 Manufacturer: Shenzhen Kaifa Technology Co., Ltd. Address of Manufacturer: 7006 Caitian Rd., Futian Dist., Shenzhen, Guangdong, China Factory: Shenzhen Kaifa Technology Co., Ltd. Address of Factory: 7006 Caitian Rd., Futian Dist., Shenzhen, Guangdong, China Equipment Under Test (EUT): EUT Name: SpotLite Model No.: BB420 Trade Mark: Beacon FCC ID: 2A9Z6-BB420 Standard(s) : 47 CFR Part 15, Subpart C Date of Receipt: 2023-03-07 Date of Test: 2023-03-09 to 2023-03-22 Date of Issue: 2023-03-24 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057302 Page: 2 of 28 Revision Record Version Chapter Date Modifier Remark 01 2023-03-24 Original Authorized for issue by: Edison Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057302 Page: 3 of 28 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Mains Power Port (150kHz-30MHz) 47 CFR Part 15, Subpart C ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass 20dB Bandwidth ANSI C63.10 (2013) Section 6.9.2 47 CFR Part 15, Subpart C 15.215 Pass Restricted Bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 Pass Radiated Emissions (9kHz-30MHz) ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Emissions (30MHz-1GHz) ANSI C63.10 (2013) Section 6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230300057302 Page: 4 of 28 3 Contents Page 1 Cover Page ............................................................................................................................................ 1 2 Test Summary ....................................................................................................................................... 3 3 Contents ................................................................................................................................................ 4 4 General Information.............................................................................................................................. 6 4.1 Details of E.U.T. ............................................................................................................................. 6 4.2 Description of Support Units ........................................................................................................... 6 4.3 Measurement Uncertainty .............................................................................................................. 6 4.4 Test Location.................................................................................................................................. 7 4.5 Test Facility .................................................................................................................................... 7 4.6 Deviation from Standards ............................................................................................................... 7 4.7 Abnormalities from Standard Conditions ........................................................................................ 7 5 Equipment List...................................................................................................................................... 8 6 Radio Spectrum Technical Requirement .......................................................................................... 10 6.1 Antenna Requirement .................................................................................................................. 10 6.1.1 Test Requirement: ................................................................................................................... 10 6.1.2 Conclusion ............................................................................................................................... 10 7 Radio Spectrum Matter Test Results................................................................................................. 11 7.1 Conducted Emissions at AC Mains Power Port (150kHz-30MHz) ................................................ 11 7.1.1 E.U.T. Operation ...................................................................................................................... 11 7.1.2 Test Mode Description ............................................................................................................. 11 7.1.3 Test Setup Diagram ................................................................................................................. 11 7.1.4 Measurement Procedure and Data ......................................................................................... 12 7.2 20dB Bandwidth ........................................................................................................................... 15 7.2.1 E.U.T. Operation ...................................................................................................................... 15 7.2.2 Test Mode Description ............................................................................................................. 15 7.2.3 Test Setup Diagram .....................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 1 of 3 Appendix RF Exposure Setup Photos for SZCR2303000573AT FCC ID:2A9Z6-BB420 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 2 of 3 Test Setup Photo Top: Side 4: Side 1: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 3 of 3 Side 2: Side 3: - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 1 of 3 Appendix Test Setup Photos for SZCR2303000573AT FCC ID:2A9Z6-BB420 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Mains Power Port (150kHz-30MHz) Radiated Emissions (9kHz-30MHz) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 3 of 3 Radiated Emissions (30MHz-1GHz) - End of the Appendix -
