2A9ZT-PVMPublic View Monitor

DONGGUAN GAGO ELECTRONICS CO.,LTD ROOM101, NO.66, MINXIN ROAD, DALINGSHAN TOWN, DONGGUAN, Declaration letter Dear Sir, We, _DONGGUAN GAGO ELECTRONICS CO.,LTD_declare product: _ Public View Monitor _with the model numbers GG-SA2PVM101, GG-SAxPVMxxx(x-(x) (x means function menu, case color, case thickness, lens type, accessory information.)_, there is no electrical change has been made to the equipment that alters the compliance characteristics. These models are the same except for model number. Please kindly handle on the project. FCC ID: 2A9ZT-PVM Thank you! Sincerely, Signature INMAN CHU SALES DIRECTOR DONGGUAN GAGO ELECTRONICS CO.,LTD

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: DONGGUAN GAGO ELECTRONICS CO.,LTD Address: ROOM 101, NO.66,MINXIN ROAD,DALINGSHAN TOWN, DONGGUAN, CHINA Product Name: Public View Monitor Model Number: GG-SA2PVM101, GG-SAxPVMxxx(x-(x) FCC Identifier: 2A9ZT-PVM We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: INMAN CHU Date: 1/12/2023 Title: SALES DIRECTOR Signature of applicant:

C5266091_X10_Ed.1 1/1 DONGGUAN GAGO ELECTRONICS CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 1/12/2023 Subject: Request for Confidentiality FCC ID: 2A9ZT-PVM To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: INMAN CHU Title: SALES DIRECTOR

FCC ID: 2A9ZT-PVM External photos FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM

Label & Location Location

FCC ID: 2A9ZT-PVM Internal photos FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM RF Chip FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM FCC ID: 2A9ZT-PVM RF Antenna FCC ID: 2A9ZT-PVM

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2212280F-1 FCC ID: 2A9ZT-PVM RF EXPOSURE EVALUATION EUT Specification EUT Public View Monitor Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(Bluetooth: 2.402GHz ~ 2.480GHz) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 18.696dBm(74.063mW) Antenna gain 2dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) 300-1500 -- -- F/1500 1500-100000 -- -- 1 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2212280F-1 FCC ID: 2A9ZT-PVM Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Channel Frequency (MHz) Max Output power (dBm) Max Output power (mW) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 2.4G WIFI 802.11b Low 2412 18.696 74.06 0.023279 1 According to KDB447498 D01 V06, Compliance with RF Exposure requirement.

Report No.: NTC2212280FV00 Page 2 of 40 Table of Contents 1. Summary of Test Result ...................................................................................................................................... 4 2. General Description of EUT ................................................................................................................................ 5 3. Test Channels and Modes Detail ........................................................................................................................ 7 4. Configuration of EUT ........................................................................................................................................... 7 5. Modification of EUT ............................................................................................................................................. 7 6. Description of Support Device ............................................................................................................................. 8 7. Test Facility and Location ................................................................................................................................... 9 8. Applicable Standards and References ................................................................................................................ 9 9. Deviations and Abnormalities from Standard Conditions ................................................................................. 10 10. Test Conditions ............................................................................................................................................... 10 11. Measurement Uncertainty ............................................................................................................................... 11 12. Sample Calculations ....................................................................................................................................... 12 13. Test Items and Results ................................................................................................................................... 13 13.1 Conducted Emissions Measurement ............................................................................................................ 13 13.2 Maximum Conducted Output Power Measurement ...................................................................................... 17 13.3 6dB Bandwidth Measurement ....................................................................................................................... 19 13.4 Power Spectral Density Measurement ......................................................................................................... 23 13.5 Band Edge and Conducted Spurious Emissions Measurement ................................................................... 27 13.6 Radiated Spurious Emissions and Restricted Bands Measurement ............................................................ 32 13.7 Antenna Requirement ................................................................................................................................... 39 14. Test Equipment List......................................................................................................................................... 40 Report No.: NTC2212280FV00 Page 3 of 40 Revision History Report Number Description Issued Date NTC2212280FV00 Initial Issue 2023-01-12 Report No.: NTC2212280FV00 Page 4 of 40 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.207 (a) AC Power Conducted Emission PASS --- §15.247(b)(3) Maximum Conducted Output Power PASS --- §15.247(a)(2) 6dB Bandwidth PASS --- §15.247(e) Power Spectral Density PASS --- §15.247(d) Band Edge and Conducted Spurious Emissions PASS --- §15.247(d),§15.209, §15.205 Radiated Spurious Emissions and Restricted Bands PASS --- §15.203 Antenna Requirement PASS --- Report No.: NTC2212280FV00 Page 5 of 40 2. General Description of EUT Product Information Product Name: PublicViewMonitor Main Model Name: GG-SA2PVM101 Additional Model Name: GG-SAxPVMxxx(x-(x) (x means function menu, case color, case thickness, lens type, accessory information.) Model Difference: These models have the same circuit schematic, construction, PCB Layout and critical components. These differences is model number, function, case color,case thickness and lens type only due to trading purpose. S/N: 2210010001 Brand Name: N/A Hardware Version: Not Stated Software Version: Not Stated Rating: DC 12V from adapter or POE Typical Arrangement: Table-top I/O Port: N/A Accessories Information Adapter: N/A Cable: N/A Other: N/A Additional Information Note: N/A Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2212280FV00 Page 6 of 40 Channel List IEEE 802.11b/ g/ n(HT20) IEEE 802.11 n(HT40) Channel Frequency (MHz) Channel Frequency (MHz) 1 2412 --- --- 2 2417 --- --- 3 2422 3 2422 4 2427 4 2427 5 2432 5 2432 6 2437 6 2437 7 2442 7 2442 8 2447 8 2447 9 2452 9 2452 10 2457 ---- ---- 11 2462 ---- ---- Technical Specification Frequency Range: 2412-2462MHz for IEEE 802.11b/g/n(HT20) 2422-2452MHz for IEEE 802.11n(HT40) Modulation Technology: DSSS, OFDM Modulation Type: CCK, DQPSK, DBPSK, 64-QAM, 16-QAM, QPSK, BPSK Number of Channel: 11 for IEEE 802.11b/g/n(HT20) 7 for IEEE 802.11n(HT40) Channel Space: 5MHz Antenna Type: Integrity antenna Antenna Gain: 2 dBi (Declared by the manufacturer) Note: N/A Report No.: NTC2212280FV00 Page 7 of 40 3. Test Channels and Modes Detail Mode Channel Frequency (MHz) Remark 1 TX 1 2412 IEEE 802.11b/ g/ n(HT20) 3 2422 IEEE 802.11n(HT40) 6 2437 IEEE 802.11b/ g/ n(HT20)/ n(HT40) 9 2452 IEEE 802.11n(HT40) 11 2462 IEEE 802.11b/ g/ n(HT20) 2. Normal Mode --- --- --- Note: TX mode means that the EUT was programmed to be in continuously transmitting mode. 4. Configuration of EUT 5. Modification of EUT No modificati…

Text truncated - open the document above for the full version.

QR/RD-P01-06B SPECIFICATION Shenzhen Guandetong Electronic Limited Shenzhen Guandetong Electronic Co., Ltd. Built-in WIFI antenna IPEX port/FPC L type board length 280MM Product specification Customer Shenzhen Weishijie Frequency segment 2400-2500MHz Customer Materia l Number 36160000007 Versions A1 http://www.szgdtrf.com Page 2 1. Product Picture 2. Product Spec. Testing Data Name 2.4G FPC Antenna Model Type GDT-C3DB-510 -280 Electrical Specifications Frenquency Range 2400-2500MHz Polarization Vertical Impedance 50 Ω Direction All directions VSWR ≦2 Power 50W Gain 2dBi Bandwidth 100MHz Mechanical Specifications Dimensions 22*18 Chassis Color Yellow Connector IPEX Cable Length 280MM Chassis Material FPC Working Temperature -40°C-+85°C Limit Temperature -40°C-+85°C Frequency (MHz) Efficiency (%) Average Gain (dB) Peak Gain (dBi) 2400 4.96 1.31 1.45 2450 4.00 1.95 2.00 2500 4.75 0.92 1.03 http://www.szgdtrf.com Page 3 3. S11（ VSWR 、Return loss 、Smith）data Horizontal: Vertical: http://www.szgdtrf.com Page 4 4. Antenna Drawing 5. Environment Function Testing Item Testing Standard Spec. Storage Environment 1. -30 °C～ +80 °C 2.45%-85% 3.86kpa-106kpa Normal High and Low Temp Testing 5 times recycle between 70°C and 40°C，and then 1-2H testing in normal environment and check surface quality. normal steady damp heat test Humidity 95±3%，temp：40°C.and keep 2H, Sample will be tested within 5mins; and then sample will be tested about 1-2H in normal environment and check surface quality. normal Vibration Frequency Range 10-55HZ, Position: 0.35MM, Speed: 50.0M/S, Recycle: 30 times normal Falling 1M altitude in accordance with the vertical axis of the direction of free fall 3 times normal

Report No.: NTC2212280FV00 Page 2 of 40 Table of Contents 1. Summary of Test Result ...................................................................................................................................... 4 2. General Description of EUT ................................................................................................................................ 5 3. Test Channels and Modes Detail ........................................................................................................................ 7 4. Configuration of EUT ........................................................................................................................................... 7 5. Modification of EUT ............................................................................................................................................. 7 6. Description of Support Device ............................................................................................................................. 8 7. Test Facility and Location ................................................................................................................................... 9 8. Applicable Standards and References ................................................................................................................ 9 9. Deviations and Abnormalities from Standard Conditions ................................................................................. 10 10. Test Conditions ............................................................................................................................................... 10 11. Measurement Uncertainty ............................................................................................................................... 11 12. Sample Calculations ....................................................................................................................................... 12 13. Test Items and Results ................................................................................................................................... 13 13.1 Conducted Emissions Measurement ............................................................................................................ 13 13.2 Maximum Conducted Output Power Measurement ...................................................................................... 17 13.3 6dB Bandwidth Measurement ....................................................................................................................... 19 13.4 Power Spectral Density Measurement ......................................................................................................... 23 13.5 Band Edge and Conducted Spurious Emissions Measurement ................................................................... 27 13.6 Radiated Spurious Emissions and Restricted Bands Measurement ............................................................ 32 13.7 Antenna Requirement ................................................................................................................................... 39 14. Test Equipment List......................................................................................................................................... 40 Report No.: NTC2212280FV00 Page 3 of 40 Revision History Report Number Description Issued Date NTC2212280FV00 Initial Issue 2023-01-12 Report No.: NTC2212280FV00 Page 4 of 40 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.207 (a) AC Power Conducted Emission PASS --- §15.247(b)(3) Maximum Conducted Output Power PASS --- §15.247(a)(2) 6dB Bandwidth PASS --- §15.247(e) Power Spectral Density PASS --- §15.247(d) Band Edge and Conducted Spurious Emissions PASS --- §15.247(d),§15.209, §15.205 Radiated Spurious Emissions and Restricted Bands PASS --- §15.203 Antenna Requirement PASS --- Report No.: NTC2212280FV00 Page 5 of 40 2. General Description of EUT Product Information Product Name: PublicViewMonitor Main Model Name: GG-SA2PVM101 Additional Model Name: GG-SAxPVMxxx(x-(x) (x means function menu, case color, case thickness, lens type, accessory information.) Model Difference: These models have the same circuit schematic, construction, PCB Layout and critical components. These differences is model number, function, case color,case thickness and lens type only due to trading purpose. S/N: 2210010001 Brand Name: N/A Hardware Version: Not Stated Software Version: Not Stated Rating: DC 12V from adapter or POE Typical Arrangement: Table-top I/O Port: N/A Accessories Information Adapter: N/A Cable: N/A Other: N/A Additional Information Note: N/A Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2212280FV00 Page 6 of 40 Channel List IEEE 802.11b/ g/ n(HT20) IEEE 802.11 n(HT40) Channel Frequency (MHz) Channel Frequency (MHz) 1 2412 --- --- 2 2417 --- --- 3 2422 3 2422 4 2427 4 2427 5 2432 5 2432 6 2437 6 2437 7 2442 7 2442 8 2447 8 2447 9 2452 9 2452 10 2457 ---- ---- 11 2462 ---- ---- Technical Specification Frequency Range: 2412-2462MHz for IEEE 802.11b/g/n(HT20) 2422-2452MHz for IEEE 802.11n(HT40) Modulation Technology: DSSS, OFDM Modulation Type: CCK, DQPSK, DBPSK, 64-QAM, 16-QAM, QPSK, BPSK Number of Channel: 11 for IEEE 802.11b/g/n(HT20) 7 for IEEE 802.11n(HT40) Channel Space: 5MHz Antenna Type: Integrity antenna Antenna Gain: 2 dBi (Declared by the manufacturer) Note: N/A Report No.: NTC2212280FV00 Page 7 of 40 3. Test Channels and Modes Detail Mode Channel Frequency (MHz) Remark 1 TX 1 2412 IEEE 802.11b/ g/ n(HT20) 3 2422 IEEE 802.11n(HT40) 6 2437 IEEE 802.11b/ g/ n(HT20)/ n(HT40) 9 2452 IEEE 802.11n(HT40) 11 2462 IEEE 802.11b/ g/ n(HT20) 2. Normal Mode --- --- --- Note: TX mode means that the EUT was programmed to be in continuously transmitting mode. 4. Configuration of EUT 5. Modification of EUT No modificati…

Text truncated - open the document above for the full version.

FCC ID: 2A9ZT-PVM Test Photo Radiated emission (Below 30MHz) Radiated emission (30-1000MHz) FCC ID: 2A9ZT-PVM Radiated emission (Above 1000MHz) Conducted emission
