M508 GPS Tracking Device （GPS+GPRS+GSM） Product Manual Edition 1.3 Copyright © 10 th Oct., 2009 GATOR GROUP CO.,LTD. All rights reserved. http://www.gatorcn.com China Printing ADD: 312# Ansheng Building,Xixiang section of 107 National road ,Bao'an, Shenzhen, China TEL: 86-75529566336 FAX: 86-75529566339 WEB: http://www.gatorcn.com EMAIL: [email protected] Content 1. Products Introduction ................................................................................................................... 4 2. Characteristics............................................................................................................................ 4 3. Specifications .............................................................................................................................. 5 3.1. Hardware Datasheet ........................................................................................................... 5 3.2. Other .................................................................................................................................. 6 4. Interface Description ................................................................................................................. 7 4.1. Power Interface .................................................................................................................. 7 4.2. Extended Interface ............................................................................................................. 8 5. Installation .................................................................................................................................. 9 5.1. Warm Reminder for Instalation ......................................................................................... 9 5.2. Wiring Diagram ................................................................................................................. 9 5.3. Paramete Settings ............................................................................................................... 9 5. Standard Accessories ............................................................................................................... 10 5. Optional Accessories ................................................................................................................. 11 Notes:  Please mount the device steadily on the flat place before using;  Please make sure the voltage value is right before connecting with battery, and placing the wires to where shouldn’t be trodden;  Please power off when plugging or taking out of any module or connector;  Please keep the device dry and don’t let any liquid fall into the device in case any damage caused in the device or circuit; If any problem caused as follows, please turn to professional technician:  When power wire, keyboard, or socket are damaged;  When liquid infiltrating into the device;  When the device work unusually or cannot resume to normal even operated according to the instruction;  When the device cannot as usual after falling, throwing or breaking;  When there is obvious damage in the device. 1. Products Introduction GPS Tracking device mainly consists of two parts such as GPS module and GSM module. GPS module is for getting location data from satellite, and GSM module is for transferring data to server so that people can check the information via PC or mobile phone. Our GPS Tracking device M528, with the best quality, stable performance and versatile functions，can be applied to various kind of fleet management like construction trucks, rental cars, logistics vehicles and public transportation, anti-theft system and security purpose. 2. Characteristics 1) small size, easy to install; 2) accurate GPS positioning, dynamic positioning deviation is less than 5 m; 3) support GPRS and SMS tracking mode, adopt UDP / TCP communication protocol in GPRS mode; 4) able to get current location immediately, and support real-time tracking (GPS data uploading at intervals); 5) support two way voice communication via handset; 6) support two way SMS communication via Mobile and PC software; 7) support authorized tapping; 8) support protection from high level voltage; 9) support the data resend from signal dead zone; 10) support remotely disable engine; 11) 3 digital inputs for detecting the status of engine, door, air condition, etc.; 12) support illegal door-open/illegal engine-start alarm, SOS alarm, power-off alarm, over-speed alarm, parking alarm, Geo-fence alarm, fatigue driving alarm 13) support mileage statistics; 14) support remote update 3. Specifications 3.1、Hardware Datasheet work voltage 12VDC work current 50mA~160mA GSM module Simcom300/340 inside contain frequency GSM 900/1800 inside contain frequency GSM 850/900/1800/1900Mhz (can be customized) Communication protocol UDP/TCP(can be customized) GPS module GPS JRC 595 with SIRFIII chipset GPS sensitivity -159dBm GPS frequency L1, 1575.42 MHz C/A coding 1.023 MHz chip rate Channels 20 channels examine track Position accuracy 10 meter, 2D RMS Speed accuracy 0.1 meter/second Time accuracy GPS time synchronization Default data WGS-84 Recover Average 0.1 second Hot start Average 1 second Warm boot Average 38 second Cold boot Average 42 second Height limit 18,000 meter (60,000 feet) max Speed limit 515 kilometer/second (1000 knots)max Acceleration limit Less than 4g 3.2、Others Work temperature -20°～ 70° C Storage temperature -30°～ 85° C Humidity 5% ～ 95% noncondensing Terminal size 101 mm × 50mm × 24mm Inside battery Continuous working no less than 4 hours LED light Red: device state；yellow：GSM module state；green：GPS module state 4. Interface Description 4.1 Power Interface Description pin color function explain/connection method 1 red Power positive input, the working voltage 9VDC ~ 34VDC, connect the positive of car battery; 2 dark Power negative input, then the negative pole of vehicle battery; 3 yellow ACC check line，connect the ACC line; 4.2 Extended interface Description pi…

Text truncated - open the document above for the full version.

1234 A B C D 4 321 D C B A RF_ANT VBAT PWRKEY EMERG_OFF SIM Interface RF PAM PMU SAW Filter RF Transceiver Reset RTC SIM Interface GPIO Serial Interface Memory Interface Serial Flash Audio ADC PCM Interface SD Interface 32KHz 26MHz Speak Mic Oil and Temperature circuit Input and Output BB&RG Digital IF Filter GPS/GALILEO Engine SRAMROM Code Power Management Backup RAM ARM7TDMI-S RTC Baseband Processor RTC FLASH EPROM RF Front-End with Integrated LNA GSM/GPRS SAW Filter Antenna Supervision &Supply RF_IN GPS UART VIN IN MP4560 LDO AP2121 LDO Interface Pin PDF created with pdfFactory trial version www.pdffactory.com

GATOR GROUP CO., LTD 5 Floor, TGK NO. 11 Building, Yangtian Road, the 72nd Zone of Bao'an, Shenzhen, China TEL: 86-755-23085553 FAX: 86-755-29566339 DOC ATTESTATION LETTER FCC ID: 2AA2S-M508 Date: Sept. 17, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: I, the undersigned, hereby attest to the fact that I will apply the Declaration of Conformity procedure to the receiver operate at frequencies from 30-960 MHz device. I understand the following FCC requirements: 1. Devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm (Select the "accredited" option to search for FCC recognized accredited test firms.)\ 2. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. 3. Pt 2.1077 contains the list of information that must be included in the Declaration of Conformity, which must be supplied with each product sold. The DoC compliance info shall be included in the User’s Manual or as a separate sheet. The info must contain the name, address, and phone number of the responsible party, which must be located within the United States. According to 2.909(c)(2), the responsible party is either the Manufacturer or if the product is imported the Importer. Sincerely, Hu Bo/Manager

GATOR GROUP CO., LTD 5 Floor, TGK NO. 11 Building, Yangtian Road, the 72nd Zone of Bao'an, Shenzhen, China TEL: 86-755-23085553 FAX: 86-755-29566339 Series Models Description FCC ID: 2AA2S-M508 Date: Oct. 22, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: To whom concern: The device (Product Name: GPS Tracker) Models Name: M508, M518, M528, M538, M548, M558, M568, M578, M588, M598 have same electrical, PCB and BOM, only the model’s name and colour are different for marketing requirements. Sincerely, Hu Bo/Manager

V1.0 Page 40 of 45 Report No.: CTL1308161300-WU 6. External and Internal Photos of the EUT External Photos of EUT V1.0 Page 41 of 45 Report No.: CTL1308161300-WU V1.0 Page 42 of 45 Report No.: CTL1308161300-WU

FCC ID Label Information 1. Label location: 2. FCC ID Label: GATOR GROUP CO., LTD GPS Tracker FCC ID: 2AA2S-M508

Internal Photos of EUT

POWER: 1: External Power VIN through LDO (MP4560) level converter generates VBAT (4.0V) for GSM module working voltage, VBAT other way then through LDO (AP2121) produces V_GPS (3.3V) for GPS Module 2: When an external power outage cases, by Bat Processor processing unit with an internal battery immediately cut Change, achieve product life role. When an external power supply built-in battery case will automatically Charging. GPS: By RF_IN (GPS antenna) to receive GPS satellite signals through the band-pass filter and an RF pre-processing After entering the baseband system, to give full GPS data via UART (serial port) External Data output. GSM / GPRS: GSM uses ARM7EJ-S core baseband processor platform, clocked at up to 104MHz. Operating frequency band: 850MHz, 900MH, 1800MHz, 1900MHz Internal component units: GPIO Serial Interface ADC AUDIO Sim Interface. RF Transceiver GPIO: responsible for the digital signal input and output control processing Serial Interfaced: responsible for receiving the GPS signal UART data stream, and do data analysis processing ADC: The AD is responsible for converting external circuit signal acquisition AUDIO: receive or deliver voice communications signals MIC and SPEAKER RF Transceiver: responsible for receiving or sending packets associated communication with the server.

Product model：M528-M50 BOM TYPE：productPage 1 serial number name of materialMaterial specificationsElement typePackaging codeDesign code amount unitremarks 1 resistance 0R Electronic -SMD 0603R119 R120 R121 R122 4 PCS 2 resistance22RElectronic -SMD 0603R113 R114 R115 R116 4 PCS 3 resistance200RElectronic -SMD 0603R108 R109 R111 R151 4 PCS 4 resistance 220R Electronic -SMD 0603R117 R118 R150 3 PCS 5 resistance470RElectronic -SMD 0603R112 R110 R152 3 PCS 6 resistance1KElectronic -SMD 0603R124 R125 2 PCS 7 resistance1MElectronic -SMD 0603R148 R149 2 PCS 8 resistance1.96K(1%)Electronic -SMD 0603R141 1 PCS 9 resistance 2.2K Electronic -SMD 0603R140 R153 2 PCS 10 resistance4.7K(1%)Electronic -SMD 0603R146 R147 2 PCS 11 resistance 5.1K Electronic -SMD 0603R126 R127 2 PCS 12 resistance 9.1k(1%) Electronic -SMD 0603R142 R145 2 PCS 13 resistance 10K Electronic -SMD 0603 R102 R103 R105 R106 R154 5 PCS 14 resistance 10K(1%) Electronic -SMD 0603 R123 1 PCS 15 resistance 26.7K(1%) Electronic -SMD 0603R131 1 PCS 16 resistance 33K Electronic -SMD 0603 R136 R137 R138 R1394 PCS 17 resistance40.2k(1%)Electronic -SMD 0603R135 1 PCS 18 resistance47.5kElectronic -SMD 0603R134 1 PCS 19 resistance62K(1%)Electronic -SMD 0603R101 1 PCS 20 resistance 100K Electronic -SMD 0603R128 R129 R130 R155 4 PCS 21 resistance200kElectronic -SMD 0603R132 1 PCS 22 resistance187K（1%）Electronic -SMD 0603R143 R144 2 PCS 23 resistance210K(1%)Electronic -SMD 0603R133 1 PCS 24 resistance910K(1%)Electronic -SMD 0603R100 1 PCS 25 resistance 15UH Electronic -SMD 0805L100 1 PCS PDF created with pdfFactory trial version www.pdffactory.com Product model：M528-M50 BOM TYPE：productPage 2 serial number name of materialMaterial specificationsElement typePackaging codeDesign code amount unitremarks 26 capacity 104 Electronic -SMD 0603 C101 C102 C103 C104 C105 C106 C107 C116 C119 C127 10 PCS 27 Non polar capacitor 1UF Electronic -SMD 0603C125 1 PCS 28 Non polar capacitor0.1UF(100V)Electronic -SMD 0805C118 1 PCS 29 Non polar capacitor10PFElectronic -SMD 0603C108 C109 C110 C111 4 PCS 30 Non polar capacitor330PFElectronic -SMD 0603C122 1 PCS 31 Non polar capacitor33PFElectronic -SMD 0603C112 C113 C114 C115 4 PCS 32 polar capacitor 22UF/50V Electronic -SMD 0805C100 1 PCS 33 Non polar capacitor102PFElectronic -SMD 0603C120 1 PCS 34 polar capacitor100UF/10VElectronic -SMD C-11.5-8C126 1 PCS 35 polar capacitor47UF/6.3VElectronic -SMD 1206-cC117 1 PCS 36 polar capacitor22UF/6.3VElectronic -SMD 1206C128 1 PCS 37 polar capacitor 1000UF/10V Electronic -DIP C4373C124 1 PCS 38 polar capacitor22UF/100VElectronic -DIP C121 1 PCS 39 diodeIN4148Electronic -SMD DIO-1206D107 1 PCS 40 diode IN5408 Electronic -DIP TO-201ADD106 1 PCS 41 diode SK34 Electronic -SMD DIO-1210D103 D104 2 PCS 42 diode SS14 Electronic -SMD DIO-1210D100 D101 D102 3 PCS 43 diode3V zener diodeElectronic -SMD DIO-1206D110 D111 2 PCS 44 diode 9.1Vzener diode Electronic -SMD DIO-1207D109 1 PCS 45 Schottky diode B2100 Electronic -SMD DIO-1206D105 1 PCS 46 Transient diode SMBJ54(C)A Electronic -SMD DIO-1206D108 1 PCS 47 triode SS9014LT Electronic -SMD SOT-23NPNQ100 Q101 Q102 Q103 Q107 5 PCS 48 triode 2SB1260Q Electronic -SMD SB1260AQ104 Q108 2 PCS 49 stacked MOS NRT4171PElectronic -SMD Q105 Q106 2 PCS 50 integrated circuit AP2121-3.3 Electronic -SMD AP2121U102 U109 2 PCS 51 integrated circuit MP4560DN Electronic -SMD SOP-8U104 1 PCS 52 integrated circuitTL431AIElectronic -SMD SOT23-5U106 1 PCS 53 integrated circuit TLC27L2 Electronic -SMD SOP-8U108 1 PCS PDF created with pdfFactory trial version www.pdffactory.com Product model：M528-M50 BOM TYPE：productPage 3 serial number name of materialMaterial specificationsElement typePackaging codeDesign code amount unitremarks 54 integrated circuit TP4055 Electronic -SMD LTC4054U107 1 PCS 55 integrated circuit MSQA6V1W5T2-1 Electronic -SMD SOT-323U103 1 PCS 56 integrated circuit M50 Electronic -SMD M10U100 1 PCS 57 module GPS-S1315R/UBLOX Electronic -SMD UBOX-GPSU101 1 PCS 58 coaxial connector ; zener diode Electronic -SMD J100 J101 2 PCS 59 jack 2PIN jack Electronic -DIP J102 1 PCS 60 jack1.27*2*2Electronic -SMD U105 1 PCS 61 wire stock 528 Power supply welding wire Electronic -SMD CON101 1 PCS 62 wire stock8 core welding wireElectronic -SMD CON100 1 PCS 63 Audio socketMicrophone holderElectronic -SMD PJ-326CON102 1 PCS 64 SIM socketFlip cardElectronic -SMD SIM6 SIMSIM100PCS 65 LED LED Electronic -DIP REDLED100 1 PCS 66 LED LED Electronic -DIP GREENLED300 1 PCS 67 lamp-socket led lamp-socketLED100 1 PCS 68 ferrule &8 PlasticThe diameter of 8MM1 PCS 69 ferrule &6 PlasticThe diameter of 6MM2 PCS 70 baffle plate baffle plate 528 baffle plate 1 PCS 71 pcb PCB 1 PCS PDF created with pdfFactory trial version www.pdffactory.com S/N Name Spec. Quantity Position 1 chip resistor R-47K (0402,±5%, 0.1W, ROHS) 1 R3 2 chip resistor R-3.3K (0402,±5%, 0.1W, ROHS) 1 R6 3 chip resistor R-100R (0402,±5%, 0.1W, ROHS) 1 R8 4 chip resistor R-0R (0402,0.1W, ±5%,ROHS ) 1 R9 5 Patch ceramics capacitors C-2P7 (0402, COG, 50V ,±0.25pF,ROHS) 1C3 6 Patch ceramics capacitors C-18P (0402 ,COG ,25V ,±5% ,ROHS) 2 C6 ,C7 7 Patch ceramics capacitors C-47P (0402, COG,25V,±5%,ROHS) 1 C2 8 Patch ceramics capacitors C-10nF (0402 ,X7R ,16V, ±10% ,ROHS) 1 C1 9 Patch ceramics capacitors C-100N (0402, X5R ,10V,±10%, ROHS) 1 C 5 10 Patch ceramics capacitors C-1uF (0402 ,X5R ,6.3V ,±10% ,ROHS) 9 C4,C8,C9,C10,C13,C14,C15,C16,C17,C18 11 Patch ceramics capacitors C-2U2 (0402, X5R, 6.3V,±20%, ROHS) 2 C11,C12 14 High Frequency Chip Inductor L-27nH (0402,±5%,300MA,ROHS) (LQG 15HN27NJ02) 1 L1 15 Chip Wire Wound Inductor L-12nH (0402,±2%, 500MA,ROHS)(LQW15AN 12NG00) 1 L2 16 Chip Bead BEAD 1000R@100MHZ (BLM15HD102SN1,0402) ROHS 1 FB1 17 ESD diode ESD Diode ： ESD0P2RF-02LRH, TSLP-2-17 (0402), Infineon 1D1 18 Chip IC U-BLOX G6010 MLF56 1 U1 19 SAW Filter Saw Filter：1.57542GHz, 1.4*1.1*0.4mm, SMT P/N:SAFEB1G57FM0F00 ROHS 1U3 20 Chip Crystal RAKON RSX-8 26MHZ 3.2mm*2.5mm 1 X1 21 Chip Crystal 32.768KHz 负载电容 12.5PF, …

Text truncated - open the document above for the full version.

序号名称规格型号封装用量零件位置 1贴片电阻R-47K (0402,±5%, 0.1W, ROHS) 0402 1R3 2贴片电阻R-3.3K (0402,±5%, 0.1W, ROHS) 0402 1R6 3贴片电阻R-100R (0402,±5%, 0.1W, ROHS) 0402 1R8 4贴片电阻R-0R (0402,0.1W, ±5%,ROHS ) 0402 1R9 5贴片瓷片电容 C-2P7 (0402, COG, 50V ,±0.25pF,ROHS)04021C3 6贴片瓷片电容 C-18P (0402 ,COG ,25V ,±5% ,ROHS)04022C6,C7 7贴片瓷片电容 C-47P (0402, COG,25V,±5%,ROHS)04021C2 8贴片瓷片电容 C-10nF (0402 ,X7R ,16V, ±10% ,ROHS) 0402 1C1 9贴片瓷片电容 C-100N (0402, X5R ,10V,±10%, ROHS)04021C5 10贴片瓷片电容 C-1uF (0402 ,X5R ,6.3V ,±10% ,ROHS)04029 C4,C8,C9,C10,C 13,C14,C15,C16 C17 C18 11贴片瓷片电容 C-2U2 (0402, X5R, 6.3V,±20%, ROHS)04022C11,C12 14高频贴片电感 L-27nH (0402,±5%,300MA,ROHS) (LQG15HN27NJ02)04021L1 15绕线贴片电感 L-12nH (0402,±2%, 500MA,ROHS)(LQW15AN12NG00)04021L2 16贴片磁珠BEAD 1000R@100MHZ (BLM15HD102SN1,0402) ROHS04021FB1 17 ESD二极管 ESD Diode：ESD0P2RF-02LRH, TSLP-2-17 (0402), Infineon 0402 1D1 18贴片ICU-BLOX G6010 MLF56QFN56pin1U1 19声表面滤波器 Saw Filter：1.57542GHz, 1.4*1.1*0.4mm, SMT P/N: SAFEB1G57FM0F00 ROHS 5PIN1U3 20贴片晶振RAKON RSX-8 26MHZ 3.2mm*2.5mm32251X1 替代贴片晶振TST 26MHZ 3.2mm*2.5mm32251X1替代 21贴片晶振32.768KHz 负载电容12.5PF, +-20ppm EPSONFC1351Y1 22 PCB US363 13mm*16mm 4层 FR4 V3.4B1PCB 23屏蔽罩 SHIELD-US363 13*16 shield 材质:洋白铜 1SHIELD 核准:审核:制作: . Ublox-16-13 9600 BOM

Tune up procedure Tune up procedure shall be over the power range or at specific operating power levels. 1. It must provide an operational voltage (12V DC) to turn on the device and on one certain channel in service mode by means of company proprietary software. 2. The Base station simulator measures the device specific RF characteristics. 3. The maximum gains of each individual device are adjusted and measured until the target value met. z For GSM 850 band： PCL = 5, PWR = 32.5 ± 1 dBm z For GPRS 850 band (1slot)： PCL = 5, PWR = 32.5 ± 1 dBm z For GPRS 850 band (2slot)： PCL = 5, PWR = 32.5 ± 1 dBm z For GPRS 850 band (3slot)： PCL = 8, PWR = 29.5 ± 1 dBm z For GPRS 850 band (4slot)： PCL = 8, PWR = 29.5 ± 1 dBm z For PCS 1900 band : PCL = 0, PWR = 29.5 ± 1 dBm z For GPRS 1900 band (1slot): PCL = 0, PWR =29.5 ± 1 dBm z For GPRS 1900 band (2slot): PCL = 0, PWR =29.5 ± 1 dBm z For GPRS 1900 band (3slot): PCL = 0, PWR =29.5 ± 1 dBm z For GPRS 1900 band (4slot): PCL = 2, PWR = 29.5 ± 1 dBm Then these appropriate gain settings are stored in each device individually. The user has no possibility to change these settings later on, and during manufacturing each device will be individual calibrated in this range. The measurement is done in a fully calibrated setup, which is based on the base station simulator. Furthermore, the highest power level is verified afterwards in a call measurement on three channels (low, middle and high). At last you can also help to update the NV by Qualcomm NV tools.
