2AA3OFFR-01Full Function Remote

The Verdin Company

Click to zoom

Application Details

Equipment Class: DSC - Part 15 Security/Remote Control Transmitter
Date of Grant: Sep 29, 2013
Application Purpose: Original Equipment
Date of Application: Sep 29, 2013
Equipment Note: Full Function Remote
Frequency Range: 418.00000000 - 418.00000000
Company: The Verdin Company
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

VERDINFULLFUNCTIONREMOTE MODEL#FFR-01 The buttons on the remote control offer easy execution of various library songs or stored shortcut function. xTo execute short-cut (1) thru (7) simply depress the desired shortcut number on the remote control number pad and then depress the Enter button (ENT). Button (8) executes the stop function. xThe Clear button (CLR) can be used to clear unwanted button entries. xTo play a library song simply enter its corresponding song number on the remote button panel then press the enter key (ENT). NOTE: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult The Verdin Company for help. Operation with non-approved equipment is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without approval of manufacture could void the user’s authority to operate this equipment.

Cover Letter(s)

Correspondence by Project Project Number: Correspondence Number Memo 2AA3OFFR-01-1 1) Please provide a certification contract. Response: The Certification Contract has been uploaded. 2) The TCB submittal attestation has an incorrect FCC ID listed. Please provide a corrected letter. Response: The TCB submittal attestation has been revised and uploaded. 3) Please provide test setup photos. Response: The test setup photos have been uploaded. 4) The operational description describes an operation that is not permitted by the rules. Please provide a description that complies with the rules. Response: The Operational Description has been revised and uploaded. 5) The user manual provides guidance on using shielded cables, however the devices has no cables. Please provide a corrected user manual. Response: The revised owners manual has been uploaded. 6) The modification letter does not list the resistor that was changed. Please provide a corrected letter. Response: The modification letter has been revised. Untitled Documenthttp://www.celectronics.com/CorrespondenceByProject.asp?ProjectNum... 1 of 19/25/2013 6:10 PM

RF Exposure Info

SAR TEST EXCLUSION This device, FCC ID: 2AA3OFFR-01, is excluded from SAR testing by the following justification. The maximum power that the transmitter IC is capable of is 10 mW. By using the following formula from section 4.3.1 of KDB 447498: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR and using the minimum test separation distance of 5 mm, the resulting calculated SAR value is: (10 mW)/5 mm) * (√.418 GHz) = 1.3 This value is below the exclusion threshold for both the 1-g SAR and 10-g extremity SAR requirements.

Test Report

Report Number: B30826A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.231 Test Report Full Function Remote Model: FFR-01 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 17 FCC PART 15 SUBPART B and C TEST REPORT for FULL FUNCTION REMOTE MODEL: FFR-01 Prepared for THE VERDIN COMPANY 444 READING ROAD CINCINNATI, OHIO 45202 Prepared by:_____________________ ALEX BENITEZ Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: AUGUST 27, 2013 REPORTAPPENDICESTOTAL BODYA B C D E PAGES 17 2 2 2 12 11 46 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30826A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.231 Test Report Full Function Remote Model: FFR-01 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 17 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 7.2 Bandwidth of the Fundamental 16 8. CONCLUSIONS 17 Report Number: B30826A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.231 Test Report Full Function Remote Model: FFR-01 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 17 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models D Diagram, Charts, and Photos  Test Setup Diagram  Antenna and Amplifier Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site – 3 Meters Report Number: B30826A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.231 Test Report Full Function Remote Model: FFR-01 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 17 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Full Function Remote Model: FFR-01 Product Description: See Expository Statement Modifications: The EUT was modified during the testing. Please see the list located in Appendix B. Customer: The Verdin Company 444 Reading Road Cincinnati, Ohio 45202 Test Date(s): August 26 and 27, 2013 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.231 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT is battery powered and cannot directly or indirectly connects to the AC public mains. 2 Radiated RF Emissions 10 kHz to 4180 MHz (Transmitter and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B30826A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.231 Test Report Full Function Remote Model: FFR-01 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 17 1. PURPOSE This document is a qualification test report based on the emissions tests performed on the Full Function Remote, Model: FFR-01. The Emissions measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred …

Text truncated - open the document above for the full version.

Test Report

DUTY CYCLE INFORMATION FOR FULL FUNCTION REMOTE MODEL: FFR-01 PULSE TIME (uS) 1 105.29 2 106.29 3 818.29 4 226.29 5 114.29 6 156.29 7 112.29 8 114.29 9 156.29 10 220.29 11 114.29 12 158.29 13 114.29 14 222.29 15 156.29 16 1028.30 17 222.29 18 152.29 19 828.29 Total 5126.52 Pulse Train with Blanking 10850 Duty Cycle 47.24903 %

Test Setup Photos
