1 CONSTRUCTION PHOTOS OF EUT 2

Label Location FCC ID: 2AA4L-HTZNLTABLET IC: 11444A-HTZNLTABLET Back cover of EUT

TF-LABEL;RATING,3-1,Rudolf 242N42500005 R00 V Amigo.huang 10/16/’13 Ref. NoteNANANA      25.5 mm 32.1 mm R 1.0mm R 1.0mmR 1.0mm R 1.0mm Caution: Only use the specified power supply (see user’s manual) Model No.: NeverLost ® 6 Tablet Input: 12V 3A P/N: 242N42500005 R00 XX-X K Made in China 10R-XXXXXXX QDID: B021483 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2AA4L-HTZNLTABLET IC:11444A-HTZNLTABLET XXXX Navigation Solutions Inc.

3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

Report No.: SA130814C33 1 of 7 Report Format Version 5.1.0 RF EXPOSURE REPORT REPORT NO.: SA130814C33 MODEL NO.: NeverLost® 6 Tablet FCC ID: 2AA4L-HTZNLTABLET RECEIVED: Aug. 14, 2013 ISSUED: Sep. 11, 2013 APPLICANT: MiTAC International Corp. ADDRESS: Building B, No. 209, Sec. 1, Nan Gang Rd., Nan Gang Dist., Taipei 11568, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA130814C33 2 of 7 Report Format Version 5.1.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 3 1. CERTIFICATION ......................................................................................................................... 4 2. RF Exposure ............................................................................................................................... 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) .................................................... 5 2.2 MPE calculation Formula ............................................................................................................ 5 2.3 Classification ............................................................................................................................... 5 2.4 calculation result of maximum conducted power ........................................................................ 6 2.5 Evaluation of Simultaneous transmission ................................................................................... 7 Report No.: SA130814C33 3 of 7 Report Format Version 5.1.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130814C33 Original release Sep. 11, 2013 Report No.: SA130814C33 4 of 7 Report Format Version 5.1.0 1. CERTIFICATION PRODUCT: Automotive Navigation Device MODEL NO.: NeverLost® 6 Tablet BRAND: Hertz APPLICANT: MiTAC International Corp. TEST SAMPLE: Production Unit STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (model: NeverLost® 6 Tablet) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : Sep. 11, 2013 Vera Huang / Specialist APPROVED BY : , DATE : Sep. 11, 2013 Roy Wu / Manager Report No.: SA130814C33 5 of 7 Report Format Version 5.1.0 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA130814C33 6 of 7 Report Format Version 5.1.0 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER Frequency Band (MHz) Operating Mode Maximum Conducted (dBm) Antenna Gain (dBi) E.I.R.P. (mW) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Burst Avg. Power Time Avg. Power GSM850 GPRS10 29.41 23.41 1 276.06 0.055 0.55 GSM1900 GPRS8 29.35 20.35 2.5 192.75 0.038 1.00 Frequency band (MHz) Conducted Avg. power (dBm) Antenna Gain (dBi) E.I.R.P. (mW) Power Density (mW/cm2) Limit (mW/cm2) WCDMA Band II 22.93 2.5 349.14 0.069 1.00 WCDMA Band V 23.23 1 264.85 0.053 0.55 2402~2480 2.37 1.5 2.44 0.0005 1.00 2412~2462 16.22 4.51 118.30 0.024 1.00 5180~5240 14.89 6.31 131.83 0.026 1.00 5260~5320 17.71 6.21 246.60 0.049 1.00 5500~5700 15.11 6.91 159.22 0.032 1.00 5745~5825 17.83 6.11 247.74 0.049 1.00 Note: For 2412~2462: Directional gain = 1.5dBi + 10log(2) = 4.51dBi For 5180~5240: Directional gain = 3.3dBi + 10log(2) = 6.31dBi For 5260~5320: Directional gain = 3.2dBi + 10log(2) = 6.21dBi F…
