2AA7V-RFI1125KHZ RFID Floor level access security interface

RFID-1 PROGRAMMING MANUAL Version 2.00 This manual contains information for programming the RFID-1 tag reader security software included in software version 2 only (v2.32 or above) www.smartrise.us | 8360 Rovana Circle, Suite 3, Sacramento, CA 95828 | 916.457.5129 GETTING STARTED The Smartrise SRU controller provides a RFID-1 interface which allows the user to program security tags for each car. Currently, the RFID-1 security feature is only available on a 3- board system (MR/CT/COP boards) and in software version 2.32 and above. Requirements The following shows requirements for programming the RFID-1 tags: 1. Tag programming can only be done from the master board (COP). 2. Group – Only one master COP allowed per group. All other car COP’s are classified as slaves. 3. Simplex – The COP board must be a master. Hardware COP Board RFID-1 Reader Drive Port RFID-1 Tag Dip A COP Board Dip A The Dip Switch settings you will use on the COP board (Dip A) are as follows: 1. Operating the RFID-1 – Dip Switch #2 on. This is always on for the RFID-1 to operate. 2. Programming a Manager Tag – Dip Switches (#2 & #3) + swiping a Tag will program that tag as the Manager Tag. This tag is needed for the programming of slave tags. 3. Deleting All Tags – Dip Switches (#2, #3 & #4) + swiping the Manager Tag will delete all tags. This needs to be done to initialize the board for the first time. 125 KHZ RFID-1 Reader The reader will plug into the Drive port on the COP board. In a Group system only one car COP board can be a Master board for programming. All other car COP boards will be slave boards. The reader should be installed so that the LED’s are visible when powered on and the plate accessible for scanning the tag when swiped across it. 125 KHZ RFID-1 Tag A small keychain tag with a numerical ID printed on it. These tags can be programmed as the Master Tag or as floor tags. The number printed on the tag is used by the software but is not needed for individual programming. When the tags are programmed they are assigned a numerical value starting at 000 (Master programmer tag), 001 (1 st tag programmed), 002 (2 nd tag programmed), etc. up to max of 585 tags. PROGRAMMING THE READER (REQUIRES ACCESS TO COP BOARD) 1. Plug the reader into the COP Drive port using a standard CAT5 cable. 2. Turn on Dip Switch #2. [This will be left on when programming or using the RFID-1 reader]. 3. Turn on Dip Switch #3 (#2 & #3 are now on) and swipe a tag across the reader. This will program that tag as the Manager Tag which will be needed to program the User Tags. 4. Turn on Dip Switch #4 (#2, #3 & #4 are now on) and swipe the Manager Tag (programmed in step #3). This will delete all tags that may be programmed in system, including the new Manager Tag programmed in Step #3. 5. Turn off Dip Switch #4 and swipe a tag across the reader reprogramming it as the new Manager Tag. 6. Turn off Dip Switch #3 (#2 is the only switch that will stay on). Now you’re ready to program the User tags. LED Patterns – Programming the Reader Red / Green Blinking w/short pause between blinking Manager Tag programmed successfully Red / Green Blinking w/long pause between blinking Delete all tags successful PROGRAMMING THE USER TAGS 1. With the solid red light on, swipe the Manager Tag across the face. You should have a solid green light with a brief red flash showing the reader is in programming mode. 2. Swipe the un-programmed tag across the reader. The LED should be solid red with a brief green flash showing that the new tag is recognized. The Car Call Lamps (CCL) will display the tag ID (001 for 1 st tag, 002 for second tag, etc.) in Binary. The following table shows an example of a 4-stop car and the Car Call Lamps that correspond with the tag ID. Tag Description ID# Floor 1 CCL Floor 2 CCL Floor 3 CCL Floor 4 CCL Master Tag 0000 User Tags 0001 X 0002 X 0003 X X 0004 X 0005 X X 0006 X X 0007 X X X 0008 X 3. Press the DCB button. The reader should now go to “Waiting for floor permissions” with the red and green LEDs flashing. Perform step “a” or “b” below. a. Press the Car Call Button(s) for each floor that this tag will unlock when swiped b. Pressing the DOB during this phase will toggle between giving permission to all or no floors. 4. Press the DCB button to save tag’s programming and reader goes back to Programming Mode. 5. Repeat steps 2~3 for each tag to be programmed. 6. When finished programming, and while in Programming Mode, press the DOB to exit programming mode. This will be done when the LED is solid green with a brief red flash. The LED should go to solid red which means it is in normal operation mode waiting for a tag swipe. LED Patterns – Programming RFID-1 Slave Tags LED Pattern Description DOB DCB Solid Green w/ brief Red flash Programming mode: Waiting for new tag to be swiped or tag ID to be entered with CCBs Exits programming mode Allows programmer to manually enter a tag ID (for modification or deletion only) Solid Red w/ brief Green flash Verification Mode: New tag recognized (CCL displays tag ID) Deletes tag Advances to “waiting for floor permissions” mode Red / Green Blinking Floor Permissions Mode: Pressing single or multiple CCB’s will enable those floors. Toggles between giving permission to ALL or NONE floors Saves permissions DCB on floor permission: Save floor permissions and go back to beginning of programming mode waiting for new tag. 1. The Door Open Button (DOB) and Door Close Button (DCB) handle several functions when programming the RFID-1. a. DOB i. DOB in Programming Mode: Exit programming mode ii. DOB when displaying tag ID or after manually entering ID: Deletes tag iii. DOB when on floor permissions: Toggles between giving permission to ALL or NONE floors b. DCB i. DCB in Programming Mode: Allows programmer to manually enter a tag ID (001, 002, etc. - see table on previous page) ii. DCB when displaying tag ID: Advances to “waiting for Floor permissions” iii. DCB when “waiting for floor permissions: Saves Pe…

Text truncated - open the document above for the full version.

8360 Rovana Circle, Suite #3, Sacramento, CA 95828 Ph. 916.457.5129 | www.smartrise.us | Fx. 916.457.4948 7/7/2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: 2AA7V-RFI1 1. Block Diagram 2. Operational Description 3. Schematics 4. Parts List / Tune-Up Procedure The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, Gilbert Zogbi CEO Smartrise Engineering

CAM350 PRO V 6.0 : Wed Jul 02 22:52:14 2014 - (Untitled)

This report contains a total of 26 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Smartrise Engineering, Inc. ADDENDUM TO TEST REPORT 94840-4 RF Reader Model: RFID-1 Tested To The Following Standards: FCC Part 15 Subpart C Section 15.207, 15.209 and RSS-210 Issue 8 Report No.: 94840-4A Date of issue: April 3, 2014 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 26 Report No.: 94840-4A TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C .................................................................................................................................................... 7 15.207 AC Mains Conducted Emissions ..................................................................................................................... 7 15.209 Fundamental ................................................................................................................................................ 15 15.209 Radiated Spurious Emissions ....................................................................................................................... 18 RSS-210 Issue 8 ........................................................................................................................................................ 22 Supplemental Information .......................................................................................................................................... 25 Measurement Uncertainty ...................................................................................................................................... 25 Emissions Test Details .............................................................................................................................................. 25 Page 3 of 26 Report No.: 94840-4A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Smartrise Engineering, Inc. 8360 Rovana, Suite 3 Sacramento, CA 95828 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: Gilbert Zogbi Project Number: 94840 Customer Reference Number: 4587 DATE OF EQUIPMENT RECEIPT: September 17, 2013 DATE(S) OF TESTING: September 17, 2013 April 2, 2014 Revision History Original: Testing of the RF Reader, RFID-1 to FCC Subpart C Section 15.209 and RSS 210 Issue 8. Addendum A: To add testing of the RF Reader, RFID-1 to FCC Subpart C Section 15.207. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 26 Report No.: 94840-4A Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Mariposa A US0103 SL2-IN-E-1147R 3082A-2 90477 A-0136 Page 5 of 2…
