2AA9U-Q407Tablet

Jelly Bean Q407 7” Quad Core Tablet 1. . . .Appearance Appearance Appearance Appearanceand and and andbutton: button: button: button: 4 9 1234567 8 10 5 Headphone jack: 3.5mm standard headphone jack TF-card slot: External T-FLASH card, support up to 32GB Mini HDMI interface: Used to connect to external HDMI displays Power button Startup: Hold down the power button for several seconds. The tablet will turn on and then the system will enter the main interface. Shutdown: In the main menu interface, press the power button for several seconds to shutdown, The system will hint . the "power off" option Click ”OK”. Now you can safely shut down. Turn off sc reen: When the screen is on, short press Power b utton to turn off screen. Short press Power button again to turn on screen. Remark 1. When the power is depleted the system will shut down automatically. 2. Restart will scan and restore the disk. It may take a longer time to enter into system. 2 3 4 5 6 7 1 Number Number Number Number # # # #Description 8 Micro USB interface: Connect the tablet and computer, realizes the data transmission.Also can use charging for tablet. Front Camera (0.3MP) Back button: Short press this button will return to the last interface Power Jack: One end of the AC adaptor can be inserted to the Power Jack and then the charger is inserted to a standard AC wall outlet to charge the battery of the tablet. 6 2. 2. 2. 2.First First First First use use use use 2.1 Battery management and charge Prior to first use, make sure the battery is fully charged Tocharge simply connect the adaptor (to AC wall outlet) or USB cable (to USB port on your computer). Charge for six hours for the first two times .Following that the battery need only be charged for 4 hours. 【Remark】: This tablet has a Built-in type Lithium ion battery, Tocharge, use a standard adaptor . Also USB interface can charge by inserting one end of USB cable to USB interface of tablet and the other end to an available USB port on your computer. While charging, the battery icon will scroll. When charging is complete the battery icon will become green and stop scrolling. In order to prolong the service life of the device, let the battery deplete before charging. 【Remark】: 1. Charge the battery at least once a month to avoid power consumption caused damage. 2. After low battery shut down, connect the DC adaptor. While cha rging, yo u will need to wait some time until the battery has enough power to switch on and enter into main menu. 3. Device charging should be in standby status to reach normal charging time; charging time may take longer if using the tablet during charging. Rear Camera (2MP) 9 10 Speaker 9 3.2 Main interface description The main interface of the handheld tablet includes two modes: the small tools on the desktop mode and the icons of application programs mode, both of which can be switched between each other via the buttons at the corners. The mode of small tools on the desktop is shown as follows: Tapbutton located in the center of the main screen to enter the interface of icon modes for application programs, which is shown as follows: 10 Tapbutton to enter the desktop interface. Note: If the tablet is switched on for the first time after being purchased, it will automatically install the built-in application programs. The tablet may operate slowly and some hints may appear on the screen. After installation of programs has been completed, the operation of tablet resumes normal. 3.3 Shortcut Mode Under the interface of the mode of small tools on the desktop, after tappingupper right corner, the Shortcut menu will pop up at thetop right of the screen, shown as follows: 11 3.4 3.4 3.4 3.4Usage Usage Usage Usageof of of ofSmall Small Small SmallTools Tools Tools Toolson on on onDesktop Desktop Desktop Desktop Users can add or delete the small tools on the desktop, as well as add or delete icons of application programs or adjust the positions of icons; the icons can be dr agged within the working zone of the desktop. Under the interface of the mode of small tools on the desktop, press and hold the icons of small tools, a sign of ‘Remove ’will pop up in the central top edge of the desktop. At that time, you are able to drag the icon anywhere on the desktop, or drag it directly to the ‘Remove ’sign to delete it. 14 After entering the interface of Browse files, it is able to copy, move, paste or delete files in the LOCAL, SD1 or U disk. Install Install Install Install Files Files Files Files Toinstall files in the file browser, tap the installation file with extension name as APK, an installation window will pop up. Select “Install” to install the software on the tablet. 21 5.8Search Tapicon to enter the interface of Google search to conduct search by text, as shown below: Type to search the web 5.9.Camera Tapicon to enter the interface of Shooting -Accessibility Q407 35 12 12 12 12. . . . Basic Basic Basic Basic function function function function Hardware configuration Size: (length* wide*thick) CPU processor speed: Memory: 8 GB RAM: 1 GB TF card: Up to 32GB Display screen: Resolution: Camera: Front and Rear Battery and capacity: rechargeable Built-in type lithium ion, G-sensor: 3 axes Record: built-in microphone Operation System: Android 4.2 7” (Capactive multi-touch)TFT capacitive touch Cortex A9, 1.2GHz 1024*600 2800mAh 191mm x 120mm x 10.5mm FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference t…

Text truncated - open the document above for the full version.

Digitac, Inc. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2014-1-13 SUBJECT: FCC Application for ( FCCID: 2AA9U-Q407) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Name: Jacob Elmann Title: Manager Tel: 86-769-89895188

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Digitac, Inc. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014/1/13 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ _ Digitac, Inc. ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： Tablet Trade Name： ULTRATAB Model Name： Q407 Serial Model： I759 FCC ID： 2AA9U- Q407 We affirm that between SIEMIC and ___ Digitac, Inc. ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Jacob Elmann Title: Manager Tel: 86-769-89895188

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Digitac, Inc. 2014-1-13 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AA9U-Q407 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Client’s name / title : Jacob Elmann / Manager Contact information / address : 140 Broadway 46th Floor,NYC,NY 10005

Digitac, Inc. Model Difference FCC ID: 2AA9U-Q407 Model : Q407, I759 All the same,Only model name is different. Regards, Client’s signature Client’s name / title : Jacob Elmann / Manager Contact information / address : 140 Broadway 46th Floor,NYC,NY 10005

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

FCC ID LABELING AND LOCATION FCC ID Label Tablet Model NO.：Q407 Input Rating：DC 5V/ 1.5A （Charging by Adapter） Battery:3.7V/ 2800mAh FCC ID: 2AA9U-Q407 Digitac, Inc. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Photo 7 Photo 8 Photo 9 Photo 10 ANT Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18

RF EXPOSURE EVALUATION METHOD FCC ID: 2AA9U-Q407 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. WIFI: TX 802.11b Mode Frequency Maximum Conducted Output Power(PK) Maximum Conducted Output Power(AV) Maximum Conducted Output Power(AV) Te s t Channe (MHz) (dBm) (dBm) (mW) CH01 2412 12.26 9.55 9.016 CH06 2437 12.59 9.35 8.610 CH11 2462 12.43 9.47 8.851 TX 802.11g Mode CH01 2412 11.36 8.79 7.568 CH06 2437 11.28 8.68 7.379 CH11 2462 11.21 8.62 7.278 TX 802.11n-HT20 Mode CH01 2412 10.22 8.41 6.934 CH06 2437 10.64 8.37 6.871 CH11 2462 10.68 8.45 6.998 TX 802.11n-HT40 Mode CH03 2422 10.76 8.42 6.950 CH06 2437 10.84 8.64 7.311 CH09 2452 10.57 8.66 7.345 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] WIFI: Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [√f(GHz)] Result Limit 802.11b CH01 9.016 5 2.412 2.80 3 CH06 8.610 5 2.437 2.69 3 CH11 8.851 5 2.462 2.78 3 802.11g CH01 7.568 5 2.412 2.35 3 CH06 7.379 5 2.437 2.30 3 CH11 7.278 5 2.462 2.28 3 802.11n20 CH01 6.934 5 2.412 2.15 3 CH06 6.871 5 2.437 2.15 3 CH11 6.998 5 2.462 2.20 3 802.11n-HT40 CH03 6.950 5 2.422 2.16 3 CH06 7.311 5 2.437 2.28 3 CH09 7.345 5 2.452 2.30 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: 2AA9U-Q407 Product： tablet Trade Name： ULTRATAB Model Name： Q407 Serial Model： I759 Report No.： NTEK-2013NT1231910F Prepared for Digitac, Inc. 1437 Pinewood St, Rahway, New JerseyUnited States, 07065 Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 65 Report No.: NTEK-2013NT1231910F TEST RESULT CERTIFICATION Applicant’s name........ Digitac, Inc. Address ........................ 1437 Pinewood St, Rahway, New JerseyUnited States, 07065 Manufacture's Name... Dongguan Digi-in Digital Technology Co.,ltd. Address ........................ North door of Jiatian industrial park, Wulian,Fenggang,Dongguan,Guangdong, P.R.C. Product description Product name .................tablet Model and/or type reference ..................... Q407 Serial Model .................... I759 Standards.................... FCC Part15.247 Test procedure ................ ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test...................................... Date (s) of performance of tests ....... 31 Dec. 2013 ~08 Jan. 2013 Date of Issue..................................... 08 Jan. 2013 Test Result......................................... Pass Testing Engineer : (Apple Huang) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 65 Report No.: NTEK-2013NT1231910F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . POWER SPECTRAL DENSITY TEST 36 4.1 APPLIED PROCEDURES / LIMIT 36 4.1.1 TEST PROCEDURE 36 4.1.2 DEVIATION FROM STANDARD 36 4.1.3 TEST SETUP 36 4.1.4 EUT OPERATION CONDITIONS 36 4.1.5 TEST RESULTS 37 5 . BANDWIDTH TEST 45 5.1 APPLIED PROCEDURES / LIMIT 45 5.1.1 TEST PROCEDURE 45 Page 4 of 65 Report No.: NTEK-2013NT1231910F Table of Contents Page 5.1.2 EUT OPERATION CONDITIONS 45 5.1.3 TEST RESULTS 46 6 . PEAK OUTPUT POWER TEST 54 6.1 APPLIED PROCEDURES / LIMIT 54 6.1.1 TEST PROCEDURE 54 6.1.2 DEVIATION FROM STANDARD 54 6.1.3 TEST SETUP 54 6.1.4 EUT OPERATION CONDITIONS 54 6.1.5 TEST RESULTS 55 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 56 7.1 DEVIATION FROM STANDARD 56 7.2 TEST SETUP 56 7.3 EUT OPERATION CONDITIONS 56 7.4 TEST RESULTS 57 8 . ANTENNA REQUIREMENT 63 8.1 STANDARD REQUIREMENT 63 8.2 EUT ANTENNA 63 9 . EUT TEST PHOTO 64 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 65 Report No.: NTEK-2013NT1231910F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 65 Report No.: NTEK-2013NT1231910F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 65 Report No.: NTEK-2013NT1231910F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment tablet Trade Name ULTRATAB Model Name Q407 Serial Model I759 Model Difference All models are identical except model names. Product Description The EUT is a tablet Operation Frequency: 802.11b/g/n(20MHz):2412~2462 MHz 802.11n(40MHz):2422~2452 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz/40MHz):150/144.44/1 30/117/115.56/104/86.67/78/52/6.5Mb ps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz: 7CH Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 12.59 dBm (Max.) 802.11g: 11.36dBm (Max.) 802.11n(20M): 10.68dBm (Max.) 802.11n(40M) : 10.84 dBm (Max.) Antenna Gain (dBi) 1.0dbi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer …

Text truncated - open the document above for the full version.

Page 64 of 65 Report No.: NTEK-2013NT1231910F 9. EUT TEST PHOTO Radiated Measurement Photos Page 65 of 65 Report No.: NTEK-2013NT1231910F Conducted Measurement Photos
