2AAAM-DXR8PPZ-BPUWireless Digital Video Monitoring System(Monitor)

STANDARD MERIT INDUSTRIAL LIMITED 604 Kalok Building, 720 Nathan Road, Kowloon, Hong Kong Date: 11-05-2023 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: (2AAAM-DXR8PPZ-BPU) Dear Sir or Madam, STANDARD MERIT INDUSTRIAL LIMITED. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, STANDARD MERIT INDUSTRIAL LIMITED certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment . If you have any questions, please contact us. Sincerely, Contact Person: TOM CHAN Company name: STANDARD MERIT INDUSTRIAL LIMITED Address: 604 Kalok Building, 720 Nathan Road, Kowloon, Hong Kong Tel.: (852) 27110990 Email: [email protected] Signature:

STANDARD MERIT INDUSTRIAL LIMITED 604 Kalok Building, 720 Nathan Road, Kowloon, Hong Kong Date (05/11/2023) Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request FCC ID: 2AAAM-DXR8PPZ-BPU Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, STANDARD MERIT INDUSTRIAL LIMITED. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation STANDARD MERIT INDUSTRIAL LIMITED. also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days (2023-11-07): Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Contact Person: TOM CHAN Company name: STANDARD MERIT INDUSTRIAL LIMITED Address: 604 Kalok Building, 720 Nathan Road, Kowloon, Hong Kong Tel.: (852) 27110990 Email: [email protected] Signature:

Ver : 3.0 Date: 16-Jun-2020 R.15 ON / OFF / SLEEP Engraving Silkscreen : White Silkscreen : PANTONE 408C Engraving VOLUMEBRIGHTNESS DXR-8 PRO Silkscreen : White Silkscreen : White Silkscreen : logo: White Silkscreen : PANTONE 408C Plastic(1): Transparent Silkscreen : PC Lense : PANTONE 406C logo: White Size:27.72X5mm PC High Glossy Plastic(2)-(3): Panton 406C ABS Texture ZX1885A Plastic(4)-(5): ABS, Transparent Cavity Side: Texture ZX1885A (outside) Core Side: Texture ZX1885A (inside) Plastic(12)-(14): White, ABS Texture ZX1885A Plastic(10)-(11): White, ABS Glossy Plastic(6)-(7): White , ABS Texture ZX1885A Plastic(8)-(9):White , PC+ ABS Glossy DXR-8 HD (RX) with DC JACK Silkscreen & Plastic information DXR-8 PRO Label Size:29.5X16.5mm Label Size:42X35mm MENU MENU TALK TALK ZOOM ANR ZOOM ANR ZOOM ANR OK OK ZA2211-000001PU Model: DXR8PPZ-B Wireless Monitor Li-ion Battery 3.85V, 2800mAh MADE IN CHINA YELLOW BLACK RED ZA2211-000001PU Model: DXR8PPZ-B Wireless Monitor Li-ion Battery 3.85V, 2800mAh MADE IN CHINA YELLOW BLACK RED INPUT: DC5V 1.5A MADE IN CHINA Customer Service Hotline: 1-800-291-0 195 FCC ID: 2AAAM-DXR8PPZ-BPU Genexus LLC INPUT: DC5V 1.5A MADE IN CHINA Customer Service Hotline: 1-800-291-0 195 FCC ID: 2AAAM-DXR8PPZ-BPU Genexus LLC

RF Antenna RF Antenna

Page: 1 of 23 TEST REPORT For SAR Report No. ...................................... : CHTEW23040048 Report vertification: Project No. ...................................... : SHT2301025101EW FCC ID ............................................. : 2AAAM-DXR8PPZ-BPU Applicant’s name ........................... : STANDARD MERIT INDUSTRIAL LIMITED Address ............................................. : 604 Kalok Building, 720 Nathan Road, Kowloon, Hong Kong Test item description .................... : Wireless Digital Video Monitoring System Trade Mark ....................................... : - Model/Type reference ....................... : DXR-8 PRO Listed Model(s) ................................. : DXR8PPZ-B, DXR8PPZ-BPU Standard ......................................... : FCC 47 CFR Part2.1093 IEEE Std C95.1: 1999 Edition IEEE Std 1528: 2013 Date of receipt of test sample..........: Apr. 11, 2023 Date of testing..............................: Apr. 12, 2023- Apr. 13, 2023 Date of issue...............................: Apr. 13, 2023 Result .................. ........................: PASS Compiled by ( position+printedname+signature) ... : File administrators: Silvia Li Supervised by ( position+printedname+signature) ... : Test Engineer: Weiyang Xiang Approved by ( position+printedname+signature) ... : Manager: Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW23040048 Page: 2 of 23 Issued: 2023-04-13 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) Contents 1. Statement of Compliance 3 2. Test Standards and Report version 4 2.1. Test Standards 4 2.2. Report version 4 3. Summary 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Testing Laboratory Information 6 3.4. Environmental conditions 6 4. Equipments Used during the Test 7 5. Measurement Uncertainty 8 6. SAR Measurement System Configuration 9 6.1. SAR Measurement Set-up 9 6.2. DASY5 E-field Probe System 10 6.3. Phantoms 11 6.4. Device Holder 11 7. SAR Test Procedure 12 7.1. Scanning Procedure 12 7.2. Data Storage and Evaluation 14 8. Position of the wireless device in relation to the phantom 16 8.1. Body Position 16 9. Dielectric Property Measurements & System Check 17 9.1. Tissue Dielectric Parameters 17 9.2. System Check 18 10. SAR Exposure Limits 21 11. Conducted Power Measurement Results and Tune-up 21 12. Antenna Location 22 13. Measured and Reported SAR Results 23 14. Test Setup Photos 23 15. External and Internal Photos of the EUT 23 Report No.: CHTEW23040048 Page: 3 of 23 Issued: 2023-04-13 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 1. Statement of Compliance Maximum Reported SAR (W/kg @1g) Type Test setting TFT Body Dist.= 0mm 0.619 Note: 1. This device is in compliance with Specific Absorption Rate (SAR) for general population/uncontrolled exposure limits (1.6 W/kg@1g) specified in FCC 47 CFR part 2 (2.1093) and IEEE Std C95.1, 2. This device had been tested in accordance with the measurement methods and procedures specified in IEEE 1528 and FCC KDB publications. Report No.: CHTEW23040048 Page: 4 of 23 Issued: 2023-04-13 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 2. Test Standards and Report version 2.1. Test Standards The tests were performed according to following standards: FCC 47 Part 2.1093: Radiofrequency radiation exposure evaluation: portable devices. IEEE Std C95.1, 1999 Edition: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. FCC published RF exposure KDB procedures: 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04: SAR Measurement Requirements for 100 MHz to 6 GHz 865664 D02 RF Exposure Reporting v01r02: RF Exposure Compliance Reporting and Documentation Considerations 447498 D04 Interim General RF Exposure Guidance v01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies TCB workshop April, 2019; Page 19, Tissue Simulating Liquids (TSL) 2.2. Report version Revision No. Date of issue Description N/A 2023-04-13 Original Report No.: CHTEW23040048 Page: 5 of 23 Issued: 2023-04-13 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 3.Summary 3.1. Client Information Applicant: STANDARD MERIT INDUSTRIAL LIMITED Address: 604 Kalok Building, 720 Nathan Road, Kowloon, Hong Kong Manufacturer: STANDARD MERIT INDUSTRIAL LIMITED Address: 604 Kalok Building, 720 Nathan Road, Kowloon, Hong Kong 3.2. Product Description Main unit Name of EUT: Wireless Digital Video Monitoring System Trade Mark: - Model No.: DXR-8 PRO Listed Model(s): DXR8PPZ-B, DXR8PPZ-BPU Power supply: 3.85VDC, 2800mAh (Supplied by Rechargeable Li-ion Battery) or 5VDC, 1500mA (Supplied by external adapter for Charging rechargeable battery) Device Dimension: Length x Width x Thickness (mm): 165 x 80 x 20 Device Category: Portable Product stage: Production unit RF Exposure Environment: Gen…
