2AAAVSRIOS-01Bluetooth Remote for iOS

Media Remote Controller For iOS devices User Manaul Bluetooth 3.0 O On Power Switch Pairing Button Features: 1, Bluetooth 3.0, with Broadcom chipset BCM20730 2, 11 hot keys for iOS devices 3, Built in intelligent power management software 4, Power by 2 pcs replaceable button batteries CR2025 5, Working range: 10 meters 6, Product size: 92x35x10mm Over view: Connect: 1, Turn on the controller, and press pairing button for 2 seconds, the blue and red LED alternate ashing, now the controller is in “pairing mode”; 2, In your iPad/iPhone device, select “setting” --”bluetooth” ; turn on “bluetooth”, it will start searching bluetooth devices; 3, When your iPad/iPhone nd the controller, select it from the list, wait for 2-4 seconds, the controller will be connect with your iPad/iPhone automatically. Hot Keys for iOS devices: Volume up/take photo (in camera mode) Previous trackPlay/PauseNext track Volume down Virtual keyboardLock screenMute Screen light downScreen light up Home Siri(press & hold) Task management (double click) FCC Certification Requirements Caution: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

Zhongshan Nikow Precision Industrial CO.,LTD. No.1 Shuguang Rd, The First Industrial Zone, Tanzhou Town,, Zhongshan City, Guangdong, China Confidentiality Request Letter Page 1 of 1 Rev 2.0 May 13, 2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Permanent Confidentiality Request Confidentiality Request regarding application for certification of FCC ID: 2AAAVSRIOS-01 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Jianhua Yuan/ DGM Contact information / address: No.1 Shuguang Rd, The First Industrial Zone, Tanzhou Town,, Zhongshan City, Guangdong, China TEL: 86-0760-86788188 FAX: 86-0760-86788189 E-mail: [email protected]

FCC Certification Label FCC ID:2AAAVSRIOS-01 Label Location on EUT EUT Bottom View/ FCC ID Label Location

FCC PART 15.249 EMI MEASUREMENT AND TEST REPORT For Zhongshan Nikow Precision Industrial CO., LTD. No.1 Shuguang Rd, The First Industrial Zone, Tanzhou Town, Zhongshan City, Guangdong, China FCC ID: 2AAAVSRIOS-01 May 15, 2013 This Report Concerns: Original Report Equipment Type: Bluetooth Remote for iOS Test Engineer: Anna Lv Report No.: BST13042035ER-3 Receive EUT Date/Test Date: May 03, 2013 / May 03, 2013 - May 15, 2013 Reviewed By: Mike Moo Prepared By: Shenzhen BST Technology Co.,Ltd. 3F,Weames Technology Building, No. 10 Kefa Road, Science Park, Nanshan District,Shenzhen,Guangdong,China Tel: 0755-26747751-3 Fax: 0755-26747751-3 ext.826 Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of Shenzhen BST Technology Co.,Ltd. This report must not be used by the client to claim product certification, approval,or endorsement by NVLAP, NIST or any agency of the US Government. FCC ID: 2AAAVSRIOS-01 BST13042035ER-3 Page 2/18 2 Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 CONTENTS .............................................................................................................................................. 2 3 TEST SUMMARY ..................................................................................................................................... 3 4 GENERAL INFORMATION ...................................................................................................................... 4 4.1 CLIENT INFORMATION......................................................................................................................... 4 4.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 4 4.3 TEST MODE........................................................................................................................................ 6 4.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 6 4.5 TEST FACILITY.................................................................................................................................... 6 4.6 TEST LOCATION................................................................................................................................. 6 4.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 6 5 TEST INSTRUMENTS LIST ..................................................................................................................... 7 6 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 8 6.1 ANTENNA REQUIREMENT:.................................................................................................................... 8 6.2 RADIATED EMISSION METHOD............................................................................................................. 9 6.2.1 Field Strength of The Fundamental Signal ................................................................................ 11 6.2.2 Spurious emissions.................................................................................................................... 12 6.2.3 Bandedge emissions.................................................................................................................. 16 6.3 20DB OCCUPY BANDWIDTH.............................................................................................................. 17 FCC ID: 2AAAVSRIOS-01 BST13042035ER-3 Page 3/18 3 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Occupied Bandwidth 15.215 (c) Pass Pass: The EUT complies with the essential requirements in the standard. N/A: not applicable. FCC ID: 2AAAVSRIOS-01 BST13042035ER-3 Page 4/18 4 General Information 4.1 Client Information Applicant: Zhongshan Nikow Precision Industrial CO., LTD. Address of Applicant: No.1 Shuguang Rd, The First Industrial Zone, Tanzhou Town, Zhongshan City, Guangdong, China Manufacturer: Zhongshan Nikow Precision Industrial CO., LTD. Address of Manufacturer: No.1 Shuguang Rd, The First Industrial Zone, Tanzhou Town, Zhongshan City, Guangdong, China 4.2 General Description of EUT Product Name: Bluetooth Remote for iOS Model No.: SRIOS-01, SR01，SR02，BT02，BT03 Test Model No.: SRIOS-01 Remark: All above models are identical in the same PCB layout, interior structure and electrical circuits. The only differences are the appearance color and model name for commercial purpose. Trade Mark: Operation Frequency: 2402MHz~2480MHz Channel numbers: 79 Channel separation: 1MHz Modulation type: GFSK Antenna Type: PCB Antenna Antenna gain: 2dBi Power supply: DC3.0V cell Remark: During the test, the new battery was used. FCC ID: 2AAAVSRIOS-01 BST13042035ER-3 Page 5/18 Operation Frequency each of channel Channel Frequency Channel Frequency ChannelFrequency Channel Frequency 1 2402MHz 21 2422MHz 41 2442MHz 61 2462MHz 2 2403MHz 22 2423MHz 42 2443MHz 62 2463MHz ...... ...... ...... ...... ...... ...... ...... ...... 19 2420MHz 39 2440MHz 59 2460MHz 79 2480MHz 20 2421MHz 40 2441MHz 60 2461MHz Note: In section 15.31(m), regards to the operating frequency range over 10 MHz, the Lowest frequency, the middle frequency, and the highest frequency of channel were selected to perform the test, and the selected channel see below: Channel Frequency The lowest channel 2402MHz The middle channel 2441MHz The Highest channel 2480MHz FCC ID: 2AAAVSRIOS-01 BST13042035ER-3 Page 6/18 4.3 Test mode Transmitting mo…
