2AAGP181001R/C CAR

ZHENCHENG TOYS FACTORY

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: May 31, 2020
Application Purpose: Original Equipment
Date of Application: May 30, 2020
Equipment Note: R/C CAR
Frequency Range: 2410.00000000 - 2470.00000000
Company: ZHENCHENG TOYS FACTORY
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Keny Xu

External Photos

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 4 External Photos for SZEM2005003341CR FCC ID: 2AAGP181001 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 4 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 4

Internal Photos

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 3 Internal Photos for SZEM2005003341CR FCC ID: 2AAGP181001 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 3 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 3

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500334102 Page: 1 of 40 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZEM2005003341CR(SGS SZ No.:T52010240187EM) Applicant: ZHENCHENG TOYS FACTORY Address of Applicant: CHENGHAI DISTRICT, SHANTOU CITY, GUANGDONG PROVINCE, SHANTOU CITY, China Manufacturer: Shantou Chenghai Zhencheng Plastic Toys Factory Address of Manufacturer: CHENGHAI DISTRICT, SHANTOU CITY, GUANGDONG PROVINCE, SHANTOU CITY, China Equipment Under Test (EUT): EUT Name: R/C CAR ltem No.: 181001, DCW500B, 181401, 181402, 181403, 18GS04, 18GS06, 18GS09, 171803, 171804, 171603B, 171604B, 172801, 18MUD01, 18MUD02 ♣ ♣ Please refer to section 2 of this report which indicates which item was actually tested and which were electrically identical. Requested Age Grading: 3+ Country of Origin: CHINA FCC ID: 2AAGP181001 Standard(s) : 47 CFR Part 15, Subpart C 15.249 Date of Receipt: 2020-05-06 Date of Test: 2020-05-07 to 2020-05-09 Date of Issue: 2020-05-15 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500334102 Page: 2 of 40 Revision Record Version Chapter Date Modifier Remark 01 2020-05-15 Original Authorized for issue by: Gebin Sun /Project Engineer Eric Fu /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500334102 Page: 3 of 40 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.249 N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 20dB Bandwidth 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.9 47 CFR Part 15, Subpart C 15.215 Pass Field Strength of the Fundamental Signal (15.249(a)) 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.5&6.6 47 CFR Part 15, Subpart C 15.249(a) Pass Restricted Band Around Fundamental Frequency 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.249(d) & 15.209 Pass Radiated Emissions 47 CFR Part 15, Subpart C 15.249 ANSI C63.10 (2013) Section 6.4&6.5&6.6 47 CFR Part 15, Subpart C 15.209 & 15.249 (a),(d) Pass Declaration of EUT Family Grouping: Item No.: 181001, DCW500B, 181401, 181402, 181403, 18GS04, 18GS06, 18GS09, 171803, 171804, 171603B, 171604B, 172801, 18MUD01, 18MUD02 Only the item 181001 was tested, since the electrical circuit design, layout, components used, internal wiring and functions were identical for the above items, with only difference on appearance and color. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200500334102 Page: 4 of 40 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 5 4.1 DETAILS OF E.U.T. ............................................................................................................................... 5 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 5 4.3 MEASUREMENT UNCERTAINTY .............................................................................................................. 5 4.4 TEST LOCATION .................................................................................................................................... 6 4.5 TEST FACILITY ...................................................................................................................................... 6 4.6 DEVIATION FROM STANDARDS ............................................................................................................... 6 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 6 5 EQUIPMENT LIST ...................................................................................................................................... 7 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 10 6.1 ANTENNA REQUIREMENT .................................................................................................................... 10 6.1.1 Test Requirement: ....................................................................................................................... 10 6.1.2 Conclusion ................................................................................................................................... 10 7 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 11 7.1 20DB BANDWIDTH .............................................................................................................................. 11 7.1.1 E.U.T. Operation .......................................................................................................................... 11 7.1.2 Test Setup Diagram ..................................................................................................................... 11 7.1.3 Measurement Procedure and Data............................................................................................. 11 7.2 FIELD STRENGTH OF THE FUNDAMENTAL SIGNAL (15.249(A)) .........................................................…
