2AAH3-1500491Wireless Speaker Kit with Subwoofer Output

THE PERFORMANCE YOU NEED ® ® Wireless Speaker Kit with Subwoofer Output User’s Guide 1500491 Please read this user’s guide before using your new speaker kit. 2 2 3 3 4 4 5 5 6 6 Package Contents Transmitter D Receiver 9V AC Adapter D 15V AC Adapter Stands (2) D 6-foot speaker wire (2) User’s Guide Features 2.4GHz digital wireless link provides crystal-clear audio signals. 34-channel selection. Up to 100 feet (30.5m) operation distance between transmitter and receiver (line of sight). Install the Transmitter 1. Make sure your amplifier is off. Connect the transmitter to your amplifier‘s speaker output terminals with the provided 6-foot speaker wire, matching polarities. Or connect your transmitter to the amplifier’s RCA output ports with RCA cables (not included). 2. Connec t the supplied AC adapter (9V, 200mA) to the DC IN 9V jack, then plug it into a standard household outlet. Place the Transmitter and ReceiverThe transmitter and receiver must be placed within 100 feet for proper operation. They can be placed horizontal ly on a flat surface, vertically in the provided stands, or mounted on a wall using the mounting holes on the bottom.n Note : If you need to mount the receiver on a wall, instal l it against the wall in such a way that the ventilation slots are not blocked. To optimize the reception performance, place the transmitter and receiver in the same orientation. Install the Receiver 1. Connect the rear speakers to the receiver with speaker wires, matching polarities. 2. Connect the supplied AC adapter (15V, 4A) to the DC IN 15V jack, and then plug it into a standard household outlet. n Note: Make sure the exposed tips of the speaker wires do not touch each other, and make sure they are fully inserted into the terminals. This speaker kit is designed for connecting to your amplifier surround speaker terminals only. For speaker wires that have proprietary connectors, you may need to strip the end of the wires to allow connection to the receiver. However, check with the speaker manufacturer before doing this, as it may void the warranty. When the RCA cables are connected, audio input from the speaker terminal will be mixed. Unplug the AC adapters from the AC outlet before unplugging it from the transmitter or receiver. Use the supplied AC adapters only. Using an AC adapter not designed for this product may cause damage. DC IN 9V DC IN 15V - OR - To rear speakers To subwoofer in From amplifier speaker output From line outFrom subwoofer out LED Indicator Power on/off -OR- -OR- 1500491_PM_EN.indd 1-6 10/15/2013 5:33:46 PM 7 7 8 8 9 9 10 10 11 11 12 12 Printed in China 09A13 1500491 Complies with the European Union’s “Restriction of Hazardous Substances Directive,” which protects the environment by restricting specific hazardous materi als and products. Increase the separation between the equipment and r eceiver. Connect the equipment into an outlet on a circuit d ifferent from that to which the receiver is connected. Consult the dealer or an experienced radio/TV techn ician for help. If you cannot eliminate the interference, the FCC r equires that you stop using your product. Changes or modifications no t expressly by the party responsible for compliance could void the user’s authority to operate the equipment.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) Thi s device may not cause harmful interference, and (2) this device must accept any interference received, including interference t hat may cause undesired operation. Limited WarrantyIgnition L.P. warrants this product against defects in materials and workmanship under normal use by the original purcha ser for ninety (90) days after the date of purchase. IGNITION L.P. MAKES NO OTHER EXPRESS WARRANTIES.This warranty does not cover: (a) damage or failure caused by or attributable to abuse, misuse, failure to follow instructions, improper installation or maintenance, alteration, a ccident, Acts of God (such as floods or lightning), or excess voltage or current; (b) improper or incorrectly performed repairs by person s who are not a Ignition L.P. Authorized Service Facility; (c) co nsumables such as fuses or batteries; (d) ordinary wear and tear or c osmetic damage; (e) transportation, shipping or insurance costs; (f ) costs of product removal, installation, set-up service, adjustment o r reinstallation; and (g) claims by persons other than the original p urchaser. Should a problem occur that is covered by this warr anty, take the product and the sales receipt as proof of purchase date to the place of purchase. Ignition L.P. will, at its opti on, unless otherwise provided by law: (a) repair the product without cha rge for parts and labor; (b) replace the product with the same or a comparable product; or (c) refund the purchase price. All repl aced parts and products, and products on which a refund is made, b ecome the property of Ignition L.P. New or reconditioned par ts and products may be used in the performance of warranty service. Repaired or replaced parts and products are warranted for the r emainder of the original warranty period. You will be charged for repair or replace- ment of the product made after the expiration of th e warranty period.IGNITION L.P. EXPRESSLY DISCLAIMS ALL WARRANTIES AN D CONDITIONS NOT STATED IN THIS LIMITED WARRANTY. AN Y IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND, IF APPLICABLE, THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, SHALL EXPIRE ON THE EXPIR A- TION OF THE STATED WARRANTY PERIOD. EXCEPT AS DESCRIBED ABOVE, IGNITION L.P. SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO THE PURCHASER OF THE PRODUCT OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUD-ING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE AND ANY LOSS O…

Text truncated - open the document above for the full version.

1 2013-9-12 Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: 2AAH3-1500491 Request is hereby submitted by Mansion Industry Co., Ltd to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Mansion Industry Co., Ltd reserves the right to discern which parties can obtain access to these information: Schematics Detailed Block diagrams Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Mansion Industry Co., Ltd and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, [Signature] [Name] Cai wei [Title] Electronic Engineer

external photos

Size: 70*26mm

internal photos

FCC ID: 2AAH3-1500491 1 INTERTEK TESTING SERVICES Analysis Report The equipment under test (EUT) is a Wireless Speaker Kit with Subwoofer Output. The EUT was powered by AC/DC adapter (Input: AC 120V, 60Hz, 7W, Output: DC 9.0V, 200mA). For more detail information pls. refer to the user manual. Modulation Type: GFSK Antenna Type: Integral antenna Antenna Gain: 1.7dBi The nominal radiated output power (e.i.r.p) specified: 0dBm (Tolerance: +/- 3dB) The nominal conducted output power specified: -1.7dBm (Tolerance: +/- 3dB) According to the KDB 447498: The maximum radiated emission for the EUT is 96.5dBμV/m at 3m in the frequency 2.440GHz = [(FS*D) ^2 / 30] mW = 1.27dBm which is within the production variation. The minimum radiated emission for the EUT is 92.7dBμV/m at 3m in the frequency 2.406GHz = [(FS*D) ^2 / 30] mW = -2.53dBm which is within the production variation. The maximun conducted output power specified is 1.3dBm = 1.35mW The source- based time-averaging conducted output power = 1.35 * Duty cycle mW= 0.62 mW The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.472) mW = 9.5 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. Transmitter Duty Cycle Calculation The duration of one cycle = 58.0ms Effective period of the cycle = 3.8*5+7.8=26.8ms DC = 26.8ms / 58.0ms = 0.4621 or 46.21%

bandedge

bw

 The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained.  This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program.  For Terms And Conditions of the services, it can be provided upon request.  The evaluation data of the report will be kept for 3 years from the date of issuance. TRF No.: FCC 15C_TX_b Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Website: www.china.intertek-etlsemko.com Mansion Industry Co., Ltd. Application For Certification FCC ID: 2AAH3-1500491 Wireless Speaker Kit with Subwoofer Output Model: 1500491 Brand Name: AUVIO 2.4GHz Transmitter Report No.: 130913008SZN-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [ 10-1-12] Prepared and Checked by: Approved by: Sign on file Jenner Liu Assistant Engineer Billy Li Supervisor Date: January 08, 2014 INTERTEK TESTING SERVICES TRF No.: FCC 15C_TX_b FCC ID: 2AAH3-1500491 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information EXHIBIT 9: Confidentiality Request EXHIBIT 10: Test Equipment List INTERTEK TESTING SERVICES TRF No.: FCC 15C_TX_b FCC ID: 2AAH3-1500491 ii MEASUREMENT/TECHNICAL REPORT Mansion Industry Co., Ltd. MODEL: 1500491 FCC ID: 2AAH3-1500491 This report concerns (check one:) Original Grant X Class II Change Equipment Type: DXX - Part 15 Low Power Communication Device Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator  the new 47 CFR [10-1-12 Edition] provision. Report prepared by: Jenner Liu Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, Block D, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Phone: (86 755) 8601 0639 Fax: (86 755) 8601 6751 INTERTEK TESTING SERVICES TRF No.: FCC 15C_TX_b FCC ID: 2AAH3-1500491 iii Table of Contents 1.0 General Description............................................................................................................................................2 1.1 Product Description...........................................................................................................................................2 1.2 Related Submittal(s) Grants.............................................................................................................................2 1.3 Test Methodology..............................................................................................................................................2 1.4 Test Facility.......................................................................................................................................................2 2.0 System Test Configuration................................................................................................................................4 2.1 Justification.........................................................................................................................................................4 2.2 EUT Exercising Software..................................................................................................................................4 2.3 Special Accessories..........................................................................................................................................4 2.4 Equipment Modification.....................................................................................................................................4 2.5 Measurement Uncertainty.................................................................................................................................5 2.6 Support Equipment List and Description.........................................................................................................5 3.0 Emission Results................................................................................................................................................7 3.1 Radiated Test Results.......................................................................................................................................8 3.1.1 Field Strength Calculation..............................................................................................................................8 3.1.2 Radiated Emission Configuration Photograph..............................................................................…

Text truncated - open the document above for the full version.

radiated photos

conducted photos
