2AAHYRTL8822CUE100FLED TV

LED COLOR TV Please read these instructions before operating your set and retain them for future reference. Model: Operating Instruction IM PORTANT SAFETY INSTRUCTIONS 1. Read these instructions – All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions – The safety and operating instructions should be retained for future reference. 3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow all instructions – All operating and use instructions should be followed. 5. Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a wet basement or near a swimming pool, and the like. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacture’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug the apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. 16. Do not install this equipment in a confined or building-in space such as a book case or similar unit, and remain a well ventilation conditions at open site. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc. 17. WARNING˖To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. 18 . WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. 19. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. 20. 21. - This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. - Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel. - The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. This apparatus with CLASSI construction Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: † Reorient or relocate the receiving antenna. † Increase the separation between the equipment and receiver. † Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. † Consult the dealer or an experienced radio/TV technician for help. 5. .................................................................................................... TV 3. Launcher ................................................................................................................. CONTENTS 1 LED COLOR TV 1. Connection and Preparation of TV........................................................................... 1.1 Accessories ....................................................................................................... 1.2 Installation of Stand............................................................................................ 1.3 Keys and Interfaces............................................................................................ 1.4 Remote Control......…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404005 Page: 1 of 16 Keny Xu EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: SZCR2509004040AT Applicant: Jinpin Electrical Company Ltd.ZhuHai.S.E.Z Address of Applicant: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, China Manufacturer: Jinpin Electrical Company Ltd. Zhuhai S.E.Z. Address of Manufacturer: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, Guangdong, China Factory: Jinpin Electrical Company Ltd. Zhuhai S.E.Z. Address of Factory: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, Guangdong, China Equipment Under Test (EUT): EUT Name: LED TV Model No.: E100XXY#, Q100XXY#, H100XXY#("x”=A-Z or 0-9,"Y"= 0-9 or blank, “#”=A-Z or 0-9), 100XXXXX##("x”=A-Z or 0-9,"#"= 0-9 or A-Z or blank ) VI-100T232   Please refer to section 3.2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: JPE, VIOS FCC ID: 2AAHYRTL8822CUE100F Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2025-09-12 Date of Evaluation: 2025-09-18 to 2025-09-28 Date of Issue: 2025-09-28 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404005 Page: 2 of 16 Revision Record Version Chapter Date Modifier Remark 01 2025-09-28 Original Authorized for issue by: Bill Chen/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404005 Page: 3 of 16 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 General Description of E.U.T. ............................................................................................................ 4 3.2 Details of E.U.T. ................................................................................................................................. 4 3.3 Separation Distance ........................................................................................................................... 6 3.4 Test Location ...................................................................................................................................... 7 3.5 Test Facility ........................................................................................................................................ 7 3.6 Deviation from Standards ................................................................................................................... 7 3.7 Abnormalities from Standard Conditions ........................................................................................... 7 4 FCC Radiofrequency radiation exposure limits .................................................................................... 8 4.1 Blanket 1 mW Blanket Exemption ...................................................................................................... 8 4.2 MPE-based Exemption ...................................................................................................................... 8 4.3 SAR-based Exemption ....................................................................................................................... 9 5 Measurement and Calculation ............................................................................................................... 13 5.1 Maximum transmit power ................................................................................................................. 13 5.2 RF Exposure Calculation ................................................................................................................. 15 6 EUT Constructional Details (EUT Photos) ........................................................................................... 16 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404005 Page: 4 of 16 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: AC 100-240V, 50/60Hz 3.0V DC (1.5V x 2 "AAA" Size Batteries) for remote controller For BT: Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK, pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: FPC Antenna Gain: 2.85dBi For BLE: Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Rata data: 1Mbps and 2Mbps Antenna Type: FPC Antenna Gain: 2.85dBi For 2.4G WIFI: Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz;802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (DBPSK, DQPSK, CCK); 802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Number of Channels: 802.11b/g/n(HT20):11;802.11n(HT40):7 Channel Spacing: 5MHz Antenna Type: FPC Antenna Gain: Antenna 1:2.71dBi, Antenna 2:2.81dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404005 Page: 5 of 16 For 5G WIFI: Operation Frequency/Number of channels (20MHz): U-NII-1: 5180-5240MHz (4 Channels); U-NII-2A: 5260-5320MHz (4 Channels); U-NII-2C: 5500-5700MHz (11 Channels); U-NII-3: 5745- 5825MHz (5 Channels) Operation Frequency/Number of channels/(40MHz)…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 1 of 3 Appendix Test Setup Photos for SZCR2509004040AT FCC ID: 2AAHYRTL8822CUE100F SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 3 of 3 Radiated Spurious Emissions Above 1GHz - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 107 of 150 802.11g_HCH_2462MHz_Ant2 (MIMO)_NTNV 802.11g_HCH_2462MHz_MIMO_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 108 of 150 802.11n(HT20)_LCH_2412MHz_Ant1 (MIMO)_NTNV 802.11n(HT20)_LCH_2412MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 109 of 150 802.11n(HT20)_LCH_2412MHz_MIMO_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 110 of 150 802.11n(HT20)_MCH_2437MHz_Ant2 (MIMO)_NTNV 802.11n(HT20)_MCH_2437MHz_MIMO_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 111 of 150 802.11n(HT20)_HCH_2462MHz_Ant1 (MIMO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 112 of 150 802.11n(HT20)_HCH_2462MHz_MIMO_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 113 of 150 802.11n(HT40)_LCH_2422MHz_Ant2 (MIMO)_NTNV 802.11n(HT40)_LCH_2422MHz_MIMO_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 114 of 150 802.11n(HT40)_MCH_2437MHz_Ant1 (MIMO)_NTNV 802.11n(HT40)_MCH_2437MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 115 of 150 802.11n(HT40)_MCH_2437MHz_MIMO_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 116 of 150 802.11n(HT40)_HCH_2452MHz_Ant2 (MIMO)_NTNV 802.11n(HT40)_HCH_2452MHz_MIMO_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 117 of 150 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Test Result 5.1.1 Ref Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 802.11b MIMO 2412 1 8.57 2 8.60 2437 1 7.86 2 7.22 2462 1 8.39 2 7.07 802.11g MIMO 2412 1 4.39 2 4.92 2437 1 5.08 2 4.35 2462 1 5.87 2 4.44 802.11n (HT20) MIMO 2412 1 6.60 2 6.81 2437 1 7.19 2 6.35 2462 1 7.72 2 6.29 802.11n (HT40) MIMO 2422 1 3.39 2 3.48 2437 1 3.79 2 3.12 2452 1 4.01 2 2.78 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 118 of 150 5.1.2 CSE Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 802.11b MIMO 2412 1 8.57 -21.43 Pass 2 8.60 -21.40 Pass 2437 1 8.57 -21.43 Pass 2 8.60 -21.40 Pass 2462 1 8.57 -21.43 Pass 2 8.60 -21.40 Pass 802.11g MIMO 2412 1 5.87 -24.13 Pass 2 4.92 -25.08 Pass 2437 1 5.87 -24.13 Pass 2 4.92 -25.08 Pass 2462 1 5.87 -24.13 Pass 2 4.92 -25.08 Pass 802.11n (HT20) MIMO 2412 1 7.72 -22.28 Pass 2 6.81 -23.19 Pass 2437 1 7.72 -22.28 Pass 2 6.81 -23.19 Pass 2462 1 7.72 -22.28 Pass 2 6.81 -23.19 Pass 802.11n (HT40) MIMO 2422 1 4.01 -25.99 Pass 2 3.48 -26.52 Pass 2437 1 4.01 -25.99 Pass 2 3.48 -26.52 Pass 2452 1 4.01 -25.99 Pass 2 3.48 -26.52 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 119 of 150 5.2 Test Graph 5.2.1 Ref 802.11b_LCH_2412MHz_Ant1 (MIMO)_NTNV 802.11b_LCH_2412MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 120 of 150 802.11b_MCH_2437MHz_Ant1 (MIMO)_NTNV 802.11b_MCH_2437MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 121 of 150 802.11b_HCH_2462MHz_Ant1 (MIMO)_NTNV 802.11b_HCH_2462MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 122 of 150 802.11g_LCH_2412MHz_Ant1 (MIMO)_NTNV 802.11g_LCH_2412MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 123 of 150 802.11g_MCH_2437MHz_Ant1 (MIMO)_NTNV 802.11g_MCH_2437MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 124 of 150 802.11g_HCH_2462MHz_Ant1 (MIMO)_NTNV 802.11g_HCH_2462MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 125 of 150 802.11n(HT20)_LCH_2412MHz_Ant1 (MIMO)_NTNV 802.11n(HT20)_LCH_2412MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 126 of 150 802.11n(HT20)_MCH_2437MHz_Ant1 (MIMO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 127 of 150 802.11n(HT20)_HCH_2462MHz_Ant1 (MIMO)_NTNV 802.11n(HT20)_HCH_2462MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 128 of 150 802.11n(HT40)_LCH_2422MHz_Ant1 (MIMO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant2 (MIMO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 1 of 150 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2509004040AT Applicant: Jinpin Electrical Company Ltd.ZhuHai.S.E.Z Address of Applicant: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, China Manufacturer: Jinpin Electrical Company Ltd. Zhuhai S.E.Z. Address of Manufacturer: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, Guangdong, China Factory: Jinpin Electrical Company Ltd. Zhuhai S.E.Z. Address of Factory: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, Guangdong, China Equipment Under Test (EUT): EUT Name: LED TV Model No.: E100XXY#, Q100XXY#, H100XXY#("x”=A-Z or 0-9,"Y"= 0-9 or blank, “#”=A-Z or 0-9), 100XXXXX##("x”=A-Z or 0-9,"#"= 0-9 or A-Z or blank ) VI-100T232   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: JPE, VIOS FCC ID: 2AAHYRTL8822CUE100F Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2025-09-12 Date of Test: 2025-09-18 to 2025-09-25 Date of Issue: 2025-09-28 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 2 of 150 Revision Record Version Chapter Date Modifier Remark 01 2025-09-28 Original Authorized for issue by: Bill Chen/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 3 of 150 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2020) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2020) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 4 of 150 Declaration of EUT Family Grouping: Model No.: E100XXY#, Q100XXY#, H100XXY#("x”=A-Z or 0-9,"Y"= 0-9 or blank, “#”=A-Z or 0-9), VI-43T232 Only the model E100F1A was tested. According to the declaration from the applicant, the electrical circuit design, layout, components used, internal wiring and functions were identical for the above models, with only difference as below: The “X” represents the backboard’s difference on pattern. The “Y” represents the appearance’s difference on decorate and colour; The “#” represents the base’s difference on colour. The difference between model VI-43T232 is only the trade mark. Model No.: 100XXXXX##("x”=A-Z or 0-9,"#"= 0-9 or A-Z or blank) The first to third "X" represents the backboard’s difference on pattern and colour. The fourth "#" represents the color difference of the surface shell decoration. The fifth “#” represents the base’s difference on colour. The “#” represents the sales area. The difference between model E100XXY#, Q100XXY#, H100XXY# are only the model No.. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404003 Page: 5 of 150 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 5 4 General Information .................................................................................................................................. 7 4.1 Details of E.U.T. ................................................................................................................................. 7 4.2 Description of Support Units .............................................................................................................. 7 4.3 Measurement Uncertainty .................................................................................................................. 7 4.4 Test Location ...................................................................................................................................... 8 4.5 Test Facility ........................................................................................................................................ 8 4.6 Deviation from Standards ................................................................................................................... 8 4.7 Abnormalities from Standard Conditions .....................................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404002 Page: 1 of 79 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2509004040AT Applicant: Jinpin Electrical Company Ltd.ZhuHai.S.E.Z Address of Applicant: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, China Manufacturer: Jinpin Electrical Company Ltd. Zhuhai S.E.Z. Address of Manufacturer: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, Guangdong, China Factory: Jinpin Electrical Company Ltd. Zhuhai S.E.Z. Address of Factory: Building 4, No.55, Jinchuan Road, Hongqi Town, Jinwan District, Zhuhai, Guangdong, China Equipment Under Test (EUT): EUT Name: LED TV Model No.: E100XXY#, Q100XXY#, H100XXY#("x”=A-Z or 0-9,"Y"= 0-9 or blank, “#”=A-Z or 0-9), 100XXXXX##("x”=A-Z or 0-9,"#"= 0-9 or A-Z or blank ) VI-100T232   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: JPE, VIOS FCC ID: 2AAHYRTL8822CUE100F Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2025-09-12 Date of Test: 2025-09-18 to 2025-09-25 Date of Issue: 2025-09-28 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404002 Page: 2 of 79 Revision Record Version Chapter Date Modifier Remark 01 2025-09-28 Original Authorized for issue by: Bill Chen/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404002 Page: 3 of 79 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2020) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2020) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2020) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2020) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2020) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2020) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2020) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2020) Section 6.10.4 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2020) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404002 Page: 4 of 79 Declaration of EUT Family Grouping: Model No.: E100XXY#, Q100XXY#, H100XXY#("x”=A-Z or 0-9,"Y"= 0-9 or blank, “#”=A-Z or 0-9), VI-43T232 Only the model E100F1A was tested. According to the declaration from the applicant, the electrical circuit design, layout, components used, internal wiring and functions were identical for the above models, with only difference as below: The “X” represents the backboard’s difference on pattern. The “Y” represents the appearance’s difference on decorate and colour; The “#” represents the base’s difference on colour. The difference between model VI-43T232 is only the trade mark. Model No.: 100XXXXX##("x”=A-Z or 0-9,"#"= 0-9 or A-Z or blank) The first to third "X" represents the backboard’s difference on pattern and colour. The fourth "#" represents the color difference of the surface shell decoration. The fifth “#” represents the base’s difference on colour. The “#” represents the sales area. The difference between model E100XXY#, Q100XXY#, H100XXY# are only the model No.. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250900404002 Page: 5 of 79 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 5 4 General Information .................................................................................................................................. 7 4.1 Details of E.U.T. ................................................................................................................................. 7 4.2 Description of Support Units .............................................................................................................. 7 4.3 Measurement Uncertainty .................................................................................................................. 7 4.4 Test Location ...............................…
