2AAKFWP300SWi-Fi Portable Phone

Liberty L2 Wi-Fi Portable Phone User Manual Model : WP300S 23 Basic Instructions 01 · Do not incinerate the battery. Please dispose of it responsibly or recycle it in accordance with local regulations. · Normal battery life should continue for at least 6 months from date of purchase. · Before first-time use, and after using the phone for a long period of time without charging, please charge the battery fully by placing the phone in the cradle. Precautions when using battery · Do not use this phone with a battery from another manufacturer, as this could damage the device. · Replace the battery if it appears swollen, as there is a risk of explosion. · Use only the specified manufacturer's adapter to charge the phone. · Keep the phone and battery away from children and pets. · Do not place the phone or battery near firearms or unlicensed radio products. · Do not submerge the phone in liquid or get the battery wet. · Do not store the phone inside a car during the summer, or other areas with high temperature and humidity. · Do not use the phone in steam rooms, or other areas with high temperature and humidity. · Do not continuously use the phone for long periods of time. · Do not place the phone directly on blankets, electric blankets, or carpeted areas. · Do not allow metallic objects to come into contact with the battery terminals. · Do not disassemble, crush, or puncture the phone or battery, as there is a risk of explosion and electric shock. User Precautions Please read these instructions carefully to protect yourself and others from personal injury or damage to property. Precautions when installing · Avoid installing in excessively hot, cold, dusty or humid places. · Avoid exposure to strong vibrations or direct sunlight. · Since the phone generates heat when it operates, please do not install it in locations with low heat tolerance. · To prevent fire or risk of electric shock, do not use with a damaged cord or plug. Do not touch the power outlet with wet hands. · Do not place on an unstable surface to avoid injury or breakage if device falls or is dropped. Precautions when cleaning · Use a dry, soft cloth when you clean the phone. · Do not use harsh chemicals such as benzene or thinner to clean the phone. · Wipe the power plug with a dry, soft cloth to avoid fire or electric shock hazards. Precautions when using · Do not touch the phone with wet hands. · Do not use the phone for anything other than its intended purpose. · Do not pull on the power plug and adapter when unplugging the phone. · If the phone emits an unusual noise or smell, or if you see smoke coming from the phone, please unplug the adapter and cable immediately. · Do not place the phone in an area that is wet or dusty. · Do not place anything heavy on top of the phone. · Do not put any foreign material inside the product or charger. · Do not place the phone near or in areas of extreme heat, such as in direct sunlight or beside a heater. · Do not place the product close to magnetic objects such as a magnet, TV, monitor or speaker. · Back up your valuable data on the phone regularly. · Please note that the phone and battery can heat up during a lengthy call. · Failure to comply with the precautions in this section will void any applicable warranty. · Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. 45 Basic Instructions 01 standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Warning · This device is for indoor use, only in the 5150~5250Mhz frequency range. · This device was tested for typical body-worn operations. · To comply with RF exposure requirements, keep at least 1.5 cm (0.5 inches) between the user's body and the headset, including the antenna. · Do not use third-party belt clips, holsters, or other accessories that contain metallic components. · Avoid use of body-worn accessories that do not meet the above criteria, as they may not comply with RF exposure requirements. User manual specifications and the IP Phone software version may be updated by the manufacturer without any notice. User Precautions FCC SAR Compliance Statement Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on safety standards previously set by both U.S. and international standards bodies: · American National Standards Institute (ANSI) IEEE. C95.1-1992. · National Council on Radiation Protection and Measurement (NCRP). Report 86.1986. · International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996. · Ministry of Health (Canada). Safety Code 6. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure CAUTION(ATTENTION) · RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. · Risque d'éxplosion si la batterie est remplacée par un un model incorect. Jetter les batteries usagées selon les instructions. FCC Compliance statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular …

Text truncated - open the document above for the full version.

WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID : 2AAKFWP300S Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Sincerely Yours, Deok-Jae Yoo /Senior Engineer /Moimstone Co., Ltd.

Date: 29 June, 2015 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Moimstone Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project: Product: Wi-Fi Portable Phone Model name: WP300S FCC ID: 2AAKFWP300S We affirm that between SIEMIC and Moimstone Co., Ltd. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Deok-Jae Yoo /Senior Engineer /Moimstone Co., Ltd.

Date: 29 June, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 Subject: Permanent Confidentiality Request for FCC ID: 2AAKFWP300S We hereby request confidential treatment of information accompanying this application as outlined below:  Block diagram  Schematics  Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, Deok-Jae Yoo /Senior Engineer /Moimstone Co., Ltd.

Date : 29 June, 2015 DTS‐UNII Device Declaration Letter To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: 2AAKFWP300S  DFS Device -- Master , Client with Radar detection capability , Client without radar detection capability , N/A  Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode or WIFI Direct capability Access point capability 2412~2462 Yes , No Yes , No Yes , No Yes , No 5180~5240 Yes , No Yes , No Yes , No Yes , No 5260~5320 Yes , No Yes , No Yes , No Yes , No 5500~5700 Yes , No Yes , No Yes , No Yes , No 5745~5805 Yes , No Yes , No Yes , No Yes , No  Country code selection ability - Yes , No If yes, pls explain how it was implemented : (pls also help to provide detail of options for each country selection)  Meet 15.202 requirement - Yes , No , pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network.  For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes cannot be modified by end user or an installer. Apply , No Apply , (If apply , pls help to provide explanation on it was implement , and how software was controlled) Name / Title: Deok-Jae Yoo / Senior Engineer Signature: Phone: +82-70-7791-3750 Fax: +82-31-426-9539 Email: [email protected] Address: 65, Heungan-daero 439 beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, KOREA

http://www.emc2000.co.kr EMC compliance Ltd. Page: 1 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. External photos of EUT http://www.emc2000.co.kr EMC compliance Ltd. Page: 2 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr EMC compliance Ltd. Page: 3 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.

FCC ID LABEL 1. FCC ID label drawing 2. FCC ID label location

http://www.emc2000.co.kr EMC compliance Ltd. Page: 1 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. Internal photos of EUT http://www.emc2000.co.kr EMC compliance Ltd. Page: 2 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr EMC compliance Ltd. Page: 3 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. 2 ㎓, 5 ㎓ Antenna

http://www.emc2000.co.kr EMC compliance Ltd. 480-5, Sindong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea TEL: 82 31 336 9919 FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. Report No.: EMC-FCC-A0021 Page: 1 of 104 SAR TEST REPORT Test report No: EMC-FCC-A0021 Type of Equipment: Wi-Fi Portable Phone Model Name: WP300S Applicant: Moimstone Co., Ltd. FCC ID: 2AAKFWP300S FCC Rule Part: CFR §2.1093 Test standards: IEEE 1528, 2003 ANSI/IEEE C95.1 KDB Publication Max. SAR(1g): 1.28 W/kg Test result: Complied This report details the results of the testing carried out on one sample, the results contained in this testreport do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in anyconfiguration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of EMC compliance Ltd. or testing done by EMC compliance Ltd. in connection with distribution or use of the product described in this report must be approved by EMC compliance Ltd. in writing. Date of receipt: 2015.05.18 Date of testing: 2015.06.19 ~ 6.28 Issued date: 2015.06.29 Tested by: Min Kyoung-hoo Approved by: Choi Cheon-sig http://www.emc2000.co.kr EMC compliance Ltd. 480-5, Sindong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea TEL: 82 31 336 9919 FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. Report No.: EMC-FCC-A0021 Page: 2 of 104 Contents 1. Applicant information ........................................................................................................................... 3 2. Laboratory information ........................................................................................................................ 4 3. Identification of Sample ......................................................................................................................... 5 4.Test Result Summary ............................................................................................................................. 6 5. Report Overview ................................................................................................................................... 6 6. Test Lab Declaration or Comments........................................................................................................ 6 7. Applicant Declaration or Comments ...................................................................................................... 6 8. Measurement Uncertainty ..................................................................................................................... 7 9. The SAR Measurement System ........................................................................................................... 11 10. System Verification ............................................................................................................................ 15 11. Operation Configurations .................................................................................................................. 18 12. SAR Measurement Procedures .......................................................................................................... 19 13. Test Equipment Information .............................................................................................................. 21 14. RF Average Conducted Output Power ............................................................................................... 22 15. SAR Test Results ............................................................................................................................... 23 17. Test Results........................................................................................................................................ 43 Annex A. Photographs............................................................................................................................. 53 Annex B. Calibration certificate .............................................................................................................. 65 http://www.emc2000.co.kr EMC compliance Ltd. 480-5, Sindong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea TEL: 82 31 336 9919 FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. Report No.: EMC-FCC-A0021 Page: 3 of 104 1. Applicant information Applicant: Moimstone Co., Ltd. Address: 65, Heungan-daero 439 beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, KOREA Telephone: +82-70-7791-3750 Fax: +82-31-426-9539 E-mail: [email protected] Contact name: Yoo Deokjae Manufacturer: Moimstone Co., Ltd. Address: 65, Heungan-daero 439 beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, KOREA http://www.emc2000.co.kr EMC compliance Ltd. 480-5, Sindong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea TEL: 82 31 336 9919 FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. Report No.: EMC-FCC-A0021 Page: 4 of 104 2. Laboratory information Address EMC compliance Ltd. 480-5, Sindong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea TEL: 82 31 336 9919 FAX: 82 505 299 8311 Certificate KOLAS No.: 231 FCC Site Designation No.: KR0040 FCC Site Registration No.: 687132 VCCI Site Registration No.: R-3327, G-198, C-3706, T-1849 IC Site Registration No.: 8035A-2 SITE MAP EMC compliance Suwon-si http://www.emc2000.co.kr EMC compliance Ltd. 480-5, Sindong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea TEL: 82 31 336 9919 FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. Report No.: EMC-FCC-A0021 Page: 5 of 104 3. Identification of Sample EUT Type Wi-Fi Portable Ph…
