1 USER’S MANUAL M716D Contents 2 Safety Notices Getting ready to use the device  What’s inside box  Product Appearance  Control buttons and connections  Technical Specifications Quick Guide  Power on / Power off  Standby and Lock screen  The desktop status bar and shortcut menu and the definition of the icons  Orientation Sensor Setting  Battery management and recharging  WIFI network settings  Mobile network settings  To install an APK file  To uninstall an APK file  Camera  Voice recording  Use the device a multi media player Music playback Video playback Photo browsing  File Management  Set OSD Language  Set Keyboard  Set Date and time  About the Device  Trouble Shootings Safety notices 3 1 ) Keep this device away from strong magnetic field to avoid any damages 2 ) Do not rub this device with any hard objects and never clean this device with any chemicals or detergents or acids or it could cause damages on surfaces. 3 ) Humidity or liquid may enter this device and causes permanent damages to the hardware inside. Do not place this device in any humid environment or under the rain. 4 ) It is recommended that volume level of the earphones should be adjusted to an appropriate level to avoid damages to your hearings due to high volume. 5 ) Do not cut off the power abruptly during software update, software download, or during this device is under any kind of operation or it may cause data lost and system error. 6 ) Over-voltage, power cable strain, bending or squeezing by heavy objects must be avoided to prevent this device from overheating or fire disaster. 7 ) To eliminate the risk of electric shock, do not connect the power plug with wet hands. 8 ) Some movies, music and pictures are under protections of copyrights, any unauthorized usages are deemed as infringements to the laws of copyrights. 9 ) The performance of the WIFI reception of this device could be influenced by the wireless equipments and networks in the surrounding areas. 10 ) Any wireless equipment will influence the flight of an airplane, please consult the airline company if you want to use this device on the airplane. 11 ) Do not use this device anywhere near any blasting operations. 12 ) Only qualified maintenance personnel is allowed to dismantle this device. 13 ) Please comply with any related restrictions and rules when using this device. 14 ) Only use this device with its original accessories and battery. 15 ) Do not use any incompatible accessories on this device. 16 ) This device is not waterproof, please keep it dry all the time. 4 17 ) For the sake of data safety, please back up the important data anytime on a timely basis. 18 ) When connecting this device with other equipments, please follow instructions on this user’s manual. 19 ) Never connect this device with any incompatible equipment. 20 ) Please consult the after-sales service in your area for any technical problems. Getting ready to use the device What’s inside box Apariencia del product Components Quantity Ta b l e t P C 1 Power Charger 1 User Manual 1 5 Technical Specifications LCD Display Size 9” TFT display Resolution 800*480 Operation System Android 4.2 PC interface High speed USB2.0 HOST for external U-disk, Mouse, etc Built-in Flash Flash Memory：8GB Built-in RAM 1GB DDRIII Capacity Expansion Support Micro SD Card up to 32GB (not included) Battery Built-in 3.7V Lithium rechargeable battery Power Supply Input: AC100V~240V 50/ 60Hz Output: DC 5V-2A Music Function Format WMA、MP3、OGG、APE、FLAC、 AAC、WAV Headset max. output （L）5mW＋（R）5mW（32Ohm） Bit rate 8Kbps ~ 320Kbps WMA、WMV、 Bit rate supported 5Kbps ~ 320 Kbps Frequency response 20Hz to 20KHz SN ratio 90dB Distortion ＜0.05% Video Function Play format MKV、AVI、RM、RMVB、MP4、 MOV、VOB、DAT、FLV、3GP, etc Max. resolution supported 2160p Ratio 4:3、wide screen for optional 6 Photo browse JPG、JPEG、BMP、GIF supported E-book Function Format Supported TXT、LRC、PDF、Html、 Htm、EPUB, etc Max. capacity 20M Recording function Format supported 3gpp Format WI-FI Function Spec 802.11b/g/n Transmission rate Max150Mbps Transmission Distance Max100m Work Frequency 2.4GHz HDMI HDMI up to 1080p 3G Support only external 3G USB-DONGLE wireless network card (3G card and USB-Dongle are not included) Auto Screen Rotation Selectable from Setting menu Loudspeaker Built-in 1W@8ohm*2 Working temperature -10 ~ 45°C OSD Languages Default language: English Other options: Catala, Cestina, Dansk, Deutsch, Romanian, Espanol, Francais, Hebrew, Hrvatski, Indonesian, Italiano, Latviesu, Leituviu, Magyar, Nederlands, Norsk Bokmal, Polski, Portugues, Romana, Romansh, Slovencina, Suomi, Svenska, Tagalog, Tieng Viet, Turkce, Russian, Korean, Chinese, Japanese Operation systems supported Compatible with Windows 98 se / 2000 / XP / Vista / 7, Mac 9.1 or above, Linux 2.4 7 Quick Guide Power on / Power off Long press button for 3 seconds to power on the device. It will take about a minute and half to boot the system. Unlock the screen by sliding to the right. To power off the device, long press button for 3 seconds, the screen will show the power off options: Cancel or OK. Tap “OK” to power off the unit or tap “Cancel” to exit to previous operation. 8 【Note】When the device is low battery, it will alert continuously and will shut down automatically when battery has completely run out. The device cannot be powered on if the battery is empty, please recharge the battery at least one minute before restart the device. Standby and Lock screen Press button shortly to turn the device to standby mode. Under standby mode, the screen is blackout and volume is muted. Press button shortly again to reactivate the device. The device will then turn to Lock screen while the primary operation of the device will continue. Unlock the screen by sliding to the right to resume to status before power saving. 9 【Note】The primary operation of the device under standby mode will pause and the primary operation of the device under Lock screen mode will continue, o…
