2AALX-HAOHIGH DEFINITION DIGITAL OTT BOX

This Receiver will take you to the new and exciting world. A world of crystal clear wide screen pictures, digital sound, more information and new services. To make full use of your new receiver please take the time to familiarize yourself with the extensive features of the unit detailed in this User Guide. If you need help in setting up please call your dealer or a customer service adviser. Main Features Android/Linux, WIFI Hotspot, ATSC support Webkit based Android full browser Browser, Media Player, Picture browser, Game, Setting, FileManager, Youtube, Twitter, Facebook and more Firmware upgrade by network,USB disk Various channel editing functions(favorite, moving, locking,renaming, deleting and sorting) Multi Language Fully support to 7 days Electronic Program Guide(EPG) 3D Graphical User Interface(Support OpenGL ES2.0) Support Record Timeshift and Player Parental control for channels Support FAT16/FAT32/FAT12 NTFS 480i/p, 576i/p, 720p, 1080i, 1080p MP4, AVI, MKV, FLV, MPEG TS H.264(MPEG4-AVC, VC-1), MPEG2, DviX3/4/5/6,Xvid MP3, AAC, OGG, MPEG, MPEG Audio, Dolby Digital JPEG, PNG, BMP,GIF DLNA 1.5 compliant Mimic Cast Easy download and installation of applications GENERAL INFORMATION 01 For Your Safety D o n o t t o u c h r e c e i v e r d u r i n g thundering in case of being electric shocked. Do not block ventilation holes of the Receiver so that air can circulate freely. Do not expose the receiver under the sunlight. And keep it away from the heat source. Keep the receiver away from flower vases, tubs, sinks, etc., in order to avoid damaging the equipment. To avoid electric-shock hazards, do not open the cabinet, refer servicing to qualified personnel only. When the abnormal phenomenon occurs, you should cut off the power immediately. GENERAL INFORMATION 02 RCU The picture is only for reference, please make the object as the standard. Key Function Standby On/Off Return to the previous menu on the menu screen or escape from the menu When watching a channel, change channels or move to the next higher or lower item in the menu When watching a channel, adjust the volume or move to the left or right item in the menu Enter main menu Adjust the volume Press to pop up the function list GENERAL INFORMATION 03 The picture is only for reference, please make the object as the standard. Rear Panel Front Panel CONNECT TO POWER SUPPLY CONNECT TO THE INTERNET CONNECT TO TV SET HDMI INPUT CONNECT TO A DIGITAL AMPLIFIER CONNECT TO INFRARED RECEIVER CONNECT TO ANTENNA CONNECT TO USB DEVICE CONNECT TO USB DEVICE CONNECT TO AV CONVERTOR GENERAL INFORMATION 0405 RESET KEY Front Panel GENERAL INFORMATION Unpacking(optional) Remote Control User's manual IRExternal power supply Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NO TE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. MAIN MENU 08 If the receiver is in Factory mode or no channel installed, system will lead you to 'Search Programs' for your first enter into 'Program' sub-menu. Then select search one TP or Auto search. Program Search Channel Number: Press OK key to pop up a drop list select the channel Number in the drop list. Frequency: Press OK key to pop up a keyboard, press keys to select the number and symbol. 4. Apps In Apps we provide many Apps such as Browser, Weather, App Store, Twitter, Facebook, Youtube, File Explorer, Settings, Mimic Cast, Homeshare and so on. You can download apps, install and uninstall apps in this menu. MAIN MENU 0910 11 System upgrade You can upgrade through USB device. Factory Data Reset Select Reset STB button and press OK key to reset the data. 5. Sur fs System here provides you many direct access to Google, Picasa, Yahoo, MSN, Twitter Facebook, and more. You can also go to other web pages by inputting address in browser. ProblemPossible causesWhat to do The display on the front panel does not light up. No sound or picture, but the front panel shows red light. Main cable is not connected. The is in standby mode.receiver Check that the main cable is plugged into the power socket. Press the standby button. No sound or picture. No signal or weak signal. Check the cable connections, antenna and other equipment connected between the antenna and the receiver. Bad picture / blocking error. Signal is too strong. Connect a signal attenuator to the antenna input. Antenna noise factor too high. Change to an with lower noise factor. antenna The is faulty.antennaChange the .antenna The RCU is not working. Battery exhausted. Change the batteries. RCU is incorrectly aimed. Aim RCU at the , or check that nothing blocks the front panel. receiver Note : If you failed to solve problems by all the recommended actions above, please contact your dealer or a customer service adviser. TROUBLE SHOOTING SPECIFICATION Configure the settings at URL http://192.168.1.254 6. Router settings Main menu consists of 5 major sub-men…
