2AAMU-SE-02WEnergy saving receptacle (ESR)

Instruction For Use SE-02W Thank you very much for using our products, please Install and use after reading the instructions carefully. Preface Energy saving receptacle (ESR) is a intelligent wall socket which is developed jointly by Yangzhou Jinding Electronics Co., Ltd and Sunrise Energy LLC to solve standby power of home appliances. Its main features are：Eliminating the standby power of electric appliances，Improving the quality and power efficiency of electricity，extending lifespan of electric appliances，reducing the electromagnetic radiation and electrical fire caused by electric appliances. I. Safety Caution 1.Don’t install the unit in some wet and inflammable circumstance. 2.Clean control with a soft damp cloth only. Do not use any chemical cleaners. 3.Don’t insert metal into socket directly which may result in electrical shock. 4.Don’t insert the electric appliance that its power greater than the rated power marked on the socket. II. Product Parameter Name：Energy saving receptacle (ESR) Model：SE-02W Material：（UL94V0）Fireproof PC shell、H62-Y copper parts Packaging：40 pieces/box Dimension：105.6mmX48mmX65.1mm Working temperature：—10°C to 50°C Working Humidity：≤95%RH Remote-controlled distance：≥5m Ratings：125V~ 60Hz 15A Frequency range：315MHz III. Installation 1. Turn power OFF. Remove old receptacle and disconnect all wires. 2. Refer to Wiring Diagrams. 3. Connect live (black wires) to brass screw terminal(s), and tighten securely. 4. Connect neutral (white wires) to silver screw terminal(s), and tighten securely. 5. Connect isolated ground wire to green grounding screw terminal, and tighten securely. Note: Isolated ground wire should be insulated and readily distinguishable (as in green with yellow striped insulation) from the building ground (green insulation). 6. Refer to Mounting Instruction (1) Important Note 1. For installation by a qualified electrician only. 2. Connect only No. 10, 12 or 14 AWG (6, 2.5 or 1.5 mm 2 ) copper or copper-clad wire to this device. Do not connect aluminum wire to this device. See device for strip length. (2) Mounting Instructions 1. Push wires into wallbox, allowing room for receptacle to be inserted. Do not pinch wires between wallbox and receptacle. 2. Mount receptacle to wallbox using screws provided. 3. Replace faceplate adapter (if removed) and snap on faceplate. Note: Mounting means not grounded. Receptacle does not self ground when mounting it to a wallbox. A ground wire connection is required for receptacle grounding. Failure to connect a ground wire to the green grounding screw terminal will result in an ungrounded receptacle. Wiring Diagrams IV. Icon Description of Use function Remote control mach coding：Press On button ESO for 2 seconds，pressing the buttons on the matched remote control aiming the socket when indicator light flashing. Light off means matching code successfully. 1. Power indicator: Indicating the current situation of the intelligent socket. 2. Intelligent socket: Electrical appliances on the socket are in a state of off or standby, it shall cut out the power automatically after 15 seconds. 3. Conversion key: Two sockets will be converted to normal power on when pressing the key, the intelligent program will be started when pressing again. 4. Always on socket: The normal open socket. 5. ESO key: Power Reset key, match code key. 6. Remote controller indicator: Indicates that if the remote key can be triggered successfully. 7. Remote control on-off key: You can connect power of intelligent socket by pressing it after matching code, and turn off by pressing again. V. Limited Warranty (Valid only in the U.S.A., Canada, Puerto Rico, and the Caribbean.) Sunrise Energy will, at its option, repair or replace any unit that is defective in materials or manufacture within one year after purchase. For warranty service, return unit to place of purchase or mail to Sunrise Energy at 12322 Highway 99, Suite E89, Everett, WA 98204. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES, AND THE IMPLIED WARRANTY OF MERCHANTABILITY IS LIMITED TO ONE YEAR FROM PURCHASE. THIS WARRANTY DOES NOT COVER THE COST OF INSTALLATION, REMOVAL OR REINSTALLATION, OR DAMAGE RESULTING FROM MISUSE, ABUSE, OR DAMAGE FROM IMPROPER WIRING OR INSTALLATION. THIS WARRANTY DOES NOT COVER INCIDENTAL OR CONSEQUENTIAL DAMAGES. Sunrise Energy’S LIABILITY ON ANY CLAIM FOR DAMAGES ARISING OUT OF OR IN CONNECTION WITH THE MANUFACTURE, SALE, INSTALLATION, DELIVERY, OR USE OF THE UNIT SHALL NEVER EXCEED THE PURCHASE PRICE OF THE UNIT. This warranty gives you specific legal rights, and you may have other rights which vary from state to state. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitation on how long an implied warranty may last, so the above limitations may not apply to you. ©2013 Sunrise Energy LLC DÉCLARATION DE LA FCC 1. Cet appareil est conforme à la partie 15 des règles de la FCC. Son fonctionnement est soumis aux deux conditions suivantes: (1) Ce dispositif ne doit pas causer d'interférences nuisibles. (2) Cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant entraîner un fonctionnement indésirable. FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Sunrise Energy LLC 9/6/2013 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _ Sunrise Energy LLC __hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description：Energy saving receptacle (ESR) Model name：SE-02W FCC ID: 2AAMU-SE-02W We affirm that between SIEMIC and _ Sunrise Energy LLC _, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature : Client’s name / title : Jeff Sun/Manager member Contact information / address : Sunrise Energy LLC/5510 166th Pl SW

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Sunrise Energy LLC 9/6/2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAMU-SE-02W We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Jeff Sun/Manager member Contact information / address: Sunrise Energy LLC/5510 166th Pl SW

Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 23 of 34 www.siemic.com.cn Annex B. EUT AND TEST SETUP PHOTOGRAPHS Annex B.i. Photograph : EUT External Photo EUT - Front View EUT - Rear View Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 24 of 34 www.siemic.com.cn EUT – Top View EUT – Bottom View Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 25 of 34 www.siemic.com.cn EUT – Left View EUT – Right View

Label Location

Model: SE-02W FCC ID: 2AAMU-SE-02W FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.

Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 26 of 34 www.siemic.com.cn Annex B.ii. Photograph 2: EUT Internal Photo EUT Uncover - Front View EUT PCB – Front View Tx Antenna Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 27 of 34 www.siemic.com.cn EUT PCB – Rear View

Sunrise Energy LLC Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A September 04, 2013 Report No.: 13050026-FCC-R1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: William Long Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 2 of 34 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Hong Kong OFTA (US002) RF , Telecom Japan MIC, (RCB 208) RF , Telecom Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 3 of 34 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 4 of 34 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS ......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS .................................................................. 9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................ 19 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 23 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 29 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................ 33 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 34 Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 5 of 34 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the Sunrise Energy LLC, The Energy saving receptacle (ESR), and model: SE-02W against the current Stipulated Standards. The Energy saving receptacle (ESR) has demonstrated compliance with the FCC 15.231:2012. EUT Information EUT Description Energy saving receptacle (ESR) Model No SE-02W Serial No N/A Input Power DC 12V(TX) Classification Per Stipulated Test Standard FCC Part 15.231:2012 Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 6 of 34 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Energy saving receptacle (ESR) with stipulated standard Applicant / Client Sunrise Energy LLC 5510 166th Pl SW Manufacturer Haojia Electronic (Shenzhen) Ltd. 1-2, west side of Fenghuangdao Road, Taian Town, Guangling District, Yangzhou, China Laboratory performing the tests SIEMIC (Nanjing-China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email: [email protected] Test report reference number 13050026-FCC-R1 Date EUT received July 03, 2013 Standard applied FCC 15.231:2012 Dates of test September 02, 2013 No of Units : 1# Equipment Category : DSC Trade Name : Sunrise Energy Test Model : SE-02W RF Operating Frequency (ies) Tx: 315.06MHz Number of Channels : 1CH Modulation : FSK FCC ID ： 2AAMU-SE-02W Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 7 of 34 www.siemic.com.cn 3 MODIFICATION NONE Title: RF Test Report for Energy savi…

Text truncated - open the document above for the full version.

Title: RF Test Report for Energy saving receptacle (ESR) Main Model: SE-02W Serial Model: N/A To: FCC 15.231:2012 Report No.: 13050026-FCC-R1 Issue Date: September 04, 2013 Page: 28 of 34 www.siemic.com.cn Annex B.iii. Photograph : Test Setup Photo Radiated Emission Test Setup Front View Below 1GHz Radiated Emission Test Setup Front View Above 1GHz
