2AANCBWTABLET PC

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2013-7-27 SUBJECT: FCC Application for (FCC ID: 2AANCBW) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Client’s name / title : karli wang/ general manager Contact information / address : Unit 04, 7/F, Bright Way Tower, No. 33 Mong Kok Road, Kowloon, Hongkong

Beneworld International (HK) Co., Limited SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Adding CFR 2.459 (obsolete) 1.0 2.0 Updated company template & Added text box (current) 2.0 3.0 Beneworld International (HK) Co., Limited SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2013/07/16 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AANCBW We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up procedure and BOM The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : karli wang/ general manager Contact information / address : Unit 04, 7/F, Bright Way Tower, No. 33 Mong Kok Road, Kowloon, Hongkong

Differences Description We Beneworld International (HK) Co., Limited state: Product name: TABLET PC Model:BW0767,BW0767A,BW0709,BW0708,BW0702, BW0736,BW0737,BW0751,BW0789, BW0781 All the model are the same circuit and RF module, except the model name. Signatory Client’s name / title : karli wang/ general manager Contact information / address : Unit 04, 7/F, Bright Way Tower, No. 33 Mong Kok Road, Kowloon, Hongkong

Beneworld International (HK) Co., Limited SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Revised wording (obsolete) 1.0 2.0 Updated company template (current) 2.0 3.0 Beneworld International (HK) Co., Limited SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/07/16 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Beneworld International (HK) Co., Limited_hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： TABLET PC Trade Name： N/A Model Name： BW0767 Serial Model： BW0767A,BW0709, BW0708,BW0702, BW0736,BW0737, BW0751,BW0789, BW0781 FCC ID 2AANCBW We affirm that between SIEMIC and Beneworld International (HK) Co., Limited any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : karli wang/ general manager Contact information / address : Unit 04, 7/F, Bright Way Tower, No. 33 Mong Kok Road, Kowloon, Hongkong

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

Label MODEL NO: BW0767 INPUT:DC 5V 2000mA TABLET PC FCC ID: 2AANCBW Made in china This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 WIFI/BT ANT GSM/WCDMA ANT Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18 Photo 19 Photo 20 Photo 21 WIFI/BT /WCDMA/GSMANT

FCC RADIO TEST REPORT FCC ID: 2AANCBW Of Product： TABLET PC Trade Name： N/A Model Number： BW0767 Serial Model： BW0767A,BW0709,BW0708,BW0702, BW0736,BW0737,BW0751,BW0789, BW0781 Report No.： NTEK-2013NT080120F2 Prepared for Beneworld International (HK) Co., Limited Unit 04, 7/F, Bright Way Tower, No. 33 Mong Kok Road, Kowloon, Hongkong Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 54 Report No.: NTEK-2013NT080120F2 TEST RESULT CERTIFICATION Applicant’s name ................. : Beneworld International (HK) Co., Limited Address .................................. : Unit 04, 7/F, Bright Way Tower, No. 33 Mong Kok Road, Kowloon, Hongkong Manufacture's Name ............ : Shenzhen Beneworld Technology Co., Ltd. Address .................................. : Building 3, Huangtian Industrial park, xixiang, Baoan District, Shenzhen, Guangdong, China Product description Product name ............................ : TABLET PC Model and/or type reference .............................. : BW0767 Serial Model： BW0767A,BW0709,BW0708,BW0702, BW0736,BW0737,BW0751,BW0789, BW0781 Ratings DC 3.7V Standards ............................. : FCC Part15.247 Test procedure ............................... : ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 15 July 2013 ~26 July 2013 Date of Issue .......................................... : 26 July 2013 Test Result .............................................. : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 54 Report No.: NTEK-2013NT080120F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 30 4 . NUMBER OF HOPPING CHANNEL 34 4.1 APPLIED PROCEDURES / LIMIT 34 4.1.1 TEST PROCEDURE 34 4.1.2 DEVIATION FROM STANDARD 34 4.1.3 TEST SETUP 34 4.1.4 EUT OPERATION CONDITIONS 34 4.1.5 TEST RESULTS 35 5 . AVERAGE TIME OF OCCUPANCY 36 Page 4 of 54 Report No.: NTEK-2013NT080120F2 Table of Contents Page 5.1 APPLIED PROCEDURES / LIMIT 36 5.1.1 TEST PROCEDURE 36 5.1.2 DEVIATION FROM STANDARD 36 5.1.3 TEST SETUP 36 5.1.4 EUT OPERATION CONDITIONS 36 5.1.5 TEST RESULTS 37 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 TEST PROCEDURE 43 6.1.2 DEVIATION FROM STANDARD 43 6.1.3 TEST SETUP 43 6.1.4 EUT OPERATION CONDITIONS 43 6.1.5 TEST RESULTS 44 7 . BANDWIDTH TEST 46 7.1 APPLIED PROCEDURES / LIMIT 46 7.1.1 TEST PROCEDURE 46 7.1.2 DEVIATION FROM STANDARD 46 7.1.3 TEST SETUP 46 7.1.4 EUT OPERATION CONDITIONS 46 7.1.5 TEST RESULTS 47 8 . PEAK OUTPUT POWER TEST 49 8.1 APPLIED PROCEDURES / LIMIT 49 8.1.1 TEST PROCEDURE 49 8.1.2 DEVIATION FROM STANDARD 49 8.1.3 TEST SETUP 49 8.1.4 EUT OPERATION CONDITIONS 49 8.1.5 TEST RESULTS 50 9 . ANTENNA REQUIREMENT 52 9.1 STANDARD REQUIREMENT 52 9.2 EUT ANTENNA 52 10 . EUT TEST PHOTO 53 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 54 Report No.: NTEK-2013NT080120F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 54 Report No.: NTEK-2013NT080120F2 1.1 TEST FACILITY BZT Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 54 Report No.: NTEK-2013NT080120F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment TABLET PC Trade Name N/A Model Name BW0767 Serial Model BW0767A,BW0709,BW0708,BW0702, BW0736,BW0737,B…

Text truncated - open the document above for the full version.

Page 53 of 54 Report No.: NTEK-2013NT080120F2 10. EUT TEST PHOTO Radiated Measurement Photos Page 54 of 54 Report No.: NTEK-2013NT080120F2 Conduction Measurement Photos
