2AANU-HTL3150BV37SoundBar Speaker

The Bluetooth ® w or d mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and an y use of such marks by Gibson Innovations Limited is under license. Other trademarks and trade names are those of their respective owners. Dolby, Pro Logic, and the double-D symbol are registered trademarks of Dolby Laboratories. Any changes or modifications made to this device that are not expressly approved by Gibson Innovations may void the user’s authority to operate the equipment. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. La marque et les logos Bluetooth ® sont la propriété de Bluetooth SIG, Inc. et leur utilisation par Gibson Innovations Limited s’effectue sous licence. Les autres désignations commerciales et marques mentionnées sont détenues par leur propriétaire respectif. Dolby, Pro Logic, y el símbolo doble-D son marcas comerciales registradas de Dolby Laboratories. Toute modification effectuée sur ce produit, qui ne sera pas approuvée expressément par Gibson Innovations, pourrait restreindre ou empêcher le bon fonctionnement de celui-ci. HDMI, el logotipo HDMI y High-Definition Multimedia Interface son marcas comerciales o marcas comerciales registradas de HDMI Licensing LLC en Estados Unidos y en otros países. Main unit: 950 x 51 x 69mm/37.4" x 2" x 2.7" /1.7kg/3.7lbs Subwoofer : 165 x 240 x 296mm/6.5" x 9.4" x 11.7" /2.8kg/6.2lbs Specifications subject to modificationEspecificaciones sujetas a modificación Pr oduct dimensions (width x height x depth)/ weight : Unidad principal: 950 x 51 x 69mm/37.4" x 2" x 2.7" /1.7kg/3.7lbs Caisson de basses: 165 x 240 x 296mm/6.5" x 9.4" x 11.7" /3.0kg/6.6lbs Dimensiones del producto (ancho x alto x fondo)/ Poids : USA and Canada Importer / Importés par: Gibson Innovations USA Inc. 3070 Windward Plaza Suite F, Box 735 Alpharetta, GA 30005 76-2170G1-0ATB7-P1 Power Adapter Power Cord Quick star t guide 6 X Optical Cable 395mm/15.6" 418mm/16.5" 295mm/11.6" W H D 55x25mm 76- 2170G1- 0ATB7- P1

HTL3150B Quick start guide Register your product and get support at www.philips.com/support Always there to help you Question? Contact Philips 1 English 1 Important Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply. Important safety instructions •Read these instructions. •Keep these instructions. •Heed all warnings. •Follow all instructions. •Do not use this apparatus near water. •Clean only with dry cloth. •Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. •Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. •Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. •Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. •Only use attachments/accessories specified by the manufacturer. •Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. •Unplug this apparatus during lightning storm or when unused for long periods of time. •Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. •Battery usage CAUTION - To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit: • Install all batteries correctly, + and - as marked on the unit. • Do not mix batteries (old and new or carbon and alkaline, etc.). • Remove batteries when the unit is not used for a long time. • The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. • Perchlorate Material - special handling may apply. See www.dtsc. ca.gov/hazardouswaste/perchlorate. • The product/remote control may contain a coin/button type battery, which can be swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion. • If you suspect that a battery has been swallowed or placed inside any part of the body, seek immediate medical attention. • When you change the batteries, always keep all new and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery. • If the battery compartment cannot be completely secured, discontinue use of the product. Keep out of reach of children and contact the manufacturer. •Apparatus shall not be exposed to dripping or splashing. •Do not place any sources of danger on the apparatus (for example. liquid filled objects, lighted candles). . 2 •This apparatus may contain lead and mercury. Dispose according to local, State or Federal laws. For disposal or recycling information, please contact your local authorities. For additional assistance on recycling options, please contact www.mygreenelectronics.com or www.eiae.org or www.recycle.philips.com. •Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. •Do not place this apparatus on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it. A falling apparatus can cause serious injury or even death. • This apparatus should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided. Make sure to leave a space of 7.8 inches (20cm) or more around this apparatus. Class II equipment symbol This symbol indicates that the unit has a double insulation system. Know these safety symbols This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. The ‘exclamation point’ calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems. WARNING: To reduce the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture and objects filled with liquids, such as vases, should not be placed on this apparatus. CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert. Care for your product Use only microfiber cloth to clean the product. Care of the environment Disposal of your old product and battery Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or visit www.recycle.philips.com. This product contains batteries: • Dispose of batteries properly. Do not incinerate. Batteries may explode if overheated. • Do not wrap in metal or aluminum foil. Wrap in newspaper before discarding. • It is suggested that you contact your local town or city to determine proper battery redemption site(s) in your area. • Please visit www.call2recycle.org for additional information on a recycling center in your area for rechargeable batteries. Notice of compliance The dev…

Text truncated - open the document above for the full version.

RF_160, Issue 02 Declaration of Authorization We Name: Gibson Innovations Limited Address: 5/F Philips Electronics Building, 5 Science Park East Ave, HK Science Park City: Shatin, NT Country: Hong Kong Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: SoundBar Speaker Type designation: HTL3150B/37 Trademark: PHILIPS FCC ID: 2AANU-HTL3150BV37 on our behalf. Date: 2015-08-31 City: Shatin, NT Name: Joseph Lau Position: Assistant Manager Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Project No.: 1507C373 Page 2 of 36 Soundbar Project No.: 1507C373 Page 3 of 36 Project No.: 1507C373 Page 4 of 36 Project No.: 1507C373 Page 5 of 36

备注： 1.贴纸上变量 ，见红框内容 时间变量规则，见上面标注 序列号变量规则，见如下 KXG11500000001 序列号含义说明 此2位为工厂代码,固定内容，保持不变 此2位代表生产年份 此2位代表生产周 此6位代表生产序列号 例如 KXG11528000020 KX为固定内容，根据机型不同而变更,根据版本不同而变更, 此序列号表示2015年28周, 订单，序列号为20。 G1 生产的 2.条码要求：类型，高度，扫描显示内容，见上面标注。 3.贴纸上面特殊地方说明 此1位为机型的代码不同品牌参考如下备注品牌， 此1位为版本号()BOM/Service version Gibson –G ONKYO –K GoGear –L Trainer –T Fidelio -F Philips –P 品牌代码: 粘贴到彩盒上 粘贴到中后壳上 71-317037-BARB1-P1 条码类型：UPC(A) 条码要求：按照源文件1：1印刷 条码扫描显示出来的内容： 注：字体必须为Crystal显示 条码类型：Code 39 条码要求：高度不能小于5mm 条码扫描显示出来的内容： 注：显示字体必须为Crystal 变量 条码类型：Code 39 条码要求：高度不能小于5mm 条码扫描显示出来的内容： 注：字体必须为Crystal显示 条码类型：Code 39 条码要求：高度不能小于5mm 条码扫描显示出来的内容： 注：显示字体必须为Crystal 变量 条码类型：Code 39 条码要求：高度不能小于5mm 条码扫描显示出来的内容： 注：字体必须为Crystal显示 条码字体：Crystal August 2015 Fabriqué en Chine Hecho en China MADE IN CHINA 15.4 Consumo de Energía Eléctrica del aparato en Modo de Espera: 0.459 Wh Consumo de Energía Eléctrica: 17.813Wh FCC ID : 2AANU-HTL3150BV37 IC : 11260A-HTL3150BV37

Project No.: 1507C373 Page 6 of 36 Project No.: 1507C373 Page 7 of 36 Project No.: 1507C373 Page 8 of 36 Project No.: 1507C373 Page 9 of 36 Project No.: 1507C373 Page 10 of 36 Project No.: 1507C373 Page 11 of 36 Project No.: 1507C373 Page 12 of 36 Project No.: 1507C373 Page 13 of 36 Project No.: 1507C373 Page 14 of 36 Project No.: 1507C373 Page 15 of 36 Project No.: 1507C373 Page 16 of 36 Project No.: 1507C373 Page 17 of 36 Project No.: 1507C373 Page 18 of 36 Project No.: 1507C373 Page 19 of 36 Project No.: 1507C373 Page 20 of 36 Project No.: 1507C373 Page 21 of 36 Project No.: 1507C373 Page 22 of 36

Report No.: BTL-FICP-2-1507C373 Page 1 of 54 FCC&IC Radio Test Report FCC ID: 2AANU-HTL3150BV37 IC: 11260A-HTL3150BV37 This report concerns (check one): Original Grant Class II Change Project No. : 1507C373 Equipment : SoundBar Speaker Model Name : HTL3150B/37 Applicant : GIBSON Innovations Ltd Address : 5/F., Philips Electronics Building,5 Science Park East Avenue, Hong Kong Science Park,Shatin, New Territories, Hong Kong Date of Receipt : Jul. 31, 2015 Date of Test : Jul. 31, 2015 ~ Aug. 12, 2015 Issued Date : Aug. 14, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3,Jinshagang 1st Road, Shixia,Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000FAX: +86-769-8319-6000 Report No.: BTL-FICP-2-1507C373 Page 2 of 54 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement b y NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FICP-2-1507C373 Page 3 of 54 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 .GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 BLOCKDIAGRAMSHOWINGTHECONFIGURATIONOFSYSTEMTESTED 12 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 .EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION 13 4.1.2 TESTPROCEDURE 13 4.1.3 DEVIATIONFROMTESTSTANDARD 13 4.1.4 TESTSETUP 14 4.1.5 EUT OPERATING CONDITIONS 14 4.1.6 EUT TEST CONDITIONS 14 4.1.7 TEST RESULTS 14 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 RADIATED EMISSION LIMITS 15 4.2.2 TESTPROCEDURE 16 4.2.3 DEVIATIONFROMTESTSTANDARD 16 4.2.4 TESTSETUP 17 4.2.5 EUT OPERATING CONDITIONS 18 4.2.6 EUT TEST CONDITIONS 18 4.2.7 TEST RESULTS (BELOW 30MHz) 18 4.2.8 TEST RESULTS (30 to 1000 MHz) 18 4.2.9 TEST RESULTS(ABOVE1000 MHz) 19 5 . BANDWIDTH TEST 20 5.1 TEST PROCEDURE 20 5.2 DEVIATION FROM STANDARD 20 5.3 TEST SETUP 20 5.4 EUT OPERATION CONDITIONS 20 5.5 EUT TEST CONDITIONS 20 5.6 TEST RESULTS 20 6 . MEASUREMENT INSTRUMENTS LIST AND SETTING 21 ATTACHMENT A - CONDUCTED EMISSION 23 Report No.: BTL-FICP-2-1507C373 Page 4 of 54 Table of Contents Page ATTACHMENT B -RADIATED EMISSION (9KHZ to 30MHZ) 26 ATTACHMENT C -RADIATED EMISSION (30MHZ TO 1000MHZ) 28 ATTACHMENT D -RADIATED EMISSION (ABOVE 1000MHZ) 37 ATTACHMENT E - BANDWIDTH 52 Report No.: BTL-FICP-2-1507C373 Page 5 of 54 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FICP-2-1507C373 Original Issue. Aug. 14, 2015 Report No.: BTL-FICP-2-1507C373 Page 6 of 54 1. CERTIFICATION Equipment : SoundBar Speaker Brand Name : PHILIPS Model Name : HTL3150B/37 Applicant : GIBSON Innovations Ltd Manufacturer : GIBSON Innovations Ltd Address : 5/F., Philips Electronics Building,5 Science Park East Avenue, Hong Kong Science Park,Shatin, New Territories, Hong Kong Date of Test : Jul. 31, 2015 ~ Aug. 12, 2015 Test Sample : Engineering Sample Standard(s) : FCC Part15, Subpart C :2014 (15.249)/ ANSI C63.4-2013 Canada RSS-210 Issue 8 Dec 2010 RSS-GEN Issue 4, Nov 2014 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FICP-2-1507C373) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FICP-2-1507C373 Page 7 of 54 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.249) Canada RSS-210 Issue 8 Dec 2010, RSS-GEN Issue 4, Nov 2014 StandardSection Test Item Judgment Remark FCC IC 15.207(a) RSS-GEN 8.8 Conducted Emission PASS 15.205 RSS-210 Annex 8 (A2.9) Restricted Band of Operation PASS 15.209 15.249(a) RSS-210 Annex 8 (A8.1(a)) Radiated Emissions PASS 15.215(c) RSS-GEN 8.8 20dB Bandwidth Test PASS NOTE: (1)”N/A” denotes test is not applicable in this test report. Report No.: BTL-FICP-2-1507C373 Page 8 of 54 2.1 TEST FACILITY The test facilities used to collect the test data in this report is at the location of No.3,Jinshagang 1st Road, Shixia,Dalang Town, Dongguan, Guangdong, China. BTL's test firm number for FCC: 319330 BTL's test firm number for IC 4428B-1 2.2 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2. The BTL measurement uncertainty is less than the CISPR 16-4-2 U cispr requirement. The…

Text truncated - open the document above for the full version.

Report No.: BTL-FICP-1-1507C373 Page 30 of 109 12. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FICP-1-1507C373 Page 31 of 109 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FICP-1-1507C373 Page 32 of 109 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FICP-1-1507C373 Page 33 of 109 Radiated Measurement Photos Above 1000MHz
