2AANZMWMCMini Microphone with Lightning /USB-C Connector

Receiver USER MANUAL Thank you for choosing our product. This smart wireless microphone offers reliable, professional-quality recording with a simple plug-and-pay setup —no app required. It can be used for live streaming, Vlog recording, interviews, video tutorials, and more. The system includes two parts: a transmitter and a receiver. MINI MICROPHONE MINI MICROPHONE with lightning/USB-C connector 1 2 2 3 4 Description Windproof net Microphone Indicator Type-C Charging Port Microphone Clip Power Button Port to Connect Phone Receiver Indicator ***Some Android phones may have incompatibility problems due to system, please consult your dealer for details*** 1 3 5 4 6 5 7 6 7 Receiver Type-C Charging Cable Lightning ® Adapter Packing list Microphone transmitter Receiver Lightning ® adapter Charging cable User Manual 1. 2. 3. 4. 5. Microphone Transmitter Low Battery AlarmPower on state Paired Red light turns off once fully charged Charging Plug the cable into the device and the USB into a power source Reverb Mode Click twice Both the receiver and transmitter will display a solid green light Green light flashes slowly Prior Pairing Alternating red and green light PausePress power button once ResetPress power button once Power Off Hold power button for 3 seconds Light turns off Power On Press and hold the power button for a few seconds The indicator light turns green Red and green lights alternate every 10 seconds PairedGreen light stays on Prior PairingGreen light slowly flashes Power OffUnplug the deviceGreen light turns off Power OnPlug-in the deviceGreen light flashes Feature OperationLight Indicator About UISpecifications: Microphone Transmitter Feature OperationLight Indicator Step 1: Connect the receiver to your phone using the designated port. How to use FCC WARNING RF Exposure information This equipment has been tested and found to comply with the limits for a Cass B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instalation. This equipment generates uses and can radiate radio frequency energy. If not installed and used by the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particuar instalation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. CAUTION: FOR YOUR SAFETY, the charging cable included with this item is intended for use with this product only Distributed By: 1616 Holdings, Inc. 701 Market Street, Suite 200, Philadelphia, P A 1910 MADE IN CHINA www.fivebelow.com Customer service: 1 (844) 452-3569 Step 2: Press the microphone’s power button. The microphone is powered on when the indicator light turns green. Step 3: When the receiver’s green indicator light remains solid, the connection is stable. You can now open your camera, live streaming app, or other compatible apps to start recording audio. Step 4: After recording, you do not need to unplug the receiver to pay back your video! Note: When the receiver is unplugged from the phone, the microphone will automatically power off after 3–5 minutes. Model: FB-MWMC Bluetooth version: V5.4 Battery type: Lithium polymer Battery capacity: 40 mAh Charging interface: Type-C charging cable with Lightning adapter 5V 0.5A Max *Charging cable included. Bluetooth range: 10 meters Bluetooth frequency: 2400MHz - 2483.5MHz BT ID: D068842 FCC ID: 2AANZMWMC 54231 9687 SIZE: 50X60MM 5-PANEL FOLD FOLD LINE CUT LINE DO NOT PRINT BOOK SIZE: 3” W X 3” H (FOLDED) PAPER: 100 LBS. MAGAZINE PAPER INKS K FB-MWMC1- MANUAL PAGE 3 COVER BACK COVER START FINISH F B-MWMC-MC1

DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Sep. 2, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2AANZMWMC DGL Group LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Amy Chao Title: N/A Address: 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States Tel.: 001-732-692-5180 Email: [email protected]

DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Sep. 2, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: 2AANZMWMC Product Name: Mini Microphone with Lightning /USB-C Connector This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Amy Chao Title: N/A Address: 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States Tel.: 001-732-692-5180 Email: [email protected] DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ The Memory used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. Compliance ☒ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. Compliance Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name: DGL Group LTD. Address: 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States FCC ID: 2AANZMWMC 2.911(d)(7) USA Designated Agent for Service of Process We, [DGL Group LTD.] (“the applicant”) designate [DGL Group LTD.] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant Company name: DGL Group LTD. Address: 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States Grantee FRN Number: 0024048670 FCC Grantee Code: 2AANZ Contact Name: Amy Chao Telephone No: 001-732-692-5180 Email: [email protected] DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States 2.911 (d)(7)USA Agent v1.5 S ignature: Title: Date: 2025-08-21 N OTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States Date: 2025/9/2 Dear Sir/Madam, We, DGL Group LTD., Hereby declares the following statement, PCB board, circuit, structure and internal of these model(s) are the same, Only model number and color are different for these model: Product name: Mini Microphone with Lightning /USB-C Connector FCC ID: 2AANZMWMC Model no.: FB-MWMC-MC1, FB-MWMC1-BLK, FB-MWMC1-PNK Sincerely, Name/Title： Amy Chao / N/A Company: DGL Group LTD. Address: 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States Phone: 001-732-692-5180 Fax: 001-732-692-5000 E-Mail: [email protected]

DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States September 5, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2AANZMWMC Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Pursuant to DA 04-1705, the applicant also requests temporary confidential treatment of the exhibits outlined below for a period of 0 days from the date of equipment authorization and prior to marketing in the United States to prevent the premature release of any sensitive information. Applicant is aware of their responsibility to notify DERYCOM in the event information regarding the product or the product is made available to the public before the requested period has expired. Sincerely, Title: N/A Address: 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States Tel.: 001-732-692-5180 Email: [email protected]

DGL Group LTD. 2045 Lincoln Highway, 3rd Floor, Edison, New Jersey 08817, United States September 2, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2AANZMWMC I, the undersigned, hereby authorize Shenzhen Tongzhou Testing Co.,Ltd. to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by Shenzhen Tongzhou Testing Co.,Ltd. shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with DGL Group LTD.. We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, Amy Chao N/A Tel: 001-732-692-5180 Fax: 001-732-692-5000 Email: [email protected]

Report No.: TZ0035250818PH02 Page 1 of 4 Exterior Photographs of EUT Fig.1 Fig.2 Report No.: TZ0035250818PH02 Page 2 of 4 Fig.3 Fig.4 Report No.: TZ0035250818PH02 Page 3 of 4 Fig.5 Fig.6 Report No.: TZ0035250818PH02 Page 4 of 4 Fig.7

Label Location FCC ID: 2AANZMWMC

Report No.: TZ0035250818PH03 Page 1 of 4 Interior Photographs of EUT Fig.1 Fig.2 Report No.: TZ0035250818PH03 Page 2 of 4 Fig.3 Fig.4 Bluetooth Antenna Report No.: TZ0035250818PH03 Page 3 of 4 Fig.5 Fig.6 Report No.: TZ0035250818PH03 Page 4 of 4 Fig.7

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AANZMWMC This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 2 RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AANZMWMC This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 2 Results RF Exposure at Separation distance (cm): 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR-based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] BLE_1M Ant1 2402 -1.72 -2 1 2.67 -0.48 0.90 2.79 BLE_1M Ant1 2440 -2.28 -3 1 2.67 -1.48 0.71 2.75 BLE_1M Ant1 2480 -3.27 -4 1 2.67 -2.48 0.56 2.72 BLE_2M Ant1 2402 -1.7 -2 1 2.67 -0.48 0.90 2.79 BLE_2M Ant1 2440 -2.36 -3 1 2.67 -1.48 0.71 2.75 BLE_2M Ant1 2480 -3.3 -4 1 2.67 -2.48 0.56 2.72 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 产品规格承认书 SPECIFICATIONS 客户: CUSTOMER: 产品名称: DESCRIPTION:Bipolarantenna 客户型号: CUSTOMERPARTNo: 产品型号: OURMODELNO:PBX3216MA01 日期: DATE: 确认签字,盖章后请返回承认书一份 PLEASERETURNTOUSONECOPYOF“SPECIFICATIONFORAPPROVAL” WITHYOURAPPROVEDSIGNATURES ApprovedLiuFeiAuditLiuFeiMakingLiuXiaoMei CustomerAcknowledgesSignature Date PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 PBX3216MA01Specification OperatingTemp.:-40 °C ~+85 °C 1.FEATURES: ●Lightweight,compact ●Widebandwidth,lowcost ●Built-inantennawithhighgain 2.APPLICATIONS: ●Bluetooth,WirelessLAN,MobileTV ●HomeRFSystem,etc 3.PRODUCTIDENTIFICATION (1)(2)(3) (1)Producttype:MultilayerchipAntenna (2)CenterFrequency:2450MHz (3)ExternalDimensions(L×W)(mm):3.2*1.6 4.SHAPEANDDIMENSIONS: LWHA 3.2±0.21.6±0.2 0.52±0.10.4±0.1 CH IP45 032 2 16 PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 Testplatereferencesize ： Company ： mm PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 Holepunchingreferencediagram APPLICATIONGUIDE 5.SPECIFICATIONS: *Testcondition:Testboardsize90*40mm Matchingcircuit:Pimatchingcircuitwillberequired PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 6.ElectricalCharacteristics: Returnloss Standingwaveratio MarkFrequencyVSWR 12400MHz1.513 22440MHz1.068 32480MHz1.464 PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 RadiationPattern TheGainpatternismeasuredinFAR-fieldchamber.DUTisplacedonthetableofrotator,a standardhornantennaandVectorNetworkAnalyzerisusedtocollectdata. ◎Efficiency Maximumgain PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 ◎ 3DGainPattern(2400MHz) ◎ 3DGainPattern(2440MHz) ◎ 3DGainPattern(2480MHz) PengBanXingYeShenZhenTechnologyCo.,Ltd Address：Room608,Building4,1970ScienceandTechnologyTown,MinzhiStreet,LonghuaDistrict,Shenzhen. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝ ± HOLEDIA＝ ± PengBanXingYeShenZhenTechnologyCo.,Ltd SCALE：N/AUNIT：mm THESEDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-3216Specification DOCUMENT NO. 3216 SPECREV. P1 7.EnvironmentalCharacteristics (1)ReliabilityTest (2)StorageCondition (a)Atwarehouse: Thetemperatureshouldbewithin0~30°Candhumidityshouldbelessthan60%RH. Theproductshouldbeusedwithin1yearfromthetimeofdelivery. (b)Onboard: Thetemperatureshouldbewithin-40~85°Candhumidityshouldbelessthan85%RH. (3)OperatingTemperatureRange Operatingtemperaturerange:-40 °C to+1…

Text truncated - open the document above for the full version.

Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 1 of 33 Appendix Test Data for BLE (Conducted Measurement) Product Name: Mini Microphone with Lightning /USB-C Connector Trade Mark: / Test Model: FB-MWMC-MC1 FCC ID: 2AANZMWMC Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: DTS Bandwidth Test Result Test Mode Antenna Frequency [MHz] DTS BW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict BLE_1M Ant1 2402 0.656 2401.652 2402.308 0.5 PASS BLE_1M Ant1 2440 0.648 2439.664 2440.312 0.5 PASS BLE_1M Ant1 2480 0.652 2479.664 2480.316 0.5 PASS BLE_2M Ant1 2402 1.108 2401.444 2402.552 0.5 PASS BLE_2M Ant1 2440 1.144 2439.408 2440.552 0.5 PASS BLE_2M Ant1 2480 1.096 2479.448 2480.544 0.5 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 2 of 33 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 3 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 4 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 5 of 33 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict BLE_1M Ant1 2402 1.0155 2401.4851 2402.5006 --- --- BLE_1M Ant1 2440 1.0208 2439.4832 2440.5040 --- --- BLE_1M Ant1 2480 1.0225 2479.4809 2480.5034 --- --- BLE_2M Ant1 2402 2.0100 2400.9977 2403.0077 --- --- BLE_2M Ant1 2440 2.0099 2438.9941 2441.0040 --- --- BLE_2M Ant1 2480 2.0151 2478.9997 2481.0148 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 6 of 33 Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 7 of 33 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 8 of 33 BLE_2M-Ant1-2440 BLE_2M-Ant1-2480 Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 9 of 33 Appendix C: Maximum peak conducted output power Test Result Peak Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict BLE_1M Ant1 2402 -1.72 ≤30 PASS BLE_1M Ant1 2440 -2.28 ≤30 PASS BLE_1M Ant1 2480 -3.27 ≤30 PASS BLE_2M Ant1 2402 -1.70 ≤30 PASS BLE_2M Ant1 2440 -2.36 ≤30 PASS BLE_2M Ant1 2480 -3.30 ≤30 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 10 of 33 Test Graphs Peak BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 11 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 12 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 13 of 33 Appendix D: Maximum peak power spectral density Test Result Test Mode Antenna Frequency [MHz] Result [dBm/3kHz] Limit [dBm/3kHz] Verdict BLE_1M Ant1 2402 -17.60 ≤8.00 PASS BLE_1M Ant1 2440 -18.31 ≤8.00 PASS BLE_1M Ant1 2480 -19.19 ≤8.00 PASS BLE_2M Ant1 2402 -20.71 ≤8.00 PASS BLE_2M Ant1 2440 -21.37 ≤8.00 PASS BLE_2M Ant1 2480 -22.33 ≤8.00 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 14 of 33 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 15 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 16 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 17 of 33 Appendix E: Band edge measurements Test Result Test Mode Antenna Ch. Name Frequency [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict BLE_1M Ant1 Low 2402 -2.62 -49.39 ≤-22.62 PASS BLE_1M Ant1 High 2480 -4.44 -48.83 ≤-24.44 PASS BLE_2M Ant1 Low 2402 -2.46 -44.87 ≤-22.46 PASS BLE_2M Ant1 High 2480 -4.27 -48.97 ≤-24.27 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 18 of 33 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 19 of 33 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 20 of 33 Appendix F: Conducted Spurious Emission Test Result Test Mode Antenna Frequency [MHz] Freq. Range [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict BLE_1M Ant1 2402 0~Reference -2.84 -2.84 --- PASS BLE_1M Ant1 2402 30~1000 -2.84 -63.06 ≤-22.84 PASS BLE_1M Ant1 2402 1000~26500 -2.84 -31.57 ≤-22.84 PASS BLE_1M Ant1 2440 0~Reference -3.24 -3.24 --- PASS BLE_1M Ant1 2440 30~1000 -3.24 -62.87 ≤-23.24 PASS BLE_1M Ant1 2440 1000~26500 -3.24 -33.78 ≤-23.24 PASS BLE_1M Ant1 2480 0~Reference -4.25 -4.25 --- PASS BLE_1M Ant1 2480 30~1000 -4.25 -62.9 ≤-24.25 PASS BLE_1M Ant1 2480 1000~26500 -4.25 -34.86 ≤-24.25 PASS BLE_2M Ant1 2402 0~Reference -2.64 -2.64 --- PASS BLE_2M Ant1 2402 30~1000 -2.64 -63.36 ≤-22.64 PASS BLE_2M Ant1 2402 1000~26500 -2.64 -30.55 ≤-22.64 PASS BLE_2M Ant1 2440 0~Reference -3.46 -3.46 --- PASS BLE_2M Ant1 2440 30~1000 -3.46 -62.65 ≤-23.46 PASS BLE_2M Ant1 2440 1000~26500 -3.46 -36.13 ≤-23.46 PASS BLE_2M Ant1 2480 0~Reference -4.18 -4.18 --- PASS BLE_2M Ant1 2480 30~1000 -4.18 -62.21 ≤-24.18 PASS BLE_2M Ant1 2480 1000~26500 -4.18 -33.69 ≤-24.18 PASS Note: offset(dB) in Reference test plots = cable loss(dB) + attenuator factor(dB); For spurious emissions plots from 30MHz to 26.5GHz, the cable loss and attenuator factors have been set in the 'Input Correction' of the Spectrum Analyzer during the test. Appendix Test Data of the Report No.: TZ0035250818FRF02 Page 21 of 33 Test Graphs BLE_1M-Ant1-2402-0~Reference-PASS B…

Text truncated - open the document above for the full version.

Report No.: TZ0035250818FRF02 Page 1 of 31 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen To…
