0102 12374 8 9 10 11 56 030405060708 N FEATURES 09 S 11121314 10 Model:WS-503 Before your first use, or when the battery runs out, please charge the speaker with the Micro USB charging cable included in the package. Plug the small Micro USB pin into the charging port on the speaker, and the other end of the cable (the standard USB 2.0 plug) into the USB port of a computer, or a USB main charger purchased from the same store, and the charger must be designed and tested compatible with this speaker. In this case, please then plug the USB charger to a wall outlet. Using a third party charger could result in electric shock and could also damage the speaker. The LED indicator keeps red when the speaker is being charged, and turns blue when fully charged. Full charge takes about 2 hours. The speaker can be charged while working. The battery of the speaker will be charged till the charging process completes. The speaker will be powered by the DC input directly and the battery will be in sleep mode after it is fully charged. When playing music at maximum volume, there may be distortion in sound. Please adjust the volume lower when there is distortion. 1. High-end Bluetooth speaker with microphone 2. Soft housing, with metal speaker mesh 3. 40MM driver delivers massive and rich sound 4. Large speaker cavity inside for excellent sound effect 5. LF membrance inside delivers outstanding bass 6. Built-in recharger battery supports up to 6 hours' playback time 7. Built-in microphone for hands-free phone call 8. Six buttons for controlling tracks on phone wirelessly 9. SIRI function can be actived for hands-free conversation 10. Easy connect to phones or other Bluetooth devices 11. Can be used as a wired speaker WARNING Please read these safety warnings and cautions carefully to ensure your personal safety and prevent property damage. Fire and Electric Shock Hazard · Do not expose your speaker to liquid, moisture, humidity, or rain. Do not use the speaker near a bathtub, sink, sauna, pool, or steam room. Exposure of the speaker to moisture could result in electric shock. · Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint, or insert foreign objects in to the speaker. Such actions could result in electric shock. · Clean the speaker only with a dry cloth. · Do not expose your speaker to extremely high or low temperatures. · Do not leave your speaker in direct sunlight for extended periods of time. · Do not leave your speaker near open flames such as cooking burners, candles, or fireplaces. · Do not block ventilation openings. Battery/Charging Hazard · Do not dispose your speaker in a fire. The battery could explode causing injury or death. · Only charge the speaker in accordance with this User Manual. · Do not charge the speaker in damp areas or in extremely high or low temperatures because this could result in electric shock. · Do not clean the speaker when it is being charged. Always unplug the charger first before cleaning the speaker. Automobile Accident Hazard · Do not leave or store the speaker or any of its accessories near or over your automobile’s air bag because serious injury may result when an air bag deploys. Fall Hazard · Do not place the speaker on high surfaces such as shelves. During music playback the speaker may move which could cause the speaker to shift and fall off the edge. CAUTION · Do not use abrasive cleaners to clean your speaker because this could cause scratches or damage. · Do not bring your speaker in to contact with any sharp objects because this could cause scratches and damage. · Do not insert anything into your speaker unless otherwise specified in this User Manual. This may damage the internal components. · Do not attempt to repair, modify, or disassemble your speaker yourself. · Do not attempt to replace the battery of the speaker. It is built-in, and not changeable by users. · Use only the USB charging cable supplied in the accessories package to charge the speaker, from the USB port of computer. Or charge the speaker with a wall main charger supplied from the same store where you purchase this speaker. Other chargers may look similar, but using them could result in electric shock and could damage the speaker. · Observe all signs and displays that require an electrical device or RF radio products to be switched off in designated areas. · Turn off your speaker prior to boarding an aircraft. Do not use the speaker inside an aircraft unless allowed by your airline. · Dispose of the speaker and the speaker’s battery in accordance with local regulations. Do not dispose of the battery with regular household waste. FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help FCC NOTICE This decive complies with part 15 of the FCC Rules. Operation is subject to the following two conditions; 1.This device may not cause harmful interferece,and 2.This device must accpept any interence received,including interfernce that may cause un…

Text truncated - open the document above for the full version.

Wisort Technology Limited Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Wisort Technology Limited FCC ID : 2AAOJWS-503 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Gareth Zhao Position General Manager Company Name Wisort Technology Limited Address 3F Lixinda Industrial Park, Fuyong No.1 Industrial Zone, Baoan, Shenzhen, China. Tel (86) 755-33516771 Fax (86) 755-33516773 Email [email protected]

Wisort Technology Limited Date: 22.07.2013 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Bluetooth Speaker Model Name WS-503, WS-501, WS-502, WS-504, WS-505 Brand Name N/A . Yours sincerely, Signatory Name Gareth Zhao Position General Manager Company Name Wisort Technology Limited Address 3F Lixinda Industrial Park, Fuyong No.1 Industrial Zone, Baoan, Shenzhen, China. Tel (86) 755-33516771 Fax (86) 755-33516773 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

50mm 30mm Company: Wisort Technology Limited Name: Bluetooth Speaker Model Number: WS-503 FCC ID: 2AAOJWS-503 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ANTENNA

Label Location

Shenzhen Certification Technology Service Co., Ltd. 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao'an District, Shenzhen 518126, P.R. China FCC ID: 2AAOJWS-503 Page 1 of 73 TEST REPORT FCC ID: 2AAOJWS-503 Applicant : Wisort Technology Limited Address : 3F Lixinda Industrial Park, Fuyong No.1 Industrial Zone, Baoan, Shenzhen, China. Equipment Under Test (EUT): Name : Bluetooth Speaker Model : WS-503, WS-501, WS-502, WS-504, WS-505 In Accordance with: FCC PART 15, SUBPART C : 2012 (Section 15.247) Report No : STI130626099 Date of Test : July 8-July 17, 2013 Date of Issue : July 18, 2013 Test Result: PASS In the configuration tested, the EUT complied with the standards specified above Authorized Signature ___________________________ (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.: STI130626099 FCC ID: 2AAOJWS-503 Page 2 of 73 Contents 1. General Information...............................................................................................................4 1.1. Description of Device (EUT)...............................................................................4 1.2. Accessories of device (EUT)...............................................................................4 1.3. Test Lab information............................................................................................4 2. Summary of test......................................................................................................................5 2.1. Summary of test result.........................................................................................5 2.2. Assistant equipment used for test.........................................................................5 2.3. Block Diagram.....................................................................................................6 2.4. Test mode.............................................................................................................6 2.5. Test Conditions.....................................................................................................7 2.6. Measurement Uncertainty (95% confidence levels, k=2)....................................7 2.7. Test Equipment.....................................................................................................8 3. Maximum Peak Output power..............................................................................................9 3.1. Limit.....................................................................................................................9 3.2. Test Procedure......................................................................................................9 3.3. Test Setup.............................................................................................................9 3.4. Test Result............................................................................................................9 4. Bandwidth.............................................................................................................................10 4.1. Limit...................................................................................................................10 4.2. Test Procedure....................................................................................................10 4.3. Test Result..........................................................................................................10 5. Carrier Frequency Separation............................................................................................14 5.1. Limit...................................................................................................................14 5.2. Test Procedure....................................................................................................14 5.3. Test Result..........................................................................................................14 6. Number Of Hopping Channel.............................................................................................16 6.1. Limit...................................................................................................................16 6.2. Test Procedure....................................................................................................16 6.3. Test Result..........................................................................................................16 7. Dwell Time............................................................................................................................19 7.1. Test limit............................................................................................................19 7.2. Test Procedure....................................................................................................19 7.3. Test Results........................................................................................................19 8. Radiated emissions...............................................................................................................21 8.1. Limit...................................................................................................................21 8.2. Block Diagram of Test setup..............................................................................21 8.3. Test Procedure.....…
