2AAP800003FULL SIZE BLUETOOTH SPEAKER

AmazonBasics Bluetooth ® Speaker Instruction Manual ∙ English Quick Setup Guide B00GUTY132 Setup Your speaker is partially charged when it arrive so you can use it right away. For the best reception, keep the speaker within 30 feet of the device it’s paired to. Pairing the speaker and a device •Turn ON the speaker. A tone sounds and the LED blinks. •Turn ON your device (like a phone or tablet). •On your device, locate your Bluetooth settings and turn on Bluetooth. •In Bluetooth Settings, scan for devices if necessary, then select Amazon_BT3 from your device’s list. The LED stops blinking and light blue. Your device and speaker are paired and your speaker is ready to use. 1 Pairing another device •Disconnect from the previous device by pressing and holding the function button. A tone sounds and the LED blinks. •Repeat the Pair the device steps for your next device. Note: You can pair multiple devices but you can only have one device actively paired at a time. Reconnecting a previously paired device •Disconnect from any other device by pressing and holding the function button. A tone sounds and the LED blinks. •If the speaker doesn’t automatically find the device you want paired (indicated by the LED blinking blue), go to your device settings and ensure that Bluetooth is still ON, then select Amazon_BT3. The speaker and device re-pair. Play music •Start playing music on your paired device. You will hear the music through the speaker. •On the speaker, press + or – to increase or decrease the volume •During music playing, you can simply press the function button to act as play/pause function. 2 Use as a speakerphone You can listen through the speaker and speak through the speaker’s microphone during phone calls. Position the speaker about 2 feet away and speak normally. If you make a call while paired: The audio and microphone automatically default to the speaker. •Use your phone to make the call •Press the call-divert button to end the call If you received a call while paired: Your phone rings through the speakerphone. To listen and speak through the speakerphone, press the call-divert button to answer the call. •Press the call-divert button to end the call. •During the phone rings through the speakerphone, you can also select press and hold the function button for 2 sec to reject the call. 3 Call-divert function After you receive your call by using the Amazon_BT3, if you want to transfer your listening and speaker of the call from the Amazon_BT3 back to the mobile device, *Press and hold the call-divert button for 2 sec. *Then, you can use your phone to answer and listen to the call. Connect with an audio cable Connect a 3.5mm audio cable (not included) from the speaker’s AUX jack to your audio device (like an MP3 player). Note: When connected to AUX, please disconnect from Bluetooth, use the controls on the device instead of the speaker. 4 MENU VOL OFF ON AUX POWER Charge the speaker After turn on the speaker, when the battery is low the speaker’s LED flashes red. If not charged, the speaker shuts off. To charge the speaker, connect the USB charging cable to the charging port and an available USB port on your computer. If the speaker is ON, the Red LED will “Flash” when charging. If the speaker is OFF, the Red LED will “Flash” while charging, and Red LED keep solid when fully charged. Remark: Please aware that the Blue LED is in ON/flashes status when the speaker is “ON”. So, there will have Blue and Red overlap lighting effect when you charging a “ON” speaker. 5 AC socket DC in OFF ON AUX POWER 6 Safety and Compliance FCC Information WARNING: To reduce the risk of fire or electrical shock, do not expose the system to rain or moisture. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance.                     This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 7 WEEE PRODUCT DISPOSAL INFORMATION Regulatory Information: Disposal of Waste Electrical and Electronic Equipment (WEEE) The Waste Electrical and Electronic Equipment (WEEE) Directive aims to minimize the impact of electrical of WEEE going to landfill. The symbol on this product or its packaging signifies that this product must be disposed separately from ordinary household wastes at its end of life. Be aware that this is your responsibility to dispose of electronic equipment at recycling centers in order to help conserve natural resources. Each country should have its collection centers for electrical and electronic equipment recycling. For information about your recycling drop off area, please contact your related electrical and electronic equipment waste management authority, your l…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Project No.: 1402C182 Page 2 of 10 Neutron Engineering Inc. Project No.: 1402C182 Page 3 of 10 Neutron Engineering Inc. Project No.: 1402C182 Page 4 of 10

FULL SIZE BLUETOOTH SPEAKER MODEL:BTV3 POWER SOURCE: DC:12.0V 1.5A FCC ID:2AAP800003 MADE IN CHINA Amazon.com, Inc. ASIN:B00GUTY132

Neutron Engineering Inc. Project No.: 1402C182 Page 5 of 11 Neutron Engineering Inc. Project No.: 1402C182 Page 6 of 11 Neutron Engineering Inc. Project No.: 1402C182 Page 7 of 11 Neutron Engineering Inc. Project No.: 1402C182 Page 8 of 11 Neutron Engineering Inc. Project No.: 1402C182 Page 9 of 11 Neutron Engineering Inc. Project No.: 1402C182 Page 10 of 11 Neutron Engineering Inc. Project No.: 1402C182 Page 11 of 11

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: 2AAP800003 Project No. : 1402C182 Equipment : FULL SIZE BLUETOOTH SPEAKER Model : BTV3 Applicant : Guoguang Electric Co.,Ltd. Address : No.8 Jin ghu Road, Xinhua Street, Huadu Reg, Guan gzhou, China According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Field Antenna: Ant. Brand Model Name Antenna Type Connector Gain (dBi) Note 1 N/A WA-P-LA-03-115PCB N/A 1.57 TX/RX Neutron Engineering Inc. Maximum measured transmitter power: Output Power (dBm) Out Power (mW) Limit (mW) 4.36 2.73 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 2.73 Mw, therefore all of them are less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 1 of 92 FCC Radio Test Report FCC ID: 2AAP800003 This report concerns (check one): Original Grant Class II Change Issued Date : Mar. 19, 2014 Project No. : 1402C182 Equipment : FULL SIZE BLUETOOTH SPEAKER Model Name : BTV3 Applicant : Guoguang Electric Co.,Ltd. Address : No.8 Jinghu Road, Xinhua Street, Huadu Reg, Guangzhou, China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Mar. 04, 2014 Date of Test: Mar. 04, 2014 ~ Mar. 17, 2014 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 2 of 92 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 3 of 92 Table of Contents Page REPORT ISSUED HISTORY 6 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 TEST PROCEDURE 20 4.2.3 DEVIATION FROM TEST STANDARD 20 4.2.4 TEST SETUP 20 4.2.5 EUT OPERATING CONDITIONS 21 4.2.6 EUT TEST CONDITIONS 21 4.2.7 TEST RESULTS (BELOW 30MHZ) 22 4.2.8 TEST RESULTS: 30MHZ - 1000MHZ 23 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 30 5 . NUMBER OF HOPPING CHANNEL 45 5.1 APPLIED PROCEDURES 45 5.1.1 TEST PROCEDURE 45 5.1.2 DEVIATION FROM STANDARD 45 5.1.3 TEST SETUP 45 5.1.4 EUT OPERATION CONDITIONS 45 5.1.5 EUT TEST CONDITIONS 45 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 4 of 92 Table of Contents Page 5.1.6 TEST RESULTS 46 6 . AVERAGE TIME OF OCCUPANCY 47 6.1 APPLIED PROCEDURES / LIMIT 47 6.1.1 TEST PROCEDURE 47 6.1.2 DEVIATION FROM STANDARD 47 6.1.3 TEST SETUP 47 6.1.4 EUT OPERATION CONDITIONS 48 6.1.5 EUT TEST CONDITIONS 48 6.1.6 TEST RESULTS 49 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 61 7.1 APPLIED PROCEDURES / LIMIT 61 7.1.1 TEST PROCEDURE 61 7.1.2 DEVIATION FROM STANDARD 61 7.1.3 TEST SETUP 61 7.1.4 EUT TEST CONDITIONS 61 7.1.5 TEST RESULTS 62 8 . BANDWIDTH TEST 66 8.1 APPLIED PROCEDURES 66 8.1.1 TEST PROCEDURE 66 8.1.2 DEVIATION FROM STANDARD 66 8.1.3 TEST SETUP 66 8.1.4 EUT OPERATION CONDITIONS 66 8.1.5 EUT TEST CONDITIONS 66 8.1.6 TEST RESULTS 67 9 . PEAK OUTPUT POWER TEST 71 9.1 APPLIED PROCEDURES / LIMIT 71 9.1.1 TEST PROCEDURE 71 9.1.2 DEVIATION FROM STANDARD 71 9.1.3 TEST SETUP 71 9.1.4 EUT OPERATION CONDITIONS 71 9.1.5 EUT TEST CONDITIONS 71 9.1.6 TEST RESULTS 72 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 76 10.1 APPLIED PROCEDURES / LIMIT 76 10.1.1 TEST PROCEDURE 76 10.1.2 DEVIATION FROM STANDARD 76 10.1.3 TEST SETUP 76 10.1.4 EUT OPERATION CONDITIONS 76 10.1.5 EUT TEST CONDITIONS 76 10.1.6 TEST RESULTS 77 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 5 of 92 Table of Contents Page 11 . MEASUREMENT INSTRUMENTS LIST AND SETTING 87 12 . EUT TEST PHOTO 89 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 6 of 92 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1402C182 Original Issue. Mar. 19, 2014 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 7 of 92 1. CERTIFICATION Equipment : FULL SIZE BLUETOOTH SPEAKER Brand Name : AmazonBasics Model Name : BTV3 Applicant Guoguang Electric Co.,Ltd. Manufacturer : Amazon.com, Inc. Address : 410 Terry Ave N Seattle, WA 98109 Factory : Guoguang Electric Co.,Ltd. Address : No.8 Jinghu Road, Xinhua Street, Huadu Reg, Guangzhou, China Date of Test : Mar. 04, 2014 ~ Mar. 17, 2014 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C : 2012 (15.247) / ANSI C63.4 : 2009 / FCC Public Notice DA 00-705, March 30, 2000. The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1402C182) were o…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 89 of 92 12. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 90 of 92 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 91 of 92 Radiated Measurement Photos 30~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1402C182 Page 92 of 92 Radiated Measurement Photos Above 1000MHz
