AEPJS3 Bluetooth ® Speaker with Magnet and Hook – Instructions SPANISH - Bluetooth ® Speaker with Magnet and Hook – Instructions FRENCH - Bluetooth ® Speaker with Magnet and Hook – Instructions ESPAÑOL FRANÇAIS ENGLISH 1390371 Rev 06/20 A Klein Tools AEPJS3 is a powered speaker designed to provide high-quality sound for smart phones, tablets, computers, or other audio devices. The AEPJS3 will also charge common mobile devices like cell phones, tablets, headphones, and other smaller USB devices. CONTENTS • AEPJS3 Bluetooth ® Speaker • 39.4" (1 m) USB Type C • 23.6" (600 mm) 1/8" (3.5 mm) Auxiliary Cable • Instruction Sheet GENERAL SPECIFICATIONS • Dimensions: 5.46" x 5.37" x 2.33" (138.6 x 136.4 x 59.2 mm) • Weight:1.14 oz. (520 g) • Wireless Compatibility:Devices with Bluetooth ® Version 4.2 • Wireless Connection Range: 100 ft. (30 m) in open space • Support Profi les: AD2P, AVRCP, HFP, SPP • Output Power: 15W • Battery Type: Internal, Li-Ion, 3.63V / 5200mAh • Battery Life: Approx. 20 hours at 70% volume • Charging Requirements: Maximum 5V DC, Minimum 1A • Certifi cations: CE, FCC, IC, & BC, NOM • Operating/Charging Temperature: 32° to 104°F (0° to 40°C) • Storage Temperature: -22° to 140°F (-30° to 60°C) • Relative Humidity: <85% non-condensing • Drop Protection: 6.6' (2 m) • Ingress Protection (IP) Rating: IP54 Specifications subject to change. WARNINGS Read, understand, and follow these instructions to ensure safe operation. Failure to observe these warnings can result in risk of fire or electric shock. • Keep these instructions for future reference. • No user-serviceable parts inside. Do not open enclosure or attempt to repair this speaker. • Never lubricate any part of this speaker. • Never place this speaker on other electrical equipment. • Do not expose to direct sunlight, open flame, heat sources, equipment that produces heat, or extremes in environmental temperature. • Never immerse in water or other liquids. Avoid spilling liquids or falling foreign objects into openings or vents on the speaker enclosure. • Water-resistant cover must be properly sealed to achieve specified water & foreign object ingress protection. Keep seal free of dirt, oil, sand, or other material that interferes with proper sealing. Failure to do so can result in risk of fire or electric shock. • Do not open water-resistant cover if wet or in a wet environment. Dry the speaker thoroughly and the seal around water-resistant cover completely before opening water-resistant cover. • When speaker is in use or charging, make sure there is adequate space to allow ventilation of internally generated heat. • Use safety-rated power supply or wall adapter. Never use power supply or wall adapter that exceeds the specified charging voltage and current. • Route the power supply cable so that it will not to be stepped on or pinched by other objects. SYMBOLS ON PRODUCT Warning or Caution Strong Magnetic Field Risk of Electrical Shock Read Manual Conforms with particular Code of Federal regulations BC Meets CEC and DOE energy effi ciency requirements Canada Energy Effi ciency Verifi ed This product has been independently tested by Intertek and meets applicable published standards NOM-NYCE – IFETEL WEEE – Battery disposal Conformité Européenne: Conforms with European Economic Area directives FEATURE DETAILS (FIG.A) 1 Power Button 10 Battery Status Indicator 2 Skip Backward Button 11 Daisy Chain LED Indicator 3 Play/Pause/Talk Button 12 Nail Hook 4 Skip Forward Button 13 Magnets (×2) 5 Daisy Chain Button 14 Auxiliary “Aux In” Jack 6 “-“ Volume Down Button 15 USB A Charge Out Port 7 “+” Volume Up Button 16 USB C Charge In/Out Port 8 Voice Control Button 17 Water/Dust-Resistant Cover 9 Bluetooth LED Indicator MAINTENANCE CLEANING: Be sure speaker is turned off and wipe with a clean, dry lint- free cloth. Do not use abrasive cleaners or solvents. STORAGE: If the speaker is to be left unused for an extended period of time, charge before storing, and recharge periodically during storage, to maintain battery's charging capacity. OPERATING INSTRUCTIONS CHARGING BATTERY Fully charge speaker before use. First-time charge should be at least 4 hours. Connect the USB Type C cable connection to USB charging port 6 ; plug the other end of cable to computer or USB AC adapter or other USB power supply (not included). USB adapter/power supply should not exceed the specified charging voltage and current (Max. 5V DC, min. 1A). Normal charging time is 3.25 to 4.25 hours. The battery level indicator will illuminate to indicate charging status (see tables below). CHARGING STATUS LED INDICATORS Cascading Not IlluminatedSolid YellowSolid GreenSolid RedBlinking LED Status% Charged Not illuminated Not illuminated Not illuminated Blinking red 0% to 24% charged Not illuminated Not illuminated Cascading Yellow Cascading red 25% to 49% charged Not illuminated Cascading Green Cascading Yellow Cascading red 50% to 74% charged Cascading Green Cascading Green Cascading Yellow Cascading red 75% to 99% charged Solid Green Solid Green Solid Yellow Solid red 100% charged ON/OFF: Press & hold power button 1 for 3 seconds, a tone will sound. Unit will automatically power off after 20 minutes of inactivity. NOTE: Turn unit off when not in use to prolong battery life. PAIRING: Wireless connection activates automatically and is ready to pair when unit is turned on. On your Bluetooth ® wireless compatible device, enable Bluetooth ® and search/scan for devices that can be paired. Select “AEPJS3” when it appears (refer to the user manual of your device). If necessary, enter “0000” as pairing passcode. A tone sounds after a successful pairing. NOTE: Unit automatically attempts to connect the last paired wireless device device but is ready to pair with any compatible device if the last paired device is not detected within 5 seconds of powering on. DISCONNECT PAIRING: 1) Turn unit off; -or 2) Double-press Power Button 1 . Bluetooth LED Indicator 9 will blink; -or 3) Plug a…
