241 EcoBoulder Waterproof Outdoor Speaker User Guide Model: GDI-EXBDR310 2 IMPORTANT SAFETY INFORMATION WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) AS THERE ARE NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions – All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions – The safety and operating instructions should be retained for future reference. 3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow all instructions – All operating and use instructions should be followed. 5. This apparatus can be used in outdoor conditions after disconnected the AC Mains supply and closing the waterproof cap for the AC inlet. It must not be used in outdoor conditions when charging. Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a wet basement or near a swimming pool, and the like' 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Only use attachments/accessories specified by the manufacturer. 10. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 11. Do not install this equipment in a confined or building-in space such as a book case or similar unit, and remain a well ventilation conditions. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc. 12. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 15. The battery (battery or batteries of battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. AVIS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of non-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. 23 You should always 1.) Use the ECOXGEAR speaker in accordance with any music or noise rules and regulations. 2.) Properly seal the ECOXGEAR prior and after each use when in humid or water environments to avoid water damage to the internal components. Salt water / air is particularly corrosive. Always make sure that the gaskets are sealed when in a salt water environment and that the unit is properly rinsed off after use. 3.) Properly clean the ECOXGEAR and ensure the gaskets have no sand, dirt, or water on them prior to storage. 4.) Store your unit with all caps properly sealed to avoid long term internal moisture damage inside your unit. 5.) Completely dry and clean your ECOXGEAR prior to attempting to charge the unit. 6.) Return the ECOXGEAR to Grace Digital if you suspect water ingress into the unit or if the unit has experienced a severe impact that may have affected the integrity of the unit to take on water. You should never 1.) Never charge your ECOXGEAR if you suspect water has entered the device. Charging a device with water inside could be potentially hazardous and cause fire or a spark. 2.) Never use your ECOXGEAR if you have dropped it or thrown it against a hard surface which may have destroyed the integrity of the speaker, housing, or gaskets. In the event of a severe impact to your unit, please return the unit to Grace Digital to review for potential damage. 3.) Never open the auxiliary doors in a water environment. This could cause water to ingress into the unit which could potentially be hazardous and cause a fire or a spark. 4.) Never connect a device to the auxiliary input jacks when in a water environment. The auxiliary jacks should only be used in a dry environment. 5.) Never attempt to fix, repair your ECOXGEAR unit. Please send it back to Grace Digital for any assessments and repairs. CARE, MAINTENANCE & PRECAUTIONS: 1.) The unit is waterproof only when the caps and door are properly closed. 2.) Close the caps and door properly before use. If the unit is placed in water without the caps or door properly closed, water may enter into the unit and void your warranty. 3.) Dry unit completely before opening the caps or door. Do NOT open the caps or door if wet or in a wet environment. 4.) Do NOT apply excessive force to any surfaces of the unit when wet or in a wet environment. 5.) Do NOT use or store the unit in places with high temperature. 6.) AVOID prolonged exposure to ultraviolet radiation (UV sunlight) and strong magnetic fields. 7.) Periodically check the rubber seal on the caps and door for premature wear. 8.) Periodically clean the rubber with a soft moist cloth and ensure no objects such as dirt, hair, sand are on the rubber seal ring. Do NOT use any oily solvent or chemicals for cleaning. 9.) Rinse off the unit with tap water after use in salt water or swimming pool. 10.) Power and / or charge the built-in rechargeable battery for portable use by connecting the AC cord to an AC outlet. 11.) Noise and audio distortion may occur when the batteries are nearing end of charge. 12.) Do NOT remove the built-in…

Text truncated - open the document above for the full version.

Grace Digital Inc.10531 4S Commons Drive#166 Suite#430,San Diego,CA 92127,USA Office (858) 748-6343 Fax (858) 408-3336 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/06/19 Subject; Request for Confidentiality FCC ID: 2AAUI-GDIEXBDR310 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Na me: Jamie Florczak Grace Digital Inc.10531 4S Commons Drive#166 Suite#430,San Diego,CA 92127,USA Office (858) 748-6343 Fax (858) 408-3336 Title: Manager Email: [email protected]

Grace Digital Inc.10531 4S Commons Drive#166 Suite#430,San Diego,CA 92127,USA Office (858) 748-6343 Fax (858) 408-3336 Letter of Authorization Company: Grace Dig ital Inc. Address: Grace Digital Inc.10531 4S Commons Drive#166 Suite#430,San Diego,CA 9 2127,USA Product Name: EcoBoulder Max Model Number: GDI-EXBDR310 FCC Identifier: 2AAUI-GDIEXBDR310 We autho rize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named eq uipment. Any in dividual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Bou lder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Co mmunication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Jamie Florczak Date: Jun. 19.2020 Title: Manager Signature of applicant:

Grace Digital Inc.10531 4S Commons Drive#166 Suite#430,San Diego,CA 92127,USA Office (858) 748‐6343 Fax (858) 408‐3336 Date: Jun 19, 2020 FCC ID: 2AAUI-GDIEXBDR310 Model Number: GDI-EXBDR310 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Grace Digital Inc. declare that this EUT (FCC ID: 2AAUI-GDIEXBDR310) will conduct FCC compliance testing, the SDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.( ShenZhen Lab.). 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen 518126 P.R. China) Please contact me if you have any question. Sincerely, Name / Title: Jamie Florczak/ Manager Company: Grace Digital Inc. Address: Grace Digital Inc.10531 4S Commons Drive#166 Suite#430,San Diego,CA 92127,USA

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Induction coil Photo 3 Photo 4 Photo 5 Photo 6 BT ANT Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17

FCC ID: 2AAUI-GDIEXBDR310 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method E (V/m) ＝ d GP**30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 *377 **30 D GP From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Measurement Result Operation Frequency: BT: 2402-2480MHz Power density limited: 1mW/ cm 2 Antenna Type: PCB antenna Antenna gain: 0dBi, R=20cm Conclusion: For the max result : 0.0013≤ 1.0 for Max Power Density, compliance RF exposure.. Signature: Date: 2020-06-19 NAME AND TITLE (Please print or type): Alex li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China. conducted pow er Evaluation result Pow er density Limits (dBm)(mW)(dBi)Numeric 2402 3.7563±142.5120.001.000.00051 2440 3.6043±142.5120.001.000.00051 2480 3.7843±142.5120.001.000.00051 24024.218 4±153.1620.001.000.00061 24413.931 4±153.1620.001.000.00061 24803.675 4±153.1620.001.000.00061 24026.5696±17 5.0120.001.000.00101 24416.413 6±175.0120.001.000.00101 24806.006 6±175.0120.001.000.00101 24027.193 7±186.3100.001.000.00131 24416.948 7±186.3100.001.000.00131 24806.678 7±186.3100.001.000.00131 π/4-DQPSK (mW/cm2 ) GFSK 8-DPSK Channel Freq. (MHz) modulation Tune-up pow er (dBm) (dBm) BLE-GFSK (mW/cm2) Antenna Gain Max tune-up pow er

Report No.: S20031400605002 Version.1.3 Page 1 of 46 RADIO TEST REPORT FCC ID: 2AAUI-GDIEXBDR310 Product: EcoBoulder Max Trade Mark: ECOXGEAR Model No.: GDI-EXBDR310 Family Model: N/A Report No.: S20031400605002 Issue Date: 01 Jun. 2020 Prepared for Grace Digital Inc. Grace Digital Inc.10531 4S Commons Drive#166 Suite#430，San Diego,CA 92127,USA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel.: +86-755-6115 6588 Fax.: +86-755-6115 6599 Website:http://www.ntek.org.cn Report No.: S20031400605002 Version.1.3 Page 2 of 46 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 4 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 3.1 FACILITIES..................................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 5 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................... 9 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................................... 9 6.2 SUPPORT EQUIPMENT ............................................................................................................................... 10 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 11 7 TEST REQUIREMENTS .................................................................................................................................... 13 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 13 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 16 7.3 6DB BANDWIDTH ....................................................................................................................................... 25 7.4 DUTY CYCLE ............................................................................................................................................... 26 7.5 PEAK OUTPUT POWER .............................................................................................................................. 28 7.6 POWER SPECTRAL DENSITY ................................................................................................................... 29 7.7 CONDUCTED BAND EDGE MEASUREMENT......................................................................................... 31 7.8 SPURIOUS RF CONDUCTED EMISSIONS ................................................................................................ 32 7.9 ANTENNA APPLICATION .......................................................................................................................... 33 8 TEST RESULTS ................................................................................................................................................... 34 8.1 MAXIMUM CONDUCTED OUTPUT POWER ....................................................................................................... 34 8.2 OCCUPIED CHANNEL BANDWIDTH .................................................................................................................. 36 8.3 MAXIMUM POWER SPECTRAL DENSITY LEVEL ............................................................................................... 40 8.4 BAND EDGE .................................................................................................................................................... 42 8.5 CONDUCTED RF SPURIOUS EMISSION ............................................................................................................. 44 Report No.: S20031400605002 Version.1.3 Page 3 of 46 1 TEST RESULT CERTIFICATION Applicant’s name ......................... : Grace Digital Inc. Address ....................................... : Grace Digital Inc.10531 4S Commons Drive#166 Suite#430，San Diego,CA 92127,USA Manufacturer's Name .................. : Xingtel Xiamen Group Co., Ltd. Address ....................................... : Xingtel Building,Chuangxin Road, Torch Hi-Tech Industrial District,Xiamen 361006, PR China Product description Product name .............................. : EcoBoulder Max Model and/or type reference ..... : GDI-EXBDR310 Family Model ............................... : N/A Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without th…
