2AAZ4B07-BTSuper bass outdoor bluetooth speaker

Super bass outdoor bluetooth speaker B07-BT user manual 1、Safety Warning and Transportation Safety Safety Warning ●For correct and safe use, please read the safety warning carefully and follow all the instruction . ●When forbidden using wireless device or device use would interrupt electronic device and safety potential , please turn off the power supply . ● In flammable and explosive area, please turn off the power supply, and follow the related instruction, so as not to cause explosion or fire. Flammable and explosive area include but not limited in: gas station, fuel section (like: capsule under the ship deck), flammable or heavy chemicals transport and store device, with explosive danger mark area, area with the mark of "turn off the two-way wireless electronic device" Transportation Safety ●When flying on plane , please follow the rule of airline. Turn off the power supply before the taking off of plane, to avoid the potential risk。 Notes It will heat slightly when charging or in normal operation, that's normal phenomenon. Please turn off the switch of power supply when cleaning the overall unit, and cut off the outer connect. ●Please take good care of the overall unit and its accessories ,and try to use in tidy environment. Don't let overall unit and its accessories to contact fire or lighting butt etc. ●Try to keep the product and its accessories dry. Don't contact water or moisture. ●Please don't fall off, throw or tread. ●Please don't use antistatic soft cloth to clean the overall unit. Don't use chemicals (like alcohol, benzene etc) chemical washing or frosted cleaning detergent. ●Please don't put the overall unit and its accessories to too cold or too hot area. ●Please use our company's authorized accessories . ●Please don't tear down the overall unit, or you could not have the free guarantee service of our company. 1. Buttons and interface description 2. Bluetooth phone call button, status indicator light 3. Micro SD card port 4. Volume selection, power switch 5. Micro usb port, charge port, line in port 6. Charge indicator light 1. system connection figure 2. Play music on the Bluetooth device 3. Noted: the effective working range between the Bluetooth and B07-BT is about 10 meters (30 feet) 4. Slide switch ④ to select the Bluetooth audio source, and then the blue status indicator light flashes. 5. Turn on Bluetooth on the device. 6. Select B07-BT on the device to pair, when the speaker has “bi” sound and the blue status indicator light growly flashes, which means the pairing is successful and it is on the status of standby. For some devices, you have to enter "0000" as the pin code. 7. Play music on the Bluetooth device. 5、Using B07-BT Dialing When calls: ●Press the Bluetooth button to answer the phone ●The direction light shines every second in calls ●Redial the bluetooth button to hang off ※You could speak directly to the Microphone, to get the best call effect ! ● In calls press the button of " Speaking key" twice to transfer to mobile to answer . Voice dial direction After matching successfully, press twice of the "speaking key" to start the voice dial function of IPHONE, could dial calls, play music. Call back the last call: On standby, press the "speaking key" for about 2 seconds, then could call the final call in our mobile phone! 6、Connect the external device player 1、Slip switch④ to AUX to choose the voice source of AUX in . The direction light turns to red. 2、Play music on your devise, B07-BT could magnify your public address 7. Technical Specifications (Note: If the Product Information changes, will inform) Product Size: Width: 1.25cm; Height: 3.55cm Weight: 0.15kg Compability: Most Bluetooth Smartphone , Sound Equipment iPad, iPad1, iPad2, iPad3, iPad4, ipad mini; Accessories: Cable used for: 35mm message input and USB charging 8、Common malfunction and exclusion No power on ●Low battery , please charge for your product. No sound ●Adjust the volume of mobile phone or Personal Computer. ●Make sure your Bluetooth Terminal are in effective Receiving Range . ●Check whether the switch is at the right tap position of sound source . Accessory B07-BT speaker, Micro usb cable, warranty card, Certificate of Approval FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

Shenzhen Gaciron Technology Co.,Ltd. Rm 3B999,7Bld,Baoan Internet Industrial Base,Baoyuan Road,Baoan,Shenzhen, China To: SIEMIC, INC. 775 Montague Expressway. Milpitas, CA 95035, USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We , Shenzhen Gaciron Technology Co.,Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Super bass outdoor bluetooth speaker model name: B07-BT, BT-M, BT-FM, BT-W, BT-S, B05, B07, B09, BT-H FCC ID: 2AAZ4B07-BT We affirm that between SIEMIC and Shenzhen Gaciron Technology Co.,Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: name / title : Wang MS/Engineer information / address: Shenzhen Gaciron Technology Co.,Ltd. (Rm 3B999,7Bld,Baoan Internet Industrial Base,Baoyuan Road,Baoan,Shenzhen China)

Shenzhen Gaciron Technology Co.,Ltd. Rm 3B999,7Bld,Baoan Internet Industrial Base,Baoyuan Road,Baoan,Shenzhen, China SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 3.0 Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAZ4B07-BT Product: Super bass outdoor bluetooth speaker Model No.: B07-BT, BT-M, BT-FM, BT-W, BT-S, B05, B07, B09, BT-H We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title : Wang MS/Engineer information / address: Shenzhen Gaciron Technology Co.,Ltd. (Rm 3B999,7Bld,Baoan Internet Industrial Base,Baoyuan Road,Baoan,Shenzhen China)

Updated on 2005/02/07 by Kally Chan DECLARATION OF IDENTITY Hereby we: Shenzhen Gaciron Technology Co.,Ltd. (Name of Manufacturer) Basic Model Number: B07-BT, Basic Brand Name: / Basic Product Name: Super bass outdoor bluetooth speaker Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): BT-M, BT-FM, BT-W, BT-S, B05, B07, B09, BT-H New / Additional Brand Name(s): / Except the following(s) : Model numbers，outlook color Signature with Company Chop : Printed Name : Wang MS DATE:2013-08-27

Label Size:20*13mm(L*W) Label Location Model No.: B07-BT FCC ID: 2AAZ4B07-BT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Antenna Location

FCC ID: 2AAZ4B07-BT Keyway Testing Technology Co., Ltd. Report No. 13KWE88591F Page 1 of 26 FCC TEST REPORT for Shenzhen Gaciron Technology Co.,Ltd. Super bass outdoor bluetooth speaker Model Number: B07-BT, BT-M, BT-FM, BT-W, BT-S, B05, B07, B09, BT-H FCC ID: 2AAZ4B07-BT Prepared for : Shenzhen Gaciron Technology Co.,Ltd. Address : Rm 3B999, 7Bld, Baoan Internet Industrial Base, Baoyuan Road, Baoan, Shenzhen, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 13KWE088591F Date of Test : Aug. 25~28, 2013 Date of Report : Aug. 29,2013 FCC ID: 2AAZ4B07-BT Keyway Testing Technology Co., Ltd. Report No. 13KWE88591F Page 2 of 26 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .............................................................................................................4 2. GENERAL PRODUCT INFORMATION ............................................................................5 2.1. Product Function.................................................................................................................... 5 2.2. Description of Device (EUT) .................................................................................................. 5 2.3. Independent Operation Modes .............................................................................................. 5 2.4. Difference between Model Numbers...................................................................................... 5 2.5. Test Supporting System......................................................................................................... 5 2.6. Test Facilities ......................................................................................................................... 5 2.7. List of Test and Measurement Instruments............................................................................ 6 3. TEST SET-UP AND OPERATION MODES......................................................................7 3.1. Principle of Configuration Selection ....................................................................................... 7 3.2. Block Diagram of Test Set-up ................................................................................................ 7 3.3. Test Operation Mode and Test Software ............................................................................... 7 3.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance.................................................................... 7 4. EMISSION TEST RESULTS.............................................................................................8 4.1. Radiated Emission Test .........................................................................................................8 5. 20DB OCCUPY BANDWIDTH ........................................................................................18 5.1. Limits.................................................................................................................................... 18 5.2. Test setup ............................................................................................................................ 18 6. BAND EDGE COMPLIANCE TEST ................................................................................21 6.1. Limits.................................................................................................................................... 21 6.2. Test setup ............................................................................................................................ 21 6.3. Conducted Emission at the Mains Terminals Test............................................................... 22 7. ANTENNA REQUIREMENT: ..........................................................................................25 8. PHOTOGRAPHS OF TEST SET-UP..............................................................................26 9. PHOTOGRAPHS OF THE EUT......................................................................................26 FCC ID: 2AAZ4B07-BT Keyway Testing Technology Co., Ltd. Report No. 13KWE88591F Page 3 of 26 Keyway Testing Technology Co., Ltd. Applicant: Address: Shenzhen Gaciron Technology Co.,Ltd. Rm 3B999, 7Bld, Baoan Internet Industrial Base, Baoyuan Road, Baoan, Shenzhen, China Manufacturer: Address: Shenzhen Gaciron Technology Co.,Ltd. Rm 3B999, 7Bld, Baoan Internet Industrial Base, Baoyuan Road, Baoan, Shenzhen, China E.U.T: Super bass outdoor bluetooth speaker Model Number: B07-BT, BT-M, BT-FM, BT-W, BT-S, B05, B07, B09, BT-H Trade Name: ------ Serial No.: ------ Date of Receipt: Aug. 25, 2013 Date of Test: Aug. 25~28, 2013 Test Specification: FCC Part 15, Subpart C: Oct. 1, 2012 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Aug. 29, 2013 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2AAZ4B07-BT Keyway Testing Technology Co., Ltd. Report No. 13KWE88591F Page 4 of 26 1. TEST SUMMARY Test Items Test Requirement Uncertainty Result Conducted Emissions 15.207 ANSI C63.4 ±2.6dB PASS Radiated Emissions 15.209 15.249 ANSI C63.4 ±3.6dB PASS 20dB Bandwidth 15.249 ANSI C63.4 ±1kHz PASS Band Edge Compliance Test 15.249 ANSI C63.4 ±3.6dB PASS Antenna Requirement 15.203 ANSI C63.4 / PASS Note：N/A means not applicable. FCC ID: 2AAZ4B07-BT Keyway Testing Technology Co., Ltd. Repor…

Text truncated - open the document above for the full version.

Set-up for Conducted Emission at the Mains Terminals Test Set-up for Radiated Emission Test
