2AB22-ESF14Smart Fitness Scale

Smart Fitness Scale Model: ESF14 User Manual Questions or Concerns? Mon–Fri, 9:00 am–5:00 pm PST/PDT [email protected] • (855) 686-3835 Kgstlb 2 Table of Contents Package Contents Specifications Safety Information Function Diagram Digital Display VeSync App Setup Before First Use Using the Smart Scale Maintenance • Calibrating the Smart Scale • Cleaning the Smart Scale • Replacing the Batteries Display Messages Troubleshooting FCC Statement Warranty Information Customer Support 3 3 4 6 7 8 9 10 11 11 11 12 13 14 16 17 19 3 Package Contents Specifications 1 x Smart Fitness Scale 3 x 1.5V AAA Batteries (Pre-Installed) 1 x Quick Start Guide 1 x Measuring Tape Weight Capacity400 lb / 28 st / 180 kg Increments0.1 lb / 0.05 kg Weight Unitslb / st / kg PlatformTempered glass Dimensions11 x 11 x 1 in / 28 x 28 x 2.5 cm Battery Type3 x 1.5V AAA batteries Auto-Off30 seconds 4 Please read and follow all instructions and safety guidelines in this manual. Safety Information Medical General Use • This scale should not be used to diagnose or treat any medical condition. • Scale data should not be used as a substitute for medical advice from a healthcare professional. • This scale uses a harmless electrical current to measure body fat. Consult a healthcare professional before using the smart scale if you use medical electronic equipment such as a pacemaker. • Check the scale before using. Do not use the scale if it is damaged in any way. • Do not strike or hit the scale. Do not use the scale if the glass is cracked or broken. Due to the nature of tempered glass, the glass will shatter if there is even a slight crack. If you see a crack, contact Customer Support immediately (page 19). • The glass platform is slippery when wet. Always make sure the platform and your feet are dry before stepping on for measurement. • Place the scale on a hard, flat surface to avoid tipping. • To weigh safely and accurately, stand with your feet shoulder-width apart while on the scale. Do not stand on the edge of the scale or jump on the scale. • Avoid standing on the scale for a long period of time, or when not weighing yourself. • Do not overload the scale. Maximum weight capacity is 400 lb / 28 st / 180 kg. • Keep the scale in a cool area with low humidity. Keep the scale away from heat sources, such as ovens or heaters. Avoid temperature fluctuations. Store the scale in a horizontal position, not a vertical position. • Handle with care. • Not for commercial use. Household use only. 5 Batteries • Do not mix new and old batteries. • If the low battery indicator “ “ appears on the display, replace the batteries. • If the scale is not in use for a long period of time, remove the batteries to extend the lifetime of the scale. SAVE THESE INSTRUCTIONS 6 Kgstlb Function Diagram A. Display B. Weighing Platform C. Anti-Skid Padding D. Battery Compartment A B C D 7 Kgstlb Digital Display A. Weight Measurement B. Wireless Connection Icon C. Weight Units B C A 8 VeSync App Setup Note: Due to app updates and improvements, the contents of this manual may change without notice. The VeSync app user interface may appear slightly different. 1. To download the VeSync app, scan the QR code or search “VeSync” in the Apple App Store ® or Google Play Store. 2. Open the VeSync app. If you already have an account, tap Log In. To create a new account, tap Sign Up. 3. Make sure your phone has Bluetooth ® turned on. 4. Follow the in-app instructions to add your smart scale. Note: • This smart scale uses the VeSync app, not the VeSyncFit app. • For Android™ users, you may need to select “Allow” to use VeSync. 9 Before First Use 1. Open the battery compartment on the underside of the scale. Remove the included AAA batteries. 2. Remove the plastic insulator strip from the battery compartment. 3. Replace the batteries (see Replacing the Batteries, page 12). Follow the guidelines in the battery compartment to match the + and – terminals. Creating a User If you are a new user, you will need to enter physical information before weighing yourself for the first time so the scale can calculate your body metrics. Follow the in-app instructions to add a user. Note: • Entering inaccurate information will make the scale’s measurements less accurate. • If you don’t identify with the available gender options, or are unsure, pick the choice that you think best physically matches you. This choice is used for physical measurements, such as body fat percentages. 10 Using the Smart Scale 1. Place the scale on a hard, flat surface. [Figure 1.1] 2. Make sure your feet are dry. Place bare feet on the scale’s conductive areas. The scale will automatically turn on and start measuring your weight. 3. Continue standing on the scale until the digits on the screen flash 3 times, showing your final measurement. If you’ve set up your smart scale in the VeSync app, additional results (such as BMI, body fat, etc) will show on the app. [Figure 1.2] Note: • To switch between pounds (lb), stone (st), and kilograms (kg), select the weight unit in the Device Settings menu in the VeSync app. • If you are pregnant, scale measurements will not be accurate. Figure 1.1 Figure 1.2 11 Maintenance Calibrating the Smart Scale Cleaning the Smart Scale If the scale has been moved or flipped upside down, it must be calibrated to ensure accurate results. 1. Place the scale on a hard, flat surface. 2. Step on the scale with 1 foot until digits appear on the display. [Figure 2.1] Then, step off. 3. The scale will show “ ” while calibrating, then “ ” when complete. [Figure 2.2] • Use a slightly damp cloth to clean the surface of the scale, followed by a soft, dry cloth to wipe away any remaining moisture. • Do not use chemical or abrasive cleaning agents to clean the scale. Figure 2.1Figure 2.2 12 Replacing the Batteries The display will show “ ” when the batteries need to be replaced. 1. Open the battery compartment on the underside of the scale. 2. Remove the old batteries and dispose of them prop…

Text truncated - open the document above for the full version.
