2AB26S-10CControl Unit

02 Index Installation General Guidance Bikey system Wi ring Configuration User Guide Operation Warranty ------------------------------ ------------------------------ ------------------------------ ------------------------------ ------------------------------ 03 05 06 10 12 03 Installation ; General Guidance - Installation is all about planning, gathering information, and careful execution. - You will need to learn how to test the polarity of a wire using a digital multi meter. - Yo u will need your basic tools to remove some vehicle panels to access the vehicle wiri ng. ATTENTION Commercial Electronics always suggests installation be performed by a certified and trained installation technician, professional installation is requirement to obtain f ull warranty. This wiring information is being provided free of charge and on an "as i s" basis, without any representation or warranty to the products being installed. It is your responsibility to insure proper installation. Commercial Electronics assumes no responsibility with regards to the accuracy or c urrency of this information. Proper installation in every case is and remains the re sponsibility of the installer. Commercial Electronics assumes no responsibility re sulting from an improper installation, even in reliance upon this information. Any h arm or injury to the installer is in no way the responsibility of Commercial Electronics. Any damage to the vehicle during installation or after installation is not the responsibility of Commercial Electronics. You will need to inspect your vehicle to be sure of a few things previous to be ginning the installation process. Check your vehicle and identify which tools are needed to remove the necessary panels. You will once again refer to your ve hicle wiring diagram to find the locations of the wires where the panels will be removed. Once done, you are ready to begin the installation. Once you identify which items you will install along with the warning, eliminate the wire s to prevent clutter. It is common practice to twist the wires of a same plug tog ether then secure them to each other with electrical tape. Do not wrap the ent ire bundle, as different wires go to different locations. Once you finish wra pping all the harness tape them to each other to create one large pigtail co ntaining all of the used wires. Th is keeps the wires together, secure and free from frays and obstruction. You will now want the identify the locations of the wires which you will connect to on yo ur bike. Take your harness of wires on the warning which you just org anized together, and split it down once more into vehicle locations. Group wire s into three different groupings, for example dash, rear and engine wires, or use yo ur own grouping procedure. Tape these wires together in their bundles to create individual wiring bundles. Preparing the Wiring Checking the Bike 04 Installation ; General Guidance When installing any electrical component into a vehicle, you will have 3 polarities which you may need to test for. There are positive, negative and reverse polarity configurations which you must know how to rest for. Testing Wires Ignition Wires ; 12Volts with key in all positions except for 'off' Testing an ignition wire is simple. Ignition wires are generally positive in polarity. Start by setting your meter to DC 12V. Next, take your black lead and put it to chassis ground(-). Next, connect the red lead to what you believe to be the ignition wire in the vehicle. It should show 0 Volts when the key is off. Next, cyc le the key through the Accessary and Ignition position. It should show 12Vo lts in both positions. Next, crank and run the vehicle. It should show power eve n while cranking. If it does, it is an ignition wire. If not, please read "testing an acce ssary wire" below. Ignition Wires are used for motorcycles alarm and Starter Wires ; 12V only in crank position. Ch eck the value of the output terminal of the starter button. Testing a starter wire is very simple. Start by location the suspected wire in the vehicle. Next, take your meters black lead and connect it to ground. Next, connect the red lead to the wire you believe is the starter wire. If push the start button,(Crank the ve hicle). The meter should Only show 12V when the key is in the crank po sition. There should be 0 volts in all other positions. Starter wires are used in Re mote Car Starter Installations. Us ing the above testing guidelines, you can test any wire. When testing an acce ssary like a horn or dome light in the vehicle, simply activate the accessary with yo ur meter leads in place to get the meter reading. The meter should only re ad power and ground on accessary items when they are activated. ACG Wires ; ACG , is connected through a gear or directly coupled to the crankshaft. Ch eck the connector connected to the ACG, cables from the control unit to dete rmine the connectable position. The criteria and method of measurement is various depending on the model and manufact urer. Specific Testing Applications 05 Installation ; Bikey system The control unit should be located in a protected environment with good access to the motorcycle wiring loom. Avoid extremes of heat i.e. exhaust engine and direct exposure to the elements, and make sure that the unit does not interfere with norm al operation of motorcycle. Suggested locations under the seat or be hind the seat are usually the best locations. The control wiring must point dow n to avoid any water ingress. Installed within 1m from the seat. To be careful not install the metal surface or metal shield space. To be installed to avoid the place that get wet with water. If the battery in the FOB (remote transmitter) is discharged, the emergence start -up is needed. The antenna is installed in a location that can be in contact to FOB ! Mark put the antenna location, easy to find. LF-Antenna Location of main system components - Control unit - FOB (Remote Transmitter) - LF-Ante nna - Harn es…

Text truncated - open the document above for the full version.

Control Unit S-10C 2014-03-25 To whom it may concern: We the undersigned, hereby authorize EMCCert DR. RAŠEK GmbH to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by EMCCert DR. RAŠEK GmbH on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from PLATO CO., LTD. Sincerely, Deuk-Soo, Kim/ CTO PLATO CO., LTD.

Control Unit S-10C 2014-03-25 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. PLATO CO., LTD. would like the following documents regarding this submission for FCC ID: 2AB26S-10C to be kept confidential. 1. Schematics 2. Part List The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Deuk-Soo, Kim/ CTO PLATO CO., LTD.

Control Unit S-10C 2014-03-25 Pursuant to 47 CFR Part 0, section 0.459, we herewith submit a request for non-disclosure of the following exhibits, related to this application for FCC ID : 2AB26S-10C The contents of the exhibits as listed below under 1 may not be disclosed to any other party than company name and must be temporary with held from public inspection under 5 U.S.C552 (b)(4) and must be temporary kept confidential. 1. Internal Photo The short-term confidentiality is scheduled to terminate on 09. 30. 2014. The reason for this request for short-term confidentiality is that the information contained in the exhibits as listed above has been classified as being temporary company confidential (with reference to 47 CFR Part 0, section 0.457(d)). Disclosure of any portion of this information to other parties prior to the date of the actual marketing of the device would cause substantial competitive harm. I, as the applicant, understand and have taken notice of the following. (a) The maximum period for short-term confidentiality is 180 days, counting from the date of issue of the Grant (b) The applicant shall inform the TCB about the date on which the device will be actually marketed. Such a notification must be received by the TCB before the date of actual marketing. The short-term confidentiality will then terminate before or on the date of the actual marketing of the device. (c) If no request from the applicant is received by the TCB for releasing the short- term confidentiality, it will terminate automatically after 180 days, counting from the date of issue of the Grant Sincerely, Deuk-Soo, Kim/ CTO PLATO CO., LTD.

CUSTOMER STF COMPANY CUSTOMER CODE PART DESCRIPTION 3D COIL 11x11LP X, Y, Z: 4.7, 4.7, 6.8mH. isotropic@134 kHz DATE EDITION DOCUMENT NAME INTERNAL CODE X-D0725-0003 14/05/2008 2 E07250003_2.doc PAGE 1/8 C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain) Phone +34 951 231 320 Fax +34 951 231 321 E-mail: [email protected] Web http://www.grupopremo.com NOTES Critical characteristics marked with (*) All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation. 3DCOIL 11x11 Low Profile 11.6/13/3 mm. 4.7 mH, 4.7 mH, 6.8 mH @134 kHz CUSTOMER STF COMPANY CUSTOMER CODE PART DESCRIPTION 3D COIL 11x11LP X, Y, Z: 4.7, 4.7, 6.8mH. isotropic@134 kHz DATE EDITION DOCUMENT NAME INTERNAL CODE X-D0725-0003 14/05/2008 2 E07250003_2.doc PAGE 2/8 C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain) Phone +34 951 231 320 Fax +34 951 231 321 E-mail: [email protected] Web http://www.grupopremo.com NOTES Critical characteristics marked with (*) All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation. 1.- DIMENSIONS AND PINS CONFIGURATION All dimensios are in mm. 4 1 2-3 Wz 8 Wy Wx 5 6-7 CUSTOMER STF COMPANY CUSTOMER CODE PART DESCRIPTION 3D COIL 11x11LP X, Y, Z: 4.7, 4.7, 6.8mH. isotropic@134 kHz DATE EDITION DOCUMENT NAME INTERNAL CODE X-D0725-0003 14/05/2008 2 E07250003_2.doc PAGE 3/8 C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain) Phone +34 951 231 320 Fax +34 951 231 321 E-mail: [email protected] Web http://www.grupopremo.com NOTES Critical characteristics marked with (*) All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation. 2.- SOLDERING 2.1.- RECOMMENDED REFLOW PROFILE The reflow condition recommended above is according to the machine used by our company. Big differences will arise as a result of the type of machine, reflow conditions, method, etc used. 2.2.- RECOMMENDED PAD LAYOUT All dimensios are in mm. 0400 (sec) 100 200 300 ºC 140 180 275 210 max 360 sec preheating 60 - 120 sec cooling zone 100 190 200 280 300 360 90 sec 30 sec 2-4ºC/ sec CUSTOMER STF COMPANY CUSTOMER CODE PART DESCRIPTION 3D COIL 11x11LP X, Y, Z: 4.7, 4.7, 6.8mH. isotropic@134 kHz DATE EDITION DOCUMENT NAME INTERNAL CODE X-D0725-0003 14/05/2008 2 E07250003_2.doc PAGE 4/8 C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain) Phone +34 951 231 320 Fax +34 951 231 321 E-mail: [email protected] Web http://www.grupopremo.com NOTES Critical characteristics marked with (*) All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation. 3.- MATERIALS 3.1.- FERRITE CORE MATERIAL Initial permeability μ i : 1000 (at 25 ºC, <10 kHz) Tc ≥ 100 ºC. Bs: ≈320 mT (at 25ºC). 3.2.- SMD BASE (LEADFRAME) Plastic material: LCP E4008. Tinned terminals: 0.25 mm total thickness. Base material CuSn6 (Phosphor Bronze), 2-3 μm Cu 4-6 μm Sn100 (finish layer) 3.3.- WIRE Selfbonding wire with modified Polyurethane MSB180, isolation Grade 1B; norms IEC 317-35, IEC 317-2. Enamelled wire with modified Polyurethane P180, isolation Grade 1; norms IEC 317-20, MW79. Diameters : 0.048 mm and 0.060 mm. 3.4.- ADHESIVE to join ferrite to plastic base Epoxy based adhesive 3.5.- LABEL Acrylate material CUSTOMER STF COMPANY CUSTOMER CODE PART DESCRIPTION 3D COIL 11x11LP X, Y, Z: 4.7, 4.7, 6.8mH. isotropic@134 kHz DATE EDITION DOCUMENT NAME INTERNAL CODE X-D0725-0003 14/05/2008 2 E07250003_2.doc PAGE 5/8 C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain) Phone +34 951 231 320 Fax +34 951 231 321 E-mail: [email protected] Web http://www.grupopremo.com NOTES Critical characteristics marked with (*) All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation. 1 3 ± 0 . 5 5 0 M I N min 24.4 2± 0.5 330± 2 max 30.4 MATERIAL LIST ITEM MATERIAL Reel SHOCK-PROOF POLYSTYROL Carrier tape PC brown color antistatic 0.3 mm Cover tape POLYESTER with ANTISTATIC 4.- PACKAGING AND LABELLING 4.1.- TAPING SPECIFICATION (According to EIA481) 4.2.- REEL 4.3. TAPING PARTS PER REEL 7" 600 CUSTOMER STF COMPANY CUSTOMER CODE PART DESCRIPTION 3D COIL 11x11LP X, Y, Z: 4.7, 4.7, 6.8mH. isotropic@134 kHz DATE EDITION DOCUMENT NAME INTERNAL CODE X-D0725-0003 14/05/2008 2 E07250003_2.doc PAGE 6/8 C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain) Phone +34 951 231 320 Fax +34 951 231 321 E-mail: [email protected] Web http://www.grupopremo.com NOTES Critical characteristics marked with (*) All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation. 4.4. LABELLING The Labelling will be according to the following Figures: Label dimensions have to fully cover the top part of the Z winding: P-725-003 CUSTOMER STF COMPANY CUSTOMER CODE PART DESCRIPTION 3D COIL 11x11LP X, Y, Z: 4.7, 4.7, 6.8mH. isotropic@134 kHz DATE EDITION DOCUMENT NAME INTERNAL CODE X-D0725-0003 14/05/2008 2 E07250003_2.doc PAGE 7/8 C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain) Phone +34 951 231 320 Fax +34 951 231 321 E-mail: [email protected] Web http://www.grupopremo.com NOTES Critical characteristics marked with (*) All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation. 5.- ELECTRICAL CHARACTERISTICS OF THE PART X Winding Wire Φ Cu (mm) Number of turns in the winding @134 kHz, 1 Vac, 25 ºC 0.048 P180 416 typ L (mH) (*) Q (*) Rdc (Ω) SRF (kHz) @ 1Vac, 25 ºC 4.7 ± 5% > 18.5 85 ± 10% > 330 Sensitivity (mV rms /A rms /m) @ 125 …

Text truncated - open the document above for the full version.

1. 제품 개요The Bikey is smartkey system for motorcycle. It using the wirel ess authentication between FOB and Controller. When you engine start, you don't need key any more, If do you h ave FOB in your pocket, can start engine just push the start bu tton. Also, It is into auto arming state. So It can be protection fro m shock, tilt,try abnormal start by theft. 2. Function chartButton Operating function condition button/Operating status start normal FOB within 1.5m grib on brake, push the start buttonstart button Engine on after authentication start Emengency FOB battery discharge state,FOB within 3cm on ext antenna grib on brake, push the start buttonstart button Engine on after authentication with stop on motorcycle using stop button engine off without stop on motorcycle using start button engine off with side Kick off side stand engine off search(panic) range min 30m FOB short click winker/horn blink 2ti mes low battery warning FOB battery voltage low only warning when eng ine start winker/horn fast blink 2times abnormal start push the start button without FOB winker/horn blin k 3times shock shock,tilt detect winker/horn blink 20times,stop when input the search function stop (시동ON상태에서)warning on warning off abnormal start, shock, tilt not working warning funct ion warning ON/OFF set function condition button/조작 status Warning ON FOB within 30m, warning off state FOB long click over 2sec winker/horn blink 1time Warning OFF FOB within 30m, warning on state FOB long click over 2sec winker/horn blink 2times 3. Install & Exterior description State LEDRF transmitter displayFunction Button - Search/Panic : click - Warning set On/Off : Long click over 2sec FOB (S-10F)Controller ( S-10C)CableEXT_Antenna

IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 14-IST-0151 1 of 12 IST(02) 029 A4 모(101025) The test result only responds to the tested sample. This report shall not be reproduced except in full, without the allowance of the test laboratory. CERTIFICATION TEST REPORT FCC CFR47 PART 15 SUBPART C Test Report File No. 14-IST-0151 ■ Basic □ Alternate Date of Receipt Feburary 24, 2014 Begin of test date March 12, 2014 Date of Issue March 26, 2014 End of test date March 18, 2014 Kind of Product Control Unit Basic Model(s) S-10C FCC ID 2AB26S-10C Applicant PLATO CO., LTD. Address 5F Pyungchon IT Venture Center, 1113-1, Bisan-Dong, Dongan-Gu, Anyang-City, Gyeonggi-Do, Korea Manufacturer PLATO CO., LTD. Address 5F Pyungchon IT Venture Center, 1113-1, Bisan-Dong, Dongan-Gu, Anyang-City, Gyeonggi-Do, Korea Test Result ■ Positive Negative Tested By Reviewed By B.O.KO S.J.CHO Comment(s) - Investigations requested : Measurement to the relevant clauses of FCC rules and regulations Part 15 Subpart C. - The test report is consists of 12 pages. - The test result only responds to the tested sample. - It is not allowed to copy this report even partly without the allowance of IST Co., Ltd. - This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4 I assume full responsibility for accuracy and completeness of these data. IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 14-IST-0151 2 of 12 IST(02) 029 A4 모(101025) The test result only responds to the tested sample. This report shall not be reproduced except in full, without the allowance of the test laboratory. TABLE OF CONTENTS Table of contents 2 Information of test laboratory, Measurement Uncertainty 3 Product Information 4 Summary 5 Equipment Under Test 6 - Radiated Emissions & Limits 7-8 - Radiated Emissions Results 9-10 - 20dB Bandwidth 11 The Photos of Test Setup 12 IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 14-IST-0151 3 of 12 IST(02) 029 A4 모(101025) The test result only responds to the tested sample. This report shall not be reproduced except in full, without the allowance of the test laboratory. INFORMATION OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. 52-20, Sinjeong-ro 41beon-gil, Giheung-gu Yongin-si, Gyeonggi-do, Korea. TEL : +82 31 326 6700 FAX : +82 31 326 6797 KOLAS Testing No. : KT118 RRA Designation No. : KR0018 FCC Registration No. : 400603 VCCI Member No. : 1739 Measurement Uncertainty Conducted Emissions U = 2.98 [dB] (Confidence level approximately 95 %, k = 2) Radiated Emissions (Antenna - Horizontal) U = 3.83 [dB] (Confidence level approximately 95 %, k = 2 ) Radiated Emissions (Antenna - Verical) U = 4.50 [dB] (Confidence level approximately 95 %, k = 2 ) IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 14-IST-0151 4 of 12 IST(02) 029 A4 모(101025) The test result only responds to the tested sample. This report shall not be reproduced except in full, without the allowance of the test laboratory. PRODUCT INFORMATION Specification(Control Unit) Part 15 Low Power Transmitter Below 1705KHz(DCD) Power DC 12V (Car Battery) Dark Current Max. 6uA LF Frequency 134.2KHz(Tx) LF Range 1m RF Frequency 433.9 MHz(Rx) RF Range Max 30m Dimension 72 x 102 x 24 mm Operating Temp -40 ~ 80°C Weight 110g Connector 16pin Note: All the testing were performed according to the procedures in FCC CFR47 PART 15 SUBPART C IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 14-IST-0151 5 of 12 IST(02) 029 A4 모(101025) The test result only responds to the tested sample. This report shall not be reproduced except in full, without the allowance of the test laboratory. SUMMARY Applied Standard : FCC CRF Part 15 Subpart C Standard Section Description result remark 15.209(a) Radiated emission, Spurious Emission and Field Strength of Fundamental Pass Meet the requirements 2.1049 20dB Bandwidth Pass Meet the requirements IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 14-IST-0151 6 of 12 IST(02) 029 A4 모(101025) The test result only responds to the tested sample. This report shall not be reproduced except in full, without the allowance of the test laboratory. Equipment Under Test EUT Type :  Table-Top.  Floor-Standing.  Table-Top and Floor-Standing(Combination).  Hand held Operation – mode of the E.U.T. : The equipment under test was operated during the measurement under following conditions :  Standby Mode  Operational Condition :  continue Transmit Configuration of the equipment under test : Following peripheral devices and interface cables were connected during the measurement : Equipment Manufacturer Model Serial No. DC Power Supply YOKOGAWA PA7011 23HM5018 EUT exercise Software To get a maximum radiated emission from the EUT, EUT was programed to transmit RF signal continuously. To activate continuous transmission, software was changed as above for testing only. To get a maximum emission levels from the EUT, the EUT was moved throughout the X, Y, and Z planes. Test Set-Up Radiated Emissions IST Co., Ltd. EMC LABORATORY TEST REPORT NO. : 14-IST-0151 7 of 12 IST(02) 029 A4 모(101025) The test result only responds to the tested sample. This report shall not be reproduced except in full, without the allowance of the test laboratory. Radiated Emissions Test, 9 kHz to 30 MHz(Magnetic Field Test) 1. The preliminary radiated measurements were performed to determine the frequency producing the maximum emissions at a distance of 3 meters according to Section 15.31(f)(2). 2. The EUT was placed on the top of the 0.8-meter height, 1 x 1.5 meter non-metallic table. 3. Emissions from the EUT are maximized by adjusting the orientation of the Loop antenna and rotating the EUT on the turntable. Manipulating the system cables also maximizes EUT emissions if applicable. 4. To obtain the final measurement data, each frequency found during preliminary measurements was re-examined and investigated. The test…

Text truncated - open the document above for the full version.

X–Axis(0.009~30MHz) Y–Axis(0.009~30MHz) Z–Axis(0.009~30MHz) X-Axis(30~1000MHz) Y-Axis(30~1000MHz) Z-Axis(30~1000MHz)
