2AB3E-IPA19CParty Power

iPA19C 3 Quickstart Guide (English) Introduction 1. Make sure all items listed in the Box Contents are included in the box. 2. READ THE SAFETY & WARRANTY MANUAL BEFORE USING THE PRODUCT . 3. MAKE SURE THE BATTERY IS COMPLETELY CHARGED PRIOR TO FIRST USE FOR MAXIMUM BATTERY LIFE . 4. Study the connection diagram. Box Contents • Party Power ™ • Audio Cable with 1/8” (3.5mm) connectors • Quickstart Guide • Safety Instructions & Warranty Information Booklet Support For the latest information about this product (system requirements, compatibility information, etc.) and product registration, visit ionaudio.com . WARNING: DO NOT splash or immerse in water or other liquids. Not for use in rain. Use only in dry locations. WARNING: DO NOT look directly into the dome light. Do not sit, stand, or apply pressure on the dome light. Rechargeable Batteries Rechargeable lead-acid batteries are the same type used in automobiles. As with your car battery, how you use this battery has a significant impact on its lifespan. With proper use and treatment, a lead-acid battery can last for years. Here are some recommendations for getting the longest life from the internal battery. General Usage Charge fully before use. Charge fully before storing. Storage For best product longevity, do not store at exceedingly hot (greater than 90°F / 32°C) or exceedingly cold (less than 32°F / 0°C) temperatures. It is acceptable to leave your sound system plugged in. This will not overcharge the battery. If you leave the battery level low and do not charge it for 6 months, it may permanently lose capacity. Repair If the battery fails to charge, check the fuse near the power cable input. If the fuse is not intact, please replace it. The battery can be replaced (details in the Technical Specifications). For Warranty and Parts, contact the Parts Dept. at 401-658-3743 or by visiting ionaudio.com. Disposal Bring the unit to a recycling center or dispose of in accordance with local ordinances. 4 ON/OFF POWER Quick Setup Connection Diagram 1. For optimal performance, place Party Power in the center of the room so it is unobstructed by walls, furniture, etc. 2. Turn down the Master Volume on the Party Power. 3. Turn on Party Power. 4. Connect your music player with an audio cable or Bluetooth (see Connecting with a Bluetooth Device for more details on this). 5. Adjust the volume on your music player and on Party Power as needed. 6. Press the Party Light button on Party Power to turn the lights on or off. 7. Turn off Party Power when not in use. Features 1. Auxiliary Input: This stereo 1/8” (3.5mm) input can be used to connect a smartphone, MP3 player, or other audio sources. 2. Bluetooth: The Paired LED will be lit when a device is paired to Party Power. This LED will not be lit when Party Power is first powered on (unless it was previously paired with a device). Press the Disconnect button to disconnect a paired Bluetooth device. 3. Master Volume Control: This adjusts the speaker’s main mix volume, which includes the Auxiliary Input and the audio of a paired Bluetooth device. 4. Power LED: Indicates various states of activity on Party Power. See the Power LED callout box for more details. 5. Party Light Button: Turns the lights on or off. 6. Dome: Displays the lights which will react to the playing music when the Party Light button is activated. 7. Power Input: Insert the included power cable here to power the unit. 8. Power ON/OFF Switch: Turns Party Power on or off. 9. Air Vents: These vents ensure the light dome operates efficiently. Note: Please ensure these vents do not get covered or blocked. TOP PANEL MICROPHONE MP3 PLAYER (not included) REAR PANEL POWER Included Audio Cable with 1/8” (3.5mm) connectors *WARNING: Do not look directly into the dome light. Do not sit, stand, or apply pressure on the dome light. 1 2 3 4 5 6 7 8 9 TABLET (not included) 6 7 8 9 ON/OFF POWER 1 2 3 4 5 Power LED: Solid Green LED = Party Power is powered on Solid Yellow LED = Battery is charging with the power on Solid Red LED = Battery is charging with the power off Solid Yellow LED = Battery is charging with the power on Solid Green / Blinking Yellow LED = Party Power is powered on and the battery is low LED OFF = Power is off, power cable is connected, and the battery is fully charged 6 Specifications Dimensions (Depth x Width x Height) 6.5” x 7.5” x 9.5” 165.10 mm x 190.50 mm x 241.30 mm Weight 5.5 lbs 2.48 kg Power Input 100–240V, 50/60 Hz; 30W Audio Power 16W (peak) Speaker 3” (72 mm) Full-range driver Frequency Response (-3dB) 80 Hz–23 kHz Supported Bluetooth Profile A2DP Bluetooth Range Up to 100 ft. / 30.5 m * Bluetooth Specification Bluetooth 4.1 Battery Life (when fully charged) Up to 10 hours with music only; up to 4 hours with lights and music. Charging Time Up to 10 hours Specifications are subject to change without notice. *Bluetooth range is affected by walls, obstructions, and movement. For optimal performance, place Party Power in the center of the room so it is unobstructed by walls, furniture, etc. Trademarks and License ION Audio is a trademark of ION Audio, LLC, registered in the U.S. and other countries. The Bluetooth word mark and logos are owned by the Bluet ooth SIG, Inc. and any use of such marks by ION Audio is under license. All other product or company names are trademarks or registered trademarks of their respective owners. For the electrostatic discharge (ESD) test of EN301 489-1/17, it was found that manual operation is needed to resume normal operation as intended after the test. 7 Guía de inicio rápido (Español) Introducción 1. Asegúrese de que todos los artículos indicados en "Contenido de la caja" estén incluidos en ella. 2. LEA EL MANUAL SOBRE LA SEGURIDAD Y LA GARANTÍA ANTES DE UTILIZAR EL PRODUCTO. 3. PARA ASEGURAR UNA MÁXIMA VIDA ÚTIL DE LA BATERÍA, ASEGÚRESE DE QUE ESTÉ COMPLETAMENTE CARGADA ANTES DE UTILIZARLA POR PRIMERA VEZ. 4. Estudie el diagrama de conexión. Contenido de la caja • Party Power • Cable de au…

Text truncated - open the document above for the full version.

Jacky Liao

August 12, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AB3E-IPA194C _ Product Name: Party Power Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Jacky Liao Position Saty/EMI Dept Manager Company Name ION AUDIO,LLC Address 200 Scenic View Drive, Cumberland, RI 02864, U.S.A Tel +866-2-2717-2389 Fax +866-2-2717-2389 Email [email protected] FCC ID:2AB3E-IPA19C Product Name: Party Power

Guanjin AC/DC convertor Mingsheng AC/DC convertor Lishi battery Leiou Battery

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10- g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison Worse case is as below: [2402 MHz 0.52dBm（1.127mW） output power] (1.127 mW /5mm) ·[√2.402 (GHz)]= 0.35 <3.0 for 1-g SAR Then SAR evaluation is not required

55 44 33 22 11 D D C C B B A A BuckBuckBuck Buck XTAL_OUTXTAL_OUT PIO4 Buck XTAL_IN Buck VREGOUT_HV Buck MIC_BIAS MIC1_P MIC1_N MIC2_N MIC2_P LINE_IN_LLINE_IN_RVREGOUT_HVSPK_LPLRVCMWAKEPIO1PIO2 BuckBuck Buck PIO3 UART_RX UART_TX PIO11 PIO6 PIO7 PIO14 PIO15 PIO16 PIO17 LED0LED1PIO5VCCIOPIO12 BAT_IN VCHG_IN RESETWAKEPIO1PIO2PIO3UART_RXUART_TXPIO11PIO6PIO7PIO14PIO15PIO16PIO17 SDA SCL WP/PIO18 LED0 LED1 PIO5 VCCIO PIO12 VCHG_IN BAT_IN VREGOUT_HV PIO4 MIC_BIAS MIC1_PMIC1_NMIC2_NMIC2_P LINE_IN_LLINE_IN_R SPK_LP VREGOUT_MV LRVCM RESET VREGOUT_MV Buck SDASCL WP/PIO18 PIO14 PIO16 PIO15PIO17 VCCIO Size Document Number Rev Date: Sheet of Title C 1 1 Tuesday, April 01, 2014 0.2 <Doc> 絡 達 科 技 股 份 有 限 公 司 300 新 竹 市 科 學 園 區 篤 行 路 6-5 號 5 樓5F., No.6-5, Dusing Rd., Hsinchu Science Park, Hsinchu 300, TaiwanTel: +886-3-612-8800Fax: +886-3-611-8833www.airoha.com AB1511 SPI flash Module with Antenna Size Document Number Rev Date: Sheet of Title C 1 1 Tuesday, April 01, 2014 0.2 <Doc> 絡 達 科 技 股 份 有 限 公 司 300 新 竹 市 科 學 園 區 篤 行 路 6-5 號 5 樓5F., No.6-5, Dusing Rd., Hsinchu Science Park, Hsinchu 300, TaiwanTel: +886-3-612-8800Fax: +886-3-611-8833www.airoha.com AB1511 SPI flash Module with Antenna Size Document Number Rev Date: Sheet of Title C 1 1 Tuesday, April 01, 2014 0.2 <Doc> 絡 達 科 技 股 份 有 限 公 司 300 新 竹 市 科 學 園 區 篤 行 路 6-5 號 5 樓5F., No.6-5, Dusing Rd., Hsinchu Science Park, Hsinchu 300, TaiwanTel: +886-3-612-8800Fax: +886-3-611-8833www.airoha.com AB1511 SPI flash Module with Antenna Antenna Matching Antenna C11uFC11uF L110uH(0805)L110uH(0805) C2533pFC2533pF C23 1.5pF C23 1.5pF U1 AB1511 QFN6X6 49PIN U1 AB1511 QFN6X6 49PIN LINE_IN_R 3 LINE_IN_L 2 AU_REF 1 SPK_LP 5 LRVCM 6 SPK_RP 7 WAKE 10 PIO1 11 VCCRF 8 RF_P 9 PIO3 15 UART_TX 17 PIO11 18 PIO6(Buzzer) 19 PIO7(crystal trim) 20 PIO18 27 BAT_P 36 RST 34 VREGOUT_MV 33 VCCIO 31 PIO5 30 LED0 28 XTAL_OUT 47 MIC2_N 44 VCCXO 46 MIC_BIAS 41 MIC2_P 45 MIC1_N 43 MIC1_P 42 VCCDIG 40 PIO4 39 VREGOUT_HV 38 VCCPLL 14 PIO12 32 XTAL_IN 48 VCHG 35 UART_RX 16 VCCVCO 13 PIO2 12 PIO14 21 PIO15 22 SCL 26 SDA 25 LX 37 VCCSPK 4 GND 49 PIO16 23 PIO17 24 LED1 29 RFRF 1 R220 OhmR220 Ohm C210uF(0805)C210uF(0805) R68 4.7K R68 4.7K C13 4.7uF(0603) C13 4.7uF(0603) R2110 OhmR2110 Ohm L26.8nHL26.8nH GNDGND 1 U4 P/N:GD25Q41BTIGR (4M) or GD25Q80TCGR (8M) U4 P/N:GD25Q41BTIGR (4M) or GD25Q80TCGR (8M) #CS 1 SO 2 #WP 3 GND 4 SI 5 SCLK 6 HOLD# 7 VCC 8 C27NCC27NC C12 0.1uF C12 0.1uF Y1 16MHz Crystal Y1 16MHz Crystal C3 1uF C3 1uF C320.1uFC320.1uF C10 4.7uF(0603) C10 4.7uF(0603) C22 1.5pF C22 1.5pF C21 0.1uF C21 0.1uF U3 AB1511_SPI flash Module with antenna U3 AB1511_SPI flash Module with antenna VCHG_IN 28 BAT_IN 29 LINE_IN_R 38 SPK_LP 39 LRVCM 40 MIC_BIAS 32 MIC1_P 33 MIC2_P 36 LINE_IN_L 37 WAKE 3 VREGOUT_MV 25 UART_TX 8 UART_RX 7 LED0 20 LED1 21 PIO17 15 PIO16 14 PIO15 13 PIO14 12 PIO12 24 VCCIO 23 PIO11 9 PIO7 11 PIO6 10 PIO5 22 VREGOUT_HV 30 PIO3 6 PIO2 5 PIO1 4 NC 1 RST 26 PIO4 31 MIC2_N 35 MIC1_N 34 SDA 17 SCL 18 GND 2 GND 16 GND 27 SPK_RP 41 WP/PIO18 19 GND 42 C60.1uFC60.1uF R67 4.7k R67 4.7k L31.2nHL31.2nH C24 1uF C24 1uF C29 10uF(0805) C29 10uF(0805) R69 300ohm R69 300ohm C150.75 pFC150.75 pF L41nHL41nH

TEST REPORT FCC ID: 2AB3E-IPA19C IC: 10541A-IPA19C Applicant : ION AUDIO,LLC Address : 200 Scenic View Drive, Cumberland, RI 02864, U.S.A Equipment Under Test (EUT): Name : Party Power Model : iPA19C Trademark : N/A Standards : FCC PART 15, SUBPART C : 2014 (Section 15.247) RSS-247 ISSUE 1 MAY 2015; RSS-GEN ISSUE 4 NOV 2014 ANSI C63.4:2014 ; ANSI C63.10:2013 Report No : T1850893 06 Date of Test : July 23- August 05, 2015 Date of Issue : August 06, 2015 Test Result : PA S S In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Alpha Product Testing Co., Ltd. Or test done by Shenzhen Alpha Product Testing Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Alpha Product Testing Co., Ltd. Approvals in writing. Page 2 of 83 Report No.: T1850893 06 Contents 1. General Information ............................................................................................................... 5 1.1. Description of Device (EUT) ...............................................................................5 1.2. Accessories of device (EUT) ...............................................................................6 1.3. Test Lab information ............................................................................................6 2. Summary of test ...................................................................................................................... 7 2.1. Summary of test result .........................................................................................7 2.2. Assistant equipment used for test .........................................................................7 2.3. Block Diagram .....................................................................................................8 2.4. Test mode .............................................................................................................8 2.5. Test Conditions .....................................................................................................9 2.6. Measurement Uncertainty (95% confidence levels, k=2) ....................................9 2.7. Test Equipment ...................................................................................................10 3. Maximum Peak Output power ............................................................................................ 11 3.1. Limit ................................................................................................................... 11 3.2. Test Procedure .................................................................................................... 11 3.3. Test Setup ........................................................................................................... 11 3.4. Test Result .......................................................................................................... 11 4. Bandwidth ............................................................................................................................. 12 4.1. Limit ...................................................................................................................12 4.2. Test Procedure ....................................................................................................12 4.3. Test Result ..........................................................................................................12 5. Carrier Frequency Separation ............................................................................................. 18 5.1. Limit ...................................................................................................................18 5.2. Test Procedure ....................................................................................................18 5.3. Test Result ..........................................................................................................18 6. Number Of Hopping Channel ............................................................................................. 21 6.1. Limit ...................................................................................................................21 6.2. Test Procedure ....................................................................................................21 6.3. Test Result ..........................................................................................................21 7. Dwell Time ............................................................................................................................. 24 7.1. Test limit ............................................................................................................24 7.2. Test Procedure ....................................................................................................24 7.3. Test Results ........................................................................................................24 8. Radiated emissions ................................................................................................................ 31 8.1. Limit ...................................................................................................................31 8.2. Block Diagram of Test setup ..............................................................................32 8.3. Test Procedure ....................................................................................................33 8.4. Test Result .................................................................................................…

Text truncated - open the document above for the full version.

Page 43 of 83 Report No.: T1850893 06 1GHz — 25GHz Radiated emissison Test result EUT: Party Power M/N: iPA19C Power: AC 120V/60Hz Test date: 2015-08-04 Test site: 3m Chamber Tested by: Peter Test mode: π/4 DQPSK Tx CH79 2480MHz Antenna polarity: Vertical No Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/ m) Margin (dB) Remark 1 4960 42.28 33.98 10.22 34.25 52.23 74 21.77 PK 2 4960 32.13 33.98 10.22 34.25 42.08 54 11.92 AV 3 7440 / 4 9920 / 5 12400 / Antenna Polarity: Horizontal 1 4960 42.66 33.98 10.22 34.25 52.61 74 21.39 PK 2 4960 32.23 33.98 10.22 34.25 42.18 54 11.82 AV 3 7440 / 4 9920 / 5 12400 / Note: 1, Measuring frequency from 1GHz to 25GHz 2, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 44 of 83 Report No.: T1850893 06 1GHz — 25GHz Radiated emissison Test result EUT: Bluetooth earphone M/N: MDS-800X Power: AC 120V/60Hz Test date: 2015-01-07 Test site: 3m Chamber Tested by: Peter Test mode: 8- DQPSK Tx CH1 2402MHz Antenna polarity: Vertical No Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/m) Margin (dB) Remark 1 4804 42.27 33.95 10.18 34.26 52.14 74 21.86 PK 2 4804 31.66 33.95 10.18 34.26 41.53 54 12.47 AV 3 7206 / 4 9608 / 5 12010 / Antenna Polarity: Horizontal 1 4804 41.95 33.95 10.18 34.26 51.82 74 22.18 PK 2 4804 31.32 33.95 10.18 34.26 41.19 54 12.81 AV 3 7206 / 4 9608 / 5 12010 / Note: 1, Measuring frequency from 1GHz to 25GHz 2, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 45 of 83 Report No.: T1850893 06 1GHz — 25GHz Radiated emissison Test result EUT: Bluetooth earphone M/N: MDS-800X Power: AC 120V/60Hz Test date: 2015-01-07 Test site: 3m Chamber Tested by: Peter Test mode: 8- DQPSK Tx CH40 2441MHz Antenna polarity: Vertical No Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/ m) Margin (dB) Remark 1 4882 42.08 33.93 10.2 34.29 51.92 74 22.08 PK 2 4882 31.75 33.93 10.2 34.29 41.59 54 12.41 AV 3 7323 / 4 9764 / 5 12205 / Antenna Polarity: Horizontal 1 4882 42.26 33.93 10.2 34.29 52.1 74 21.9 PK 2 4882 31.87 33.93 10.2 34.29 41.71 54 12.29 AV 3 7323 / 4 9764 / 5 12205 / Note: 1, Measuring frequency from 1GHz to 25GHz 2, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 46 of 83 Report No.: T1850893 06 1GHz — 25GHz Radiated emissison Test result EUT: Bluetooth earphone M/N: MDS-800X Power: AC 120V/60Hz Test date: 2015-01-07 Test site: 3m Chamber Tested by: Peter Test mode: 8- DQPSK Tx CH79 2480MHz Antenna polarity: Vertical No Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/ m) Margin (dB) Remark 1 4960 42.06 33.98 10.22 34.25 52.01 74 21.99 PK 2 4960 41.28 33.98 10.22 34.25 51.23 54 2.77 AV 3 7440 / 4 9920 / 5 12400 / Antenna Polarity: Horizontal 1 4960 42.38 33.98 10.22 34.25 52.33 74 21.67 PK 2 4960 31.75 33.98 10.22 34.25 41.7 54 12.3 AV 3 7440 / 4 9920 / 5 12400 / Note: 1, Measuring frequency from 1GHz to 25GHz 2, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 47 of 83 Report No.: T1850893 06 9. Band Edge Compliance 9.1. Block Diagram of Test Setup  9.2. Limit All the lower and upper band-edges emissions appearing within restricted frequency bands shall not exceed the limits shown in RSS-GEN, all the other emissions outside operation shall be at least 20dB below the fundamental emissions, or comply with RSS-GEN limits. 9.3. Test Procedure All restriction band and non- restriction band have been tested ˈonly worse case is reported. 9.4. Test Result PASS. (See below detailed test data) All the restricted frequency bands shall not exceed the limits shown in RSS-GEN, all the other emissions outside operation shall be at least 20dB below the fundamental emissions, or comply with RSS-GEN limits. Page 48 of 83 Report No.: T1850893 06 Radiated Method GFSK ( CH Low ) Band Edge Test result EUT: Party Power M/N: iPA19C Power: AC 120V/60Hz Test date: 2015-08-04 Test site: 3m Chamber Tested by: Peter Test mode: Tx CH Low 2402MHz Antenna polarity: Vertical Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/m) Margin (dB) Remark 2390 43.04 27.62 3.92 34.97 39.61 74 34.39 PK 2390 -- 27.62 3.92 34.97 -- 54 -- AV 2400 42.37 27.62 3.94 34.97 38.96 74 35.04 PK 2400 -- 27.62 3.94 34.97 -- 54 -- AV Antenna Polarity: Horizontal 2390 42.53 27.62 3.92 34.97 39.1 74 34.9 PK 2390 -- 27.62 3.92 34.97 -- 54 -- AV 2400 42.74 27.62 3.94 34.97 39.33 74 34.67 PK 2400 -- 27.62 3.94 34.97 -- 54 -- AV Note: 1, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector : PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too …

Text truncated - open the document above for the full version.

Photos of Radiated emission Photos of Conducted Emission test
