2AB3E-IPA25Wireless Speaker System

ION Audio, LLC
Wireless Speaker System - FCC ID 2AB3E-IPA25 - ION Audio, LLC
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Aug 08, 2014
Application Purpose
Original Equipment
Date of Application
Aug 08, 2014
Equipment Note
Wireless Speaker System
Frequency Range
2402.00000000 - 2480.00000000
Company
ION Audio, LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

IMPORTANT SAFETY INSTRUCTIONS& WARRANTYINFORMATION ENGLISH ( 3±13 ) INSTRUCCIONES IMPORTANTES DE SEGURIDADE INFORMACIÓ N DE LA GARANTÍA ESPAÑOL ( 14±21 ) INSTRUCTIONS IMPORTANTES DE SÉCURITÉET INFORMATIONS DE GARANTIE FRANÇAIS ( 22±29 ) ISTRUZIONI IMPORTANTI DI SICUREZZA ELE INFORMAZIONI DELLAGARANZIA ITALIANO ( 30±37) WICHTIGE SICHERHEITSANWEISUNGEN UND GARANTIEINFORMATIONEN DEUTSCH ( 38±45 ) 2 PRODUCT WARRANTY (U.S.A.) 1.What is covered and for how long? ALL PRODUCTS: inMusic Brands, Inc. ("inMusic") warrants to the original purchaser that ION Audio products and all other accessories are free from defects in material and workmanship under normal use and service for the period commencing upon the date of purchase from an authorized ION Audio dealer and continuing for the following period of time after that date for ninety (90)days.IONAudiowarrantsfactory-refurbished merchandise to be free of material and operational defects for a period of ninety (90) days from the original date of retail sale. This refurbished merchandise warranty is not transferable. 2.What is not covered?This Limited Warranty is conditioned upon proper use of the product by the purchaser. This Limited Warranty does not cover: ¦Damage caused by improper installation or improper connection to any peripheral ¦Damage caused by an external electrical fault ¦Damage from use of parts not manufactured or sold by ION Audio ¦Product purchased from anyone other than an ION Audio authorized dealer ¦Modifications to product not approved in writing by ION Audio ¦Equipment that has the serial number removed or made illegible ¦Normal cosmetic and mechanical wear ¦Damage or loss during transit to an Authorized ION Audio Repair Center ¦Units that are purchased and/or located outside of the continental USA 3 3.What are inMusic's obligations?During the applicable warranty period, ION Audio will repair or replace, at ION Audio's sole option, without charge to the purchaser, any defective component part of the product. To obtain service under this Limited Warranty, purchaser must first contact ION Audio and obtain a return authorization number ("RA#"). Purchaser must then return the product to ION Audio in an adequate container for shipping, accompanied by purchaser's sales receipt or comparable proof of sale showing the date of purchase, the serial number of the product, and the seller's name and address. To obtain an RA# and assistance on where to return the product, contact ION Audio customer service at 401-658-3743. Upon receipt, ION Audio will repair or replace the defective products. ION Audio may, at ION Audio's sole option, use rebuilt, reconditioned, or new parts or components when repairing any product or replace a product with a rebuilt, reconditioned, new or comparable product. Repaired products will be warranted for a period equal to the remainder of the original Limited Warranty on the original product or for 90 days, whichever is longer. All replaced parts, components, boards, and equipment become the property of ION Audio. If ION Audio determines that any product is not covered by this Limited Warranty, purchaser must pay all parts, shipping, and labor charges for the repair or return of such product. 4.What are the limits on inMusic's liabilities?THE WARRANTIES GIVEN IN THIS LIMITED WARRANTY, TOGETHER WITH ANY IMPLIED WARRANTIES COVERING ION AUDIO PRODUCTS, INCLUDING WITHOUT LIMITATION ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, INMUSIC OR ION AUDIO SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES, LOSS OF PROFITS, DAMAGES TO PURCHASER'S PROPERTY, OR INJURY TO PURCHASER OR OTHERS ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE ANY ION AUDIO PRODUCT, BREACH OF WARRANTY, OR NEGLIGENCE, INCLUDING BUT NOT LIMITED TO INMUSIC'S OR ION AUDIO'S OWN NEGLIGENCE, EVEN IF INMUSIC, ION 4 AUDIO, OR THEIR AGENTS HAVE BEEN ADVISED OF SUCH DAMAGES, OR FOR ANY CLAIM BROUGHT AGAINST PURCHASER BY ANY OTHER PARTY. THIS LIMITED WARRANTY IS THE COMPLETE WARRANTY FOR ION AUDIO PRODUCTS, AND IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT AND STATES PURCHASER'S EXCLUSIVE REMEDY. IF ANY PORTION OF THIS LIMITED WARRANTY IS ILLEGAL OR UNENFORCEABLE BY REASON OF ANY LAW, SUCH PARTIAL ILLEGALITY OR UNENFORCEABILTY SHALL NOT AFFECT THE ENFORCEABILITY OF THE REMAINDER OF THIS LIMITED WARRANTY WHICH PURCHASER ACKNOWLEDGES IS AND WILL ALWAYS BE CONSTRUED TO BE LIMITED BY ITS TERMS OR AS LIMITED AS THE LAW PERMITS. This Limited Warranty allocates risk of product failure between purchaser and ION Audio, and ION Audio's product pricing reflects this allocation of risk and the limitations of liability contained in this Limited Warranty. The agents, employees, distributors, and dealers of ION Audio are not authorized to make modifications to this Limited Warranty, or make additional warranties binding on ION Audio or inMusic. Accordingly, additional statements such as dealer advertising or presentation, whether oral or written, do not constitute warranties by ION Audio or inMusic and should not be relied upon. 5.How does state law apply to this warranty? SOME STATES DO NOT ALLOW THE EXCLUSION ORLIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR HOWLONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO PURCHASER. This Limited Warranty gives you specific legal rights. You may also have other rights, which vary from one jurisdiction to another. 5 PRODUCT WARRANTY(NON-U.S.A.) 1.inMusic Brands, Inc. ("inMusic") warrants to the original purchaser that ION Audio products are free from defects in material and workmanship under normal use and service for the period commencing upon the date of purchase from an authorized ION Audio dealer and continuing for the …

Text truncated - open the document above for the full version.

Users Manual

PARTY ROCKER LIVE Quickstart Guide English ( 3 – 5 ) Guía de inicio rápido Español ( 6 – 8 ) Guide d'utilisation rapide Français ( 9 – 11 ) Guida rapida Italiano ( 12 – 14 ) Kurzanleitung Deutsch ( 15 – 17 ) Snelstartgids Nederlands ( 18 – 20 ) Snabbstartsguide Svenska ( 21 – 23 ) Pikakäyttöopas Suomi ( 24 – 26 ) Appendix English ( 27 ) 3 Quickstart Guide (English) Support For product registration, visit the ION website: ionaudio.com For the latest information about this product, visit ionaudio.com/partyrockerlive For additional product support, visit ionaudio.com/support For safety/warranty information, visit ionaudio.com/warranty WARNING: DO NOT splash or immerse in water or other liquids. Not for use in rain. Use only in dry locations. WARNING: DO NOT look directly into the dome light. Do not sit, stand, or apply pressure on the dome light. Quick Setup / Connection Diagram 1. Make sure all items listed in Box Contents at the beginning of this guide are included in the box. 2. READ SAFETY INSTRUCTION BOOKLET BEFORE USING THE PRODUCT. 3. For optimal performance, place Party Rocker Live in the center of the room so it is unobstructed by walls, furniture, etc. 4. Move Light Mode switch to OFF. 5. Turn down the Master Volume on the Party Rocker Live. 6. Turn on Party Rocker Live. 7. Connect your music player with an audio cable or Bluetooth. (see Connecting with a Bluetooth Device for more details on this) 8. Adjust the volume on your music player and on Party Rocker Live as needed. 9. Adjust the Light Mode switch on Party Rocker Live as needed. 10. Turn off Party Rocker Live when not in use. Diagram and Parts Description 1. Microphone Input with Volume Control (1/4"): This mono input accepts a 1/4" input such as a microphone, guitar, or other musical instrument. 2. Auxiliary input: This stereo 1/8” input can be used to connect a smartphone, MP3 player, or other audio source. 3. Bluetooth: The Paired LED will be lit when a device is paired to Party Rocker Live. This LED will not be lit when Party Rocker Live is first powered on (unless it was previously paired with a device). Press the Disconnect button to disconnect a paired Bluetooth device. BOX CONTENTS  Party Rocker Live  Microphone with mic cable  Audio Cable with 1/8” (3.5mm) connectors  Power Cable (standard IEC)  Quickstart Guide  Safety Instructions & Warranty Information Booklet TOP PANEL MICROPHONE MP3 PLAYER (not included) MICROPHONE REAR PANEL POWER 1 2 3 4 5 6 7 4 4. Master Volume Control: This adjusts the speaker’s main mix volume, which includes Microphone Input, Auxiliary Input, and the audio of a paired Bluetooth device. 5. Power LED: Indicates whether Party Rocker Live is on or off. 6. Light Mode: There are three modes to select from for how the dome lights react to the music. • Auto = the dome lights spin and change color with a predetermined pattern regardless of the beat of the music playing. • Beat Sync = the dome lights spin and change color to the beat of the music playing. • App Mode = the dome lights are controlled using the mobile app (available for Android or iOS). 7. Dome: The dome light can spin and react to the music playing (depending on the Light Mode that is selected). 8. Power Cable Input (IEC): Insert the included power cable here to power the unit. 9. Power ON/OFF Switch: Turns Party Rocker Live on or off. 10. Air Vents: These air intake and air outtake vents operate when Light Mode is turned on to ensure the light dome operates efficiently. Note: Please ensure these vents do not get covered or blocked. Troubleshooting If the sound is distorted: Try lowering the volume control of your sound source or musical instrument. Also, try to reduce the overall volume of Party Rocker Live. If there is too much bass: Try adjusting the tone or EQ control on your sound source to lower the bass level. This will allow you to play the music louder before clipping (distortion) occurs. If there is a high-pitched whistling noise when using microphones: This is probably feedback. Point the microphone away from the speaker. If you can’t hear the microphone over the music volume: Turn down the music volume from your source. Connecting with a Bluetooth Device 1. Turn on your Bluetooth device. 2. Power on Party Rocker Live and it will automatically go into pairing mode to search for Bluetooth devices. You will know you are in pairing mode when the LED is off. 3. If your Bluetooth device is not able to pair to the amp, press the disconnect button on the amp to break previous Bluetooth connections and reset the Bluetooth module. 4. Navigate to your Bluetooth device’s setup screen, find “Party Rocker Live” and connect. Note: If your Bluetooth device prompts for a pairing code, enter ‘0000’. 5. Paired LED will light up solid when it is 'paired'. Note: If you experience trouble pairing or playing music, update your device's OS. 6. To disconnect pairing, press the ‘Disconnect’ button on Party Rocker Live. 7. To connect to another Bluetooth device, repeat steps 3-4. Note: Maximum range will be achieved when using devices with Bluetooth 4.0. WARNING: Do not look directly into the dome light. Do not sit, stand, or apply pressure on the dome light. 8 9 1010 1010 5 Installing the Party Rocker App IMPORTANT: To ensure the best possible experience with the app, use the most current Android OS or iOS on your iPad, iPhone, or iPod touch (not included). Note: Ensure that your device has internet access via your service provider or wireless connection. You can also download the app on your computer, but remember to connect and sync your iPad, iPhone, or iPod touch to transfer the app to iPad, iPhone, or iPod touch. Follow these steps below to download the free app on your Android device, iPad, iPhone, or iPod touch: 1. On your device, go to the respective Apple App Store or Google Play Store. 2. Search for the free Party Rocker app and download it. Follow the on-screen instructions to download and install the Party Rocker app. 3. Once d…

Text truncated - open the document above for the full version.

Cover Letter(s)

DATE :2014-07-22 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Name Jamy Yu Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-22891499 fax:+86-0769-22895596 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with: Applicant name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Yours sincerely, Signatory Name Andy Wu Position Compliance PM Company Name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Tel / Fax +886-2-2717-2389 E-Mail [email protected]

Cover Letter(s)

DATE :2014-07-22 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AB3E-IPA25 Product Name: Wireless Speaker System Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Yours sincerely, Signatory Name Andu Wu Position Compliance PM Company Name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Tel / Fax +886-2-2717-2389 E-Mail [email protected]

ID Label/Location Info

Product DevelopmentArtwork Release product name / description revision print date description code -- created changes from last revision Layer 1 -- Ref/info -- DO NOT PRINT PART COLOR: Pantone Process Black C Layer 2 -- Mech -- DO NOT PRINT checked 1:1 scale Party Rocker LIVE Andy Kyte iPA25 Bottom Panel Sticker Layer 3 -- Black Sticker Ben Sun REV C 05/22/2014 Layer 4 -- White

RF Exposure Info

东莞市东电检测技术有限公司 Dongguan Dongdian Testing Service Co.,Ltd Tel: 0769-22891499 http://www.dgddt.com IEIE Public Laboratory Page 1 of 1 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2480MHz, 3.14dBm (2.06mW) output power] (2.06/5) ·[√2.480(GHz)]= 0.649<3.0 for 1-g SAR Then SAR evaluation is not required Jamy Yu 2014-07-28

Test Report

Dongguan Dongdian Testing Service Co., Ltd Report No:DDT-RE140571 Page 1 of 80 FCC&IC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel: +86-0769-22891499 Http://www.dgddt.com Applicant : ION Audio, LLC Address : 200 SCENIC VIEW DRIVE, SUITE 201 CUMBERLAND, RI 02864, U.S.A. Equipment under Test : Wireless Speaker System Model No : PARTYROCKER LIVE Trade Mark : ION FCC ID : 2AB3E-IPA25 IC : 10541A-IPA25 Manufacturer : ION Audio, LLC Address : 200 SCENIC VIEW DRIVE, SUITE 201 CUMBERLAND, RI 02864, U.S.A. Report No: DDT-RE140571 Issued Date: 2014/07/24 PARTY ROCKER LIVE Dongguan Dongdian Testing Service Co., Ltd Report No:DDT-RE140571 Page 2 of 80 TABLE OF CONTENTS Test report declares......................................................................................................................4 1. Summary of test results ............................................................................................................... 5 2. General test information .............................................................................................................. 6 2.1. Description of EUT ..................................................................................................................... 6 2.2. Accessories of EUT..................................................................................................................... 6 2.3. Assistant equipment used for test ................................................................................................ 6 2.4. Block diagram of EUT configuration for test ............................................................................. 6 2.5. Test environment conditions ....................................................................................................... 7 2.6. Test laboratory............................................................................................................................. 7 2.7. Measurement uncertainty ............................................................................................................ 8 3. Maximum Peak Output Power ....................................................................................................8 3.1. Test equipment ............................................................................................................................ 8 3.2. Block diagram of test setup ......................................................................................................... 9 3.3. Limits .......................................................................................................................................... 9 3.4. Test Procedure............................................................................................................................. 9 3.5. Test Result................................................................................................................................... 9 4. 20dB Bandwidth and 99% Bandwidth ...................................................................................... 10 4.1. Test equipment .......................................................................................................................... 10 4.2. Block diagram of test setup ....................................................................................................... 10 4.3. Limits ........................................................................................................................................ 10 4.4. Test Procedure........................................................................................................................... 10 4.5. Test Result................................................................................................................................. 11 4.6. Original test data ....................................................................................................................... 11 5. Carrier Frequency Separation.................................................................................................... 18 5.1. Test equipment .......................................................................................................................... 18 5.2. Block diagram of test setup ....................................................................................................... 18 5.3. Limits ........................................................................................................................................ 18 5.4. Test Procedure........................................................................................................................... 18 5.5. Test Result................................................................................................................................. 18 5.6. Original test data ....................................................................................................................... 19 6. Number Of Hopping Channel ...................................................................................................20 6.1. Test equipment .......................................................................................................................... 20 6.2. Block diagram of test setup ....................................................................................................... 20 6.3. Limits ........................................................................................................................................ 20 6.4. Test Procedure........................................................................................................................... 20 6.5. Test Result................................................................................................................................. 20 6.6. Original tes…

Text truncated - open the document above for the full version.

Test Setup Photos

Dongguan Dongdian Testing Service Co., Ltd Report No: DDT-RE140571 Page 73 of 80 12. Test setup photograph

Contact Information

Applicant

Hill Lien(Director of Compliance)
[email protected]886-2-2717-2389Fax: 886-2-2717-2735

Test Firm

Dongguan Dongdian Testing Service Co.,LtdJamy Yu
[email protected]086-0769-22891499

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz2.06 mW
Confidentiality
Long Term
Grant Notes
Power output listed is conducted.
