2AB3E-IPA76CWIRELESS RECHARGEABLE SPEAKER

Block Rocker iPA76C Quickstart Guide English ( 3 – 6 ) Appendix English ( 7 ) 3 Quickstart Guide (English) Introduction 1. Make sure all items listed in the Box Contents are included in the box. 2. READ THE SAFETY & WARRANTY MANUAL BEFORE USING THE PRODUCT. 3. MAKE SURE THE BATTERY IS COMPLETELY CHARGED PRIOR TO FIRST USE FOR MAXIMUM BATTERY LIFE. 4. Study the connection diagram. 5. Ensure the Master Volume on Block Rocker is at zero. 6. Connect your devices. 7. Raise the volume to a comfortable level. 8. Return the Master Volume to zero when you are finished using Block Rocker. Box Contents Block Rocker Microphone with mic cable 3.5mm (1/8”) to 3.5mm (1/8”) cable Power Cable (standard IEC) Quickstart Guide Safety & Warranty Manual Support For the latest information about this product (system requirements, compatibility information, etc.) and product registration, visit ionaudio.com. Quick Setup Rechargeable Batteries Rechargeable lead-acid batteries are the same type used in automobiles. As with your car battery, how you use this battery has a significant impact on its lifespan. With proper use and treatment, a lead-acid battery can last for years. Here are some recommendations for getting the longest life from the internal battery. General Usage Charge fully before use. Charge fully before storing. Storage For best product longevity, do not store at exceedingly hot (greater than 90°F / 32°C) or exceedingly cold (less than 32°F / 0°C) temperatures. It is acceptable to leave your sound system plugged in. This will not overcharge the battery. If you leave the battery level low and do not charge it for 6 months, it may permanently lose capacity. Repair If the battery fails to charge, check the fuse near the power cable input. If the fuse is not intact, please replace it. The battery can be replaced (details in the Technical Specifications). For Warranty and Parts, contact the Parts Dept. at 401-658-3743 or by visiting ionaudio.com. Disposal Bring the unit to a recycling center or dispose of in accordance with local ordinances. 4 Connection Diagram Items not listed under the Box Contents are sold separately. Features 1. Microphone Input with Volume Control (1/4"): This mono input accepts a 1/4" input such as a microphone, guitar, or other musical instrument. 2. Auxiliary input: This stereo 3.5mm (1/8”) input can be used to connect a CD player, MP3 player, or other audio source. 3. Bluetooth Button: Press this button to enter pairing mode. To stop pairing to a Bluetooth device, press and hold this button for 3 seconds. 4. Link Button: Press this button on both speakers to link two Block Rockers together. 5. Bluetooth Icon: The Bluetooth icon will not be lit when Block Rocker is first powered on (unless it was previously paired with a device). The Bluetooth icon will be lit solid when a device is paired to Block Rocker. The Bluetooth icon will blink when in pairing mode. 6. Link Icon: The Link icon will not be lit when Block Rocker is first powered on (unless it was previously linked to another Block Rocker). The Link icon will remain solid when linked. The Link icon will blink while linking. This can take up to 1 minute. 7. Master Volume Control: This adjusts the speaker’s main mix volume, which includes the Microphone Input, Auxiliary Input, Tuner, and the audio of a paired Bluetooth device. REAR PANEL POWER (for charging) TOP PANEL MICROPHONE MP3 PLAYER TABLET LINKING TWO BLOCK ROCKER iPA76Cs 1 2 3 4 7 8 9 10 13 14 15 1717 18 19 1616 5 6 1111 1212 1 2 3 4 7 8 9 10 13 14 15 17 18 1919 16 5 6 11 12 5 8. AM/FM Presets: Store a favorite radio station and quickly tune to a preset radio station. There are 6 numeric positions for AM stations and 6 numeric positions for FM stations. To add a preset: A. Select either the AM or FM band and then use the Tuner buttons to select the desired radio station. B. Press and hold a numeric preset button to assign the current station to that preset number. The display will show “SAVE” to show the station has been saved. To use an added preset, tap a preset number once lightly to go to the stored radio station. 9. Radio Selector: This button sets the tuner to AM or FM or turns the radio off. 10. Display: Displays the current radio station, battery status, Bluetooth status, and link status. 11. Charging Indicator: With the battery charging indicator, when the power cable is connected, movement of the top battery segment shows the battery is charging. When fully charged, all battery segments will be lit without blinking. When the power cable is disconnected, the battery segment shows the level of the battery. 12. Lightning Bolt Icon: The lightning bolt icon will illuminate when the IEC power cable is connected to wall power. 13. Tune/Track Buttons: Tap these buttons to tune in a radio station or go to the previous/next track on a Bluetooth connected device. To "seek" (jump to the next available station), hold either button down for a few seconds until it starts to seek a station. The unit will remember the last station it was on and start at that station when powered off and on again. 14. Play/Pause: Press to play or pause a track from a connected Bluetooth device. 15. USB Charging Ports: Connect your device’s charge cable here to charge it. USB charging only functions when the unit’s power is turned on. Each USB port is 5V, 1A. Note: To charge smartphones and tablets faster, put the device’s screen to sleep. 16. Antenna: Adjust this FM antenna to get the best radio reception. Fold this down when not using the radio and when moving the unit. 17. NFC (near-field communication): Touch and briefly hold your supported and enabled device to the NFC logo to pair the device. 18. Power Cable Input (IEC): Insert the included power cable here to charge the unit. Note that the Block Rocker can be used with the power cable while it simultaneously charges the battery. The lightning bolt charge indicator illuminates when the power cable is connected. 19. Power ON/OFF Switch: T…

Text truncated - open the document above for the full version.

IMPORTANT SAFETY INSTRUCTIONS & WARRANTY INFORMATION ENGLISH ( 3 – 7 ) INSTRUCCIONES IMPORTANTES DE SEGURIDAD E INFORMACIÓN DE LA GARANTÍA ESPAÑOL ( 8 – 11 ) INSTRUCTIONS IMPORTANTES DE SÉCURITÉ ET INFORMATIONS DE GARANTIE FRANÇAIS ( 12 – 15 ) ISTRUZIONI IMPORTANTI DI SICUREZZA E LE INFORMAZIONI DELLA GARANZIA ITALIANO ( 16 – 19 ) WICHTIGE SICHERHEITSANWEISUNGEN UND GARANTIEINFORMATIONEN DEUTSCH ( 20 – 23 ) 3 PRODUCT WARRANTY (U.S.A.) 1. What is covered and for how long? ALL PRODUCTS: inMusic Brands, Inc. ("inMusic") warrants to the original purchaser that ION Audio products and all other accessories are free from defects in material and workmanship under normal use and service for the period commencing upon the date of purchase from an authorized ION Audio dealer and continuing for the following period of time after that date for ninety (90) days. ION Audio warrants factory-refurbished merchandise to be free of material and operational defects for a period of ninety (90) days from the original date of retail sale. This refurbished merchandise warranty is not transferable. 2. What is not covered? This Limited Warranty is conditioned upon proper use of the product by the purchaser. This Limited Warranty does not cover: ƒ Damage caused by improper installation or improper connection to any peripheral ƒ Damage caused by an external electrical fault ƒ Damage from use of parts not manufactured or sold by ION Audio ƒ Product purchased from anyone other than an ION Audio authorized dealer ƒ Modifications to product not approved in writing by ION Audio ƒ Equipment that has the serial number removed or made illegible ƒ Normal cosmetic and mechanical wear ƒ Damage or loss during transit to an Authorized ION Audio Repair Center ƒ Units that are purchased and/or located outside of the continental USA 3. What are inMusic's obligations? During the applicable warranty period, ION Audio will repair or replace, at ION Audio's sole option, without charge to the purchaser, any defective component part of the product. To obtain service under this Limited Warranty, purchaser must first contact ION Audio and obtain a return authorization number ("RA#"). Purchaser must then return the product to ION Audio in an adequate container for shipping, accompanied by purchaser's sales receipt or comparable proof of sale showing the date of purchase, the serial number of the product, and the seller's name and address. To obtain an RA# and assistance on where to return the product, contact ION Audio customer service at 401-658-3743. Upon receipt, ION Audio will repair or replace the defective products. ION Audio may, at ION Audio's sole option, use rebuilt, reconditioned, or new parts or components when repairing any product or replace a product with a rebuilt, reconditioned, new or comparable product. Repaired products will be warranted for a period equal to the remainder of the original Limited Warranty on the original product or for 90 days, whichever is longer. All replaced parts, components, boards, and equipment become the property of ION Audio. If ION Audio determines that any product is not covered by this Limited Warranty, purchaser must pay all parts, shipping, and labor charges for the repair or return of such product. 4. What are the limits on inMusic's liabilities? THE WARRANTIES GIVEN IN THIS LIMITED WARRANTY, TOGETHER WITH ANY IMPLIED WARRANTIES COVERING ION AUDIO PRODUCTS, INCLUDING WITHOUT LIMITATION ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, INMUSIC OR ION AUDIO SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES, LOSS OF PROFITS, DAMAGES TO PURCHASER'S PROPERTY, OR INJURY TO PURCHASER OR OTHERS ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE ANY ION AUDIO PRODUCT, BREACH OF WARRANTY, OR NEGLIGENCE, INCLUDING BUT NOT LIMITED TO INMUSIC'S OR ION AUDIO'S OWN NEGLIGENCE, EVEN IF INMUSIC, ION AUDIO, OR THEIR AGENTS HAVE BEEN ADVISED OF SUCH DAMAGES, OR FOR ANY CLAIM BROUGHT AGAINST PURCHASER BY ANY OTHER PARTY. THIS LIMITED WARRANTY IS THE COMPLETE WARRANTY FOR ION AUDIO PRODUCTS, AND IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT AND STATES PURCHASER'S EXCLUSIVE REMEDY. IF ANY PORTION OF THIS LIMITED WARRANTY IS ILLEGAL OR UNENFORCEABLE BY REASON OF ANY LAW, SUCH PARTIAL ILLEGALITY OR UNENFORCEABILTY SHALL NOT AFFECT THE ENFORCEABILITY OF THE REMAINDER OF THIS LIMITED WARRANTY WHICH PURCHASER ACKNOWLEDGES IS AND WILL ALWAYS BE CONSTRUED TO BE LIMITED BY ITS TERMS OR AS LIMITED AS THE LAW PERMITS. This Limited Warranty allocates risk of product failure between purchaser and ION Audio, and ION Audio's product pricing reflects this allocation of risk and the limitations of liability contained in this Limited Warranty. The agents, employees, distributors, and dealers of ION Audio are not authorized to make modifications to this Limited Warranty, or make additional warranties binding on ION Audio or inMusic. Accordingly, additional statements such as dealer advertising or presentation, whether oral or written, do not constitute warranties by ION Audio or inMusic and should not be relied upon. 5. How does state law apply to this warranty? SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO PURCHASER. This Limited Warranty gives you specific legal rights. You may also have other rights, which vary from one jurisdiction to another. 4 PRODUCT WARRANTY (NON-U.S.A.) 1. inMusic Brands, Inc. ("inMusic") warrants to the original purchaser that ION Audio products are free from defects in material and workmanship under normal use and service for the period commencing upon the date of purchase from an authorized ION …

Text truncated - open the document above for the full version.

DATE :2015-01-27 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Name Jamy Yu Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-22891499 fax:+86-0769-22895596 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with: Applicant name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Yours sincerely, Signatory Name Andy Wu Position Compliance PM Company Name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Tel / Fax +866-2-2717-2389 E-Mail [email protected]

DATE :2015-01-27 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AB3E-IPA76C Product Name: BT Speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Yours sincerely, Signatory Name Andy Wu Position Compliance PM Company Name ION Audio, LLC Address 200 Scenic View Drive, Suite 201 Cumberland, RI 02864, U.S.A. Tel / Fax +866-2-2717-2389 E-Mail [email protected]

Label

东莞市东电检测技术有限公司 Dongguan Dongdian Testing Service Co.,Ltd Tel: 0769-22891499 http://www.dgddt.com IEIE Public Laboratory Page 1 of 1 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2480MHz, 1.57dBm (1.44mW) output power] (1.44/5) ·[√2.480(GHz)]= 0.454 <3.0 for 1-g SAR Then SAR evaluation is not required Jamy Yu 2015-01-28
