2AB3E-ISP120Motorized Wireless Speaker with Solar Panel and Cupholders

ION Audio, LLC
Motorized Wireless Speaker with Solar Panel and Cupholders - FCC ID 2AB3E-ISP120 - ION Audio, LLC
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Mar 16, 2020
Application Purpose
Original Equipment
Date of Application
Mar 16, 2020
Equipment Note
Motorized Wireless Speaker with Solar Panel and Cupholders
Frequency Range
2402.00000000 - 2480.00000000
Company
ION Audio, LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Manual Version 1.1 1 2 534 7 6 8 11 1 2 9 10 Party Boat Quickstart Guide Box Contents Party Boat Remote Control Power Adapter (2) AAA Batteries Screwdriver for Remote Control Quickstart Guide/Safety & Warranty Information Support IMPORTANT: For the full User Guide, visit ionaudio.com. For the latest information about this product (documentation, technical specifications, system requirements, compatibility information, etc.) and product registration, visit ionaudio.com. For additional product support, visit ionaudio.com/support. Features IMPORTANT: This equipment is not suitable for use in locations where children are likely to be present. Note: Use the included remote control to turn on the boat motors, change the direction of the boat, FM radio controls, playback/pause, track selection, volume, and to power off the unit. 1. Volume Up (+) / Down (-): Press these buttons to change the volume of the speaker. 2. Previous (<) / Next (>) Track/Tune: Press and release these buttons to go to the previous or next FM radio station. Press and hold these buttons to seek backwards or forward for a clear FM radio station. Press and release these buttons to skip to the previous or next Bluetooth track. 3. FM Mode: Press this button to enter FM mode. Hold the button for 3 seconds to enter Preset Creation mode. 4. Bluetooth Button: Press this button briefly to begin Bluetooth connecting. Press and hold this button to disconnect a paired Bluetooth device. 5. Bluetooth/FM Indicator: This LED blinks blue when Bluetooth pairing or illuminates solid blue when connected to a Bluetooth device. When in FM mode, this LED is solid green and blinks slowly when in FM Preset Creation mode. 6. Power On/Off: Press and hold this button to turn Party Boat on/off. Press this button twice to enable or disable voice prompts. Note: Party Boat will power off after 1 hour if there is no audio playing. 7. Charging Indicator: The LED is solid red when the battery is charging. When the power is on and the battery is fully charged, the red LED will turn off. Note: A voice prompt will be heard when the unit needs to be charged. 8. Play/Pause: Press to play or pause a track from a connected Bluetooth device. Press and release this button to select a previously saved preset station. 9. Power Adapter Input*: Insert the included power adapter here to charge Party Boat. Make sure Party Boat and its connections are dry before charging. Never charge when wet. 10. USB Charge Port*: Connect your smartphone's charge cable here to charge it. In order to charge a device, Party Boat needs to be powered on. 11. Aux Input*: This stereo 1/8” (3.5 mm) input can be used to connect a CD player, MP3 player, or other audio source. *IMPORTANT: Cover the Aux In, USB Charging Port, and Power Adapter Input with the cap in the locked position when using Party Boat in water. Make sure Party Boat and its connections are dry before charging. Never charge when wet. Driving Party Boat Using the Remote CAUTION: Always keep hands, fingers, hair, tools, and any loose or hanging objects away from rotating parts. Note: To ensure Party Boat does not travel out of range of the remote (75 ft. / 22.9 m), the Party Boat motors will stop after 10 seconds of traveling in a single direction. Press the directional button again if you would like the motors to continue. Press and release a directional button on the remote control to move Party Boat in that direction. To move in a new direction, press and release a different directional button. To make a right or left turn when driving straight, press the Right or Left directional buttons. As Party Boat turns, press the Up directional button when the boat is facing 90 degrees to stop turning and continue in the new direction. To stop Party Boat from moving, press and release the same directional button again. Adjusting the Motor Speed: 1. Press and hold the Play/Pause button and the Up button on the remote control for 2 seconds to enter Motor Speed Adjustment mode. Party Boat will then move forward and continuously play a tone. 2. Press and release the Left or Right directional button to adjust the speed of the left or right motor. 3. Press and release the Up button to increase the speed of the motor at increments of 5% each time it is pressed. Press and release the Down button to increase the speed of the motor at increments of 5% each time it is pressed. 4. Press and hold the Play/Pause button and the Up button again to save the speed and exit. Note: If a button is not pressed within 10 seconds, it will automatically save and exit the Motor Speed Adjustment mode. The default motor speed is 100% when first starting up. The unit will remember the speed when powering off. App Control IMPORTANT: To ensure the best possible experience with the ION Sound XP app, use the most current Android OS or iOS on your device. Note: Ensure that your device has internet access via your service provider or wireless connection. You can also download the app on your computer, but remember to connect and sync your device to transfer the app. Follow these steps to download the free app on your device: 1. Open the Apple App Store or Google Play on your device. 2. Search for the ION Sound XP app. 3. Follow the on-screen instructions to download and install the app. 4. Once downloaded, the ION Sound XP app will appear on your device's home screen. Solar Charging To use the solar panel to charge Party Boat, place the loudspeaker in direct sunlight for at least 3 hours for best results. The rate of charging depends on the amount of sunlight the solar panel receives. The unit will charge slower when receiving indirect sunlight. Using the Radio Selecting a Radio Station: 1. Press the FM button. 2. Select a radio station using the </> buttons. Saving a Preset: 1. Press and release the </> buttons to select a FM radio station that you want to save as a preset. 2. Press and hold the FM button for 3 seconds to enter Preset Creation mode. 3. Press and release …

Text truncated - open the document above for the full version.

Attestation Statements

ION Audio, LLC I, the undersigned, Declaration: They are identical to each other, only except for model name, appearance in color or decorating parts and silkscreen for marketing purpose. 1) Model No.: PARTY BOAT 2) Model No.: ISP120 3) Model No.: PARTY BOATXXXXXXXX (XX can be 0-9, A-Z or blank) 4) Model No.: ISP120XXXXXXXX (XX can be 0-9, A-Z or blank) FCC ID: 2AB3E-ISP120 Sincerely, Client’s signature : 2019/12/17 Client’s name / title: Jacky Liao / Safety/Senior Compliance Manager Contact information / address: 200 Scenic View Drive, Cumberland, RI 02864, U.S.A. Telephone: 886-2- 2717-2389 Fax No.: 886-2- 2717-2735 *************************************************************************

Cover Letter(s)

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: ION Audio, LLC Address: 200 Scenic View Drive, Cumberland, RI 02864, U.S.A. Product Name: Motorized Wireless Speaker with Solar Panel and Cupholders Model Number: PARTY BOAT, ISP120, PARTY BOATXXXXXXXX, ISP120XXXXXXXX FCC Identifier: 2AB3E-ISP120 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jacky Liao Date: 12/23/2019 Title: Safety/Senior Compliance Manager Signature of applicant:

Cover Letter(s)

C5266091_X10_Ed.1 1/1 ION Audio, LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 12/17/2019 Subject: Request for Confidentiality FCC ID: 2AB3E-ISP120 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: 2019/12/17 Name: Jacky Liao Title: Safety/Senior Compliance Manager

External Photos

External Photos M/N: PARTY BOAT External Photos M/N: PARTY BOAT External Photos M/N: PARTY BOAT External Photos M/N: PARTY BOAT External Photos M/N: PARTY BOAT

ID Label/Location Info

Revision v1.0 版本 Date: 2019-12-21 日期 Model No: ISP120 型号 Sheet of Drawn By Qiu Sheng Wu File 文件: Size 尺寸 1 AA BB CC DD 1 2 2 3 3 4 4 5 5 6 6 PARTY BOAT IPX7iSP120 67mm 30mm Label Location

Internal Photos

Internal Photos M/N: PARTY BOAT Internal Photos M/N: PARTY BOAT Internal Photos M/N: PARTY BOAT Internal Photos M/N: PARTY BOAT FM Antenna Bluetooth Antenna 2 RX Antenna 433.92MHz Internal Photos M/N: PARTY BOAT Bluetooth Antenna1

RF Exposure Info

FCC ID: 2AB3E-ISP120 EST Technology Co. ,Ltd Report No. ESTE-R1912070 Page 1 of 7 FCC 47 CFR MPE REPORT ION Audio, LLC Motorized Wireless Speaker with Solar Panel and Cupholders Model Number: PARTY BOAT FCC ID: 2AB3E-ISP120 Prepared for: ION Audio, LLC 200 Scenic View Drive, Cumberland, RI 02864, U.S.A. Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R1912070 Date of Test: Dec. 06~13, 2019 Date of Report: Dec. 16, 2019 FCC ID: 2AB3E-ISP120 EST Technology Co. ,Ltd Report No. ESTE-R1912070 Page 2 of 7 Maximum Permissible Exposure 1. Applicable Standards Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. 1.1. Limits for Maximum Permissible Exposure (MPE) (a) Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-10000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-10000 1.o 30 Note: f=frequency in MHz; *Plane-wave equivalent power density FCC ID: 2AB3E-ISP120 EST Technology Co. ,Ltd Report No. ESTE-R1912070 Page 3 of 7 1.2. MPE Calculation Method E (V/m) = d G×P×30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d×377 G×P×30 From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained FCC ID: 2AB3E-ISP120 EST Technology Co. ,Ltd Report No. ESTE-R1912070 Page 4 of 7 2. Conducted Power Result Antenna 1 Mode Frequency (MHz) Peak output power (dBm) Peak output power (mW) Target power (dBm) Antenna gain (dBi) (Linear) GFSK 2402 0.30 1.072 0 ±1 -0.58 0.875 2441 0.17 1.040 0±1 -0.58 0.875 2480 -0.10 0.977 -1±1 -0.58 0.875 π/4-DQPSK 2402 1.10 1.288 1 ±1 -0.58 0.875 2441 0.89 1.227 0±1 -0.58 0.875 2480 0.59 1.146 0±1 -0.58 0.875 BLE 2402 0.29 1.069 0 ±1 -0.58 0.875 2440 0.17 1.040 0±1 -0.58 0.875 2480 -0.11 0.975 -1±1 -0.58 0.875 EST Technology Co. ,Ltd Report No. ESTE-R1912070 Page 5 of 7 FCC ID: 2 AB3E-ISP120 Ant enna 2 Mode Frequency (MHz) Peak output power (dBm) Peak output power (mW) Target power (dBm) Antenna gain (dBi) (Linear) GFSK 2402 0.34 1.081 0 ±1 2 1.585 2441 0.43 1.104 0±1 2 1.585 2480 0.43 1.104 0±1 2 1.585 π/4-DQPSK 2402 1.06 1.276 1 ±1 2 1.585 2441 1.09 1.285 1±1 2 1.585 2480 1.18 1.312 1±1 2 1.585 BLE 2402 0.07 1.016 0 ±1 2 1.585 2440 0.50 1.122 0±1 2 1.585 2480 0.79 1.199 0±1 2 1.585 FCC ID: 2AB3E-ISP120 EST Technology Co. ,Ltd Report No. ESTE-R1912070 Page 6 of 7 3.Calculated Result and Limit Antenna 1 Mode Target power (dBm) Antenna gain Power Density (S) (mW /cm2) Limited of Power Density (S) (mW /cm2) Test Result (dBi) (Linear) GFSK1 -0.580.875 0.00022 1 Compiles π/4-DQPSK2 -0.580.875 0.00028 1 Compiles BLE1 -0.580.875 0.00022 1 Compiles Ant enna 2 Mode Target power (dBm) Antenna gain Power Density (S) (mW /cm2) Limited of Power Density (S) (mW /cm2) Test Result (dBi) (Linear) GFSK1 2 1.585 0.00040 1 Compiles π/4-DQPSK2 2 1.585 0.00050 1 Compiles BLE1 2 1.585 0.00040 1 Compiles FCC ID: 2AB3E-ISP120 EST Technology Co. ,Ltd Report No. ESTE-R1912070 Page 7 of 7 Antenna 1+2 Mode Power Density (S) (mW /cm2) Antenna 1 Power Density (S) (mW /cm2) Antenna 2 Power Density (S) (mW /cm2) Total Limited of Power Density (S) (mW /cm2) Test Result GFSK0.00022 0.00040 0.00062 1 Compiles π/4-DQPSK 0.00028 0.00050 0.00078 1 Compiles BLE0.00022 0.00040 0.00062 1 Compiles End of Test Report

Test Report

FCC ID: 2AB3E-ISP120 EST Technology Co., Ltd Report No.ESTE-R1912068 Page 1 of 100 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of ION Audio, LLC Motorized Wireless Speaker with Solar Panel and Cupholders Model Number: PARTY BOAT Additional Model: ISP120, PARTY BOATXXXXXXXX, ISP120XXXXXXXX (XX can be 0-9, A-Z or blank) FCC ID: 2AB3E-ISP120 Prepared for: ION Audio, LLC 200 Scenic View Drive, Cumberland, RI 02864, U.S.A. Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R1912068 Date of Test: Dec. 05~13, 2019 Date of Report: Dec. 16, 2019 FCC ID: 2AB3E-ISP120 EST Technology Co., Ltd Report No.ESTE-R1912068 Page 2 of 100 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION ........................................................................................................................ 3 1. GENERAL INFORMATION ................................................................................................................. 5 1.1. Description of Device (EUT) ........................................................................................................... 5 1.2. Antenna Information ........................................................................................................................ 5 2. SUMMARY OF TEST ......................................................................................................................... 6 2.1. Summary of test result ...................................................................................................................... 6 2.2. Test Facilities .................................................................................................................................... 7 2.3. Measurement uncertainty ................................................................................................................. 8 2.4. Assistant equipment used for test ..................................................................................................... 8 2.5. Block Diagram .................................................................................................................................. 8 2.6. Test mode ......................................................................................................................................... 9 2.7. Channel List .................................................................................................................................... 10 2.8. Power Setting of Test Software ...................................................................................................... 10 2.9. Test Equipmen ................................................................................................................................ 11 3. MAXIMUM PEAK OUTPUT POWER ................................................................................................. 12 3.1. Limit ............................................................................................................................................... 12 3.2. Test Setup ....................................................................................................................................... 12 3.3. Spectrum Analyzer Setting ............................................................................................................. 12 3.4. Test Procedure ................................................................................................................................ 12 3.5. Test Result ...................................................................................................................................... 13 4. 20 DB BANDWIDTH ...................................................................................................................... 22 4.1. Limit ............................................................................................................................................... 22 4.2. Test Setup ....................................................................................................................................... 22 4.3. Spectrum Analyzer Setting ............................................................................................................. 22 4.4. Test Procedure ................................................................................................................................ 22 4.5. Test Result ...................................................................................................................................... 23 5. CARRIER FREQUENCY SEPARATION .............................................................................................. 32 5.1. Limit ............................................................................................................................................... 32 5.2. Test Setup ....................................................................................................................................... 32 5.3. Spectrum Analyzer Setting ............................................................................................................. 32 5.4. Test Procedure ................................................................................................................................ 32 5.5. Test Result ...................................................................................................................................... 33 6. NUMBER OF HOPPING CHANNEL .................................................................................................. 42 6.1. Limit ............................................................................................................................................... 42 6.2. Test Setup ....................................................................................................................................... 42 6.3. Spectrum Analyzer Se…

Text truncated - open the document above for the full version.

Test Setup Photos

Conducted Test M/N: PARTY BOAT Radiated Test (30-1000 MHz) Radiated Test (Above 1GHz)

Contact Information

Applicant

Hill Lien(Director of Compliance)
[email protected]886-2-2717-2389Fax: 886-2-2717-2735

Technical Contact

EST Technology Co., Ltd.Iceman Hu
[email protected]86-769-83081888

Dongguan · China

Non-Technical Contact

EST Technology Co., Ltd.Iceman Hu
[email protected]86-769-83081888

Test Firm

EST Technology Co., Ltd.Iceman Hu
[email protected]+86 0769-83081888

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz2.60 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End-users must be provided with operating procedures for satisfying RF exposure compliance.
